quadient iX-5 Series User manual

Weighing Platform
Shelf
LAN Cable Power Cable MeterInk Cartridge
Lift machine slightly on the left hand side and align the hooks to attach the automatic feeder (b)
– attach the catch tray (c) to the right hand side of the machine.
5
Lift the cover of the machine to reveal the
ink cartridge (i) and meter (j) locations.
Attach the weighing platform (e) and
shelf (if applicable) (d).
6
Turn on the machine using the switch behind the
power cable (h) and follow the steps on screen.
8
Unpack all components from the box, remove packaging
and any transit tape.
Place the meter (j) into the meter bay and slide in until it fits securely
into position.
Insert the ink cartridge (i) at an angle into the machine with the ‘TOP’
and ‘LOCK’ stickers facing upwards. Push the ink cartridge (i) towards
the back of the machine until you hear a ‘click’ - close the cover of the
machine.
k
Machine Base
Automatic
feeder
Catch Tray
Machine components:
Back of the machine
4
13
2
1
7
Connect the weighing platform connector (f) and automatic feeder
cable (k) at the back of the machine. Then connect the LAN cable
(g) and power cable (h) to either side of the machine.
Weighing Platform
Cable
k
Automatic
feeder cable
Select LAN and press to test connection type.
OK
Installation Process
1 LAN
9
Follow the steps on screen to complete the
procedure
Next
Installation Process
Press the ‘Next’ to start the
Online service
declaration.
11
iX-5 Series Base
Quick Installation Guide
OK
Installation Process
Enter the registration PIN code
Enter the registration PIN code : 00000
10
00000
Mem For more information or if you experience any issues, please visit :
kbhelp.quadient.com/ix5_ug_en_dl
For more help with your installation, please visit: kb.quadient.co.uk/ix5_install

Shortcut keys
B1 Rates and Services selection
B2 Job Memory (rate, imprint settings and account)
B3 Credit management
B4 Label printing
B5 Weighing modes
B6 Type of imprint and Imprint settings
B7 Sleep/wake (amber/green)
B8 Stops printing
B9 Starts printing
Screen Information
A1 Rate and services (to change: B1)
A2 Date printed (to change: B6)
A3 Weighing type (to change: B5)
A4 Imprint position oset
A5 Type of imprint (to change: B6)
A6 Postage and weight
A7 Job Memory (can contain rate, imprint settings and account)
A8 Current account
A9 Reset counter : to perform this action, press the button on the
right side of the machine (N5)
A10 Credit
To reset the machine...
Press:
Adding credit
Press
choose ‘Credit’ and follow
the instructions on screen.
Note: in order to add credit to the
machine there must be funds available in
your postage account.
To access your full user guide,
please visit :
kbhelp.quadient.com/ix5_ug_en_dl
4
2. When the rollers start, insert the
mail into the machine from the
left hand side.
To seal the envelopes
1. To seal the envelopes (if applicable)
Use the button at the front of the
feeder. Check water level in the bottle.
When all steps are completed
print the imprint:
If you want to print on a label or
automatically seal the envelope,
check additional options below.
1. Press to start the motors of
your franking machine.
1. Insert labels into the dispenser until
a click, printing side facing the right.
2. Press to enter the number
of labels to print and then press
to clear the information
on screen.
to wake the machine
up with default settings.
to return to the home screen.
1st Inl. Letter
A0155977/A - 03/03/2023
00000
A9
Credit £ 1,000.00
Getting to know your franking machine Quick steps to franking your mail
