Panasonic KX-HGT100-B User manual

Increase Connection Options
while Lowering Costs.
The Panasonic KX-HGT100-B uses the latest SIP (Session
Initiation Protocol) technology, helping to lower business
telephone costs and simplify communication management.
It supports local office users or remote workers,
connecting over high-speed broadband IP network
from virtually anywhere.
It’s compatible with the KX-TDE and KX-NCP PBX
Panasonic Communications Systems so it’s
ideal for companies with geographically
diverse office locations and helps connect
all employees with customers, wherever
they may be.
SIP Telephone
Enhanced Communications Solutions
KX-HGT100-B

BTS090002SS
KX-HGT100-B Specifications
Feature Description
Display 2 Line x 16 Character Monochrome LCD with 4-level Contrast
Network Interface 2 Ethernet Ports (10/100 Base-T) for PC and LAN
Power 100V-240V AC (50Hz) Adaptor (Optional) or Power
over Ethernet (IEEE802.3af) Class 1 (Not PC-Port)
Headset Jack 1 port
Keypad Dial Keypad, Mute, Speaker Phone, Program, Information,
Hold, Transfer, Message (VM), Auto (Speed dial), Redial
Speakerphone Supported
VoIP Protocol SIP (RFC3261)
Voice Codec G.711(u-LAW/A-LAW), G.729A, G.726 (32kbps, PBX not supported)
(NB:G722 (Peer-to-Peer) is not supported)
Network Protocol DHCP, Static IPv4 TCP/IP, UDP, ICMP
Security Digest MD5 Authentication (Password authentication)
Remote Management HTTP (Port 80 by default optional for port 8080)
DTMF In / Outband, RFC2833
QoS Diffserv (TOS)
Caller ID Available
Speed Dial 10 stations
Redial 10 Last Calls
Ringer Volume 4 Level (High / Mid / Low / OFF)
Ringer Pattern 3
Key Tone 3 Level (High / Low / OFF)
Call Log Up to 50 events (Access by “Navi” Key when On-Hook)
Hold / Transfer Depends on ITSP Service Specification
Operating Environment 5ºC - 40ºC (41ºF - 104ºF)
Dimensions (HxWxD) Approx. 3-5/32" x 5-29/32" x 8-5/32" (80mm x 150mm x 215mm)
Mass (Weight) Approx. 1.4 Ib. (624.4g)
Optional AC Adaptor PQLV206X
Headset KX-TCA86, KX-TCA91, KX-TCA92
Compatible Systems
This model supports the following PBX version and CODEC types:
KX-NCP500/KX-NCP1000: PBMPR Software File Version 1.0000 or later
KX-TDE600: PGMPR Software File Version 2.0000 or later
KX-TDE100/KX-TDE200: PMMPR Software File Version 2.0100 or later
CODEC: G.729A, G.711
Key Features
• SIP Protocol
• 2-Line LCD Display
• Caller ID*
• Call Log
• Hold, Transfer, Speed Dial & Voicemail Access
• Speaker Phone
• Easy Installation
• Power Over Ethernet (PoE)
• 2-Ethernet port
• Web Programming for Installer
* Requires subscription to fee-based telephone service.
Design and specifications subject to change without notice.
