Razor E100S User manual

Owner’s Manual
NOTE: The E100/E100S/E125/E150 must be traveling up to 5kmh (3mph) before
motor will engage. Kick start up to 5kmh (3mph) while applying throttle to engage motor.
If you have any problems with this product in
the first instance please call 0118 973 6222.
Do not return product to store unless advise to do so.
CUSTOMER SERVICE
E100 PINK RAZE100-P
E100 RED RAZE100-09
E100 BLACK/SILVER RAZE100-SIL
E100S RAZE100S
Item Number:
v.1_10-11_Recreation
Read and understand this entire manual before riding!
DO NOT RETURN TO STORE!
This does not affect your statutory rights.
NOTE: Manual illustrations are for demonstration purposes only. Illustrations
may not reflect exact appearance of actual product. Specifications subject to
change without notice.

WARNING: Riding the electric scooter can be a hazardous activity.
Certain conditions may cause the equipment to fail without fault of the
manufacturer. Like other electric vehicles, the scooter can and is intended
to move, and it is therefore possible to lose control, fall off and/or get into
dangerous situations that no amount of care, instruction or expertise can
eliminate. If such things occur you can be seriously injured or die, even when
using safety equipment and other precautions. RIDE AT YOUR OWN RISK
AND USE COMMON SENSE.
This manual contains many warnings and cautions concerning the
consequences of failing to maintain, inspect or properly use your electric
scooter. Because any incident can result in serious injury or even death, we
do not repeat the warning of possible serious injury or death each time such
a possibility is mentioned.
APPROPRIATE RIDER USE AND
PARENTAL SUPERVISION
This manual contains important safety information. It is your responsibility
to review this information and make sure that all riders understand all
warnings, cautions, instructions and safety topics and assure that young
riders are able to safely and responsibly use this product. Razor recommends
that you periodically review and reinforce the information in this manual with
younger riders, and that you inspect and maintain your children’s vehicle to
insure their safety.
The recommended rider age is 8 and older. Any rider unable to fit comfortably
on the scooter should not attempt to ride it. A parent’s decision to allow his
or her child to ride this product should be based on the child’s maturity, skill
and ability to follow rules.
Keep this product away from small children and remember that it is
intended for use only by persons who are, at a minimum, completely
comfortable and competent while operating the scooter.
DO NOT EXCEED THE WEIGHT LIMIT OF 54 kg (120lb). Rider weight does not
necessarily mean a person’s size is appropriate to fit or maintain control of
the scooter.
Do not touch the brakes or motor on your scooter when in use as these parts
can become very hot.
ACCEPTABLE RIDING PRACTICES AND
CONDITIONS
Always check and obey any local laws or regulations which may
affect the locations where the electric scooter may be used.
Ride defensively. Watch out for potential obstacles that could catch your
wheel or force you to swerve suddenly or lose control. Be careful to avoid
pedestrians, skaters, skateboards, scooters, bikes, children or animals who
may enter your path, and respect the rights and property of others.
Do not activate the speed control on the hand grip unless you are on the
scooter and in a safe, outdoor environment suitable for riding. The electric
scooter must be moving at 5kmh (3 mph) before the motor will
engage.
Do not attempt or do stunts or tricks on your electric scooter. The scooter is
not made to withstand abuse from misuse such as jumping, curb grinding or
any other type of stunts.
Maintain a hold on the handlebars at all times.
Never allow more than one person at a time to ride the scooter.
Never use near steps or swimming pools.
Keep your fingers and other body parts away from the chain, steering system,
wheels and all other moving components.
Never use headphones or a cell phone when riding.
Never hitch a ride with another vehicle.
Do not ride your scooter in wet or icy weather and never immerse the scooter
in water, as the electrical and drive components could be damaged by water
or create other possibly unsafe conditions.
The electric scooter is intended for use on flat, dry surfaces such as
pavement or level ground without loose debris such as sand, leaves, rocks or
gravel. Wet, slick, bumpy, uneven or rough surfaces may impair traction and
contribute to possible accidents. Do not ride your scooter in mud, ice, puddles
or water. Avoid excessive speeds that can be associated with downhill rides.
Never risk damaging surfaces such as carpet or flooring by use of an electric
scooter indoors.
Do not ride at night or when visibility is limited.
PROPER RIDING ATTIRE
Always wear proper protective equipment such as an approved safety helmet
(with chin strap securely buckled). Elbow pads, kneepads, a long-sleeved shirt
and long pants are recommended. A helmet may be legally required by local
law or regulation in your area. A long-sleeved shirt, long pants, and gloves
are recommended. Always wear athletic shoes (lace-up shoes with rubber
soles), never ride barefooted or in sandals, and keep shoelaces tied and out
of the way of the wheels, motor and drive system.
USING THE CHARGER
The charger supplied with the electric scooter should be regularly examined
for damage to the cord, plug, enclosure and other parts, and in the event of
such damage, the scooter must not be charged until the charger has been
repaired or replaced.
Use only with the recommended charger.
Use caution when charging.
The charger is not a toy. Charger should be operated by an adult.
Do not operate charger near flammable materials.
Unplug charger and disconnect from scooter when not in use.
Do not exceed charging time.
Always disconnect from the charger prior to wiping down and cleaning your
scooter with liquid.
FAILURE TO USE COMMON SENSE AND HEED THE ABOVE
WARNINGS INCREASES RISK OF SERIOUS INJURY. USE WITH
APPROPRIATE CAUTION AND SERIOUS ATTENTION TO SAFE
OPERATION.
SAFETY WARNINGS
1
Safety Warnings ............................................................ 1
Before You Begin........................................................... 2
Assembly And Set-Up ................................................ 3-4
Connectors/Hardware Maintenance.............................. 4
Repair and Maintenance............................................. 5-6
Troubleshooting Guide................................................ 7-8
Electric Scooter Parts .................................................... 9
Warranty ...................................................................... 10
CONTENTS

Inspect the contents of box for scratches in paint, dents or kinked cables that may have occurred during
shipping.
MAKE SURE POWER SWITCH IS TURNED “OFF” BEFORE CONDUCTING ANY ASSEMBLY
OR MAINTENANCE PROCEDURES.
Razor recommends assembly by an adult.
BEFORE YOU BEGIN
2
WARNING:
DO NOT USE NON-
RAZOR PRODUCTS
WITH YOUR RAZOR
ELECTRIC SCOOTER.
Required Tools
(E100S ONLY) Bicycle-style tire pump
for Schrader valve
tires, with pressure
gauge
(Not included)
(E100S ONLY)
Twist Grip Throttle
Brake Lever
Seat
(if applicable)
Handlebar Stem
-Battery
-Motor
-Control Module
Limiter
Front Fork
Quick Release
-On/Off Switch
-Charger Port
-Reset Button
Charger
Plug
Charger
Port
Charger
(Note: Charger design may vary
from one shown)
Need Help? Call 0118 973 6222.

ASSEMBLY AND SET-UP
q Attaching Handlebars
q Inflating Tire
1Inflate front tire to PSI indi-
cated on sidewall of tire.
Note: The pressurized air
supplies found at gasoline
stations are designed to inflate
high-volume automobile tires.
If you decide to use such an
air supply to inflate the tire,
first make sure the pressure
gauge is working, then use very
short bursts to inflate to the
correct PSI. If you inadvertently
over-inflate the tire, release the
excess pressure immediately.
3Adjust tension of the quick
release to where you can close
lever all the way to secure stem.
q Attaching the Seat (if applicable)
2Unscrew four screws on
middle of deck.
3Place seat post on deck and
secure .
1 Attach seat to seat post.
3
Note: Make sure the cables/
wires are out of the way before
inserting the stem in the fork.
12

4
CONNECTORS/HARDWARE MAINTENANCE
Safety Gear
Always wear proper protective gear such as an approved safety
helmet. Elbow pads and kneepads are recommended. Always
wear athletic shoes (lace-up shoes with rubber soles), never ride
barefooted or in sandals, and keep shoelaces tied and out of the
way of the wheels, motor and drive system.
Battery
Make sure power switch is turned off whenever scooter is not in
use. Never store in freezing or below freezing temperatures!
Brake
Check brakes for proper function. When you squeeze lever, brake
should provide positive braking action. When you apply brake with
speed control on, brake cut-off switch should stop motor. Make
sure that brakes are not rubbing.
Frame, Fork and Handlebars
Check for cracks or broken connections. Although broken frames
are rare, it is possible for an aggressive rider to run into a curb or
wall and wreck and bend or break a frame. Inspect regularly.
Tires
Periodically inspect tires for excess wear, and regularly check
front tire pressure and re-inflate as necessary.
q
q
q
q
q
q Charging Battery
Charge battery prior to use.
•Initialchargetime:12hours • Runtime:Upto40minutesofcontinuousridetime
•Rechargetime:upto12hours • Averagebatterylife:250charge/dischargecycles
When scooter is not in regular
use, recharge battery at least
once a month until normal use is
resumed.
2
WARNING: Always
disconnect scooter from charger
before cleaning with liquid.
Note: If your charger does not
look like the one illustrated,
your unit has been supplied
with an alternative charger.
The specifications and charging
procedure would not change.
The charger has a small window
with one LED or two LEDs to
indicate charge status.
Chargers have built-in
protection to prevent battery
from being over-charged.
Charger may get warm during
use. This is normal for some
chargers and is no cause for
concern.
1Turn OFF power before
charging.
ASSEMBLY AND SET-UP
WARNING: Failure
to recharge the battery at least
once a month may result in
a battery that will no longer
accept a charge.
Charger
Charger
Plug
Charger
Port
Need Help? Call 0118 973 6222.

q Chain and Rear Tire Replacement
1Loosen screws and remove
chain guard.
2Using two 13mm wrenches,
loosen the locknuts by turning
the wrenches counter clockwise.
3 To loosed the chain, push the
tensioner down to create some
slack in the chain.
1 Loosen brake cable bolt.
q Front Tire Replacement
2Loosen front axle bolts.
Remove wheel and install
replacement wheel.
9-2
9-1
9-2
9-1
9-2
9-5
9-6
9-3
9-2
Right (Throttle)
9-3 - (Short) spacer
9-2 - Washers
9-1 - 17mm locknut
Left (Brake)
9-5 - (Long) spacer
9-2 - Washers
9-1 - 17mm locknut
Middle
9-6 - Front axle bolt
Note: Hardware sequence
5
REPAIR AND MAINTENANCE
Turn power “OFF” before conducting any maintenance procedures.
q Adjusting Brakes
1Thread brake lever adjuster
1/4 to 1/2 turn until desired
brake adjustment is attained. If
it still needs further adjustment,
proceed to step 2.
2 If too tight or has too much
slack, loosen brake cable and
adjust accordingly.
3 Inspect brake pads (A) for
proper alignment against wheel
or excess wear. To realign
brake pads, loosen fixing nut (B)
and adjust pad to contact rim.
Retighten and test. Readjust as
needed.

6
REPAIR AND MAINTENANCE
4 Remove wheel.
Note sequence of hardware:
19-1 M8 Nut
19-2 Washer
19-3 Plate cute washer
19-5 Spacer
5Push the chain tensioner
down to install the chain on
both sprockets.
6With two 13mm wrenches,
tighten the axle.
7Replace the chain guard.
Need Help? Call 0118 973 6222.
q Battery Care and Disposal
Do not store the battery in temperatures above 75° F (23.8° C) or below -10° F (-23.3° C).
CONTAINS SEALED NON-SPILLABLE LEAD BATTERIES. BATTERIES MUST BE RECYCLED.
Disposal: Your Razor product uses sealed lead-acid batteries which must be recycled or disposed of in
an environmentally sound manner. Do not dispose of a lead-acid battery in a fire. The battery may explode
or leak. Do not dispose of a lead-acid battery in your regular household trash. The incineration, land filling
or mixing of sealed lead-acid batteries with household trash is prohibited by law in most areas. Return
exhausted batteries to a federal or state approved lead-acid battery recycler or a local seller of automotive
batteries.
q Charger
The charger should be regularly examined for damage to the cord, plug, enclosure and other parts, and, in
the event of such damage, the scooter must not be charged until the charger has been repaired or replaced.
WARNING: If a
battery leak develops, avoid
contact with leaking acid and
place damaged battery in a
plastic bag. If acid comes into
contact with skin or eyes,
flush with cool water for at
least 15 minutes and contact a
physician.

7
TROUBLESHOOTING GUIDE
Scooter does not run
Scooter suddenly
stopped working while
in use
Short run time (less than
15 minutes per charge)
Scooter runs sluggishly
Problem Possible Cause Solution
Scooter must be traveling
5kmh (3 mph) before motor will
engage.
Battery needs a charge
Charger is not working
Tripped circuit breaker
Undercharged battery
Battery is old and will not accept
full charge
Brakes are not adjusted
properly
Riding conditions are too stressful
Tire is not properly inflated
Scooter is overloaded
Brake dragging
Brakes are not adjusted properly
Kick start to 5kmh (3mph) while twisting the throttle to engage motor.
Charge the battery. A new battery should be charged for at least 12
hours before using the scooter for the first time and up to 12 hours
after each subsequent use.
Check all connectors. Make sure the charger connector is tightly
plugged into the charging port and that the charger is plugged into
the wall.
Make sure power flow to the wall outlet is on.
Check all wires and connectors to make sure they are tight.
The circuit breaker (next to on/off switch) will automatically shut off
the power if the motor is overloaded.
An excessive overload, such as too heavy a rider or too steep a hill,
could cause the motor to overheat. If the scooter suddenly stops
running, wait a few seconds and then push the breaker to reset the
circuit. Correct the conditions that caused the breaker to trip to avoid
repeatedly tripping the breaker.
Charge the battery. A new battery should be charged for at least 12
hours before using the scooter for the first time and up to 12 hours
after each subsequent use.
Check all wires and connectors. Make sure the battery connector is
tightly plugged into the charger connector and that the charger is
plugged into the wall.
Make sure power flow to the wall outlet is on.
Even with proper care, a rechargeable battery does not last forever.
Average battery life is 1 to 2 years depending on scooter use and
conditions. Replace only with a Razor replacement battery.
Refer to adjusting the brakes instructions on page 5.
Use only on solid, flat, clean and dry surfaces such as pavement or
level ground.
The tire is inflated when shipped, but it invariably will lose some
pressure between the point of manufacturing and your purchase.
Refer to instructions on page 3 of this manual to properly inflate tire.
Make sure you do not overload the scooter by allowing more than
one rider at a time, exceeding the electric scooters 54kg (120lbs)
maximum weight limit, going up a hill or towing objects behind the
scooter. If the scooter is overloaded, the circuit breaker may trip and
shut off power to the motor. Correct the riding conditions that caused
the overload, wait a few seconds, and then push the breaker to reset
the circuit. Avoid repeatedly tripping the circuit breaker.
Turn off scooter and use your fingers to twist the adjuster in either
direction until front wheel is centered between pads.
Refer to adjusting the brakes instructions on page 5.

8
TROUBLESHOOTING GUIDE
Sometimes the scooter
doesn’t run, but other
times it does
Scooter makes loud
noises or grinding sounds
Problem Possible Cause Solution
Loose wires or connectors
Motor or electrical switch
damage
Chain is too dry
Check all wires around the motor and all connectors to make sure
they are tight.
Contact your local Razor authorized service center for diagnosis and
repair.
Apply a lubricant such as 3 in 1TM or Tri-FlowTM to the chain.
For more helpful troubleshooting guides, visit us at www.razor.com.
Need Help? Call 0118 973 6222.

9
Keep your scooter running for years with genuine Razor parts. Visit our web site or e-mail us for more information on spare part availability.
(Specifications subject to change without notice.)
E100 SERIES ELECTRIC SCOOTER PARTS
01 Handlebar grip (right/left)
02 Single speed twist grip throttle
02-1 Sleeve
03 Handlebar stem
04 Brake lever assembly
05 Quick release lever
06 Headset (upper/lower)
07 Front fork
07-1 V Spring push button
08 Limiter
09 Front wheel complete
(refer to pg. 5 for hardware sequence)
10 Front caliper brake with brake pad
11 On/ Off switch
12 Charger port
13 Reset button
14 Control module
15 Battery (2- 12V/ 4.5Ah)
16 Kickstand
17 Motor (24V / 100W)
18 Rear wheel complete
(refer to pg.6 for hardware sequence)
19 Chain Tensioner
20 Chain
21 Chain guard
22 Deck plate with grip tape
23 Seat with post (if applicable)

10
Razor Limited Warranty
The manufacturer warranties this product to be free of manufacturing defects
for a period of 90 days from date of purchase. This Limited Warranty does
not cover normal wear and tear, tires, tubes or cables, or any damage, failure
or loss caused by improper assembly, maintenance, or storage or use of the
Razor electric scooter.
This Limited Warranty will be void if the product is ever
•usedinamannerotherthanforrecreationortransportation
•modiedinanyway;
•rented.
The manufacturer is not liable for incidental or consequential loss or damage
due directly or indirectly to the use of this product.
WARRANTY
Razor does not offer an extended warranty. If you have purchased an
extended warranty, it must be honored by the store at which it was
purchased.
For your records, save your original sales receipt with this manual and write
the serial number below.
10/2011
U.S. Design Patent D497,397 S
Printed in China for:
Razor USA LLC
Distributed in the UK by:
Re:creation Group PLC,
Alberto House, Marino Way,
Hogwood Lane, Finchampstead,
Berkshire, RG40 4RF
Copyright © 2003-2012 Razor USA LLC. All rights reserved. RAZOR and the Razor Logo Design are
among the registered trademarks of Razor USA LLC in the United States and/or select foreign coun-
tries. eSpark is trademark of Razor USA.
Need Help? Call 0118 973 6222.
E100 PINK RAZE100-P
E100 RED RAZE100-09
E100 BLACK/SILVER RAZE100-SIL
E100S RAZE100S
Item Number:
