protech SP-7625 User manual

USER
USERUSER
USER’
’’
’S
SS
S
MANUAL
MANUALMANUAL
MANUAL
S
SS
SP
PP
P-
--
-7
77
762
6262
625
55
5/
//
/762
762762
7627
77
7/
//
/
762
762762
762
9
99
9
15”/17”/19” Panel PC
Powered by Intel
®
3
rd
Gen Core
i5/i3 & Pentium
®
CPU
With GA, 4COM, 4USB & 2LAN
S
P
-
762
5
/
762
7
/
762
9
M
2

SP-7625/7627/7629
15”/17”/19” High Performance Panel PC
COPYRIGHT NOTICE & TRADEMARK
All trademarks and registered trademarks mentioned herein are the property of their
respective owners.
This manual is copyrighted in July 2014 (Revised in May 2015). You may not
reproduce or transmit in any form or by any means, electronic, or mechanical,
including photocopying and recording.
DISCLAIMER
This user’s manual is meant to assist you in installing and setting up the system. The
information contained in this document is subject to change without any notice.
CE NOTICE
This is a class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.

FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference
in which case the user will be required to correct the interference at his own expense.
You are cautioned that any change or modifications to the equipment not expressly
approve by the party responsible for compliance could void your authority to operate
such equipment.
CAUTION! Danger of explosion if battery is incorrectly replaced. Replace only with the same or
equivalent type recommended by the manufacturer. Dispose of used batteries according to the
manufacturer’s instructions.
WARNING! Some internal parts of the system may have high electrical voltage. And therefore
we strongly recommend that qualified engineers can open and disassemble the system. The
LCD and touch screen are easily breakable, please handle them with extra care.

Contents
TABLE OF CONTENTS
CHAPTER 1 INTRODUCTION
1-1 About This Manual....................................................................
1-2
1-2 System Illustration......................................................................
1-3
1-3 System Specifications.................................................................
1-9
1-4 Safety Precautions......................................................................
1-11
CHAPTER 2 SYSTEM CONFIGURATION
2-1 System External I/O Port & Pin Assignment..............................
2-2
2-2 Mainboard Component Locations & Jumper Settings................
2-8
CHAPTER 3 SOFTWARE UTILITIES
3-1 Introduction................................................................................
3-2
3-2 Intel
®
Chipset Software Installation Utility…..……..................
3-3
3-3 Intel
®
Matrix Storage Manager Utility (RST)…........................
3-4
3-4 Intel
®
USB3.0 eXtensible Host Controller Utility......................
3-5
3-5 Intel
®
Management Engine Components Utility…....................
3-6
3-6 VGA Driver Utility....................................................................
3-7
3-7 LAN Driver Utility……………………………………………..
3-8
3-8 Sound Driver Utility……………………………………………
3-9
3-9 Touchscreen Driver Utility…………………………………….
3-10
CHAPTER 4 BIOS SETUP
4-1 Introduction................................................................................
4-2
4-2 Entering Setup............................................................................
4-4
4-3 Main……...................................................................................
4-7
4-4 Advanced…………………….........................….......................
4-8
4-5 Chipset……………....................................................................
4-31
4-6 Boot..………………..................................................................
4-39
4-7 Security………………………………………………………...
4-42
4-8 Save & Exit…………………………………………………….
4-45

Contents
APPENDIX A SYSTEM DIAGRAMS
Exploded Diagram for Panel.................................................................
A-2
Exploded Diagram for Touchscreen......................................................
A-11
Exploded Diagram for Whole System...................................................
A-29
Exploded Diagram for Board Stand......................................................
A-47
Exploded Diagram for CD Tray............................................................
A-48
Exploded Diagram for HDD Holder.....................................................
A-49
Exploded Diagram for System Fan........................................................
A-50
APPENDIX B TECHNICAL SUMMARY
Block Diagram......................................................................................
B-2
Interrupt Map.........................................................................................
B-3
DMA Channels Map……......................................................................
B-8
I/O Map.................................................................................................
B-9
Memory Map…………………………………………………………..
B-13
Watchdog Timer Configuration…………..…………………………...
B-15
Flash BIOS Update…………………………………………………….
B-18

Page:1-1
INTRODUCTION
This chapter gives you the information for SP-7625/7627/7629. It
also outlines the System specification.
Section includes:
About This Manual
System Specifications
Safety Precautions
Experienced users can skip to chapter 2 on page 2-1
for Quick Start.
CHAPTER
1

Chapter 1 Introduction
SP-7625/7627/7629 USER ′ S MANUAL
Page: 1-2
1-1. ABOUT THIS MANUAL
Thank you for purchasing our SP-7625/7627/7629, 15”/17”/19” high performance
panel PC with Intel
®
3
rd
Gen. Corei5/i3 & Pentium
®
processor, enhanced with
VGA, 4COM, 4USB and 2LAN. SP-7625/7627/7629 provides faster processing speed,
greater expandability and can handle more task than before. This manual is designed
to assist you how to install and set up the system. It contains four chapters. The user
can apply this manual for configuration according to the following chapters:
Chapter 1 Introduction
This chapter introduces you to the background of this manual, and the specifications
for this system. The final page of this chapter will indicate how to avoid damaging this
board.
Chapter 2 Hardware Configuration
This chapter outlines the component locations and their functions. In the end of this
chapter, you will learn how to set jumper and how to configure this card to meet your
own needs.
Chapter 3 Software Utilities
This chapter contains helpful information for proper installations of the VGA utility,
LAN utility, and Sound utility.
Chapter 4 BIOS Setup
This chapter indicates you how to set up the BIOS configurations.
Appendix A System Diagrams
This appendix gives you the exploded diagrams and part numbers of the SP-7625/
7627/7629.
Appendix B Technical Summary
This appendix gives you the information about the Technical maps, Watchdog-timer
configuration, and Flash BIOS Update.

Chapter 1 Introduction
SP-7625/7627/7629 USER ′ S MANUAL
Page: 1-3
1-2. SYSTEM ILLUSTRATION
SP-7625
Front View
402.8
Touch Area
303
Rear View
391
288 268
371
Unit: mm

Chapter 1 Introduction
SP-7625/7627/7629 USER ′ S MANUAL
Page: 1-4
Top View
371
360
Bottom View
Side View Quarter View
85.75
23.2
18.9
17.7
201
67
Unit: mm

Chapter 1 Introduction
SP-7625/7627/7629 USER ′ S MANUAL
Page: 1-5
SP-7627
Front View
366
452
Touch Area
Rear View
407.2
431.6
345.6 311.2
Unit: mm

Chapter 1 Introduction
SP-7625/7627/7629 USER ′ S MANUAL
Page: 1-6
Top View
407.2
360
Bottom View
Side View Quarter View
93.25
3
1
1.2
30.7
10
201 88.6
Unit: mm

Chapter 1 Introduction
SP-7625/7627/7629 USER ′ S MANUAL
Page: 1-7
SP-7629
Front View
497
420
Touch Area
Rear View
435.4
360.4
466
389
Unit: mm

Chapter 1 Introduction
SP-7625/7627/7629 USER ′ S MANUAL
Page: 1-8
Top View
435.4
360
Bottom View
Side View Quarter View
93.35
360.4
113.2
30.8
10
201
Unit: mm

Chapter 1 Introduction
SP-7625/7627/7629 USER ′ S MANUAL
Page: 1-9
1-3. SYSTEM SPECIFICATION
System
CPU Support Intel
®
3
rd
Gen. Corei5/i3
Intel
®
Pentium
®
Chipset Intel
®
Q77
OS Support Microsoft Windows 7
Memory Support 1 x DDR3 SO-DIMM socket, up to 16 GB
Watchdog 1~255s Watchdog timer
Power Supply AC IN 100~230V ATX power
Front Bezel Stainless steel
IP65 For front panel only
Mounting Type VESA 100 x 100 mm & Wall Mount
Net Weight SP-7625: 7.5 kg
SP-7627: 9 kg
SP-7629: 10.6 kg
Dimension (W x H x D) SP-7625: 402.8 x 303 x 85.8 mm
SP-7627: 452 x 366 x 93.3 mm
SP-7629: 497 x 420 x 93.4 mm
Certificate CE/FCC
I/O Ports
Serial Port 4 x COM ports :
COM1/3/4 for RS-232 only
COM2 for RS-232/422/485
Parallel Port 1 port, bi-direction, SPP/EPP/ECP
USB 4 x USB3.0
LAN 2 x LAN, RJ45 10/100/1000 Mbps, support Wake-on-
LAN:
LAN1: Intel
®
82579LM
LAN2: Intel
®
82583V
VGA 1 x VGA
Keyboard & Mouse PS/2 Connector with mini-DIN connector

Chapter 1 Introduction
SP-7625/7627/7629 USER ′ S MANUAL
Page: 1-10
Audio Line-out, Line-in, MIC
GPIO 4 in / 4 out (with 5V)
Expansion slot 2 x PCI slot (optional), 1 x mini PCIe slot
Drive Bay 2 x 2.5" SATA HDD, 1 x slim CD-ROM (optional)
Display
LCD Panel Size SP-7625: 15”
SP-7627: 17”
SP-7629: 19”
Resolution (Brightness) SP-7625: 1024 x 768, 400 nit, LED backlight
SP-7627: 1280 x 1024, 350nit LED backlight
SP-7629: 1280 x 1024 , 300nit LED backlight
Touchscreen (ELO) 5W Analog resistive (USB interface)
Environment
Temperature Operating: 0 ~ 50°C (32 ~ 122°F)
Storage: -20 ~ 80°C (-4 ~ 176°F)
Humidity Operating: 20~90% RH (no condensation)
Storage: 10 ~ 95% RH (no condensation)

Chapter 1 Introduction
SP-7625/7627/7629 USER ′ S MANUAL
Page: 1-11
1-4. SAFETY PRECAUTIONS
Follow the messages below to avoid your systems from damage:
1. Keep your system away from static electricity on all occasions.
2. Prevent electric shock. Don’t touch any components of this card when the card is
power-on. Always disconnect power when the system is not in use.
3. Disconnect power when you change any hardware devices. For instance, when
you connect a jumper or install any cards, a surge of power may damage the
electronic components or the whole system.

Page 2-1
HARDWARE
CONFIGURATION
** QUICK START **
CHAPTER
2
Helpful information describes the jumper & connector settings, and
component locations.
Section includes:
Jumper & Connector Quick Reference Table
Component Locations
Configuration and Jumper settings
Connector’s Pin Assignments

Chapter 2 Hardware Configuration
SP-7625/7627/7629 USER ′ S MANUAL
Page: 2-2
2-1. SYSTEM EXTERNAL I/O PORT & PIN ASSIGNMENT
I/O View
AC IN
Screen is downwards.
LAN2
USB3
USB4
LAN1
COM4COM3 COM2 DIO
Line-in
Line-out
MIC
USB1
USB2
COM1
MS
KB VGALPT

Chapter 2 Hardware Configuration
SP-7625/7627/7629 USER ′ S MANUAL
Page: 2-3
2-1-1. Keyboard & Mouse Ports
KB_MS1: PS/2 Keyboard & Mouse Port
Keyboard:
PIN
ASSIGNMENT
PIN
ASSIGNMENT
1
KBDATA
4
VCC5
2
NC
5
KBCLK
3
GND
6
NC
Mouse:
PIN
ASSIGNMENT
PIN
ASSIGNMENT
7
MSDATA
10
VCC5
8
NC
11
MSCLK
9
GND
12
NC
2-1-2. COM Ports
COM1, COM2, COM3, COM4: COM Ports
PIN
ASSIGNMENT
PIN
ASSIGNMENT
1
COM_DCD#
6
COM_DSR#
2
COM_RX
7
COM_RTS#
3
COM_TX
8
COM_CTS#
4
COM_DTR#
9
COM_RI#
5
GND
Note: COM2 port is connected from a connector on
board. Refer to the section COM connector.
5
19
6
COM1/COM2/
COM3/COM4/
3
12
456
9
78
10 1112
MS
KB
KB_MS1

Chapter 2 Hardware Configuration
SP-7625/7627/7629 USER ′ S MANUAL
Page: 2-4
2-1-3. VGA Port
VGA:VGA Port
PIN
ASSIGNMENT
PIN
ASSIGNMENT
1
CRTRED
9
CRTVCC_L
2
CRTGREEN
10
GND
3
CRTBLUE
11
NC
4
NC
12
CRTDATA
5
GND
13
HSYNC
6
CRT_ALWAYS_
ON
14
VSYNC
7
GND
15
CRTCLK
8
GND
2-1-4. LAN Port
LAN1, LAN2:RJ45 LAN Ports
PIN
ASSIGNMENT
PIN
ASSIGNMENT
1
MDI_0P
5
MDI_2P
2
MDI_0N
6
MDI_2N
3
MDI_1P
7
MDI_3P
4
MDI_1N
8
MDI_3N
LAN LED Indicator:
Left Side LED
Red Color On
Giga LAN Speed Indicator
Off
No LAN switch/hub connected.
Right Side LED
Orange Color Blinking
LAN Message Active
Off
No LAN Message Active
15 610 1115
VGA
Red Orange
8 1
LAN1/
LAN2/
