quadient IS-440 User manual

INSTALL AND CONNECT THE ELEMENTS: 1Feeder (see
respective Quick Install Guides), 2Base, 3Catch tray.
CONNECT THE LAN to a network RJ45 plug of the Base and
to the LAN wall socket using the LAN cable B.
OPEN THE BASE COVER,remove the headset protecting
strips and insert the headset in its compartment, then push
the headset back until it clicks.
WRITE DOWN THE PSD number, you may need the number later. INSTALL THE PSD in one of the slots and then close the cover. CONNECT THE SYSTEM POWERPLUG. Follow the installation wizard on the screen. Refer to the installation section in the User Guide.
IS-440 QUICK INSTALLATION GUIDE
CAUTION: use a solid and steady table, far
from any door or fan.
7
4
8
5
3
6
2
3
1
C
BC
A
1Check the box contents.
2
If included in your system, CONNECT THE SCALE (see its
Quick Install Guide).
For more information about your mailing
system, please visit:
kbhelp.quadient.com/is440_dl

2c
1
3
2a
2b
K7
K8
K9
K4
K1
K2 K5
K6
K3
4
Changing the ink cartridge If jamming occurs... Adding credit
IS-440
QUICK START GUIDE
For more specific information about your
mailing system, see the User Guide :
Shortcut keys
Getting to know your mailing system
Applying postage
Control display
Key the postage in directly
If you know the amount...
Choose rate and services
When the weight is displayed...
Put your mail on the scale
To weigh your mail...
or
Enter the weight manually
Press :
To reset the mailing system
1
2
1
2
K1
K2
K3
K4
K5
K6
K7
K8
K9
Rates and Services selection
Memorized jobs (rate, stamp settings, account)
Credit management
Type of imprint and Imprint settings
Label printing
Weighing modes
Sleep / wake (amber / green)
Stops printing
Starts printing
Press OK to validate your selection and
return to the home screen.
Rate and services (to change: K1)
Date printed (to change: K4)
Weighing type (to change: K6)
Imprint position oset
Type of imprint (to change: K4)
Postage and weight
Memorized job (can contain rate, stamp settings
and account)
Current account
Credit (adding funds: K3)
D1
D2
D3
D4
D5
D6
D7
D8
D9 1
2
1
2
To print on labels
To seal the envelopes
1
1
2
Check that the D3 icon is set to .
Otherwise, press and then select the
option Standard weighing.
Press and then select the option
Manual weight entry.
Enter the weight and press OK.
Type the amount on the keyboard.
Press OK.
The home screen
displays the postage.
3
1
2
Press on the control panel.
Under the base, lift up the release handle and,
using your other hand, remove envelopes or
labels from the mail run.
On feeder: raise cover, push down at the left of
upper blue lever to release mail runner.
Remove the jammed material then push down
on the mechanism to relocate.
Press , type 2 and follow
instructions onscreen.
Note: to complete this operation
successfully, your postal services
account must have a positive credit
balance of the corresponding amount.
Print the stamp
When the postage is displayed...
Use the button at the
front of the feeder deck.
Check water bottle level.
If you want to print on a label or automatically
seal the envelope, check additional options
below.
Press to start the motors of your
mailing system.
Insert the mail piece in
the mail path, the
imprint printing
position on the upper
right side.
Press .
The rate selection
screen is displayed.
4155898K/B - 30/03/2020
Current rate and select-
ed services are
displayed in this area of
the screen.
To change the rate and/or add services:
3
1
2
On the new ink cartridge,
remove the protective
strips from the printing
heads.
Raise base cover and
follow instructions printed
on sticker inside.
Use rate buttons 1 to 9 to select an available
Class or Service, or select Other selections
to gain access to the Rate wizard and Rate
history keys.
kbhelp.quadient.com/is440_ug_en_dl
Insert labels into the
dispenser until a click,
printing side facing the
right.
Press to enter the number of labels
to print and then press .
To clear the information on the screen.
To wake the machine up with default
settings.
To return to the home screen
1st Letter
0000
0 g
20/01/20
1st Letter
Mem:
None
OFF
Reset counterItems: 2
ABC
Funds Available 0
Homescreen - [Standard]
0000
0 g
1st Letter
No services
Standard
1
Registered
2
Express
3
Courier
4
Priority
5
Other selection
0000
0 g
Sig.ing
3
2
1st Letter
20/01/2020
0000
0 g
0 g
D2
D3
D4
D1 D6
D7
D8
D5
D9
