ParaBody 890 User manual

1
890 WEIGHT HORN ATTACHMENT
CLASSH
PART # 7192801
REV.A Revision: 09/26/01
USER’S GUIDE
WARNING:
Read and follow all directions
for each step to insure proper
assembly of this product.
Version: 890107

THERE IS A RISK ASSUMED BY INDIVIDUALS WHO USE THIS TYPE OF
EQUIPMENT. TO MINIMIZE RISK FOLLOW THESE RULES!
1. Before using, read all the warnings and instructions
on the use of this machine. Use only for intended
exercise. DO NOT modify the machine.
2. Obtain a medical exam before beginning any
exercise program.
3. Keep body and clothing free of all moving objects.
4. Inspect the machine before use. DO NOT use it if it
appears damaged. DO NOT attempt to fix a broken or
j
ammed machine. Notify your authorized ParaBody
dealer before use and have repairs made by an
authorized service technician.
5. Be certain that weight pin is completely inserted.
Use only the pin provided by the manufacturer. If
unsure, call your authorized ParaBody dealer.
6. Never pin the weights or prop plate into an elevated
position. DO NOT use the machine if found in this
condition. DO NOT attempt to fix. Notify your
authorized ParaBody dealer.
7. Inspect cables and their connections before using
machine. Pay particular attention to the cable ends.
DO NOT attempt to fix. Notify your authorized
ParaBody dealer before use and have repairs made by
an authorized service technician.
8. Make sure all spring loaded pull pins are fully
engaged in the adjustment position and fully tighten
thumbscrew before use.
9. Children must not be allowed near this machine.
Supervise teenagers.
.
IMPORTANT SAFETY INFORMATION
TABLE OF CONTENTS
Safety Statement.............2
General Notes..................3
Tools Required................3
NOTE: In a continual effort to improve our products, specifications are subject to change
2001 Life Fitness, a division of Brunswick Corporation. All rights reserved.
ParaBody is a trademark of Brunswick Corporation
www.parabody.com
2
Parts list..........................4
Assembly Instructions.....4-7
General Maintenance.......8
Warranty Statement..........9
Product Services..............10
Insert-Registration Card
©

IMPORTANT NOTES
Please note:
Tools Required forAssembly
* Thank you for purchasing the ParaBody 890 Weight HornAttachment. Please read these
instructions thoroughly and keep them for future reference. This product must be assembled
on a flat, level surface to assure its proper function.
3
NOTE:BOLTLENGTHIS MEASURED FROMTHEUNDERSIDE OFTHEHEADOFTHEBOLT.
BOLT LENGTH RULER:
* This product must be assembled on a flat, level surface to assure its proper function. DO NOT
securely tighten any frame connections until the entire frame has been assembled, unless
otherwise stated.
Bolt Length Ruler
0123456
1/2 1/2 1/2 1/2 1/2 1/2
BOLT LENGTH
* 3/4” wrench
* Ratchet with 3/4” socket

4
PARTS LIST
PART #
6799601
3102910
3102502
3102801
3119302
KEY
1
2
3
4
5
QTY
4
8
8
8
4
DESCRIPTION
PLATEHOLDER
1/2X 3”BOLT
1/2”WASHER
1/2”LOCKNUT
1-3/4”ROUNDENDCAP
FIGURE 1
STEP 1:
UPRIGHTFRAME
• Removeanddiscardtheeight9/16”CAPPLUGSfromthe UPRIGHT FRAMES as shown in FIGURE 1.
9/16”CAPPLUG
INSTALLATION SHOWN FOR888SMITH MACHINE. 838SQUATRACKINSTALLATION SHOWNONPAGE 6&7.

5
FIGURE 2
STEP2:
0123456
1/2 1/2 1/2 1/2 1/2 1/2
• Insertfour1-3/4”ROUND END CAPS (5) into the end of the four PLATE HOLDERS (1) as shown in FIGURE 2.
• SECURELY assemble the four PLATE HOLDERS (1) to the UPRIGHTFRAMES as shown in FIGURE 2, usingeight1/2X3”BOLTS
(2),eight1/2”WASHERS (3), and eight 1/2” LOCK NUTS (4).
2 1/2 X 3”
5
3
4
1
UPRIGHTFRAME

6
FIGURE 1
STEP 1:
CROSS
BRACE
• Remove and discard the four 1/2 X 3” BOLTS, four 1/2” WASHERS, and four 1/2” LOCK NUTS from the CROSS BRACE as shown in
FIGURE1.
1/2X3” BOLT
INSTALLATION SHOWN FOR 838 SQUAT MACHINE. 888 SMITH MACHINE INSTALLATION SHOWN ON PAGE 4 & 5.
1/2”WASHER
1/2”
LOCK
NUT

7
FIGURE 2
STEP2:
0123456
1/2 1/2 1/2 1/2 1/2 1/2
• Insertfour1-3/4”ROUND END CAPS (5) into the end of the four PLATE HOLDERS (1) as shown in FIGURE 2.
• SECURELYassembletwoPLATE HOLDERS(1) andtheCROSS BRACE to the UPRIGHTFRAMES as showninFIGURE2,using
four1/2X3” BOLTS(2) and four 1/2” LOCKNUTS(4).
2 1/2 X 3”
5
1
UPRIGHTFRAME
CROSS
BRACE
• SECURELYassemblethetwoPLATE HOLDERS(1) totheUPRIGHTFRAMESasshowninFIGURE2, using four 1/2 X 3” BOLTS
(2),four1/2”WASHERS(3),andfour 1/2” LOCK NUTS (4).
4 3

MAINTENANCE
MODEL #________________________
SERIAL #_________________________
DATE OF PURCHASE: _____________
DEALERS NAME: _________________
DEALERS PHONE #_______________
8
* We recommend cleaning your product (pads and frame) on a regular basis, using warm soapy
water. Touch-up paint can be purchased from your ParaBody customer service representative
at [phone].
* Inspect equipment daily. Tighten all loose connections are replace worn parts immediately.
Failure to do so may result in serious injury
Thankyouforpurchasingthe ParaBody890WeightHornAttachment.
Please note:
* PLEASE RECORD THE INFORMATION REQUESTED BELOW. IN THE EVENT
YOU MAY NEED SERVICE YOU WILLBEASKED FOR THIS INFORMATION.
REMEMBER TO FILL OUT YOUR WARRANTY REGISTRATION CARD AND
MAIL BACK.

9
NOTES:
LIMITED WARRANTY
ParaBodyextends the following LIMITEDWARRANTYto the original owner of the ParaBody products. The Warranty terms apply to IN HOMEUSE ONLY.
1. LIMITEDWARRANTYONFRAMEAND WELDS. If theframe ofthe ParaBodyproduct or aweld shouldcrack orbreak, it willbe repaired
or replaced by ParaBody. Terms: Lifetime – for so long as the Customer owns the ParaBody product.
2. LIMITED WARRANTYON PARTS. Ifthe followingpartsare defectivein materialor workmanship,ParaBody willsupply replacementparts:
all bolts, nuts, washers, bearings, bushings, pulleys, thumbscrews, collars, cable retaining clips, adjustable pre-stretch slides, roller pad
shafts, allen head bolts, weight selector pin, weight stack shaft, set screws, protector caps, adjustment chain, cotter pin, plunger, spring
and knob. Terms: Lifetime – for so long as the Customer owns the ParaBody product.
3. LIMITED WARRANTY ON CABLESAND UPHOLSTERY. If the coated cables or upholstery are defective in material or workmanship,
ParaBody will repair or replace them, at its option. Terms: Three (3) years.
4. CONDITIONSAND EXCEPTIONS. Any product misuse, abuse or alteration, any attempt to repair by a person other than an authorized
ParaBody Service Center, any improper assembly, accident, or any other condition resulting from occurrences beyond the control of
ParaBody will void this Limited Warranty.
5. REPLACEMENTAND REPAIR EXPENSES. ParaBody will provide only replacement parts or repair under this warranty. The Owner is
responsiblefor allother costs. Suchcosts may include,but arenot limitedto: a. laborcharges forservice, removal,repairorreinstallation
ofthe ParaBodyproduct oranycomponent part; b.shipping,delivery, handlingand administrativecharges forreturning partstoParaBody;
and c. all necessary or incidental costs related to installation of the replacement parts.
6. SHIPPING. Ifshipping bythe Ownersis deemednecessary (insole discretionof ParaBody),partsshould beshipped intheir originalcarton
orequivalent packaging,fully insured withshipping chargesprepaid. ParaBody willnot assumeany responsibility forany lossor damage
incurredin shipping.
7. CLAIMPROCEDURES. If service onyour ParaBodyproduct is requiredduring thewarranty period, pleasecontact ourCustomer Service
Departmentat1-800-328-9714 forinstructionsregarding returningorreplacing parts. Pleasehaveavailablethe followinginformation: (i) the
dealer’s name; (ii) the date of purchase; (iii) the serial # (s) of your product (the serial number location is called out on the final assembly
drawingincluded with yourassembly instruction); (iv)a descriptionofthe natureof the problem.
8. OWNER’S RIGHT. ThisLimited Warranty givesyou specificlegal rights. You mayalsohaveotherrights, whichvary dependingon locallaw.
9. LIMITATION OF IMPLIED WARRANTIES. All implied warranties, except to the extent prohibited by applicable law, shall have no greater
duration than the warranty period set forth above. There are no warranties which extend beyond the description inthis Limited Warranty.
Because local laws do not allow limitations on how long an implied warranty lasts, the above limitations may not apply to you.
10. DISCLAIMER. No otherexpress warranty hasbeen made orwill bemade on behalfof ParaBodywith respect toany ParaBody productor
the operation, repair or replacement of any ParaBody product. ParaBody shall not be responsible for injury, loss of use of the ParaBody
product,inconvenience, loss ordamage topersonal property, whetherdirect orindirect, and incidentalor consequentialdamages,so the
above limitation or exclusion may not apply to you.
