Profile Design 35SLC User manual

Extensions
1
AEROBAR EXTENSIONS
REVISION 01-05-25-2022

Extensions
1
INTRODUCTION
Thank you for purchasing this set of Profile Design Aerobar Extensions. These instructions apply to the 35SLC, 43SLC, 4525SLC, 50SLC, 35A, 43A,
4525A, 50A.
Please read these instructions thoroughly before attempting to install this item. Proper installation is required for compliance with Profile Design's
warranty policy. If you are not familiar with installation of Aerobars or their accessories, please seek the assistance of your local Profile design dealer
by logging on to www.profile-design.com and using "dealer search" or by calling Profile Design's customer service number p.# 888.800.5999.
Note to Dealers: If you install this product for the consumer, please provide him/her with this owner’s manual after installation.
Tools and materials required:
• Assembly compound such as Finish Line Fiber Grip™
• Cutting guide
• Hacksaw with a 32T blade for Carbon Extensions
• Hacksaw with a 18T blade for Aluminum Extensions
• Half round file
• Electrical/Insulation tape
• Clean, lint free cloth

Extensions
2
Your Extension kit should contain:
Optional accessories compatible with these extensions:
WARNING: Periodically check the extension for damage, particularly for scratches through the clearcoat (carbon parts) that could lead to
degradation and weakening of the base material. Replace your extension if you notice any damage from use or accident.
• Two (2) extensions (Carbon or Aluminum)
• Two (2) grip end bar plugs
• Two (2) cable exit bar plugs
• Aeria II Series Brackets
• Sonic Series Brackets
• Universal Computer Mount
If anything is missing from the extension kit please contact your dealer.

Extensions
32
COMPONENT LIST
01 03 02 04
35A / 35SLC 340mm
QTY.
Req.
Part.#Ref.# Part Description
185224535a Aerobar Extensions 340mm (L)
285224635a Aerobar Extensions 340mm (R)
385227735SLC Aerobar Extensions 340mm (L)
485227835SLC Aerobar Extensions 340mm (R)
1
1
1
1

Extensions
4
05 07 06 08
35A / 35SLC 400mm
COMPONENT LIST
QTY.
Req.
Part.#Ref.# Part Description
5852266 35a Aerobar Extensions 400mm (L)
6852267 35a Aerobar Extensions 400mm (R)
7852279 35SLC Aerobar Extensions 400mm (L)
8852280 35SLC Aerobar Extensions 400mm (R)
1
1
1
1

Extensions
54
09 11 10 12
43A / 43SLC 400mm
COMPONENT LIST
QTY.
Req.
Part.#Ref.# Part Description
852275 43a Aerobar Extensions 400mm (L)
852276 43a Aerobar Extensions 400mm (R)
852281 43SLC Aerobar Extensions 400mm (L)
9
10
11
12 852282 43SLC Aerobar Extensions 400mm (R)
1
1
1
1

Extensions
6
13 15 14 16
4525A / 4525SLC 400mm
COMPONENT LIST
QTY.
Req.
Part.#Ref.# Part Description
852247 4525a Aerobar Extensions 400mm (L)
852248 4525a Aerobar Extensions 400mm (R)
852283 4525SLC Aerobar Extensions 400mm (L)
13
14
15
16 852284 4525SLC Aerobar Extensions 400mm (R)
1
1
1
1

Extensions
76
17 18
50A 340mm
COMPONENT LIST
QTY.
Req.
Part.#Ref.# Part Description
852270 50a Aerobar Extensions 340mm (L)17
18 852271 50a Aerobar Extensions 340mm (R)
1
1

Extensions
8
19 21 20 22
50A / 50SLC 400mm
COMPONENT LIST
QTY.
Req.
Part.#Ref.# Part Description
852249 50a Aerobar Extensions 400mm (L)
852250 50a Aerobar Extensions 400mm (R)
852285 50SLC Aerobar Extensions 400mm (L)
19
20
21
22 852286 50SLC Aerobar Extensions 400mm (R)
1
1
1
1

Extensions
98
Aluminum Extensions - End Plug Carbon Extensions - End Plug
COMPONENT LIST
QTY.
Req.
Part.#Ref.# Part Description
168428 End Plug - Round Aluminum (Front)
716669 End Plug - Round Carbon (Front)
716667 End Plug - With Slot Hole / Logo (Rear)
23
24
25
2
2
2
23 25 24 25

Extensions
10
35A / 35SLC 4525A / 4525SLC
PART DRAWINGS
80
400
35°
80
340
35°
106
400
45°
25°

Extensions
1110
43A / 43SLC 50A / 50SLC
PART DRAWINGS
400
84.2
43°
340
120
50°
400
120
50°

Extensions
12
PRODUCT SPECIFIC SETUP LIMITATIONS
60 mm
10 mm

Extensions
1312
01
TORQUE SETTINGS
1Extension clamp M6x15mm 6Nm (53 inlbf)
Ref.# Location Bolt Size Torque

Extensions
14
INSTALLATION INSTRUCTIONS
1. Install the extensions in the desired position and tighten the extension fixing bolt
so they are held snugly.
2. Install the shifters (if using bar end models) as per the shifter manufacturer’s
instructions. We recommend a light coating of assembly compound on the inside
of the extension prior to installing the shifter.
3. Install the cables as per instructions from the shifter manufacturer.
4. Check the placement of the brackets and extensions then use a torque wrench to
tighten the extension clamp.
Assembly compound
Threadlocker

Extensions
1514
1. Carefully determine the required extension length by performing a bike fit or measuring the
existing extensions.
2. Mark the point at which you wish to make a cut.
3. We recommend checking your measurements after first marking the cut line to ensure that you do
not inadvertently cut the extensions too short.
4.Mount the cutting guide securely in a vice. Then place the extension in the guide and line up the
marked cut line with the slot in the cutting guide.
5. Using the hacksaw, make firm strokes of the blade through the guide, allowing the blade to do
the work. Do not apply excessive force to the hacksaw as you risk snapping the blade and the
possibility of injury.
6. Repeat the process for the second extension.
7. Once you have cut both extensions, use the half round file to remove any sharp edges from both
the interior and exterior faces of the extension. A deburring tool may be used on Aluminum
extensions (not Carbon).
a. For carbon a 32T or carbon specific blade is recommended. Wrap the extension with insulation
tape at the cut line to limit the risk of splintering the carbon at the blade exit point.
b. If cutting carbon, wear a breathing mask, gloves and eye protection then dispose of the dust
residue carefully. Airborne dust particles are a respiratory hazard.
c. For Aluminum an 18T blade is recommended.
HOW TO CUT THE EXTENSIONS

Extensions
16
