Pottinger s Series User manual

Operator‘s manual
GB
+ INSTRUCTIONS FOR PRODUCT DELIVERY . . . Page 3
"Translation of the original Operating Manual" Nr. 99 2441.GB.80L.0
• Rotary Swather
TOP 1252
TOP 1252 M
TOP 1252 C
TOP 1252 C s-line
(Type 2441 : + . . 01001)

ALLG./BA SEITE 2 / 0000-GB
Important information concerning Product
Liability.
According to the laws governing product liability, the manufacturer and dealer are obliged to hand the
operating manual to the customer at the time of sale, and to instruct them in the recommended operating,
safety, and maintenance regulations. Confirmation is necessary to prove that the machine and operating
manual have been handed over accordingly.
For this purpose,
- document A is to be signed and sent to Pöttinger,
- document B remains with the dealer supplying the machine,
- and the customer receives document C.
In accordance with the laws of product liability, every farmer is an entrepreneur.
According to the laws of product liability, property damage is damage caused by a machine and not to
it. An excess of Euro 500 is provided for such a liabilioty.
In accordance with the laws of product liability, entrepreneurial property damages are excluded from
the liability.
Attention! Should the customer resell the machine at a later date, the operating manual must be given
to the new owner who must then be instructed in the recommended regulations referred to herein.
GB Dear Farmer
You have just made an excellent choice. Naturally we are very happy
and wish to congratulate you for having chosen Pöttinger. As your
agricultural partner, we offer you quality and efficiency combined with
reliable servicing.
In order to assess the spare-parts demand for our agricultural machines
and to take these demands into consideration when developing new
machines, we would ask you to provide us with some details.
Furthermore, we will also be able to inform you of new developments.
Pöttinger Newsletter
www.poettinger.at/landtechnik/index_news.htm
The latest expert information, useful links and entertainment

Dokument D
GB-0600 Dokum D Anbaugeräte
PÖTTINGER Landtechnik GmbH
Industriegelände 1
A-4710 Grieskirchen
Tel. 07248 / 600 -0
Telefax 07248 / 600-2511
TMachine checked according to delivery note. All attached parts removed. All safety equipment, drive shaft and operating
devices at hand.
TOperation and maintenance of machine and/or implement according to operating instructions explained to the customer.
TTyres checked re. correct pressure.
TWheel nuts checked re. tightness.
TDrive shaft cut to correct lenght.
T*VYYLJ[WV^LY[HRLVɈZWLLKPUKPJH[LK
TFitting to tractor carried out: to three-point linkage
TTrial run carried out and no defects found.
TFunctions explained during trial run.
TPivoting in transporting and operating position explained.
TInformation given re. optional extras.
TAbsolute need to read the operating manual indicated.
Please check. X
According to the product liability please check the above mentioned items.
INSTRUCTIONS FOR
PRODUCT DELIVERY
GB
In order to prove that the machine and the operating manual have been properly delivered, a confirmation is necessary.
For this purpose please do the following:
- sign the document A and send it to the company Pöttinger or via the internet to www.poettinger.at
- document B stays with the specialist factory delivering the machine.
- document C stays with the customer.

- 4 -
0800-GB_INHALT_2441
TABLE OF CONTENTS GB
Attention!
Observe Safety
Hints in the
supplement!
Table of contents
WARNING SIGNS
Meaning of warning signs..........................................5
CE sign ......................................................................5
GENERAL SAFETY TIPS
Travelling with implement in tow ...............................6
Coupling and uncoupling the implement ..................6
Regulations for Use ...................................................6
Travelling on roads.....................................................6
Before starting work ..................................................6
Checking before operation........................................6
PERFORMANCE DESCRIPTION
Overview....................................................................7
Variants......................................................................7
TRACTOR REQUIREMENTS
Tractor........................................................................8
Ballast weight ............................................................8
Lifting gear (Three-point linkage)...............................8
Hydraulic positioning control on the lifting gear........8
Necessary hydraulic connections..............................9
Necessary power connections ..................................9
ATTACHING THE MACHINE
Machine attachment................................................10
Connecting the cardan shaft ...................................10
Set up electric connection.......................................11
Swather - Brake unit ...............................................11
Fold support wheel up.............................................11
Parking brake...........................................................11
Hydraulic connections – Variant: Standard .............12
Hydraulic connections – Variant: Power Control /
ISOBUS operation ...................................................13
DISMOUNTING THE MACHINE
Uncouple / Park the machine ..................................14
TRANSPORT
Changing from transport- to work-position.............15
Changing from work- to transport-position.............16
Decrease transport height .......................................16
Changing from working position to off-road working
position....................................................................17
Driving on public roads............................................18
POWER CONTROL - OPERATION
Control panel ...........................................................19
Power control initial operation.................................19
Button functions ......................................................20
WORK-menu ...........................................................20
Raking height menu.................................................20
Config-menu............................................................21
TEST-menu ..............................................................22
DATA-menu..............................................................22
Diagnostic functions................................................23
ISOBUS - TERMINAL
Operating structure – Swathr with ISO bus
solution ....................................................................25
Button indication .....................................................26
Diagnostic functions................................................29
Joystick - Configuration ..........................................30
Setting the Joystick .................................................30
USE
General guidelines for working with the machine....31
Working width adjustment.......................................32
Swath width adjustment..........................................32
Rotor running gear...................................................33
Setting the working height (raking height)...............33
WORKING ON SLOPES
Take care when turning on slopes! ..........................35
MAINTENANCE
Safety point .............................................................36
General maintenance hints......................................36
Cleaning of machine parts.......................................36
Parking in the ope....................................................36
Winter storage .........................................................36
Drive shafts..............................................................36
Hydraulic unit...........................................................36
Working on the hydraulic unit..................................37
Working on the Cardan shaft...................................37
Bolt connections......................................................37
Tyres ........................................................................37
Greasing ..................................................................37
Protective fittings!....................................................37
Rotor........................................................................38
Gear.........................................................................39
Hydraulic unit...........................................................39
Spring tines..............................................................39
Lubrication chart .....................................................41
Connecting the brake hoses ...................................42
Brake adjustment ....................................................42
Cleaning the line filters ...........................................42
HYDRAULIC BRAKE UNIT
Connecting the break line........................................43
Brake adjustment ....................................................43
TECHNICAL DATA
Technical Data .........................................................44
Position of Vehicle Identification Plate ....................45
Defined use of the Rotary Swather..........................45
SUPPLEMENT
Recommendations for work safety .........................48
Driveshaft.................................................................49
Lubricants ...............................................................51
Hydraulics plan........................................................53
Emergency information sticker................................54
Connection diagram ................................................55
Connection diagram ................................................56
Sensor settings........................................................57
Emergency menu.....................................................58

- 5 -
0900-GB WARNBILDZEICHEN_2441
GB
CE sign
The CE sign, which is affixed by the manufacturer, indicates outwardly that this machine conforms to the engineering
guideline regulations and the other relevant EU guidelines.
EU Declaration of Conformity (see Supplement).
By signing the EU Declaration of Conformity, the manufacturer declares that the machine being brought into service
complies with all relevant safety and health requirements.
Meaning of warning signs
No. Warning signs Meaning No. Warning signs Meaning
1
495.173
Caution!
Do not enter rotor areas while
driving motor is running
5Do not stand in the drive
shaft area.
2Turn engine off and remove
buttonbeforeanymaintenance
or repair work.
6Never reachinto the crushing
danger area as long as parts
may move.
3Before putting the machine
into operation, read the
operator`s manual and follow
the safety precautions.
7Do not touch any moving
machine parts. Wait until
all parts have come to a
full stop.
4Stay clear of swinging area of
implements.
WARNING SIGNS
16
5 7
2 3 6
1

- 6 -
0800_GB-AllgSicherheit_3842
GB
Travelling with implement in tow
The attached implement influences the travelling
characteristics of the towing vehicle.
• Danger of tipping exists when working on slopes.
• The driving must be adapted to the corresponding
terrain and ground conditions.
• The towing vehicle is to
be sufficiently equiped
with weights at thefront
or at the rear in order to
guarantee the steering
and braking capacity (a
minimum of 20% of the
vehicle'stareweight on
the front axle).
• Transporting people on the implement is not
permitted.
Coupling and uncoupling the implement
• Danger of injury exists when coupling the implement
to the tractor!
• When coupling, do not stand between tractor and
implement while tractor is reversing !
• No-one must enter the area between tractor and
implement unless both vehicles have been secured
against rolling with wheel chocks !
• Drive shaft connection or disconnection is only to
be undertaken when the motor has stopped.
Regulations for Use
Regulations for Use: See chapter „Technical Data“.
• The trailer‘s load limits (permitted axle load, support
load, total weight) maynot be exceeded.The relevant
details are located on the right side of the trailer.
• In addition, observe the power limits of the tractor
being used.
Travelling on roads
• Observe the road rules
GENERAL SAFETY TIPS
20%
Kg
Important!
General safety
hints for the use
of this implement!
Before starting work
a. Before commencing work, the operator must be aware
of all operating devices and functions.The learning
of these is too late after having already commenced
operation!
b. Before commencing any work check that implement
is safe for road travel and operation.
c. The danger of being crushed or cut exists in the Pick-
up, cutting unit, tailgate and upper extension areas.
d. Before driving the vehicle, the driver must ensure that
nobody will be endangered and that no obstructions
are present. If the tractor driver does not have a clear
view of the roadway immediately behind the implement,
he must be guided when reversing.
e. Observe the safety information fixed to implement.
An explanation of what the individual graphic warning
symbols mean can be found on page 5.
f. Observe also the tips in the respective chapters and
in the supplement to this operating manual.
Checking before operation
The following tips should make preparing the implement
for operation easier. Detailled information for individual
points can be found in the respective chapters in this
operating manual.
1. Check that all safety equipment (covers, casings, etc.)
is in good condition and fixed in the proper positions
of protection on the implement
2. Grease and oil the implement according to the
lubrication chart. Check the gearing for tightness and
the oil level.
3. Check that tyres have the correct air pressure.
4. Check that wheel nuts are sitting firmly.
5. Ensure the correct p.t.o.-r.p.m.
6. Make the electrical connections to the tractor and
check that they are correct. Take note of the tips in
the operating manual!
7. Carry out the following adaptions:
• Drawbar height
• Cardan shaft length
8. Secure the implement only with the equipment
provided.
9. Cut drive shaft tocorrect length and checkthat overload
safeguard is functioning (see Supplement)
10. Check the electronic unit function.
11. Connect hydraulic lines to tractor.
• Check hydraulic hoses for damage and wear.
• Ensure the correct connection.
12. All swivelling parts must be secured against dangerous
position changes.
13. Check parking brake and service brake functions.

0900-GB_ÜBERSICHT_2441
GB
- 7 -
PERFORMANCE DESCRIPTION
Overview
46
38
2
1
7
5
9
075-09-01
Descriptions:
(1) Rotary unit front right
(2) Rotary unit rear right
(3) Rear lighting unit
(4) Running gear
(5) Hoop guard (collapsible to reduce transport height)
Diag.: Top 1252
(6) Tine bearers (removable to reduce transport height)
(7) Feeler wheel “external”
(8) Drawbar
(9) Step sequence control (only for the standard variant)
Variants
Designation Description
Standard Operation via tractor hydraulics
Power Control Operation via power control
ISOBUS Operation via ISO bus control
Hydraulic rake height adjustment Rake height is adjusted at the push of a button using hydraulic motors with Power
Control or ISO bus control
Feeler wheel “internal” Additional rotary unit guide wheel
Brake unit Hydraulic or pneumatic

0900-GB_SCHLEPPER VORAUSSETZUNG_2441
GB
- 8 -
TRACTOR REQUIREMENTS
Tractor
To operate this machine the following tractor requirements are
necessary:
- Tractor power: from 52 kW / 70 hp
- Linkage: lower link cat. II
- Connections: see table “Necessary hydraulic and power
connections”
Ballast weight
The front of the tractor is to have sufficient ballast to guarantee braking
and steering abilities
At least 20% of the tractor’s tare weight on the front
axle!
Lifting gear (Three-point linkage)
- The tractor’s lifting gear (three-point linkage) must be designed for
the occurring load (see technical information).
- The lifting struts are to be set at the same length (4) using the relevant
adjusting equipment
(See the tractor manufacturer’s operator’s manual)
- If the lifting struts on the lower linkage can be fixed in various
positions, then select the back position. this will relieve the tractor’s
hydraulic unit.
- The limiting chain or lower link stabilisers (5) are to be set so that
the coupled implement CANNOT move sideways. (Safety measure
for transportation)
Hydraulic positioning control on the lifting gear
The lifting hydraulics are to be switched to positioning
control when:
- transporting
- coupling and uncoupling the machine
- the control has been switched off.
20%
Kg
371-08-16
371-08-16

0900-GB_SCHLEPPER VORAUSSETZUNG_2441
GB
TRACTOR REQUIREMENTS
- 9 -
Necessary hydraulic connections
Design Used for
Single action
hydraulic
connection
Double action
hydraulic
connection
Identification (on
the implement)
Standard Lifting/lowering rotary units X 1
Standard Working width and swath width X 2
Standard Left rotary unit working width X*) 3
Power Control / ISOBUS Terminal
Hydraulic connection “Advance” SN 16 red
Hydraulic connection “Return” SN 20 blue
Load sensing connection SN 6 *)
Hydraulic brake unit **) Hydraulic connection with hydraulic coupler according to ISO 5676
Air brake unit **) Red supply line
Yellow brake line
Necessary power connections
Design Used for Volt Power connection
Standard Lighting 12 VDC According to DIN-ISO 1724
Power Control / ISOBUS Control 12 VDC According to DIN-ISO 9680
*) not crucially necessary
**) Depends on which brake unit is fitted to the machine

- 10 -
1100-GB_Anbau_2441
GB
ATTACHING THE MACHINE
Safety
advice:
see Supplement
A1, points1-8.
Machine attachment
Hitching the machine to the lifting gear of the tractor.
- Link full floating axle to lower link
- secure coupling bolts (1) properly
- Secure with linch pin (3)
Connecting the cardan shaft
- Turn motor off and remove ignition key
- Clean and grease machine’s attachment profile and tractor’s p.t.o. shaft before attaching cardan shaft.
- Attach wide angle joint (4) to machine first. Then attach cardan shaft to tractor’s p.t.o. shaft
- To prevent protector cap on all shafts from turning, secure it with chain (5)
- Before operation, check lengths of drive shafts and
adapt if necessary (see chapter "Adaption of Drive
Shaft" in supplement B also).
Procedure for cutting to length
- Zur Längenanpassung Gelenkwellenhälften in kürzester
Betriebsstellung (L2) nebeneinander halten und
anzeichnen.
3
1
4
5
• Bring running frame into horizontal position
025-05-04
L2
Attention!
Attach and ope-
rate the swather
running frame
in a horizontal
position using the
tractor’s lifting
gear. Otherwise
the danger of
deforming the
spring tines exists
when lifting and
lowering the
rotor!

- 11 -
1100-GB_Anbau_2441
GB
ATTACHING THE MACHINE
Set up electric connection
Lighting
- Connect 7-channel plug to tractor
- Check that lighting is functional on machine
Operation: (for Power Control operation)
- Connect the 3-channel plug to the DIN 9680 socket
on the tractor
Operation: (for ISOBUS operation)
- Connect the 3-channel plug to the DIN 9680 socket
on the tractor
Fold support wheel up
- Swing jack stand up after attaching the machine (5b)
- Push jack stand foot down with your foot and then
swing up
- The pin locks automatically
Swather - Brake unit
Variant: Air brake unit
- connect yellow brake lines
- connect red brake lines
- recharge pressure tank
- brakes are now released
See also chapter “Air brake unit”
Variant: Hydraulic brake unit
- Connect brake line
Parking brake
- Release parking brake after attaching the machine
- Then turn handle (1) inward
Attention:
Jack stand will
swing up automa-
tically when dis-
engaged - Danger
of crushing!

- 12 -
1100-GB_Anbau_2441
GB
ATTACHING THE MACHINE
Safety
advice:
see Supplement
A1, points1-8.
Hydraulic connections – Variant: Standard
1
2
1
2
3
3
2
2
075-09-17
Hydraulikleitungen beim Traktor anschließen
Connect hydraulic lines to tractor
- Turn p.t.o. off before connecting
- Put lever (ST) on the control unit into the floatingposition
(0).
- Take care that snap-lock couplers are clean.
- Only connect hydraulic system to the tractor when
stopcock is closed (position A).
Lever position:
Pos.1: Operation with 2 control devices
- The working width for the front rotary units is
simultaneously increased or decreased.
- Pulling on the rope (S) will alter the swath width via
both rear rotary units
Pos. 2: Operation with 3 control devices
- The working width for the front rotary units left and
right is individually increased or decreased
- Theworking width ofthe right rotary unit is increased
or decreased using the second control device
Pulling on the rope (S) will alter the swath width via
both rear rotary units
- The working width of the left rotary unit is increased
or decreased using the third control device
Pos. 1 Pos. 2

- 13 -
1100-GB_Anbau_2441
GB
ATTACHING THE MACHINE
Hydraulic connections – Variant: Power Control / ISOBUS operation
Connect hydraulic lines to tractor
- Turn p.t.o. off before connecting
- Put lever (ST) on the control unit into the floatingposition
(0).
- Take care that snap-lock couplers are clean.
Single-action control unit
Should the tractor only have a single-action servo-valve,
then it is absolutely necessary to have an oil-return pipe
(T) fitted by a specialist.
- Connect pressure hose (1) to the single-action control
unit. Connect oil-return hose (2) to tractor’s oil-return
pipe
Double-action control unit
- Connect pressure line (1) and oil-return pipe (2).
(Pressure line is any line which goes to the pressure
filter on the machine)
LS Line (Optional extra)
- Connect load sensing line to LS connection on the
tractor.
- the tractor must be turned off for this
Note!
An unpressurized
oil-return must be
guaranteed on the
tractor to prevent
any possible oil
heating
TD 26/92/48
s
h
0
ST
The swather’s hydraulics must be adapted
to the tractor’s hydraulics. Adaptation
is carried out using the screw (7) on the
hydraulic valve block.
Tractor with constant-current pump
= open hydraulic system (standard system)
- Loosen the locking nut
- Unscrew screw (7) about 5 turns
- Retighten lock nut
Tractor with constant-pressure pump
= closed hydraulic system
(z.B.: John-Deere, CASE -MAXXUM, CASE - MAGNUM,
FORD SERIE 40 SLE)
- Turn screw (7) completely in
Tractor with load-sensing (LS)
- Turn screw (7) completely in

- 14 -
0800-GB Abbau_2441
GB
DISMOUNTING THE MACHINE
Uncouple / Park the machine
Danger!
Securely support
raised machine
before carrying
out any work
under on it -
Danger of injury
Only work on the
machine with the
drive and motor
turned off
Attention!
Park the machine
only on even firm,
ground – Stability!
The machine can be lowered both from the
working position and from the transport
position.
• Shut off the engine and remove the ignition key.
• Put lever (ST) on the control unit into the floatingposition
(0).
Variant: Power control / ISO bus
With the control panel switched on,
press “Transport position” button to
reduce any existing line pressure in
the machine’s hydraulics.
This makes connecting replacement
hydraulic lines easier.
• Close all stop valves(pos. A)
(only for machines without operating device)
• Disconnect hydraulic lines from tractor.
• Remove pull rope from tractor cabin.
- Place the electro-cable and hydraulic lines in hose
holder receptacle
• Swing jackstand down
- Disengage spring loaded bolt (B)
- Swing jackstand (5a) down and lock into place
• Disconnect cardan shaft (4)
• Firmly apply handbrake (1)
• Disconnect brake lines
Machines with air brakes
• Disconnect air hoses from tractor:
- disconnect red hose coupling first
- then yellow hose coupling
Machines with hydraulic brakes
• Disconnect hydraulic brake hose from rapid action
coupling on tractor
• Secure machine against rolling with wheel chocks
• Disconnect lower link
• Move tractor carefully away
3
1
4
5

GB
1000_GB-TRANSPORT_2441 - 15 -
TRANSPORT
Attention!
Changing from
working position
to transport
position is only to
be carried out on
even, firm ground.
Make sure that
swivel area is free
and that nobody
is standing in the
danger area.
Changing from transport- to work-position
Variant: Power Control / ISOBUS
• Switching on operating device
• Move servo-valve to (h) – enable oil flow
• Lower rotary units to off-road transport
position using key
• Swing rotary unitsinto working position using
key
• Set working width
- Set working width, see chapter “Operation”
Variant: Standard
• Open all stop valves (pos. E)
• Set servo-valve (ST) to raise briefly to release transport
safety device (T).
• Lower all rotary units using servo-valve (ST)
Tip: Leave the servo-valve (ST) on lower long enough
to allow the hydraulic cylinder to be fully extended.
Only this will guarantee optimum rotor ground
adaptation.
• Set working width
- Set working width, see chapter “Operation”
075-09-05

GB
TRANSPORT
1000_GB-TRANSPORT_2441 - 16 -
Variant: Power Control / ISOBUS
• Set all rotary units to minimum working width
• Raise rotary units to off-road transport
position using key
• Raise rotary units to transport position using
key
• Switch operating device off
Note! After switching operating device off, move
hydraulic servo-valve (ST) to 0 position (otherwise oil
heats up!)
Variant: Standard
• Retract rear rotary units completely (transport
height!)
• Retract front rotary units completely
• Raise all rotary units using servo-valve (ST)
Safety tip:
Transport safety device control!
Each rotary unit is secured with the
hook!
• Close all stop valves(pos. A)
Changing from work- to transport-position
Attention!
Changing from
working position
to transport
position is only
to be carried out
on even, firm
ground.
Make sure that
swivel area is
free and that
nobody is
standing in the
danger area.
075-09-07
Decrease transport height
1. Swing hoop guard back
Swinging hoop guard back (6) back should only be
carried out when necessary, e.g. to reduce implement’s
total height
• Swing hoop guard (6) inward per rotor and secure with
spring cotter pin (6a)
2. Remove tine arms
Removal of tine arms (1) should only be carried out
when necessary, e. g. to reduce implement's total
height.
• Pin 4 tine arms (1) per rotor to the retaining bar on the
running frame and secure with linch pin (1a)
Attention!
For safety reasons,
turn off drive
shaft and wait
for rotor to stop
completely.
Danger of injury
through spring-
loaded tines
when fitting and
removing tine
arms, therefore
handle with
caution
Transportbreite verringern
Um die max. zulässige Transportbreite von 3m nicht zu
überschreiten,ist die Arbeitshöhe / Kreisel aufdie niedrigste
Einstellung zu bringen
371-08-23
Achtung!
Auf max. Trans-
portbreite achten!
Arbeitshöhe der
Kreisel auf die
niedrigste Einstel-
lung bringen vor
dem Transport!

GB
TRANSPORT
1000_GB-TRANSPORT_2441 - 17 -
Variant: Power control / ISO bus
The step sequence for changing from working position to off-road position is realized automatically through the
control
The mechanical step sequence control is therefore not available!
Details of the setting possibilities:
- See chapter “Power control – CONFIG menu”
- See chapter “ISO bus – Terminal, Set menu)
Variant: Standard
Changing from working position to off-road working
position is carried out with a mechanical Step sequence
control.
Step sequence control: (mounted on the front right
rotor).
* For lifting:
Lifting the rear rotor begins path-offset *) to the front
rotor to enable the swath to be properly formed.
* For lowering:
Lowering the rear rotor begins path-offset *) to the
front rotor. This will not damage any possibly existing
swaths.
Setting possibilities:
The height of the front rotor is adjusted using the adjusting
screw (1) on the upper lift limit (oH).
Example: Screw adjusting screw (1) in -> the
front rotors are lifted higher in the off-road
position. (Base setting (GS): 360mm)
The path-offset of the rear rotor is adjusted using the
adjusting screw (2) on the lower lift (uH).
Example: Screw adjusting screw (2) in -> the
rear rotors are lifted sooner to the off-road
position. (Base setting (GS): 295mm)
Control rope (SZ)
The control rope (SZ) prevents a change from working
position or off-road position to transport position when
front right rotor is extended.
Be aware! Incorrectly set control rope
tension influences the step sequence control
function.
Changing from working position to off-road working position
Attention!
Changing from
working position
to transport
position is only
to be carried out
on even, firm
ground.
Make sure that
swivel area is
free and that
nobody is
standing in the
danger area.
075-09-10
oH 1
uH 2
SZ
SZ 3
Attention!
If the lift limit
setting is altered,
then the other lift
limit and control
rope tension is to
be re-set also.
*) The path depends upon the lift limit setting.

GB
TRANSPORT
1000_GB-TRANSPORT_2441 - 18 -
Only transport the machine in the transport position!
Driving on public roads
• Observe the official regulations of your country.
• Travelling on open roads may only be carried out as
described in chapter "Transport position".
• Protection devices must be in proper condition.
• Before travelling bring all swivelling parts into their
correct positions and secure against dangerous
changes to position.
• Check that lighting functions before travelling.
Hydraulic lower link
• Fix the hydraulic lower
link (U) in such a way
thatthe machine cannot
swing out sideways.
Danger!
Danger of injury from protruding machine
parts!
- Fitguardstrip (1) tothe outward protruding
spring tines
Attention!
Always close stop
valves during
road transport
otherwise
danger exists
to other road
users through
unintentional
hydraulic control
operation

- 19 -
0800_GB-Power-Control_2441
GB
POWER CONTROL - OPERATION
Control panel
Display indicator:
• WORK
• CONFIG
TEST (sensor test)
- DATA (software versions, operating hours, Hectare
counter)
Description of the buttons:
1 Raise all rotary units to transport position
2 Lower all rotary units to the off-road transport
position
3 Select - rotary unit front left
4 Select - rotary unit rear left
5 Select - rotary unit front right
6 Select - rotary unit front right
7 Raise selected rotary units from working position
to off-road position
8 Lower selected rotary units from off-road position
to working position
9 Special menu / OK
10 Display of stored values / working width and
working height
11 Load working height (press SHORT button).
Save current working height (press LONG button
-> 5 secs. or until beep)
12 Raking height menu
13 Menu navigation
14 Menu navigation
15 Load working height (press SHORT button).
Save current working height (press LONG button
-> 5 secs. or until beep)
17 STOP
18+19 In the navigation: Alter values (-) (+)
In WORK menu: Alter working width of selected
rotary units
Inworking height adjustment:Alter working height
(raking height) of selected rotary units
20 ESC – return to previous menu (press SHORT
button)
Display
When the machine is turned on, the machine’s current
status is displayed on the work screen
Note!
Always store
control panel in a
weather-resistant
location.
Symbol description:
1 Activated rotary units
2 Current hectare count
3 Current working width
4 Minimum swath width display
3
2
1
1
246 8
35 7
911 12
13 14
17 18
15
19 20
10
4
Power control initial operation
Switching control device ON and OFF
Switching on
- Briefly press key
Switching off
- Press key for 3 seconds
Note!
After switching
off the control
panel move the
hydraulic servo-
valve (ST) to
the 0 position to
prevent possible
oil overheating!
Note!
Standby power
(400mA) also
flows to a
switched off
control panel.
Disconnect after
operation to save
the battery.

- 20 -
0800_GB-Power-Control_2441
GB
POWER CONTROL - OPERATION
Button functions
Selection buttons for “Rotary units”
• These buttons have a selection function
- By pressing the button once the relevant rotary unit
is preselected or re-selected
• The swivelling function will then be carried out by
pressing the buttons
- “Raise selected rotary units from
working position to off-road position”
or
- “Lower selected rotary units from off-
road position to working position”
• To adjust the working width and working height the
relative rotary units are also selected with these
buttons
Take note!
When the
"STOP"button
is pressed then
all functions are
stopped
Buttons to start a swivelling function
- The buttons are tentative, that means the swivelling
function takes place only as long as the button remains
pushed
• By pressing this button all rotary units are
raised to the transport position
- For this all rotary units must be in the
off-road position
• By pressing this button all rotary units are
lowered to the off-road position
WORK-menu
The operating device starts after switching on using the WORK menu. With that the machine’s current function stand
are displayed.
a
bc
Meanings of Indicators:
aDisplay selected rotary units
(The selected rotary units are coloured black)
bDisplay current area yield in hectares per
hour
cDisplay the current working width
dDisplay MIN = minimum rear swath width
d
Starting from the work menu, press the
“Rake height menu” button.
Note!
Automatic rake
height setting
using Power
control only
functions when
the optional
equipment
necessary for it is
on the machine!
Raking height menu
Menu function:
Set raking height of rotary units, save and set at zero
level.
- Select rotary units
- Set raking heights with the +/- button
- Press “Menu” button for 5 secs. Current raking
height is set at zero level
- “I/O” button – back to previous menu
- Load working height (press SHORT button).
Save currentworking height (pressLONG button
-> 5 secs. or until beep)
Note!
The menu can be
exited at any
time by pressing
the “I/O” button
