quadient IS-480 User manual

INSTALL AND CONNECT THE ELEMENTS: 1Feeder and
optional Dynamic Scale (see respective Quick Install Guides),
2Base, 3Catch tray.
If included in your system, CONNECT THE SCALE (see its
Quick Install Guide).
OPEN THE BASE COVER,remove the headset protecting
strips and insert the headset in its compartment, then push
the headset back until it clicks.
WRITE DOWN THE PSD number, you may need the number
later. INSTALL THE PSD in one of the slots and then close the cover.
CONNECT THE SYSTEM POWERPLUG. Follow the installation wizard on the screen. Refer to the installation section in the User
Guide.
IS-480 QUICK INSTALLATION GUIDE
CAUTION: use a solid and steady table, far
from any door or fan.
For more information about your mailing
system, please visit:
kb.quadient.co.uk/is480_ug
7
4
8
5
3
6
2
3
1
C
BC
A
1Check the box contents.
2
CONNECT THE LAN to a network RJ45 plug of the Base and
to the LAN wall socket using the LAN cable B.

1
3
2a
2b
IS-480
4
Press Clear or Wake
To reset previous settings...
Choose rate and services
When the weight is displayed...
Print the stamp
To print on labels:
To seal the envelopes:
A0021393/C -03/04/2020
For your installation Pin Code please visit
www.quadient.co.uk
Consumables,
contact Quadient Supplies:
0845 880 0002
Put your mail on the scale
To weigh your mail...
or
When the postage is displayed...
Enter the weight manually
Touchscreen main areas
Shortcut keys
Getting to know your mailing system
If jamming occurs...Changing the ink cartridge Adding credit
Applying postage
1
2
+
If needed, press to get back to the
home screen.
To get back to default rate settings,
press on the keyboard.
If the system is asleep, press to
wake it up with default settings.
1
2
3
1
2
If you want to print on a label or automatically
seal the envelope, check additional options
below.
Press to start the motors of your mail-
ing system.
Insert the mail piece in
the mail path, the
imprint printing
position on the upper
right side.
Current rate and select-
ed services are
displayed in this area of
the screen.
Insert labels into the
dispenser until a click,
printing side facing the
right.
Tap the D3 area on the screen to activate
( ) or deactivate ( ) the sealer.
(tactile areas: )
Rate and services
Date printed
Weighing type
Envelope sealing
Imprint position oset
Type of imprint (to change: K5)
Postage and weight
Memorized job (can contain rate, stamp settings
and account)
Current account
Credit (adding funds: K4)
D0
D1
D2
D3
D4
D5
D6
D7
D8
D9
K1
K2
K3
K4
K5
K6
K7
K8
Rates and services selection
Memorized jobs (rate, stamp settings, account)
Label printing
Credit management
Type of imprint and imprint settings
Sleep / wake (amber / green)
Stops printing
Starts printing
Press to enter the number of labels
to print and then press .
Tap the D2 area on the screen and select
(Standard weighing).
Tap the D2 area on the screen and
select (Manual weight entry).
Enter the weight and press OK.
Press OK to validate your selection and
return to the home screen.
Use rate buttons 1to 9to select an available
Class and/or Services, or select Rate wizard.
Press , type 2and follow instructions
onscreen.
Note: to complete this operation
successfully, your postal services
account must have a positive credit
balance of the corresponding amount.
To change the rate and/or add services:
Press .
The rate selection
screen is displayed.
Press on the control panel.
Under the base, lift up the release handle and,
using your other hand, remove envelopes or
labels from the mail run.
On feeder: raise cover, push down at the left
of upper blue lever to release mail runner.
Remove the jammed material then push down
on the mechanism to relocate.
1
23
On the new ink cartridge,
remove the protective
strips from the printing
heads.
Raise base cover and
follow instructions printed
on sticker inside.
1
2
1
2
D6
D7
D8
D9
D5
D1
D2
D3
D4
D0
K7
K8
K6
K2
K3
K4
K5
K1
For more specific information about your
mailing system, see the User Guide.
