Profile Design ERGO+ ARMREST KIT User manual

Ergo+ & Race+ Armrest Kits
1
ERGO+ & RACE+ ARMREST KITS
REVISION 01-05-25-2022

Ergo+ & Race+ Armrest Kits
1
INTRODUCTION
Thank you for purchasing this Profile Design Armrest kit. These instructions apply to the Ergo+ and Race+ kits.
Please read these instructions thoroughly before attempting to install this item. Proper installation is required for compliance with Profile Design's
warranty policy. If you are not familiar with installation of Aerobars or their accessories, please seek the assistance of your local Profile design dealer
by logging on to www.profile-design.com and using "dealer search" or by calling Profile Design's customer service number p.# 888.800.5999.
Note to Dealers: If you install this product for the consumer, please provide him/her with this owner’s manual after installation.
Tools and materials required:
• 4mm Hex Wrench
• Torque Wrench with a 4mm hex bit
• Grease such as Finish Line Premium Grease

Ergo+ & Race+ Armrest Kits
2
Your Armrest kit should contain:
WARNING: Periodically check the Armrest for damage, particularly deep scratches in the cup. Replace the armrest if you notice any damage from
use or accident.
• Two (2) armrest cups with hook & loop stickers
• Two (2) armpad cushions (foam)
• Four (4) M6x15 countersunk bolts
If anything is missing from the Armrest kit please contact your dealer.
Please note that threaded areas have been pre-treated by Profile Design during production with a special blue thread locking compound. This special
compound is easy to detect on the threads of all bolts provided. If you cannot detect this thread locking compound or you are re-installing the bolt,
re-apply a suitable blue thread locking compound as available from Loctite® or another company before assembly.

Ergo+ & Race+ Armrest Kits
32
COMPONENT LIST
QTY.
Req.
Part.#Ref.# Part Description
1200072Armrest - Ergo+ W/Hook Sticker Side A(Left)
2200073Armrest - Ergo+ W/Hook Sticker Side B(Right)
3685224 Pad - Ergo+/Race+ Ultra 10mm
4685221Armrest - Race+ W/Hook Sticker Side A(Left)
5685222
685222
313593
Armrest - Race+ W/Hook Sticker Side B(Right)
1
1
2
1
1
6Pad - Ergo+/Race+ Ultra 10-5mm2
7Bolt - M6x12 FHB w/Nylok Stainless(SUS304)4
02 03
05 06
01
04
07

Ergo+ & Race+ Armrest Kits
4
PART DRAWINGS
124 mm
108.5 mm
15 mm
18.5 mm
130 mm
108.5 mm
124 mm
94.5 mm
15 mm
18.5 mm
130 mm
108.5 mm
ERGO+ RACE+
Pad available: 10mm Pad available: Tapered - 10mm center, 5mm edge

Ergo+ & Race+ Armrest Kits
54
PRODUCT SPECIFIC SETUP LIMITATIONS
• The armrests are not designed to be used in the reverse position.

Ergo+ & Race+ Armrest Kits
6
TORQUE SETTINGS
1Armrest Bolts M6x12mm CS 4.7Nm (42 inlbf)
Ref.# Location Bolt Size Torque
01

Ergo+ & Race+ Armrest Kits
76
INSTALLATION INSTRUCTIONS
•Torque the bolts to 4.7Nm
•Torque the bolts to 4.7Nm
1. Apply a light coating of grease to the surface of the armrest mount to protect
against corrosion.
2. Fasten the armrests to the brackets using the M6x15mm countersunk bolts,
note that the armrests have an offset design so care is required to ensure each
side is positioned in the same way.
3. Torque the bolts to 4.7Nm using the torque wrench.
4. Apply a light coating of grease to the surface of the bolts as a protective layer
against the effects of sweat.
5. Attach the cushion by placing carefully on hook and loop backing of the
armrest and hold firmly for 30 seconds. Repeat for the other armrest. Note
that the cushions on these models of armrest are symmetrical, so it doesn’t
matter which side each cushion is applied to.

Ergo+ & Race+ Armrest Kits
8
1. To fit the armrests first ensure the inner face of the armrest is free of lint and
grease, if the armrest has previously had a hook and loop sticker applied the
residue should first be removed either mechanically or with a citrus based solvent.
2. Before applying the hook and loop sticker, you may choose to wipe down the
surface with isopropyl alcohol to ensure good adhesion. Remove the backing from
the hook and loop sticker and apply it to the armrest, smoothing the sticker out to
ensure there are no air bubbles trapped under it.
3. Allow the sticker 24 hours to cure before use.
HOW TO INSTALL NEW ARMPADS

Ergo+ & Race+ Armrest Kits
98
ARMREST USAGE
Do not put force on the side of the armrests!
WARNING

Ergo+ & Race+ Armrest Kits
10
• Profile Design Worldwide Two Year Limited Warranty.
• Profile Design, LLC (distributor) warrants to the original retail purchaser ("you") that the Profile Design product for which you received
this warranty is free from defects in material and workmanship for (2) two years from the date of original retail purchase. For more
details on this warranty, its exclusions and/or how to make a claim under the warranty please call +1 310.747.0085 extension 161 or visit
www.profile-design.com/pages/warranty
WARNING

Ergo+ & Race+ Armrest Kits
1110
2677 El Presidio Street
Long Beach, CA 90810
Ph: 310-884-7756
w
ww.profile-design.com
© Profile Design LLC
