quadient IS-6000 User manual

Installation Guide
IS-6000
Postage meter

Safety Requirements1.
Please read this section carefully before connecting or using your equipment.
Power Connection
Before powering up your Franking System, please check to ensure the system meets your
local AC voltage requirements. For information on power specifications, please refer to the
plates at the back of each System component.
In addition to checking the power requirements, we also recommend that you:
•Use an outlet that is easily accessible.
•Do not route the power cord between pieces of furniture or over sharp edges.
•Avoid using outlets controlled by wall switches or shared by other equipment.
•Make sure there is no strain on the power supply cord.
THIS EQUIPMENT MUST BE GROUNDED
•Only connect the power plug to an outlet provided with a
protective ground contact.
•To reduce the risk of fire, use only the power cord supplied
with the franking system.
•Do not use ground adaptors.
•Do not use this product on a wet floor or near water.
•In case of liquid spillage, disconnect the power cord from the
outlet and proceed to cleaning.
To reduce the risk of fire, only connect the modem to the telephone
lineusingsuppliedcable(seeSystemSpecificationsonpage321).
| Page 6 | aug-05-2014 10:23 |

Compliance
Energy Star® Compliance
Office equipment is generally powered on 24 hours a day, so power management features
are important for saving energy and reducing air pollution.
Your Postage Meter is an Energy Star® qualified Postage Meter that automatically goes
into a low-power 'Sleep' mode after a period of inactivity.
Spending a large portion of time in low-power mode not only saves energy but helps your
equipment run cooler and last longer.
Environmental compliance
A program is implemented for the recycling of worn Postage Meter at the end of their
lifetime. Contribute in a responsible way to the environmental protection by consulting your
retailer internet site, or by contacting him. He will inform you of the collection and treatment
processes of these machines.
CE compliance
Products presented in this guide conform to requirements of directives number 2006/95/CE
and 2004/108/CE.
This is a class A product. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user
will be required to correct the interference at his own expense.
| Page 7 | aug-05-2014 10:23 |

How to Turn the System ON/OFF
1. Press either side of the switch to turn the Postage Meter ON or OFF.
- The dash (or I) indicates the ON side.
- The circle (or O) indicates the OFF side.
After switching the system OFF, there may be a delay of up to 20
seconds to park the print head and free the remaining voltage.
System Sleep Mode
Your Postage Meter is Energy Star® qualified and automatically goes into a low-power
'Sleep' mode after a period of inactivity.
A very low-power 'Sleep' mode, called 'Soft-off' is also available.
•The Postage Meter will automatically switch to 'Sleep' mode after 2 minutes of
non-activity. The Supervisor can change this 2-minute default setting.
•The Postage Meter can be set to 'Sleep' mode manually by a short press on the
Sleep/Wake button.
•The Postage Meter can be set to 'Soft-off' mode manually by a long press on the
Sleep/Wake button.
The light located on the display indicates:
- Amber (continuous): the Postage Meter is in Sleep mode (low power mode).
- Amber (blinking): the Postage Meter is in Soft-off mode (very low power mode).
- Green: the Postage Meter is in Wake up mode and ready for use.
SLEEP / WAKE KEY
The Sleep/Wake key is located at the top right corner
of the control panel.
Wakes the Postage Meter up or turns it to 'Sleep' or
'Soft-off' mode.
Sleep/wake
| Page 31 | aug-05-2014 10:23 |

How to Switch Between 'Sleep' And 'Wake' Modes
1. Press the Sleep/Wake key to switch between “Sleep” and “Wake” modes.
To avoid weighing errors, make sure the Weighing Platform is clear
when you Wake up the machine.
Mail processing Start/Stop
To process mail, use the following keys.
START / STOP KEYS
Red button – Stops mail processing.
Stop
Green button – Starts mail processing.
Start
| Page 32 | aug-05-2014 10:23 |

2.GeneralSpecifications
Base
•Dimensions(cm) (Width x Length x Height): 64 x 22 x 34
•Weight: 21kg
•Power supply: 230 V (+/- 10 %) 3 prong
•Frequency: 50Hz
•Maximum Input Power: 294W
•Ambient Temperature:+10°Cto40°C
Relative Humidity: 20 % to 80 % relative humidity (without condensation).
Feeder
•Dimensions(cm) (Width x Length x Height): 46 x 80 x 35
•Weight:29kg
•Power supply: 120 V (+/- 10 %) 3 prong
•Frequency:50Hz
•Maximum Current Rating :5A
•Ambient Temperature: +10 °C to 40°C
•Relative Humidity: 20 % to 80 % relative humidity (without condensation).
Dynamic Weighing Module
•Dimensions(cm) (Width x Length x Height): 64.2 x 48.5 x 28
•Weight:17kg
•Power supply: 120 V (+/- 10 %) 3 prong
•Frequency:50Hz
•Maximum Input Power:71W
•Ambient Temperature:+10°Cto40°C
•Relative Humidity: 20 % to 80 % relative humidity (without condensation).
| Page 323 | | aug-05-2014 10:23 |

.SystemConnections
Base + Feeder
CAN
Power
| Page 324 | aug-05-2014 10:23 |

Base + Feeder + Dynamic Weighing Module
CAN
Power
| Page 325 | aug-05-2014 10:23 |

Base + Stacker
Power
| Page 326 | aug-05-2014 10:23 |

.SystemConnectors
Base connectors
On the left-hand side
The ON/OFF switch is located at the rear of the right
hand side of the Postage Meter base.
ON/OFF switch
To wall socket
Power connector
To Conveyor Stacker
Power connector
For future use
RJ 45
To any USB device*
USB ports
USB devices : Keyboard, Printer, Modem, LAN adaptor, Bar Code Reader…
All USB devices have to be plugged with the system powered OFF.
| Page 327 | | aug-05-2014 10:23 |

On the right-hand side
To any USB devices*USB ports
To Weighing Platform
RS232 (COM1/2)
To Feeder or Dynamic Weighing Module
CAN
To display
DVI Connector
Power connector
USB devices : Keyboard, Printer, Modem, LAN adaptor, Bar Code Reader…
All USB devices have to be plugged with the system powered OFF.
| Page 328 | aug-05-2014 10:23 |

Feeder connectors
Power connector
To Feeder or Dynamic Weighing Module
CAN
For future use
RJ45
Dynamic Weighing Module connectors
To BaseCAN
To Feeder
CAN
Power connector
| Page 329 | aug-05-2014 10:23 |

To BasePower connector
Conveyor Stacker connectors
Power connector
| Page 330 | aug-05-2014 10:23 |
