AQUA 380 BWS

PR-2366

This product manual contains important information about the safe installation and use of this projector.

Pleaseread and followthese instructions carefullyandkeepthismanualin a safeplaceforfuturereference.

PR LIGHTING LTD.

http://www.pr-lighting.com

INDEX

SAFETYANDWARNINGS…………………………………………………………………………………………

INSTRUCTIONS……………………………………………………………………………………………………

●CLEANINGANDMAINTENANCE………………………………………………………………………………

●LUBRICATION……………………………………………………………………………………………………

●TROUBLESHOOTING……………………………………………………………………………………………

APPEARANCE………………………………………………………………………………………………………

INSTALLATION ……………………………………………………………………………………………………

●RIGGING…………………………………………………………………………………………………………

●POWERCONNECTIONS………………………………………………………………………………………

●DMXCONTROLCONNECTIONS………………………………………………………………………………

●DMXTERMINATOR……………………………………………………………………………………………

●INSTALLATION/REPLACEMENTOFALAMP…………………………………………………………………

SETUPANDCONFIGURATION……………………………………………………………………………………

●FRONTPANELOPERATION……………………………………………………………………………………

●DMXSTARTADDRESS…………………………………………………………………………………………

●DMXWIRELESSCONTROL……………………………………………………………………………………

●STAND-ALONEMODE……………………………………………………………………………………………

●MASTER/SLAVEMODE …………………………………………………………………………………………

OPERATIONMENU ………………………………………………………………………………………………

DMXPROTOCOL …………………………………………………………………………………………………

ERRORINFORMATION …………………………………………………………………………………………

TECHNICALDATA…………………………………………………………………………………………………

10..

CIRCUITDIAGRAM ………………………………………………………………………………………………

11.

COMPONENTORDERCODES……………………………………………………………………………………

ACCESSORIES

The following items are suppliedwith the projector andplease check:

Name

Quantity

Unit

Remark

Gclamp

Pcs

XLRconnectors

Set

Maleandfemale

Safetycord

User manual

Ω clamp

Pcs

Optional

Please note that as part of our ongoing commitment to continuous product development, specifications are subject to change

without notice. Whilsteverycareistakeninthepreparationof the manualwereserve therightto changespecificationsinthe

course of product improvement. The publishers cannot be held responsible for the accuracy of the information herein, or any

consequencearisingfromthem.

Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / orthe unit are

in good condition before installation anduse. Should there be any damage caused by transportation, consult your dealerand

donotusethe unit.Any damagecausedby improperusewill notbeassumedbythemanufacturerand/ordealer.

Anyfuturetechnicalchangesarenotsubjecttofurthernotice.

Note: Forthe products made by Guangzhou PR lighting Ltd, the warranty for the whole product isone yearstarting from

thedelivery datebutthelightsource isnotwithinthewarranty.

1. SAFETYANDWARNINGS

NOTE

Before a projector’s installation, power-on, operation and maintenance, please carefully read

the safety information hereinafter!

Thefollowingsafetysignsareusedintheusermanual.

Warning

User

Manual

Electrical

shock

Goggles

Protective

Gloves

Flames

High

Temperature

● When unpacking , checkif there istransportation damage before using the projector. Should there be any damage

causedby transportation,consultyourdealeranddo not useit.

●The manufacture is not responsible for loss caused bythe user not following the manual or changing the projector

ashe/shelikes

●Please be noted that thedamage caused by changingthe projector at will is not warranted.

● Do not hesitate to contact the dealer or the manufacturer if any questionsoradvice.

●Thelamp shouldbereplaced ifdamagedordeformedby heat.

● Theprojectoris forindoorandoutdooruse,IP66.

● Itcanbe usedinhumidanddustyareas.And itcancontact waterandother non-corrosiveliquids.

●The projector should be kept away from high temperature, fire, electrical surge, vibration and strong light while

beingoperated

●The projector is only intended for installation, operation and maintenance by qualified personnel. And the

operationmuststrictlyfollowtheproceduresinthemanual

●No repairablepartsintheprojectoranddo notopencoversformaintenancebyyourself.

●Don’t look straightly into the light sources especially for epileptics, otherwise eyes willbeburned.

●Do not connectthis device to any type ofdimmerpack

●If there are visible damages onthe lamp, lens and protective cover for the screen, i.e., to the extent whichaffects

itsperformancelikecrackingordeformation,pleasestopusingitandcontactthemanufacturefortheir

replacement withoriginalparts,otherwise itsperformancewillbecompromised

●The installing location of a projector shouldn’t make it stared in less than 4 meters for too long.

●Before operation, please confirm that all covers(housing) are on and screws tightened. It’s forbidden to use a

projectorwhilecovers(housing)areoff

●Keepthelamp cleananddo nottouch itwithbarehands.

●Whileoperatingit, wearprotectiveitemslikeeyegoggles,glovesandetc...

●Anyelectricalconnectionmustbecarriedoutbyaqualifiedperson.

●Before installation,pleaseconfirmthe voltagesupplied matcheswhatisrequired forthe projector

●Eachprojector mustbeproperlyearthed and installedasper relatedelectricalstandards.

●Do notuse power cord withitsinsulator damagedandconnectthepowercord withother cables.

●If the projector is not used or under cleaning,, please hold the plug and unplugit. Do not unplug it forcefully

orbypullingthepower cable.

●Allpower cordsmustconform torelatedsafety andregulations

●Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other

electrical parts’ life will be shortened .

●There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety

cordsupplied throughthesafetycord holesforsafetysupport.

●Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from

power mains.

●After running under normal ambient temperatures, the temperature of the housing of the projector including

thesurfaceofthe heat sinkwillreach80℃atmaximum.

●While the lamp is stricken for the first time, there will be smoke and strange smell. It’s normal and does not

mean theprojector has somedefects.

● Don’t touch the metallic housing of a runningprojectortoavoidbeingburned.

●Do notmount theprojectordirectlyoninflammablesurface.

●Do not project the beam straightly on combustible items and the minimum distance between the projector

andilluminateditemsis18m.

●A projector should be installed with good ventilation and the minimum distance between the projector and

wallsis50cm.Atthesametime,pleaseensure thefansandairinletsandoutletsare workable.

●Do not let front lens of a projector exposed to sunlight or any strong light sources at any angle, otherwise a

fireinsidecanbecausedbecauseoffocused lightinsidetheprojector.

2. INSTRUCTIONS

●CLEANINGANDMAINTENANCE

If a projector can’t start. Please check if the fuse is blown up. If it does, replace it with a new fuse with same ratings. And the

projector has over-temperature protective device. If the temperature is too high, the protective device will be triggered to shut the

projector off. When it happens, please check if the fans run normally or fan shield is blocked by dust. After the issue is solved,

restart theprojector.

The accumulationofoil, smoke and dust on the lens will compromise the light output. Cleaning a projector is verynecessary to

ensure a reliable use of it. Cooling fans need to be cleaned every15days. Internal lens, reflector and hot mirror need to be cleaned

periodicallyto optimize lightoutput.

Cleaningfrequencyis to bedecided by operations and its environment. Use soft cloth and normal detergent for glass for cleaning

work. It’s advised external optical system be cleaned every 20days and internal optical systems every 30/60days. Keep lens clean

and do nottouchoptical partswith bare hands.

●Beforeanymaintenanceandcleaning,pleaseensuretheprojectisoffthepower

●Onlyqualifiedpersonis allowed todo maintenance

●Duringmaintenance and before maintenance, theprojector mustbeoff power.

●To avoid internal damage, sun light or other light mustn’t penetrate into the projector via front lens

whetheritrunsornot

●Do notuse alcoholorother organicsolventtocleanthe housingto avoiddamage.

●Do notuseanysolvent withchemical elementsto cleancolorfiltersorhotmirror.

●LUBRICATION

To ensure smooth movement of gobos and focus lens, it’s advised rotators’ bearings and 2 sliding bars for focus lens be lubricated

every 2 months. Highquality and high temperature lubricant/greaseisadvised..

●TROUBLESHOOTING

PROBLEM

ACTION

The projector doesn’t switch on

Check thefuseonthepower socket.

Checkthelamp.

Thelampison but the projector doesn’t respond

to the controller

Makesurethatthe fixture’s start address is right

Replaceorrepair theXLRsignal cable.

Theprojector functionsintermittently

Makesurethefanisworkingwellorfansandtheirshieldsarenotblocked

Beam appears dim, Lowinbrightness

Makesurethe lamp is within itslifespan

Removedustor greasefromthelenses.

Theprojectimageappearstohavea halo

Carefullycleanthelamp,opticallensesandothercomponents.

HeavilyDefectiveBeam

Check if lensare in goodcondition(notcracked)

Cleandustorgreaseonthelens.

3. APPEARANCE

4. INSTALLATION

●RIGGING

Head

Clamp

Please run the safety cord

through its hole for safety

Arm

Base

Safetycord

Take 2 clamps and 1 safety cords out from the package and mount 2 clamps on the underside of fixture with 4 retainers attached to

each clamp. Hang the fixture on the structure and fasten the screws attached to each clamp. (See the WARNING on the underside of

the base as shown above) Always ensure that the projector is firmly anchored to avoid vibration and slipping whilst functioning.

Always ensure that the structure that youare goingto mount the projector issecure and is strongenough to supportthe weight of the

fixture.

WARNING:

●TheprojectorMUSTbeliftedorcarriedbytheHANDLESinsteadofclamps.

●.For safety the safety cord should afford 10 times the Projector’s weight.

●POWERCONNECTION

Connectthepowercordasfollows:

L(live)=brown

E(earth)=yellow/green

N(neutral)=blue

Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each

projectorbe connected withpower separatelyso that they maybeindividuallyswitchedonandoff.

Note: If projectors are connected in series, please connect POWERIN port of the 1st projector with the Power Mains, then

connectitsPOWEROUTwithPOWER INof the2nd projector,andsoontillall fixturesareconnected. Ifthevoltagesupplied

is 200V-240V, the maximum projectors connected is 8pcs, if it is 100V-120V, the maximum is 4pcs. The diameter of the cores

ofthewiresforthePowerin/outcables mustbeequalorbiggerthan2.5mm2 .

●The earth wire(yellow/green) must be connected to the ground. And electrical connection must be in

accordancewiththestandardsconcerned.

●Ifanyquestionsaboutthe electrical installation, donotcontinuebutconsult aqualifiedelectrician.

●DMXCONTROLCONNECTION

Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with

each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the

projector)or5pinXLRplugsand sockets.TheXLR'sareconnectedasshowninthefigureabove.

Note: care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. XLR plugs and sockets

mustn’t be connected in any way other than mentioned in the above figure. The projector accepts digital control signals in protocol

DMX512(1990).

Connect the controller’s DMX output to the first fixture’s DMX input, and connect the first fixture’s DMX output to the second

fixture’s DMX input and connect the rest fixtures in the same way. Eventually connect the last fixture’s DMX output to a DMX

terminatorasshowninthefigurebelow.

●DMXTERMINATOR

In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents

electrical noisefromdisturbingandcorruptingtheDMXcontrolsignals.

The DMX terminator is simply an XLR connector with a 120(ohm) resistor connected across pins 2 and 3, whichis then plugged

intotheoutputsocketonthelastprojector inthechain.Theconnectionsareillustrated below.

● INSTALLATION/REPLACEMENTOFALAMP

Locktheyokebefore fitting/replacingthelamp.

Just as Shown by Figure 1, after Opening the airflow cover as shown by loosening 4 tightening screws, the structure like figure 2 will

beseen.

Just as shown by the figure 2, loosenthe 4 tightening screws of the bob-weightblock, take it down and the structure like figure 3 will

beseen.

Justas shownbyfigure 3,loosenthe8 tighteningscrewsoflampcover,openthecoverand structurelikethefigure4 willbe seen.

Unplug thelamp with power wires, hold the bottom of thelamp by hand and move it asdirected by thearrowusing force to make the

other end of the lamp off the holder. At last take the lamp out ofthe bottom of the head. Before placing a newlamp inside , plug the

lamp withpowerwirestightly. Lamp placementand itsremovalare inoppositeorders

Note: Don’t touch the internal surface of the reflector and the burner of the lamp with bare hands so as not to impair the beam output.

While lamp’s installation, do not damage the metal wire around the burner.

Putbackthelampcover,bob-weightblock,airflowcover andtightenallscrews.

Important: Pleaseread "Instructions" enclosedwiththelampcarefullybefore itsuse.

Controller

Output Input TerminatorOutput Input

120

DMX TERMINATOR

CONNECTION

Connect a 120 (OHM) resistor

across pins 2 and 3 in an XLR plug

and insert into the DMX out socket

on the last unit in the chain. PIN 3

PIN 2

颗导风盖

锁紧螺丝

颗配重

锁紧螺丝

颗散热器

锁紧螺丝灯泡

图图

Lamp

8 Screws for heat

sink

4 Screws for

Bob-weightblock

4 Screws for

fancover

Figure 1

Figure 2

Figure3

Figure 4

5. SETUPANDCONFIGURATION

●FRONTPANELOPERATION

ProjectorconfigurationcanbesetconvenientlyviapushbuttonandLCDdisplay.

Launch the projector and press button ENTER for more than 3 secondsto unlock the panel, the LCD will show the function menu of

the projector, each main menu has its submenus and each submenu has a specific function. For details, please see the

“OPERATION MENU” section.

Pressbutton UP or DOWN ifyouwanttobrowsethroughthevariousSetupOptions.

Pressbutton ENTER to saveyour settingsorenterthesubmenu.

Pressbutton UP or DOWN to changevalues(plusorminus)

Pressbutton FUNC,it willreturnto the upper menu.Ifbutton FUNC notpressed, thedefault willshowdisplaystatusautomatically.

●DMX STARTADDRESS

Eachprojector must be givena DMX start address so that the correct projector responds to the correct controlsignals. This DMX start

address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the

controller. The projector has 3 DMXmodes. There are short mode ,standard mode and extended mode. For example standard mode

has 27 channels, so set the No. 1 projector’s address 001, No. 2 projector’s address 028, No. 3 projector’s address 055, No. 4

projector’s address082,andsoon.

Launch theprojector. Pressbutton ENTER more than3secondsto unlockpanel.

Pressbutton ENTER to displayDMXaddress;

Pressbutton UP and DOWN,youcanset theaddress;

Pressbutton ENTER to confirm;afterpoweredon next time,thedefaultwillbe lastvaluesaved

Pressbutton FUNC,it willreturntotheuppermenu

●DMXWIRELESSCONTROL

Theprojector haswirelesscontrolfunction with wirelessreceivermoduleandantenna for remotecontrol.

Thesetupofitisbelow:

1. Enter into the projector’s menu. Select the menu “Config Settigns” via the bottoms of UP and DOWN

2. Select DMX control Mode---- Wireless First (Note: Do not select XLR ONLY),then wireless indication in the

front panel willbe on,meaning wireless controlfunction is activated.

Only afterthe projector islinked with a transmitter, canit receive wireless signal sent bythe transmitter. If unlinking it, Press

“Enter” forthemenuofUnlinkWireless underthe upperlevel menuofConfigSettigns.

●STAND-ALONEMODE

Operate the projector without connecting with a controller, enable the master mode through the operation panel, the

projector will run in Stand-Alone mode automatically.

DMX address can be set at any number within 512.

●MASTER/SLAVEMODE

Many projectors can run synchronously in the Master/Slave mode by linking them with each other. First,

connect the first fixture’s DMX output to the second fixture’s DMX input using XLR-XLR control cable and then connect the second

fixture’s DMX output to the third fixture’s DMX input, and so on until all projector are connected in this way. Eventually connect the

last fixture’s DMX output to a DMX terminator. Set 1st projector as the master and others are Slaves.

Start Addresses of all Slaves are 001; Operation mode of the Master can be set any mode for a Master’ and Slaves’ operation modecan

besetaccordingly.

AfterPoweredon,thegroup willruninMaster/SlaveMode

6. OPERATIONMENU

1st

LEVEL

2ndLEVEL

3rdLEVEL

4thLEVEL

5thLEVEL

Address

DMXAddress

1-490（Short）

1-486（Standard）

1-481（Extended）

IP Address

DefaultIPAddress

2.X.X.X/10.X.X.X

CustomIP Address

X.X.X.X

SubnetMask

X.X.X.X

ArtNetUniverse

0-255

sACNUniverse

1-63999

Reset

Total Reset

ReallyReset?

ConfirmorCancel

Pan&TiltReset

ReallyReset?

ConfirmorCancel

ColourSystemReset

ReallyReset?

ConfirmorCancel

Master Slave Slave

Output Input TerminatorOutput Input

GoboReset

ReallyReset?

ConfirmorCancel

Dimmer/Strobereset

ReallyReset?

ConfirmorCancel

Zo.Fo.Fr.Pr.Reset

ReallyReset?

ConfirmorCancel

Config

Settings

DMXChannelMode

Short23CH

Standard 27CH

Extended32CH

ViewSelected Mode

Ch.01Strobe

Ch.02Dimmer

….

Ch XXControlFunction

Lamp Control

OFF/ ON

On ByPowerOn

OFF/ ON

ControlByDMX

OFF/ ON

ECOPower

OFF/ ON

Signal Select

(Onlyforthe

projectorswith

wirelessreceiver

assembly)

XLROnly

XLRFirst

WirelessOnly

WirelessFirst

WirelessIn/XLR Out

ArtNetOnly

ArtNetIn/XLROut

sCANOnly

sCANIn/XLROut

LossofDMX

Normaltimeout

Hold LastValue

DisplayConfig

DisplayMode

OffAfterDelay

OnAlways

DisplayInvert

InvertOFF

InvertON

InvertAuto

LanguageSetting

English\Chinese

TemperatureUnit

CelsiusDegree

FahrenheitDegree

Un-LinkWireless

(Onlyforthe

projectorswith

wirelessreceiver

assembly)

ReallyUn-Link?

ConfirmorCancel

Factorydefaults

RestoreDefaults?

ConfirmorCancel

Option

Settings

Pan/TiltSettings

PanDMXInvert

OFF/ ON

TiltDMX Invert

OFF/ ON

PanTiltSwap

OFF/ ON

XYFeedback

OFF/ON

Pan/Tiltmode

Speed/Time

Note:"SpeedMode"meansPan

andTiltwillmovefromPointAto

PointBattheir respective

maximumspeeds."TimeMode"

meansbothPanandTilt will arrive

atdesignatedpointat thesametime.

It's advised TimeModebeused if

theprojectorrunscirclesorin

obliquelines.

InvertSettings

DimmerInvert

OFF/ ON

ZoomInvert

OFF/ ON

CYMInvert

OFF/ ON

ViewDMXValues

Channel Value

Strobe XXX

Dimmer XXX

DimmerFine XXX

CYMMacro XXX

Cyan XXX

Yellow XXX

Magenta XXX

ColourWheel XXX

ColourWheelFine XXX

Fixed GoboWheel XXX

Rot.GoboWheel1 XXX

Rot.Gobo1 Rotation XXX

Rot.Gobo1 RotationF. XXX

Information

EffectWheel XXX

EffectWheelRotation XXX

Prism XXX

PrismRotation XXX

Frost XXX

AnimationWheel XXX

Focus XXX

Zoom XXX

Pan XXX

PanFine XXX

Tilt XXX

TiltFine XXX

Pan/TiltSpeed&Time XXX

Power/SpecialFun. XXX

Lamp Hours

LampHours=××××h

ResetLamp Hours

Total Hours

Total Hours=××××h

Temperature

DisplayBoard=×××C

Panboard=×××C

Tiltboard=×××C

DriverBoard1=×××C

DriverBoard2=×××C

HeadSensor=×××C

SoftwareVersion

PCB Sys Boot

DisplayBoard xxx xxx

Pan board xxx xxx

Tiltboard xxx xxx

DriverBoard1 xxx xxx

DriverBoard2 xxx xxx

ElectronicSN

XXXXXX

RDMDeviceLabel

AQUA380BWS

ANSIE1.20RDM

FanStatus

Fan Speed Status

LampFan xxx on/off

ColorFan xxx on/off

HeadFan xxx on/off

AccelerationSensor

X Axis:XXX

YAxis: XXX

ZAxis:XXX

Position:XXX XXX

Lamp Fan Errors

Fan ErrorCount

Lamp Fan XXX

ColorFan XXX

Head Fan XXX

Service

ManualEffectControl

Strobe XXX

Dimmer XXX

DimmerFine XXX

CYMMacro XXX

Cyan XXX

CyanFine XXX

Yellow XXX

YellowFine XXX

Magenta XXX

MagentaFine XXX

ColourWheel XXX

Colour WheelFine XXX

Fixed GoboWheel XXX

Rot.GoboWheel1 XXX

Rot.Gobo1 Rotation XXX

Rot.Gobo1 RotationF. XXX

EffectWheel XXX

EffectWheelRotation XXX

Prism XXX

PrismRotation XXX

Frost XXX

AnimationWheel XXX

Focus XXX

FocusFine XXX

Zoom XXX

ZoomFine XXX

Pan XXX

PanFine XXX

Tilt XXX

TiltFine XXX

Pan&TiltSpeed XXX

FactoryMode

XXX

Operation

Mode

DMXMode

Change OperationMode?

ConfirmorCancel

MasterMode

PresetMemory

ChangeOperationMode?

ConfirmorCancel

UserMemory1

ChangeOperationMode?

ConfirmorCancel

UserMemory2

ChangeOperationMode?

ConfirmorCancel

Stand-AloneMode

PresetMemory

ChangeOperationMode?

ConfirmorCancel

UserMemory1

ChangeOperationMode?

ConfirmorCancel

UserMemory2

ChangeOperationMode?

ConfirmorCancel

StaticScene

ChangeOperationMode?

ConfirmorCancel

EditUserMemory

EditUserMemory1

EditUserMemory2

（1~200Scenes）

SceneXX

（1~200Scenes）

Strobe XXX

Dimmer XXX

DimmerFine XXX

CYMMacro XXX

Cyan XXX

CyanFine XXX

Yellow XXX

YellowFine XXX

Magenta XXX

MagentaFine XXX

ColourWheel XXX

ColourWheelFine XXX

Fixed GoboWheel XXX

Rot.GoboWheel1 XXX

Rot.Gobo1 Rotation XXX

Rot.Gobo1 RotationF. XXX

EffectWheel XXX

EffectWheelRotation XXX

Prism XXX

PrismRotation XXX

Frost XXX

AnimationWheel XXX

Focus XXX

FocusFine XXX

Zoom XXX

ZoomFine XXX

Pan XXX

PanFine XXX

Tilt XXX

TiltFine XXX

User

Memories

Pan&TiltSpeed XXX

FadeTime XXX

Holdtime XXX

DelayTime XXX

Delayunit (msec/s/m)

LinktoStep XXX

EditStaticScene

Strobe XXX

Dimmer XXX

DimmerFine XXX

CYMMacro XXX

Cyan XXX

CyanFine XXX

Yellow XXX

YellowFine XXX

Magenta XXX

MagentaFine XXX

ColourWheel XXX

ColourWheelFine XXX

Fixed GoboWheel XXX

Rot.GoboWheel1 XXX

Rot.Gobo1 Rotation XXX

Rot.Gobo1 RotationF. XXX

EffectWheel XXX

EffectWheelRotation XXX

Prism XXX

PrismRotation XXX

Frost XXX

AnimationWheel XXX

Focus XXX

FocusFine XXX

Zoom XXX

ZoomFine XXX

Pan XXX

PanFine XXX

Tilt XXX

TiltFine XXX

Pan&TiltSpeed XXX

Init UserMemory

ResetUserMemory1

ResetUserMemory?

ConfirmorCancel

ResetUserMemory2

ResetUserMemory?

ConfirmorCancel

ResetStaticScene

ResetStaticScene?

ConfirmorCancel

7. DMXPROTOCOL

Short

mode

Standard

mode

Extended

Mode

FUNCTION

DMX

DESCRIPTION

Strobe

000-010

011-025

Open

026-225

Strobespeedfromslowtofast

226-246

Randomstrobefromslowtofast

247-255

Open

Dimmer

000-010

011-255

Lineardimming（0-100%）

DimmerFine

000-255

Dimmerin16bit

CMYMacro

000-016

Open

017-035

Yellow+Magenta=Red

036-054

Yellow

055-073

Yellow+Cyan=Green

074-092

Cyan

093-111

Cyan+Magenta=Purple

112-128

Magenta

129-255

CMYcolormixingfrom slowto fast

Cyan

000-255

LinearCyan(0-100%)

CyanFine

000-255

Cyanin16bitControl

Yellow

000-255

LinearYellow(0-100%)

YellowFine

000-255

Yellowin16bit Control

Magenta

000-255

LinearMagenta(0-100%)

Magenta Fine

000-255

Magenta in16 bit Control

ColorWheel

000-063

Indexing(0-360degrees)

064-067

Open

068-071

Color1(DarkRed)

072-075

Color2(DarkBlue)

076-079

Color3(Yellow)

080-083

Color4(Green)

084-087

Color5(Plum)

088-091

Color6(SkyBlue)

092-095

Color7(Red)

096-099

Color8(DarkGreen)

100-103

Color9(DarkYellow)

104-107

Color10(Blue)

108-111

Color11(Orange)

112-115

Color12(CTO)

116-119

Color13(UV)

120-127

Open

128-191

Rotation,Clockwisefromslowtofast

192-255

Rotation,Anti-Clockwisefromfast toslow

Color wheel Fine

000-255

ColorWheelin16Bit

FixedGobo

000-006

Hole1(Open)

007-017

Hole2

018-028

Hole3

029-039

Gobo1

040-050

Gobo2

051-061

Gobo3

062-072

Gobo4

073-083

Gobo5

084-094

Gobo6

095-105

Gobo7

106-116

Gobo8

Wheel

117-127

Gobo9

128-142

Clockwiserotation fromslowtofast

143-156

AntiClockwiserotation fromslowto fast

157-166

Hole2 shakeeffect fromfasttoslow

167-174

Hole3 shakeeffect fromfasttoslow

175-183

Gobo1shake effect fromfasttoslow

184-192

Gobo 2shakeeffect fromfasttoslow

193-201

Gobo3shake effect fromfasttoslow

202-210

Gobo 4shakeeffect fromfasttoslow

211-219

Gobo5shakeeffect fromfasttoslow

220-228

Gobo 6shakeeffect fromfasttoslow

229-237

Gobo7shakeeffect fromfasttoslow

238-246

Gobo 8shakeeffect fromfasttoslow

247-255

Gobo 9shakeeffect fromfasttoslow

RotatingGobo

Wheel

000-007

Open

008-017

Gobo 1

018-027

Gobo 2

028-037

Gobo 3

038-047

Gobo 4

048-057

Gobo 5

058-067

Gobo 6

068-077

Gobo 7

078-087

Gobo 8

088-097

Gobo 9

098-107

Gobo 10

108-117

Gobo 11

118-127

Gobo 12

128-143

ForwardRotation FromslowtoFast

144-159

ReverseRotation FromslowtoFast

160-167

Shake of Gobo1fromslowto fast

168-175

Shake of Gobo2fromslowto fast

176-183

Shake of Gobo3fromslowto fast

184-191

Shake of Gobo4fromslowto fast

192-199

Shake of Gobo5fromslowto fast

200-207

Shake of Gobo6fromslowto fast

208-215

Shake of Gobo7fromslowto fast

216-223

Shake of Gobo8fromslowto fast

224-231

Shake ofGobo 9fromslowtofast

232-239

Shake of Gobo10fromslowtofast

240-247

Shake of Gobo11fromslow tofast

248-255

Shake of Gobo12fromslowtofast

Gobo Rotation

000-128

Gobo Indexing(0~360degrees)

129-188

Rotation （ClockwiseFromslowto Fast）

189-195

Stop

196-255

Rotation （Anti-ClockwiseFromslowtoFast）

GoboRotation

Fine

000-255

Gobo Rotation in16Bit

EffectWheel

000-063

064-127

Linearprism

128-255

Circularprism

EffectWheel

Rotation

000-127

Circularprismindexing

128

Stop rotating

129-191

Clockwiserotation fromslowtofast

192

Stop rotating

193-255

Anti-Clockwiserotationfromslowto fast

Prism

000-016

Open

017-255

Prism

Prism Rotation

000-127

Prism Indexing

128

Stop

129-191

Rotation(Clockwise fromslowtofast)

192

Stop

193-255

Rotation(Anti-Clockwisefromslowtofast)

Frost

000-255

LinearFrost

AnimationWheel

000-011

012-020

WheelIn

021-255

Wheelmovesbackandforthfromslowtofast

Focus

000-255

Linearfrost

FocusFine

000-255

Focusin16bitprecision

Zoom

000-255

Linearfrost

Zoom Fine

000-255

Zoomin16bitprecision

Pan

000-255

Pan(0°~540°)

Pan Fine

000-255

Panin16bitprecision

Tilt

000-255

Tilt(0°~270°)

Tilt Fine

000-255

Tilt in16bitprecision

Pan &Tilt Speeds

000-255

Pan &Tilt Speed fromFastto Slow

Control

000-019

Reserved

Thefollowing functionswillbeactivatedaftertheDMX value

hasbeenheld for more than5s.

020-024

Display On

025-029

Display Off

030-034

Reserved

035-039

LampHalfPower

040-044

LampFullPower

045-089

Reserved

090-094

Pan&TiltSpeed Mode

095-099

Pan &TiltTimeMode

100-129

Reserved

130-139

Lamp On

140-149

Pan &TiltReset

150-159

Color System Reset

160-169

GoboWheels Reset

170-179

Dimmer/ShutterReset

180-189

Frost/Focus/Prism Reset

190-199

Reserved

200-209

TotalReset

210-229

Reserved

230-239

LampOff

240-255

Reserved

Note:

1. The projector can’t be turned on within 1 minute after the lamp-off.

2.Fanerrorcancauselamp-off.

3.Note:"SpeedMode" meansPanandTiltwill movefromPointAtoPointBattheirrespectivemaximumspeeds."TimeMode"

meansbothPanandTiltwillarriveatdesignatedpointatthesametime. It'sadvisedTime Modebe usediftheprojectorrunscirclesor

inobliquelines.

4.Ifbothrotatinggobo wheelandfixed gobo wheelaretobe used,theformerispriortothelatter.

8. ERRORINFORMATION

Thesystemcandetectsome errorsduring thereset,if displayed, touch the logo toviewthe error.

The errormessagesareasfollows:

Name

Type

Correction

Pan

Timeout/magnetSensor/Encoder
