Profile Design DRV/GMR Series User manual

DRV/GMR Handlebar
1
DRV/GMR HANDLEBAR
REVISION 01-12-18-2020

DRV/GMR Handlebar
1
INTRODUCTION
Thank you for purchasing this Profile Design Handlebar. These instructions apply to the DRV/GMR aluminium handlebar.
Please read these instructions thoroughly before attempting to install this item. Proper installation is required for compliance with Profile Design's
warranty policy. If you are not familiar with installation of handlebars or their accessories, please seek the assistance of your local Profile design dealer
by logging on to www.profile-design.com and using "dealer search" or by calling Profile Design's customer service number p.# 888.800.5999.
Note to Dealers: If you install this product for the consumer, please provide him/her with this owner’s manual after installation.
Tools and materials required:
• Assembly compound such as Finishline Fiber Grip™

DRV/GMR Handlebar
2
Your Handlebar kit should contain:
• One (1) handlebar (aluminium)
Components compatible with this Handlebar
• Any Profile Design Stem
• Sonic, Neosonic, Supersonic brackets
If anything is missing from the Handlebar kit please contact your dealer.
Please note that threaded areas have been pre-treated by Profile Design during production with a special blue thread locking compound. This special
compound is easy to detect on the threads of all bolts provided. If you cannot detect this thread locking compound or you are re-installing the bolt,
re-apply a suitable blue thread locking compound as available from Loctite® or another company before assembly.
WARNING: Periodically check the Handlebar for damage, particularly for scratches through the anodised coating (aluminium parts) or clearcoat
(carbon parts) that could lead to degradation and weakening of the base material. Replace your Aerobar if you notice any damage from use or
accident.

DRV/GMR Handlebar
32
W1
438
458
478
498
W2
461.8
481.8
501.8
521.8
W
360
380
400
420
149
96
70
142
105
105
W
W1
W2
100
50 50
W1 W2
480.1
500.1
520.1
503.9
523.9
543.9
W
400
420
440
W
W1
W2
120 5050
154
154
101
75
120
120
PART DRAWINGS
DRV/GMR SERIES
1/ZEROFIVE
1/TWENTY

DRV/GMR Handlebar
4
MAX TORQUE SETTINGS
01
02
04
03
Ref.# Location Torque
1
2
Armrest Bolts
Stem clamp
Extension clamp
Handlebar clamp
4.7Nm (42 inlbf)f)
6Nm (53 inlbf)
6Nm (53 inlbf)
6Nm (53 inlbf)
3
4

DRV/GMR Handlebar
54
INSTALLATION INSTRUCTIONS
1. Apply a thin coating of assembly compound to the inside faces of the stem clamp.
2. Install the stem as per the manufacturers instructions.
3. Torque the stem bolts to the manufacturers specification, being careful to not exceed
6Nm(53in1bf).
1.If you are using aerobars with this handlebar.
2. Apply a thin coating of assembly compound to the inside faces of the aerobar bracket clamp.
3. Install the aerobar as per the manufacturers instructions.
4. Torque the aerobar bracket bolts to the manufacturers specification, being careful to not exceed
6Nm(53in1bf).
WARNING:
Overtightening the handlebar clamp may lead to cracking
and possible failure of the handlebar.

DRV/GMR Handlebar
6
• Profile Design Worldwide Two Year Limited Warranty.
• Profile Design, LLC (distributor) warrants to the original retail purchaser ("you") that the Profile Design product for which you received
this warranty is free from defects in material and workmanship for (2) two years from the date of original retail purchase. For more
details on this warranty, its exclusions and/or how to make a claim under the warranty please call +1 310.747.0085 extension 161 or visit
www.profile-design.com/pages/warranty
WARNING

DRV/GMR Handlebar
76
2677 El Presidio Street
Long Beach, CA 90810
Ph: 310-884-7756
w
ww.profile-design.com
© Profile Design LLC
