Polycom VVX 601 User manual

For more information, visit epb.com/customer-support/business-support
or call 423-648-1500, option 2
1
PLACING AND ANSWERING AUDIO CALLS
VVX 301, 401, 501 and 601 can manage a maximum of 24 active, incoming, and held audio calls at
a time. However, you can have only one active call in progress with numerous other incoming calls
or calls on hold on all phones. Additionally, your system administrator can set up your phone to
have up to six lines with unique extension numbers, or the same extension number as other lines
on your network.
PLACING AUDIO CALLS
You can place audio calls on your phone, and you have the option to use the handset, the
speakerphone, or a headset.
To place a call from the Dialer
1. Do one of the following:
a. Start typing a phone number.
b. Press a line key, OR
c. Pick up the handset, or press the Speakerphone key or Headset key.
2. Enter a number or select a recent contact. On VVX 501 and 601 phones, tap the onscreen
keyboard icon pad to enter numbers.
3. On VVX 301 and 401 phones, select Dial. On VVX 501 and 601 phones, tap the Dial icon.
REDIALING A NUMBER
Your phone automatically keeps a record of all the calls placed on your phone. You can recall the last
contact you call using the Redial icon or soft key.
To redial a number:
1. Do one of the following:
a. Select the Redial icon on the Home screen.
b. Press the Redial soft key.
SWITCH AMONG THE HANDSET, HEADSET, AND SPEAKERPHONE
To switch among methods:
During a call, pick up the handset, press the Headset key or press the Speakerphone key.
For example, if you’re using the handset, press the Headset key to switch to the headset,
or press the Speakerphone key to switch to the speakerphone.
POLYCOM®
Phone User Guide

For more information, visit epb.com/customer-support/business-support
or call 423-648-1500, option 2
2
When using the speakerphone, the Speakerphone key glows green. When using the headset, the
Headset key glows green if an analog headset is connected or blue if a USB headset is connected.
HOLDING AND RESUMING CALLS
When you are in a call, you can place a call on hold and resume the call.
To hold a call:
During an active call, select Hold. If you’re in the Calls screen, highlight the call rst.
A hold icon is displayed on the line of the held call, and a red LED light ashes on the line key for
all phones.
To resume a held call:
1. Do one of the following:
a. Select Resume.
b. From the Calls screen, select the call to highlight it, and select Resume.
TRANSFERING A CALL
You can transfer a call to another contact and choose the transfer type you want to use for the call.
To transfer a call:
1. During a call, do one of the following:
a. Press Transfer to use the default transfer type.
b. Press and hold Transfer and select a transfer type - either Blind or Consulative.
2. Dial a number or choose a contact from the call list or directory. If the transfer type is set to
Blind, the call is transferred immediately.
3. If the transfer type is set to Consultative, press Transfer after speaking with your contact.
MANAGING CALLS
You can see the number of calls for each line from the Lines screen, as shown next. On all VVX
phones, a green light on the line key indicates a line with an active call, and a red light indicates
a line with one or more held calls.
To manage a call from the Calls screen:
1. Select a call. The call is highlighted.
2. Do one of the following:
a. Select Hold to place an active call on hold.
b. Select Resume to make a held call active.
2

For more information, visit epb.com/customer-support/business-support
or call 423-648-1500, option 2
3
c. Select End Call to end a call with a contact. You can end active calls only, so resume the held
call rst before ending it.
d. Select Transfer to send the call to another contact.
e. Select Conference to initiate a conference call.
IGNORE OR SILENCE INCOMING CALLS
You can ignore or silence a call to stop your phone from ringing. Even if you ignore the call and
silence the ringer, an incoming call notication continues to display on your phone.
To ignore or silence a call:
From the Incoming Call screen, select Ignore for private lines, or Silence for shared lines.
The Incoming Call screen disappears, your phone stops ringing, and either the Home or Calls
screen is displayed.
Reject Incoming Calls
You can reject a call and send the call directly to voicemail. Rejected calls display in the Missed Calls
list in your Recent Calls list. Rejecting calls is not available for shared lines.
To reject an incoming call:
From the Incoming Call screen, select Reject. The call goes directly to voicemail.
INITIATING CONFERENCE CALLS
You can initiate an audio conference call with two contacts and hold, resume, or split a conference
call on your VVX phone. VVX phones can manage a maximum of 12 active or held conference calls
at a time. However, you can have only one active conference call in progress with numerous other
conference calls on hold.
Initiate Conference Calls
You can initiate a conference by calling two people and selecting the Conference soft key or hard key.
To initiate a conference call:
1. Call a contact.
2. After the contact answers, select the Conference soft key. The call is held.
3. Enter another contact’s number or select a contact from the directory or the call lists.
4. When the contact answers, select the Conference soft key. All call participants are added to a
conference call.
WORKING WITH SHARED LINES
All VVX phones support multiple and shared lines. Your administrator can customize your phone so
that you have multiple shared lines enabled.
3

For more information, visit epb.com/customer-support/business-support
or call 423-648-1500, option 2
4
4
The following features are not available or have limitations on phones with shared lines:
• Forwarding an incoming call is not available.
• Enabling Do Not Disturb on shared lines disables ringing only, and a visual notication of the call
is displayed with the option to answer the call.
MANAGE CALL LISTS AND DIRECTORIES
MANAGE CALL LISTS AND DIRECTORIES
VIEW RECENT CALLS
All VVX phones maintain a Recent Calls list that includes missed, received, and placed calls.
Each list holds up to 100 entries.
You can perform the following tasks from the Recent Calls list:
• Remove calls from the list.
• Select a call record to view call details.
• Select a call record to automatically call a contact.
To view your Recent Calls list:
Navigate to Directories > Recent Calls.
VIEW CALL DETAILS
In the Recent Calls list, you can view call details, edit call details before calling a contact,
save a contact to your directory, and delete call entries.
To view call details:
Select Info or tap the Info icon next to a call record.
SAVE A RECENT CONTACT
From the Call Details screen, you can save a contact to the Contact Directory.
To save a contact to your Contact Directory:
From the Call Details screen, select Save. If the person is already in your Contact Directory,
but is not a favorite, Add to Favorites is displayed.
DELETE A CONTACT
You can delete contacts from the Recent Calls list.

For more information, visit epb.com/customer-support/business-support
or call 423-648-1500, option 2
5
5
To delete a contact from the Recent Calls list:
Select Delete or tap the Delete icon.
EDIT RECENT CONTACT ENTRIES
You can edit a contact’s phone number stored in your Recent Calls list before returning the contact’s call.
To edit a recent contact’s number before calling the contact:
1. Select Edit or tap the Edit Number icon.
2. Edit the number, and select Dial or tap the dial icon.
COMMPORTAL WEB INTERFACE
This helpful tool enables you to manage your phone and settings through an easy-to-use
Web based portal.
LOGGING IN
1. Go to https://phone.epbFi.com
2. Enter your phone number.
3. Enter your password (same as your voicemail PIN).
DASHBOARD PAGE
This displays new voice messages, recent received and missed calls, contacts and settings you have
applied to your phone.
MESSAGES & CALLS
• The Messages tab displays new and saved voice messages. Play, delete or mark as
heard/unheard.
• Missed Calls, Dialed Calls and Received Calls show you all your recent call activity.
CALL MANAGER
• The Summary tab of Call Manager provides a description of what will happen to your incoming calls.
• The other tabs enable you to change the settings of your call coverage, including Call
Forwarding, Do Not Disturb and Find Me/Follow Me.
CHANGE PASSWORD
1. Go to Settings page.
2. Click Change Password next to Account Password.
3. Enter your new password in the Confirm Password box.

For more information, visit epb.com/customer-support/business-support
or call 423-648-1500, option 2
6
6
4. Re-enter your new password.
5. Click Change Password.
CONFIGURE PHONE KEYS
1. Select the Settings page.
2. Click on the Set Keys link.
SET THE TIME AND DATE DISPLAY
To update the time and date display:
1. Navigate to Settings > Basic > Preferences > Time & Date.
2. From the Time & Date screen, do one of the following:
a. Select Clock Date to change the date format.
b. Select Clock Time to change the time format.
VOICEMAIL-TO-EMAIL
1. Log into CommPortal.
2. Click the Settings tab.
3. Click Messages tab under settings.
4. Check the Forward Messages as Emails check box.
5. Click on the text Add an Email Address.
6. Enter your email address. If you want to leave the message in the inbox, check the Leave
Original in Inbox check box. (This will NOT clear when you check your email messages,
you will have to go and delete them thru the phone or CommPortal).
7. Click Apply for your changes to work.
DELETE MESSAGES FROM IN BOX
1. Login to CommPortal.
2. Click the Messages & Calls tab. Here you can listen, delete or forward messages to another
voicemail box or an email. You can even reply if you have microphone set up on your computer.
3. To delete, click the X to the right of each message you want to delete. That message will be sent
to the Deleted tab, where it will stay for a specied amount of time.
4. To permanently delete messages, go to the Deleted tab and click the Xto the right of message.
5. Under both the Messages & Deleted tabs you have the option to delete all at one time. Click
the Delete All tab at bottom left of each screen.
For more information, see the Help Section under the gear icon in the upper right hand corner of the
CommPortal screen.
CUSTOMIZE YOUR PHONE

For more information, visit epb.com/customer-support/business-support
or call 423-648-1500, option 2
7
7
CUSTOMIZE YOUR PHONE
SET THE LANGUAGE Your phone supports several languages that you can choose to display.
Check with your system administrator to nd out which languages are supported on your phone.
To change the language:
1. Navigate to Settings > Basic > Preferences > Language.
2. From the Language screen, select a language. The language on your phone updates
automatically.
SET THE TIME AND DATE DISPLAY
To update the time and date display:
1. Navigate to Settings > Basic > Preferences > Time & Date.
2. From the Time & Date screen, do one of the following:
a. Select Clock Date to change the date format.
b. Select Clock Time to change the time format.
c. Select Clock Order to change the order of the time and date display.
3. From the Clock Date, Clock Time, or Clock Order screen, select the format you want.
SELECT A BACKGROUND PICTURE
To change the background picture:
1. Navigate to Settings > Basic > Preferences > Background. The Background screen is
displayed. Depending how your system is set up, you might have to navigate to Settings >
Basic > Preferences > Background > Select Background. The Select Background
screen is displayed instead.
2. Select a background image, if available.
Adding Personal Photos as Your Background
You can upload a personal photo to use as your background using the Web Conguration Utility
or using a USB ash drive on VVX 501 and 601 phones. When you set one of your pictures as the
background picture, the picture is displayed as Local File in the Backgrounds list.
ENABLE TRANSPARENT LINE KEYS
By default, your phone displays line keys with a blue background. If you have a background picture
set on your VVX phone, the background is partially or fully covered depending on the amount of
line keys you have. On VVX 501 and 601 phones, you can change line keys to have a transparent
background that enables you to fully see the background you set for your phone.

For more information, visit epb.com/customer-support/business-support
or call 423-648-1500, option 2
8
8
To enable transparent line keys:
1. Navigate to Settings > Basic > Preferences > Idle Screen Settings.
2. On the Idle Screen Settings screen, select Transparent Lines, and select Enabled. The
line keys are displayed without a background, as shown next.
ENABLE SCREEN SAVERS
The screen saver automatically starts each time your phone is idle for a certain amount of time.
When you enable the screen saver, you can choose to have your phone either display default photos
stored on the phone, or the idle browser.
To enable a screen saver:
1. Navigate to Settings > Basic > Preferences > Screen Saver.
2. From the Screen Saver screen, select Screen Saver and select Enabled.
3. Select Wait Time and enter the number of minutes the phone can wait after no activity before
displaying the screen saver. You can enter any time between one and 9999 minutes.
The default time is 15 minutes.
4. Select Type and select either Default or Idle Browser.
5. Press Save.
You can stop the screen saver at any time by Pressing any key or touching the screen. When your
phone is idle again for a specied period of time, the screen saver starts again.
Use Personal Photos as Screen Savers
On VVX 501 and 601 phones you can enable your phone to display your personal photos as a screen
saver. To set up a screen saver of your pictures, you need to set up certain screen saver settings,
place your pictures on a USB ash drive, and attach the USB ash drive to the phone.
CHANGING AUDIO SETTINGS
Change Incoming Call Notifications
You can choose whether you hear sound eects—all phone sounds except call audio—from
the handset, headset, speaker, or the active audio device you set. For example, you can congure
your phone to ring on your headset instead of the speaker. By default, you hear all sound eects
from the speaker.
To change your incoming call notifications:
1. Navigate to Settings > Basic > Preferences > Audible Ringer.
2. From the Audible Ringer screen, select a location to hear sound eects.

For more information, visit epb.com/customer-support/business-support
or call 423-648-1500, option 2
9
SET A RINGTONE FOR INCOMING CALLS
A simple way to personalize your phone is to change your phone’s ringtone. You can pick unique
ringtones for the dierent lines on your phone. The default ringtone is Low Trill.
To select an incoming call ringtone for your phone or a line:
1. Navigate to Settings > Basic > Ring Type.
2. When there are multiple lines on your phone, select a line.
3. From the Ring Type screen, select a ringtone.
4. Select Play or tap the Play icon to hear the ringtone.
SET A RINGTONE FOR INDIVIDUAL CONTACTS
You can select unique ringtones for various contacts in your directory. This helps you quickly identify
callers as your phone rings.
To select a ringtone for a contact:
1. From your Contact Directory, select a contact.
2. From the Contact Information screen, select Edit or tap the Edit icon.
3. From the Edit Contact screen, select Ring Type and select a ringtone.
4. Select Play or tap the Play icon to hear the ringtone.
5. From the Edit Contact screen, select Save.
CHANGE THE VOLUME
You can increase the volume of your ringtone and the audio during a call.
To change the volume of the ringtone or audio during calls:
Press one of the Volume keys to increase or decrease the audio.

For more information, visit epb.com/customer-support/business-support
or call 423-648-1500, option 2
10
