protech POS-3120 Series User manual

USER’S
MANUAL
POS-3120 Series
Mini POS System Powered by
Intel
®
Atom
®
Platform
PO
S
-
31
2
0
Series
M
4

Preface
POS-3120 Series POS System
With LCD / Touchscreen
PREFACE
COPYRIGHT NOTICE
This user’s manual is meant to assist users in installing and setting up the
system. The information contained in this document is subject to change
without any notice.
This manual is copyrighted July 2011 (Revised Edition: January 2012). You
may not reproduce or transmit in any form or by any means, electronic, or
mechanical, including photocopying and recording.
ACKNOWLEDGEMENTS
All trademarks and registered trademarks mentioned herein are the property
of their respective owners.
CE NOTICE
This is a class A product. In a domestic environment this product may cause
radio interference in which case the user may be required to take adequate
measures.

Preface
FCC NOTICE
This equipment has been tested and found to comply with the limits for a Class
A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void your
authority to operate such equipment.
CAUTION! Danger of explosion if battery is incorrectly replaced. Replace only with the
same or equivalent type recommended by the manufacturer. Dispose of used batteries
according to the manufacturer’s instructions.
WARNING! Some internal parts of the system may have high electrical voltage. And
therefore we strongly recommend that qualified engineers can open and disassemble the
system.
The LCD and Touchscreen are easily breakable, please handle them with extra care.

Contents
TABLE OF CONTENTS
CHAPTER 1 INTRODUCTION
1-1 About This Manual ....................................................... 1-2
1-2 POS System Illustration ................................................ 1-3
1-3 System Specification ..................................................... 1-7
1-4 Safety Precautions ......................................................... 1-9
CHAPTER 2 SYSTEM CONFIGURATION
2-1 Jumper & Connector Quick Reference Table ............... 2-2
2-2 Component Locations ................................................... 2-3
2-3 How to Set the Jumpers ................................................ 2-5
2-4 COM Port & VGA Connector ………………………. 2-7
2-5 COM RI and Voltage Selection ……………………… 2-10
2-6 Mini-DIN and USB Connector ………………………. 2-14
2-7 LAN & USB Connector ……………………………… 2-15
2-8 Cash Drawer Connector ……………………………… 2-16
2-9 Cash Drawer Power Selection ………………………...
2-17
2-10 Power LED Connector …………………………………. 2-18
2-11 Smart Fan Connector ………………………………… 2-18
2-12 Power Connector …………………………………….. 2-18
2-13 Reset Switch Connector ……………………………… 2-19
2-14 Power for Thermal Printer Connector ………………... 2-19
2-15 External Speaker Connector ………………………….. 2-19
2-16 Inverter Connector …………………………………… 2-20
2-17 MSR/ Card Reader Connector ……………………….. 2-21
2-18 Printer Connector …………………………………….. 2-21
2-19 LVDS Connector …………………………………….. 2-22
2-20 SATA Connector ……………………………………... 2-24
2-21 SATA Power Connector ……………………………… 2-24
2-22 Touch Panel Connector ………………………………. 2-25
2-23 Touch Panel Selection ……………………………….. 2-25
2-24 Clear CMOS Data Selection ………………………… 2-26
2-25 Compact Flash Connector …………………………… 2-27

Contents
CHAPTER 3 SOFTWARE UTILITIES
3-1 Introduction …............................................................... 3-2
3-2 Intel®Chipset Software Installation Utility ….............. 3-3
3-3 VGA Driver Utility …………………………….…….. 3-4
3-4 LAN Driver Utility ….................................................... 3-5
3-5 Sound Driver Utility ….................................................. 3-6
3-6 Touch Screen Driver Utility ………………………….. 3-7
3-7 Wireless Driver Utility (Optional) …………………… 3-8
CHAPTER 4 AMI BIOS SETUP
4-1 Introduction …............................................................... 4-2
4-2 Entering Setup …........................................................... 4-3
4-3 Main ……...................................................................... 4-5
4-4 Advanced ……............................................................... 4-6
4-5 Boot …........................................................................... 4-17
4-6 Security ……….............................................................
4-21
4-7 Chipset ……………………………………………….. 4-22
4-8 Exit …............................................................................ 4-26
APPENDIX A SYSTEM ASSEMBLY
Exploded Diagram for 2 Inch Thermal Printer Assembly …… A-2
Exploded Diagram for 3 Inch Thermal Printer Assembly …… A-6
Exploded Diagram for Printer Paper Holder Assembly ……… A-9
Exploded Diagram for Fan Assembly ……………………..…. A-10
Exploded Diagram for Empty Top Case Assembly ………….. A-12
Exploded Diagram for Fingerprint Module ………………….. A-14
Exploded Diagram for POS-3120 Hard Disk Drive Assembly . A-16
Exploded Diagram for I-Button Assembly …….…………….. A-19
Exploded Diagram for POS-3120 CPT LCD Assembly …….. A-21
Exploded Diagram for POS-3120 Data Image LCD Assembly A-23
Exploded Diagram for POS-3120 Mini-PCIE Installation …... A-25
Exploded Diagram for POS-3120 Motherboard …………….. A-27

Contents
Exploded Diagram for POS-3120 MSR Assembly …..……… A-31
Exploded Diagram for POS-3120 MSR Module ……………. A-32
Exploded Diagram for POS-3120 Printer Assembly ………… A-34
Exploded Diagram for POS-3120 Top Cover Assembly ….… A-36
Exploded Diagram for VFD Module Assembly ……………... A-37
APPENDIX B TECHNICAL SUMMARY
Block Diagram ......................................................................... B-2
Interrupt Map ............................................................................ B-3
DMA Channels Map ................................................................ B-4
I/O Map .................................................................................... B-5
Watchdog Timer Configuration ............................................... B-7
Flash BIOS Update …….......................................................... B-9

Page:1-1
INTRODUCTION
This chapter gives you the information for the POS-3120. It also
outlines the system specifications.
Sections included:
About This Manual
POS System Illustration
System Specifications
Safety Precautions
Experienced users can jump to chapter 2 on page 2-1
for a quick start.
CHAPTER
1

Chapter 1 Introduction
Page: 1-2 POS-3120 SERIES USER
′ S MANUAL
1-1. ABOUT THIS MANUAL
Thank you for purchasing our POS-3120 Series System. The POS-3120 is an
updated system designed to be comparable with the highest performance of
IBM AT personal computers. The POS-3120 provides faster processing speed,
greater expandability and can handle more tasks than before. This manual is
designed to assist you how to install and set up the whole system. It contains
four chapters and two appendixes. Users can configure the system according to
their own needs.
Chapter 1 Introduction
This chapter introduces you to the background of this manual. It also includes
illustrations and specifications for the whole system. The final section of this
chapter indicates some safety reminders on how to take care of your system.
Chapter 2 System Configuration
This chapter outlines the location of motherboard components and their
function. You will learn how to set the jumpers and configure the system to
meet your own needs.
Chapter 3 Software Utilities
This chapter contains helpful information for proper installations of the Intel
Utility, VGA Utility, LAN Utility, Sound Utility, and Touch Screen Utility.
Chapter 4 AMI BIOS Setup
This chapter indicates you how to change the BIOS configurations.
Appendix A System Assembly
This appendix gives you the exploded diagrams and part numbers of the POS-
3120.
Appendix B Technical Summary
This appendix gives you the information about the allocation maps for the
system resources, Watchdog Timer Configuration, and Flash BIOS Update.

Chapter 1 Introduction
POS-3120 SERIES USER ′ S MANUAL Page: 1-3
1-2. POS SYSTEM ILLUSTRATION
POS-3120 i-Button Type

Chapter 1 Introduction
Page: 1-4 POS-3120 SERIES USER
′ S MANUAL
POS-3120 Finger Printer Type

Chapter 1 Introduction
POS-3120 SERIES USER ′ S MANUAL Page: 1-5
POS-3120 Empty Type

Chapter 1 Introduction
Page: 1-6 POS-3120 SERIES USER
′ S MANUAL
POS-3120 SIDE VIEW

Chapter 1 Introduction
POS-3120 SERIES USER ′ S MANUAL Page: 1-7
1-3. SYSTEM SPECIFICATIONS
MAINBOARD (PROX3120LF)


CPU Type:
Intel
®
ATOM™ Pineview D525


Chipset:
Intel
®
ICH8M


Memory:
2 x DDR3 SO-DIMM Slot, 1G DDR3 SO-DIMM default (up to 4GB)


Cache:
Depended on CPU


Real-Time Clock / Calendar:
Embedded in Intel ICH8M South Bridge


BIOS:
AMI BIOS


Keyboard Connector:
PS/2 Keyboard, with mini DIN connecter on rear panel .


Mouse Connector:
PS/2 Mouse, with mini DIN connecter on rear panel .


Serial Port:
3 x DB-9, 1 x RJ45, +5V/ 12V selectable


Universal Serial BUS Port:
4 x USB2.0 ports
1 x USB2.0 on side bezel


LAN Function:
1 x 10/100/1000 Mbps


Audio Function:
1 x 2W Speaker

Chapter 1 Introduction
Page: 1-8 POS-3120 SERIES USER
′ S MANUAL


VGA Function:
1 x DB-15 VGA Interface


Dimension (W x H x D):
300mm x 299mm x 135mm (11.81" x 11.77" x 5.31")


System Weight:
4.5kg


LCD Panel:
Type XGA/SVGA
Max. Resolution 1024 x 768 / 800 x 600
Size/Type 10.4” / TFT
Viewing Angel (degree) +70°~-70°horizontal
+60°~-60°vertical
Brightness 300 / 230 cd / m2
Signal Interface (bit) TTL (18-bit)
LCD MTBF 20,000
Back Light MTBF (Hrs) 20,000


Touch Panel:
10.4” 5wire Analog resistive


Printer:
2” or 3” easy loading thermal printer with Auto cutter
(* Diameter of paper roll can not exceed 8 cm.)


I-Button (Optional):
Read only, output through PS/2 KB interface


MSR (Optional):
JIS-I or II, ISO Tracker 1+2+3 (PS/2 KB Interface)


Wireless LAN (Optional):
Mini PCIe Wireless LAN Module (802.11b/g/n, 1T1R)


Fingerprint (Optional):
Embedded Fingerprint module (USB interface)

Chapter 1 Introduction
POS-3120 SERIES USER ′ S MANUAL Page: 1-9
1-4. SAFETY PRECAUTIONS
The following messages are safety reminders on how to protect your systems
from damages, and extending the life cycle of the system.
1. Check the Line Voltage
a. The operating voltage for the power supply should be within the range of
100V to 240V AC; otherwise the system may be damaged.
2. Environmental Conditions
a. Place your POS-3120 on a sturdy, level surface. Be sure to allow enough
space around the system to have easy access needs.
b. Avoid installing your POS-3120 system in extremely hot or cold places.
c. Avoid exposure to sunlight for a long period of time (for example, in a
closed car in summer time. Also avoid the system from any heating
device.). Or do not use the POS-3120 when it has been left outdoors in a
cold winter day.
d. Bear in mind that the operating ambient temperature is between 0°C and
35°C (32°F and 95°F).
e. Avoid moving the system rapidly from a hot place to a cold place, and
vice versa, because condensation may occur inside the system.
f. Protect your POS-3120 against strong vibrations, which may cause hard
disk failure.
g. Do not place the system too close to any radio-active device. Radio-
active device may cause signal interference.
h. Always shutdown the operation system before turning off the power.
3. Handling
a. Avoid placing heavy objects on the top of the system.
b. Do not turn the system upside down. This may cause the hard drive to
malfunction.
c. Do not allow any objects to fall into this product.
d. If water or other liquid spills into the product, unplug the power cord
immediately.

Chapter 1 Introduction
Page: 1-10 POS-3120 SERIES USER
′ S MANUAL
4. Good Care
a. When the outside case gets stained, remove the stains using neutral
washing agent with a dry cloth.
b. Never use strong agents such as benzene and thinner to clean the surface
of the case.
c. If heavy stains are present, moisten a cloth with diluted neutral washing
agent or alcohol and then wipe thoroughly with a dry cloth.
d. If dust is accumulated on the case surface, remove it by using a special
vacuum cleaner for computers.

Page 2-1
SYSTEM
CONFIGURATION
Helpful information that describes the jumper and connector
settings, and component locations.
Sections included:
Jumper & Connector Quick Reference Table
Component Locations
Configuration and Jumper settings
Connector Pin Assignments
CHAPTER
2

Chapter 2 System Configuration
Page: 2-2 POS-3120 USER
’ S MANUAL
2-1. JUMPER & CONNECTOR QUICK REFERENCE TABLE
Connector & Jumper Name Page
COM Port & VGA Connector COM1, COM3, COM4, COM2-1,
JVGACOM2 2-7
COM Port RI and Voltage Selection JP_COM1, JP_COM2, JP_COM3,
JP_COM4 2-10
MINI-DIN and USB Connector JPS2USB1, USB5, USB6 2-14
LAN & USB Connector JRJ45USB1 2-15
Cash Drawer Connector DRW1, DRW2 2-16
Cash Drawer Power Selection JP14 2-17
Power LED Connector LED_1 2-18
Smart Fan Connector FAN1 2-18
Power Connector POWER1 2-18
Reset Switch Connector RST_SW1 2-19
Power for Thermal printer Connector PRT_PWR1 2-19
External Speaker Connector SPK1 2-19
Inverter Connector INV1, INV2 2-20
MSR/ Card Reader Connector PS2 2-21
Printer Connector LPT1 2-21
LVDS Connector LVDS1, LVDS2 2-22
SATA Connector SATA1 2-24
SATA Power Connector JPWR_4P1 2-24
Touch Panel Connector TOUCH1 2-25
Touch Panel Selection JP16 2-25
Clear CMOS Data Selection JP1 2-26
Compact Flash Connector CF1 2-27

Chapter 2 System Configuration
POS-3120 USER ’ S MANUAL Page: 2-3
2-2. COMPONENT LOCATIONS
2
41
3
1
23
4
5
61
2
5
6
1
2
2
16
5
5
6
1
2
5
6
1
2
1
4
9
13
14
12
85
21 24
20
16
1
2
5
6
1
69
5
1
2
5
6
COM3
9 1
10 212
3
4
PWR_IN1
1
3
1
3
1
2
1
2
21
78
2
1
7
8
1
11
1
1
1
4
1
2
3
4
1
7
1
4
1
415
9 1
10 2
203
73
2
72 71
74
1
204
203
73
2
72 71
74
1
204
1
19
20
2
1
29
30 2
17
1
2
3
15
1 6
5
1
106
1
2
14
2
1 9
10
1
14
13
26
1
3
1
1
4
POS-3120 Mainboard Front Connector, Jumper and Component locations

Chapter 2 System Configuration
Page: 2-4 POS-3120 USER
’ S MANUAL
M_PCIE1
12
15 16
17 18
51 52
POS-3120 Mainboard Rear Connector, Jumper and Component locations
