PR Lighting LS150 TREE User manual

1
LS150TREE
PR-6821
The user manual contains important information about the safe installation and use of a projector. Please read
andfollowtheseinstructions carefullyandkeepthemanual in asafe placeforfuture reference.
PR LIGHTING LTD.
http://www.pr-lighting.com

2
INDEX
1.SAFETYANDWARNINGS
2. INSTRUCTIONS
●CLEANINGAND MAINTENANCE
●TROUBLESHOOTING
3.APPEARANCE
4. INSTALLATION
●RIGGING
●PLACEAUNITONAFLATSURFACE
●TRANSPORTATION
●POWERCONNECTIONS
●DMXCONTROLCONNECTION
●DMXTERMINATOR
5. SETUPANDCONFIGURATION
●FRONTPANELOPERATION
●DMXSTARTADDRESS
●STAND-ALONEMODE
●MASTER/SLAVEMODE
6.OPERATIONMENU
7. DMXPROTOCOL
8.TECHNICALDATA
9.CIRCUITDIAGRAMANDPCBCONNECTIONS
●CIRCUITDIAGRAM
●PCB CONNECTIONS
10.COMPONENTORDERCODES
3
4
4
4
5
5
6
6
6
6
6
7
7
8
8
8
8
9
10
11
14
14
15
16
ACCESSORIES
The followingitemsaresuppliedwith theprojectorand pleasecheck:
Name
Quantity
Unit
Remark
Clamps
1
Pc
Powercord
1
Pc
XLR LoopCable
2
Set
Safetycord
1
Pc
User manual
1
Pc
Transparent Cover+seal+ screws×6
1
Set
Optional
Please note that as part of our ongoing commitment to continuous product development, specifications are subject to changewithout notice.
Whilst every care is taken in the preparation of the manual we reserve the right to change specifications in the course of product
improvement.Thepublisherscannotbeheldresponsiblefortheaccuracyof theinformationherein, oranyconsequencearising fromthem.
Every unit is tested completely and packed properly by the manufacturer. Please make sure the packing and / or the unit are in good
conditionbeforeinstallationand use.Shouldthere beany damage caused bytransportation, consultyourdealerand donot usetheunit.Any
damagecausedbyimproperusewillnotbeassumed by themanufacturerand/ordealer.
Any future technical change in the user manual won’t be with any further notice.
Note: Forthe productsmade by GuangzhouPRlighting Ltd, thewarrantyfor the wholeproduct is one year starting fromthe delivery date
butthelight sourceisnotwithinthewarranty.

3
1. SAFETYANDWARNINGS
.
NOTE
Before a projector’s installation, power-on,operationandmaintenance,pleasecarefullyread
thesafetyinformationhereinafter!
Thefollowingsafety signsareusedinthe usermanual.
Warning
User
Manual
Electrical
shock
Goggles
Protective
Gloves
Flames
High
Temperature
● When unpacking , check if there is transportation damage before using the projector. Should there be
anydamagecausedbytransportation,consultyourdealeranddonotuseit.
●The manufacture is not responsible for loss caused by the user not following the manual or changing the
projector ashe/shelikes
●Please be noted that the damage caused by changing the projector at willisnotwarranted.
●Do nothesitate tocontact thedealerorthemanufacturer ifanyquestionsor advice.
●The unit can be used indoors and outdoors and for its IPrating .please refer to Technical Data section of this user
manual.
● Useonlyindrylocations. Keep this unit awayfromrain andmoisture,excessiveheat,humidityand dust. Donot
allowcontactwith wateroranyotherliquids.
●It’s forbidden to make theunit withlowerprotectionleveldirectlyorindirectlycontactwater orother liquids.
●The projector should be kept away from high temperature, fire, electrical surge, vibration and strong light while
beingoperated
●The projector is only intended for installation, operation and maintenance by qualified personnel. And the
operationmuststrictly followtheproceduresinthemanual
●No repairable parts in theprojector and do notopencoversfor maintenancebyyourself.
●Don’t look straightly into the lightsourcesespeciallyfor epileptics,otherwise eyeswillbeburned.
●Do not connect this device to any typeofdimmerpack
●After lamp switched on, the minimumdistancebetweentheprojectorandilluminated surfaceis1.5m
●lens and other optical parts shall be replaced immediately if they have deformed or been damaged, otherwise the
lightoutputwillbecompromised.
●Before operation, please confirm that all covers(housing) are on and screws tightened. It’s forbidden to use a
projector whilecovers(housing)areoff
●Keep the lamp clean and do not touch it with bare hands.
●While operating it, wear protective items.
●Any electrical connection must be carried out by a qualified person .
●Before installation, please confirm the voltage supplied matches what is required for the projector
●Each projector must be properlyearthedandinstalledasper relatedelectricalstandards.
●Do not use power cord with its insulator damaged and connect the power cord with other cables.
●If the projector is not used or under cleaning,, please hold the plug and unplug it. Do not unplug it forcefully or
bypullingthe powercable.
●All powercords mustconformtorelatedsafetyandregulations
●While beingoperated,theprojectorshould notbeunderrainsorinhumidity.
●Do not switch on and off the projector constantly in very short intervals, otherwise the light source’s and other
electricalparts’ lifewillbeshortened .

4
●There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety cord
suppliedthroughthe safetycord holes forsafetysupport.
●Before any installation, maintenanceand cleaningwork,please ensuretheprojectoris disconnectedfrompower
mains.
●Under normal temperature, the temperature of the housing will be 55℃; after being stable, the unit’s
surfacetemperature willbe70℃
●While the lamp is stricken for the first time,there will be smoke and strange smell. It’s normal and does not
meantheprojectorhassome defects.
●While operated, do not touch the metallic housing. It is very hot during operation.
●Do not mount the projector directly on inflammable surface.
●Do not project the beam straightly on combustible items and the minimum distance between the projector
and illuminateditems is10m.
●A projector should be installed with good ventilation and the minimum distance between the projector and
wallsis50cm.Atthesame time,pleaseensurethefansand airinletsandoutlets areworkable.
2. INSTRUCTIONS
●CLEANINGANDMAINTENANCE
For the units with optical lens, because of the accumulation of the smoke, oil and dust on lens, the light output will be
compromised. For the reliable use of the unit, it is very necessary to keep it clean. The unit is IP65 rating waterproof device.
Unless approval by some professional technician for necessary internal component replacement, it’s forbidden to dismantle the
unit.
Cleaning frequencyis to bedecided by operations and its environment. Use soft cloth and normaldetergent for glass for cleaning
work. It’s advised external optical system be cleaned every 20days. Keep lens clean and do not touch optical parts with bare
hands.
●Beforeanymaintenance and cleaning,pleaseensuretheprojectisoffthepower
●Onlyqualifiedpersonisallowedtodo maintenance
●During maintenance andbeforemaintenance, theprojector mustbeoff power.
●To avoid internal damage, sun light or other light mustn’t penetrate into the projector via front lens whether
itrunsor not
●Do not use alcohol or other organic solvent to clean the housing to avoid damage.
●Do not use any solvent with chemical elements to clean color filters or hot mirror.
●TROUBLESHOOTING
PROBLEM
ACTION
The projector doesn’t switch on
Checkthepowercordconnection
Power Switch fails or is not connected well, call a professional
technicianforrepairingandchecking
Control board is not connected normally, call a professional technician
forrepairingandchecking,
The projectcanbe turned on,buttheLEDlamps
can’t be on
LED lamp board is notconnected well, call a professional technician for
repairingand checking
The LED lamps canbeon,butnotcontrolled
byDMX
CheckifDMXStartAddressisproperlyset
CheckifXLRcablefails ornot
Thebrightnessdecreasesobviously
Ambient temperature is too hot which makes the projector too hot,
pleasetakeappropriate ventilationmeasures

5
3. APPEARANCE
4. INSTALLATION
5. ●RIGGING
Take 1 clamp and 1 safety cord out from the package and tightenthe clamp with the arm, and thenmount the whole uniton the truss,
tighten the clamp’s retainers to keep the unit stable. (See the WARNING on the underside of the base as shown above) To pass the
SAFETYCORDthroughtheARM forsafety!Alwaysensurethatthe unit is firmlyanchoredto avoidvibrationand slippingwhilst
Arm
Safety Clamp
Warning
For safety, please
run the safety cord
through the safety cord
hole and ensure it is
tightened .
arm
body

6
functioning. Always ensurethat the structure that you are going to mount the unit to is secure and strong enough to support the weight
oftheunit Loosen thebigknob and adjust the head’s angle for the effect desired and the tighten it. The installation is completed.
(iftheunitiswitwirelesscontrol, whilebeing hung,theantennashould facedown)
●PLACEAUNITONAFLATSURFACE
Before placing a unit on a flat surface, loosen the small knob with the support and make the angle between the arm and the support
60degrees.Tightenthesmallknob. Loosenhebig knobandadjusttheanglebetweenthe armand unitasdesiredand thentightenit.
.(If the unit is with wireless control,afterthe unit isplaced on aflat surfacethe antenna should face up)
●TRANSPORTATION
Beforetransportation,tightenboth knobs after the armandsupport are overlapped.
WARNING:
●TheprojectorMUSTbe lifted orcarriedbytheHANDLESinsteadofclamps.
●.For safety the safety cord should afford 10 times the Projector’s weight.
●POWERCONNECTION
Connectthepower cordas follows:
L(live)=brown
E(earth) =yellow/green
N(neutral)=blue
Before power connection, please ensure the power supplied must match what the nameplate says. It is recommended that each
projector beconnectedwithpowerseparatelyso thattheymaybeindividuallyswitchedonandoff.
Note: If projectors are connected in series, please connect POWERIN port of the 1st projector with the Power Mains, then
connectitsPOWEROUTwithPOWERINof the2nd projector,and so ontillall fixturesare connected.Ifthevoltage supplied
is 200V-240V, the maximum projectors connected is 8pcs, if it is 100V-120V, the maximum is 4pcs. The diameter of the cores
ofthewiresfor thePowerin/outcablesmustbeequalorbiggerthan2.5mm2.
●Theearth wire(yellow/green) must be connectedto theground.And electricalconnectionmust bein
accordancewiththestandardsconcerned.
●Ifanyquestionsaboutthe electricalinstallation,donotcontinue butconsulta qualifiedelectrician.
●DMXCONTROLCONNECTION:
Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with
each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon5 pin (which are included with the
projector)or5pinXLRplugsand sockets.The XLR'sareconnectedasshowninthefigureabove.
Note: care should be taken to ensure that none of the pins touch the metallic body of the plug or each other. XLR plugs and sockets
mustn’t be connected in any way other than mentioned in the above figure. The unit accepts digital control signals in protocol
DMX512(1990).
Connect the controller’s DMX output to the first fixture’s DMX input, and connect the first fixture’s DMX output to the second
fixture’s DMX input and connect the rest fixtures in the same way. Eventually connect the last fixture’s DMX output to a DMX
terminatorasshowninthefigurebelow.

7
●DMXTERMINATOR
In the Controller mode, at the last fixture in the chain, the DMX output has to be connected with a DMX terminator. This prevents
electricalnoisefromdisturbingandcorruptingtheDMXcontrolsignals.
The DMX terminator is simply an XLR connector with a 120(ohm) resistor connected across pins 2 and 3, which is then plugged
intotheoutputsocketonthe lastprojectorinthe chain.The connectionsare illustratedbelow.
6. SETUPANDCONFIGURATION
●FRONTPANELOPERATION
To browse through or modify the projector’s functions, press key ENTER for more than 3 seconds to unlock the control panel and
enter the menus. To set or browse through the projector’s functions, press key UP or DOWN. Press the key ENTER to enter the
submenusandthe currentparameterswillbedisplayedwhile flashing.Press key UP or DOWN tochange values(plusorminus)
Presskey ENTER to save your changesand enter into the upperlevelmenuwhile flashings stop;
Presskey FUNC,itwillreturnto theupper menu(parametersnotsaved)orbrowse through1st levelmenus;
Presskey FUNC for1 secondornonekeyispushed for1minute, the menu will be escapedand currentoperationmodedisplayed.
IfDMXsignalisavailable, LEDindication ison.Otherwiseitisoff.
●DMXSTARTADDRESS
EachProjectormustbegivena DMXstartaddressso that the correctprojectorrespondstothe correctcontrolsignals. ThisDMXstart
DMX
Controller
Teminator
DMX OUT DMX IN DMX OUT DMX IN
21
3
120
DMX TERMINATOR
CONNECTION
Connect a 120 (OHM) resistor
across pins 2 and 3 in an XLR plug
and insert into the DMX out socket
on the last unit in the chain. PIN 3
PIN 2

8
address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the
controller.The Unit has1 DMXmode.It has7channels, so set the No. 1 projector’s address 001, No. 2 projector’s address 008,No.3
projector’s address 015, No. 4 projector’s address022,andsoon.
Launch theprojector. Pressbutton ENTER morethan2secondsto unlockpanel.
Pressbutton ENTER todisplayDMXaddress;
Pressbutton UP and DOWN,youcanset theaddress;
Pressbutton ENTER to confirm;afterpoweredonnext time,the default willbelastvalue saved
Pressbutton FUNC, itwillreturntotheuppermenu
.
●STAND-ALONEMODE
Operate the projector without connecting with a controller, enable the master mode through the operation panel, the
projector will run in Stand-Alone mode automatically.
DMX address can be set at any number within 512.
●MASTER/SLAVEMODE
Many projectors can run synchronously in the Master/Slave mode by linking them with each other. First,
connect the first fixture’s DMX output to the second fixture’s DMX input using XLR-XLR control cable and then connect the second
fixture’s DMX output to the third fixture’s DMX input, and so on until all projector are connected in this way. Eventually connect the
last fixture’s DMX output to a DMX terminator. Set 1st projector as the master and others are Slaves.
StartAddressesofall Slaves are 001; Operation mode of the Master can be set any mode for a Master’ and Slaves’ operation mode can
be setaccordingly
AfterPowered on,the group willruninMaster/Slave Mode
7. OPERATIONMENU
1stlevel menu
2ndlevelmenu
3rdlevelmenu
4thlevelmenu
Address
001 -512
DMXAddress
ConfigSetup
MasterSlave
Slave
DefaultSlave
Master
LanguageSetup
English
Default：English
Chinese
LcdLightSetup
On
Backlightwillbeoff
3minutesafternone
button ispushed
Off
Slave
Master Slave
Teminator
DMX OUT DMX IN DMX OUT DMX IN

9
Display Invert
Yes
No
FactorySetting
Yes
PRMTransmit
Yes
cleanProgra
Yes
Moto offset
Color
Focus
-128-127
-128-127
Moto Reset
Yes/No
Information
LEDTemperature
XX
FixtureuseTime
XXXX
SoftwareVersion
X.X.X
TestMode
Auto Test
Dimmer
000 -255
LEDbrightness
Color
000 -255
Motorposition
Effect
000 -255
Motorposition
Focus
000 -255
Motorposition
OperationMode
DMX Mode
Yes
User Memory
Yes
PresetMemory
(PR01~PR16)
PR01~PR16
User PrograEdit
（ET01~ET16）
Dimmer
000 -255
Strobe
000 -255
Color
000 -255
Effect
000 -255
Focus
000 -255
KeepTime
000 –200(0-20S)
8. DMXPROTOCOL
Channel No.
Function
DMXValue
Description
1
Dimmer
000-255
2
Dimmer Fine
000-255
Dimmer in16bit
3
Strobe
000-007
No
008-255
Strobespeedfromslowtofast
4
Colorwheel
000-009
White
010-019
White -Magenta
020-029
Magenta

10
9. TECHNICALDATA
ELECTRICSPECIFICATIONS
Inputvoltage:100V~240VAC，50/60Hz
Inputpower:160W@ 230V
Maximumcurrent:AC0.9A
Powerfactor：PF>90%
LIGHTSOURCESPECIFICATIONS
Qty 1pc,TX-3636W150FC120-NUVENG-A01
030-039
Magenta–Orange
040-049
Orange
050-059
Orange-Yellow
060-069
Yellow
070-079
Yellow-Blue
080-089
Blue
090-099
Blue–Cyan
100-109
Cyan
110-119
Cyan -White
120-127
White
128-191
Clockwiserotationfromslowtofast
192-255
Anti-clockwiserotationfromslowtofast
5
EffectWheel
000-001
No
002-127
Clockwiserotationfromslowtofast
128-255
Anti-clockwiserotationfromslowtofast
6
Focus
000-255
Motorposition
7
Function
000-199
No
200-209
Motorreset
210-255
No

11
PowerConsumption 150WLEDWhite
ManufacturersRatedLamp Life 50000hours
Color temperature: 7500K
COLORS
1pccolor wheel(5colors+Open),continualrotation, magnetsensorpositioning
Function
1effectwheel,independentlyandbi-directionallycontinuallyrotating
1pcfixedgobo
DIMMER
Linear Dimmer from0-100%
STROBE
Electronic Strobe0-25FP.S.withpresetstrobepulseeffect
BEAMANGLE
Beamangle:55°,motorizedfocus(Optional30°)
CONTROL
International standardDMX512 signalcontrolprotocol
DMX5123pin(Optional5pin)interfaces
Master/SlavesynchronizedMode
Stand alone mode,presetmode,selftestmodeand staticscene mode
3operationmodes(DMX mode,user memory,presetmemory)
OTHERFUNCTIONS
LCDcolor screen
DMX 512port forfirmware upgrade,a convenientandquickwayfor firmwareupgradeviaDMXcable
Overtemperatureprotection
BuiltinNTCtemperaturedetecting function,IfLEDlampisover heat, itspowerwillbedecreased intelligently
Fixturetime,DMX512channelvalueandsoftwareversionwillbedisplayed
Displaycanbeinverted
HOUSING
HightensilecastAluminum alloy,IP65
NETWEIGHT
8.5Kg
OPERATIONTEMPERATURE:
Maximumambienttemperature 40℃
SIZES:

12
RIGGINGFIGURE
LIGHTOUTPUTFORWHITE:
9. CIRCUITDIAGRAMANDPCBCONNECTIONS
DISTANCE (m)
2m
2m
0m 1m
1m
3m
3m
02.5 57.5 10 12.5
1324 331 147 83 53 0
4m 5m
6m 7m
4m 5m
6m 7m
DIAMETER (m) 2.42 4.85 7.27 9.7 12.12
0

13
●CIRCUITDIAGRAM

14
●PCB CONNECTIONS
MasterBoard
Diverboard
No
Name
1
ThermalSensor
2
Reserved
3
PWMsignal
interface
4
Reserved
5
Power
6
Fan
7
Reserved
8
485 signalinterface
9
DMX signal
interface
10
Reserved
No
Name
1
Power
2
LED Driver

15
10.COMPONENTORDERCODES
No.
Name
CodeNo.
Qty
Remarks
1
SWITCHINGPOWERSUPPLY
6230010129
1
100-240VAC24V/12.5A
2
LED LIGHTSOURCE 150W
6150000004
1
TX-3636W150FC120-NUVENG
-A01TIANXIN
3
STEPPER MOTOR
60300400100
2
24BYJ48-51
4
LED CONSTANTCURRENT
SUPPLYOFPR-6810
6230000005
1
5
STEPPER MOTOR
030040235A
1
25PM30005-04N 42X37X73,
4 COILS, 500MM IN LENGTH,
RUIBAO

16
PR LIGHTING LTD.
1582 XingyeAvenue,NancunPanyu
Guangzhou,511442China
TEL:[phone]
PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products.
CounterfeitingWillbeProsecuted! P/N: 6320000112A
Version:20200702
