PI N--472 10 Series User manual

Physik Instrumente (PI) GmbH & Co. KG, Auf der Roemerstrasse 1, 76228 Karlsruhe, Germany
Phone [phone], Fax [phone], Email [e-mail], www.pi.ws
MP144E
N-472 Linear Actuator
User Manual
Version: 1.3.0
Date: 29.10.2019
This document describes the following products:

N-472.x10/.x10Y, N-472.x1V/.x1VY
PiezoMike linear actuator, M10×1 thread

N-472.x20/.x20Y, N-472.x2V/.x2VY
PiezoMike linear actuator, 9.5 mm (0.375")
clamping shank
Models:
x represents the travel range:
1 = 7 mm
2 = 13 mm
Y: Turned cable exit
0: Not suitable for use in a vacuum
V: Vacuum-compatible to 10-6 hPa

The following company names and brands are registered trademarks of Physik Instrumente (PI) GmbH & Co.
KG:
PI®, NanoCube®, PICMA®, PILine®, NEXLINE®, PiezoWalk®, NEXACT®, Picoactuator®, PInano®, PIMag®,
Q-Motion®
The patents held by PI are found in our patent list:
http://www.physikinstrumente.com/en/about-pi/patents
© 2019 Physik Instrumente (PI) GmbH & Co. KG, Karlsruhe, Germany. The text, photographs and drawings in
this manual are protected by copyright. With regard thereto, Physik Instrumente (PI) GmbH & Co. KG retains
all the rights. Use of said text, photographs and drawings is permitted only in part and only upon citation of
the source.
Original instructions
First printing: 29.10.2019
Document number: MP144E, CBo, version 1.3.0
Subject to change without notice. This manual is superseded by any new release. The latest release is
available for download (p. 3) on our website.

1About this Document 1
1.1 Objective and Target Audience of this User Manual.................................................. 1
1.2 Symbols and Typographic Conventions...................................................................... 1
1.3 Figures ........................................................................................................................ 2
1.4 Other Applicable Documents ..................................................................................... 2
1.5 Downloading Manuals................................................................................................ 3
2Safety 5
2.1 Intended Use .............................................................................................................. 5
2.2 General Safety Instructions ........................................................................................ 5
2.2.1 Organizational Measures............................................................................... 6
2.2.2 Measures for Handling Vacuum-Compatible Products ................................. 6
3Product Description 7
3.1 Model Overview ......................................................................................................... 7
3.2 Product View .............................................................................................................. 9
3.3 Product Labeling....................................................................................................... 11
3.4 Scope of Delivery...................................................................................................... 12
3.5 Suitable Controllers .................................................................................................. 12
3.6 Technical Features.................................................................................................... 13
3.6.1 ID Chip.......................................................................................................... 13
4Unpacking 15
5Installation 17
5.1 General Notes on Installation................................................................................... 17
5.2 Installing the Linear Actuator into a Mechanical Mounting and Connecting it
to the Protective Earth Conductor ........................................................................... 19
5.3 Preparing a Vacuum-Compatible N-472 for Connection to the Controller.............. 22
6Startup and Operation 25
6.1 General Notes on Startup and Operation ................................................................ 25
6.2 Operating Parameters .............................................................................................. 28
6.3 Operating the N-472................................................................................................. 28
6.4 Determining the Reference Position Manually ........................................................ 29
Contents

7Maintenance 31
8Troubleshooting 33
9Customer Service 35
10 Technical Data 37
10.1 Specifications............................................................................................................ 37
10.1.1 Data Table.................................................................................................... 37
10.1.2 Materials Used for Vacuum-Compatible Models ........................................ 39
10.1.3 Maximum Ratings........................................................................................ 40
10.1.4 Ambient Conditions and Classifications ...................................................... 40
10.2 Step Size and Axial Force.......................................................................................... 41
10.3 Lifetime..................................................................................................................... 42
10.4 Operating Time and Duty Cycle................................................................................ 42
10.5 Dimensions ............................................................................................................... 45
10.5.1 Models with Turned Cable Exit.................................................................... 45
10.5.2 Models with M10x1 Thread......................................................................... 46
10.5.3 Models with Clamping Shank ...................................................................... 48
10.6 Pin Assignment ......................................................................................................... 50
11 Old Equipment Disposal 51
12 EU Declaration of Conformity 53

1 About this Document
N-472 Linear Actuator MP144E Version: 1.3.0 1
In this Chapter
Objective and Target Audience of this User Manual..................................................................... 1
Symbols and Typographic Conventions ......................................................................................... 1
Figures............................................................................................................................................ 2
Other Applicable Documents......................................................................................................... 2
Downloading Manuals ................................................................................................................... 3
1.1 Objective and Target Audience of this User Manual
This manual contains information necessary for the intended use of the N-472.
It assumes that the reader has a fundamental understanding of basic servo systems as well as
motion control concepts and applicable safety procedures.
The latest versions of the user manuals are available for download (p. 3) on our website.
1.2 Symbols and Typographic Conventions
The following symbols and typographic conventions are used in this user manual:
CAUTION
Dangerous situation
Failure to comply could lead to minor injury.
Precautionary measures for avoiding the risk.
NOTICE
Dangerous situation
Failure to comply could cause damage to equipment.
Precautionary measures for avoiding the risk.
INFORMATION
Information for easier handling, tricks, tips, etc.
1
About this Document

1 About this Document
2 Version: 1.3.0 MP144E N-472 Linear Actuator
Symbol/Label Meaning
1.
2.
Action consisting of several steps whose sequential order must be
observed

Action consisting of one or several steps whose sequential order is
irrelevant

List item
p. 5
Cross-reference to page 5
RS-232
Labeling of an operating element on the product (example: socket of the
RS-232 interface)
Warning sign on the product which refers to detailed information in this
manual.
1.3 Figures
For better understandability, the colors, proportions, and degree of detail in illustrations can
deviate from the actual circumstances. Photographic illustrations may also differ and must not
be seen as guaranteed properties.
1.4 Other Applicable Documents
The devices and software tools from PI mentioned in this documentation are described in their
own manuals.
Description Document
E-871.1A1N Compact PiezoMike - Q-Motion®
controller, 1 axis, TCP/IP, USB, RS-232
PZ285E user manual
PIMikroMove
SM148E software manual

1 About this Document
N-472 Linear Actuator MP144E Version: 1.3.0 3
1.5 Downloading Manuals
INFORMATION
If a manual is missing or problems occur with downloading:
Contact our customer service department (p. 35).
Downloading manuals
1. Open the website www.pi.ws.
2. Search the website for the product number (e.g., N-472) or the product family (e.g.,
PiezoMike).
3. Click the corresponding product to open the product detail page.
4. Click Downloads.
The manuals are shown under Documentation.
5. Click the desired manual and fill out the inquiry form.
The download link will then be sent to the email address entered.

2 Safety
N-472 Linear Actuator MP144E Version: 1.3.0 5
In this Chapter
Intended Use.................................................................................................................................. 5
General Safety Instructions............................................................................................................ 5
2.1 Intended Use
The N-472 is a laboratory device as defined by DIN EN 61010-1. It is intended for indoor use and
use in an environment that is free of dirt, oil and lubricants.
The N-472 is a linear actuator for integration into mechanical and optomechanical components.
For integration, the mechanics, in which the N-472 is to be installed, must have suitable
mountings.
A piezoelectric motor is installed in the N-472 linear actuator that acts on the fine-threaded
screw and moves it.
When at rest, the drive is self-locking and therefore requires no current and generates no heat.
It holds the position with maximum force.
The N-472 is not intended for continuous operation. For further information on the operating
conditions of the N-472, see "Technical Data" (p. 37).
The intended use of the N-472 is only possible in conjunction with a suitable controller (p. 12),
which is available from PI. The controller is not included in the scope of delivery of the N-472.
The controller must provide the required operating voltages. It must also be able to read out
and process the signals from the position sensors so that the servo control system can function
properly.
2.2 General Safety Instructions
The N-472 is built according to state-of-the-art technology and recognized safety standards.
Improper use can result in personal injury and/or damage to the N-472.
Use the N-472 for its intended purpose only, and only when it is in perfect technical
condition.
Read the user manual.
Eliminate any malfunctions that may affect safety immediately.
The operator is responsible for the correct installation and operation of the N-472.
2
Safety

2 Safety
6 Version: 1.3.0 MP144E N-472 Linear Actuator
2.2.1 Organizational Measures
User manual
Always keep this user manual together with the N-472.
The latest versions of the user manuals are available for download (p. 3) on our
website.
Add all information from the manufacturer to the user manual, for example
supplements or technical notes.
If you give the N-472 to a third party, include this user manual as well as other relevant
information provided by the manufacturer.
Do the work only if the user manual is complete. Missing information due to an
incomplete user manual can result in minor injury and damage to equipment.
Install and operate the N-472 only after you have read and understood this user
manual.
Personnel qualification
The N-472 may only be installed, started, operated, maintained, and cleaned by authorized and
appropriately qualified personnel.
2.2.2 Measures for Handling Vacuum-Compatible Products
When handling the vacuum version of the linear actuator, attention must be paid to
appropriate cleanliness. At PI, all parts are cleaned before assembly. During assembly and
measurement, powder-free gloves are worn. Afterwards, the linear actuator is cleaned once
again by wiping and shrink-wrapped twice in vacuum-compatible film.
Touch the linear actuator only with powder-free gloves.

3 Product Description
N-472 Linear Actuator MP144E Version: 1.3.0 7
In this Chapter
Model Overview............................................................................................................................. 7
Product View.................................................................................................................................. 9
Product Labeling .......................................................................................................................... 11
Scope of Delivery ......................................................................................................................... 12
Suitable Controllers ..................................................................................................................... 12
Technical Features ....................................................................................................................... 13
3.1 Model Overview
The models differ as follows:
Travel range
Type of installation
Suitability for use in a vacuum
Position of the cable exit
In the product number, these are coded as follows by the character following the period:
Character following
the period Meaning Possible values
First character
Travel range
1 = 7 mm
2 = 13 mm
Second character
Type of installation
1 = M10×1 thread
2 = 9.5 mm clamping shank
Third character
Suitability for use in
a vacuum
0 = not suitable
V = up to 10-6 hPa
Fourth character
Position of the cable
exit
No entry = standard cable exit
Y = turned cable exit (i.e., turned by 180°)
3
Product Description

3 Product Description
8 Version: 1.3.0 MP144E N-472 Linear Actuator
PiezoMike linear actuators with M10
×
1 thread
Model Description
N-472.110
Closed loop PiezoMike linear actuator, 7 mm, M10×1 thread
N-472.110Y
Closed loop PiezoMike linear actuator, 7 mm, M10×1 thread, turned cable exit
N-472.210
Closed loop PiezoMike linear actuator, 13 mm, M10×1 thread
N-472.210Y
Closed loop PiezoMike linear actuator, 13 mm, M10×1 thread, turned cable exit
PiezoMike linear actuators with M10
×
1 thread, vacuum-compatible to 10-6 hPa
Model Description
N-472.11V
Closed loop PiezoMike linear actuator, 7 mm, M10×1 thread, vacuum
compatible to 10-6 hPa
N-472.11VY
Closed loop PiezoMike linear actuator, 7 mm, M10×1 thread, vacuum
compatible to 10-6 hPa, turned cable exit
N-472.21V
Closed loop PiezoMike linear actuator, 13 mm, M10×1 thread, vacuum
compatible to 10-6 hPa
N-472.21VY
Closed loop PiezoMike linear actuator, 13 mm, M10×1 thread, vacuum
compatible to 10-6 hPa, turned cable exit
PiezoMike linear actuators with clamping shank
Model Description
N-472.120
Closed loop PiezoMike linear actuator, 7 mm, 9.5 mm (0.375") clamping shank
N-472.120Y
Closed loop PiezoMike linear actuator, 7 mm, 9.5 mm (0.375") clamping shank,
turned cable exit
N-472.220
Closed loop PiezoMike linear actuator, 13 mm, 9.5 mm (0.375") clamping shank
N-472.220Y
Closed loop PiezoMike linear actuator, 13 mm, 9.5 mm (0.375") clamping
shank, turned cable exit
PiezoMike linear actuators with clamping shank, vacuum-compatible to 10-6 hPa
Model Description
N-472.12V
Closed loop PiezoMike linear actuator, 7 mm, 9.5 mm (0.375") clamping shank,
vacuum compatible to 10-6 hPa
N-472.12VY
Closed loop PiezoMike linear actuator, 7 mm, 9.5 mm (0.375") clamping shank,
vacuum compatible to 10-6 hPa, turned cable exit
N-472.22V
Closed loop PiezoMike linear actuator, 13 mm, 9.5 mm (0.375") clamping
shank, vacuum compatible to 10-6 hPa
N-472.22VY
Closed loop PiezoMike linear actuator, 13 mm, 9.5 mm (0.375") clamping
shank, vacuum compatible to 10-6 hPa, turned cable exit

3 Product Description
N-472 Linear Actuator MP144E Version: 1.3.0 9
3.2 Product View
N-472 models with M10x1 thread
The description of the product components is also valid for models with turned cable exit.
Figure 1: Models with thread and standard cable exit (example illustration): Standard version (left)
and vacuum version (right)
1Screw head
2Fine-threaded screw (rotating)
3Base body
4M10x1 mounting nut
5M10x1 mounting thread
6Ball tip for connecting to the movable part of the mechanical mounting
7Unscrew lock (circlip) for fine-threaded screw
8Product labeling
9Cable for connecting to the controller (sensor cable not illustrated)

3 Product Description
10 Version: 1.3.0 MP144E N-472 Linear Actuator
N-472 models with clamping shank
The description of the product components is also valid for models with turned cable exit.
Figure 2: Models with clamping shank and standard cable exit (example illustration):
Standard version (left) and vacuum version (right)
1Screw head
2Fine-threaded screw (rotating)
3Base body
4Clamping shank (9.5 mm diameter, 6 mm clamping width)
5M9x1 mounting nut
6Ball tip for connecting to the movable part of the mechanical mounting
7Unscrew lock (circlip) for fine-threaded screw
8Product labeling
9Cable for connecting to the controller (sensor cable not illustrated)
Directions of Motion
Figure 3: Directions of motion of the N-472
Pay attention to further information on the operating conditions in the "Technical Data" section
(p. 37).

3 Product Description
N-472 Linear Actuator MP144E Version: 1.3.0 11
3.3 Product Labeling
Figure 4: N-472: Product labeling
Figure 5: Type plate (N-472.110 as example)
Figure 6: Laser marking (for vacuum-compatible models, N-470.41U as an example)

3 Product Description
12 Version: 1.3.0 MP144E N-472 Linear Actuator
Position Labeling Description
A Manufacturer's logo
A WWW.PI.WS Manufacturer's address (website)
B CE conformity mark
B Warning sign "Pay attention to the manual!"
B Old equipment disposal (p. 51)
B Symbol for the protective earth conductor (p. 19)
B Country of origin: Germany Country of origin
C N-472.110 Product name (example), the characters following
the period refer to the model
C 123456789 Serial number (example), individual for each N-472
Meaning of each position (from the left):
1 = internal information
2 and 3 = year of manufacture
4 to 9 = consecutive number
Only with models that are not suitable for use in a vacuum:
C R: 00.001 Revision number (example)
C Data matrix code (example; contains the serial
number)
3.4 Scope of Delivery
Product number Components
N-472
Linear actuator according to order (p. 7)
000049906
Hook wrench
MP171EK
Short instructions for PiezoMike linear actuators
For vacuum-compatible models only:
N472B0001
Motor / sensor cable, D-sub 15 (m) to open end, 2 m, on the air side
3.5 Suitable Controllers
Product number Description
E-871.1A1N
Compact PiezoMike - Q-Motion® controller, 1 axis, TCP/IP, USB,
RS-232

3 Product Description
N-472 Linear Actuator MP144E Version: 1.3.0 13
3.6 Technical Features
3.6.1 ID Chip
An ID chip is in the D-sub connector (m) of the linear actuator, in which the data on the linear
actuator is stored (e.g., linear actuator type, serial number, date of manufacture, hardware
version).
When switched on or rebooted, controllers from PI read the data from the ID chip.
For more information on the ID chip recognition, see the manual of the controller used.

4 Unpacking
N-472 Linear Actuator MP144E Version: 1.3.0 15
INFORMATION
When handling the vacuum version of the linear actuator, attention must be paid to
appropriate cleanliness. At PI, all parts are cleaned before assembly. During assembly and
measurement, powder-free gloves are worn. Afterwards, the linear actuator is cleaned once
again by wiping and is then shrink-wrapped twice in vacuum-compatible film.
Touch the linear actuator only with powder-free gloves.
1. Unpack the N-472 with care.
2. Compare the contents with the scope of delivery according to the contract and the
delivery note.
3. Inspect the contents for signs of damage. If any parts are damaged or missing, contact
our customer service department (p. 35) immediately.
4. Keep all packaging materials in case the product needs to be returned.
4
Unpacking
