quadient IS-420 User manual

INSTALL AND CONNECT THE ELEMENTS: 1Hand feed table,
2Base, 3Catch tray.
CONNECT THE LAN to a network RJ45 plug of the Base and
to the LAN wall socket using the LAN cable B.
If included in your system, CONNECT THE SCALE (see its
Quick Install Guide).
OPEN THE BASE COVER,remove the headset protecting
strips and insert the headset in its compartment, then push
the headset back until it clicks.
WRITE DOWN THE PSD number, you may need the number
later. INSTALL THE PSD in one of the slots then close the cover. CONNECT THE SYSTEM POWERPLUG. Follow the installation wizard on the screen. Refer to the installation section in the User Guide.
IS-420 QUICK INSTALLATION GUIDE
CAUTION: use a solid and steady table, far
from any door or fan.
7
4
8
5
3
6
2
3
1
C
BC
A
1Check the box contents.
2
For more information about your mailing
system, please visit:
kbhelp.quadient.com/is420_dl

2c
1
3
4
2a
2b
IS-420
QUICK START GUIDE
K7
K8
K9
K4
K1
K2 K5
K6
K3
1st Letter
20/01/20
Mem: None
Acc t : 11
0000
0 g
No services
1st Letter
No services
20/01/20
0000
0 g
0000
0 g
For more specific information about your
mailing system, see the User Guide :
Press :
To reset the mailing system
Key the postage in directly
If you know the amount...
Choose rate and services
When the weight is displayed...
kbhelp.quadient.com/is420_ug_en_dl
Put your mail on the scale
To weigh your mail...
or
Enter the weight manually
Shortcut keys
Getting to know your mailing system
Applying postage
Changing the ink cartridge
Screen main areas
1
2
1
2
1
2
3
Current rate and selected
services are displayed in
this zone of the screen.
Rate and services (to change: K1)
Date printed (to change: K4)
Weighing type (to change: K6)
Imprint position oset
Postage and weight
Job memory (can contain rate, stamp settings
and account)
Current account
D1
D2
D3
D4
D5
D6
D7
K1
K2
K3
K4
K5
K6
K7
K8
K9
Rates and services selection
Memorized jobs (rate, stamp settings, account)
Credit management
Type of imprint and Imprint settings
Label printing
Weighing modes
Sleep / wake (amber / green)
Stops printing
Starts printing
Check that the D3 icon is .
Otherwise, press and then select the
option Standard weighing.
Press and then select the option
Manual weight entry.
Enter the weight and press OK.
Press OK to validate your selection and return
to the home screen.
Use the keypad to select an available Class
and/or Services, or select key 8 for the wizard.
To change the rate and/or add services:
Press .
The rate selection
screen is displayed.
2
On the new ink cartridge,
remove the protective
strips from the printing
heads.
Raise base cover and
follow instructions printed
on sticker inside.
Print the stamp
To print on labels
When the postage is displayed...
1
2
If you want to print on a label, see the alternative
sequence below.
Press to start the motors of your mailing
system.
Insert the mail piece in
the mail path, the
imprint printing position
on the upper right side.
Insert labels into the
dispenser until a click,
printing side facing the
right.
Press to enter the number of labels
to print and then press .
2
If jamming occurs... Adding credit
Press , type 2 and follow the instructions onscreen.
Note: to complete this operation successfully, your postal
services account must have a positive credit balance of the
corresponding amount.
Press on the control
panel to stop the motor.
Under the base, lift up
the release handle and,
using your other hand,
remove stuck envelope
or labels.
2
1
2
Type the amount on the keyboard.
Press OK.
The home screen
displays the postage.
4155897J/C - 29/05/2020
1
1
1
To clear the information on the screen.
To wake the machine up with default
settings.
To return to the home screen
1st Letter
No services
0000
0 g
Standard
1
Registered
3
Express
5
Courier
2
Priority
4
Wizard
6
D5
D6
D7
D4
D3
D2
D1
