JEFFERIES 10X12 FT
OCTAGON SOFT TOP GAZEBO
ASSEMBLY INSTRUCTIONS
ITEM#: A101013211
SKU# 810490385
Need help? We are here for you! 1(866)578 – 6569 24/7 • Toll Free

•Please read and understand this entire manual before attempting to assemble or install the product.
•Before beginning assembly of product, make sure all parts are present. Compare parts with package contents list and
hardware contents list. If any part is missing or damaged, do not attempt to assemble the product.
•The assembled gazebo should be located at least 6 feet from any obstruction such as fence, garage, house, overhanging
branches, laundry lines or electrical wires.
•Some parts may contain sharp edges. Wear protective gloves if necessary, during assembly.
•This unit is heavy. For safety, do not assemble this item alone. Two people are recommended for safe assembly.
•Check all nuts and bolts periodically for tightness and, when required, tighten them again.
•Pay attention to the parts orientation
• Install the gazebo on level ground.Stakes are provided to secure the gazebo to the ground.
• Do not assemble the gazebo on sandy, muddy or loose soil, as stakes do not have enough anchorage in these types of soil.
• If you wish to secure the gazebo to a wood deck or concrete surface, use anchors suited to these surfaces.
•Snow must be cleared off regularly during snowy days.Remove the snow at the roof top when it is thicker than 2 inches. In order to
avoid damage, use a plastic snow rake to remove excessive snow and ice buildup from roof and keep away from falling debris.
• Do not leave the gazebo where there is a risk of high wind, as possible damage will occur to the structure.
•Any assembly or maintenance of the product must be carried out by adults only.
• Please check your state and local regulations prior to purchasing. Some jurisdictions may require permits for installation and
use. Some special procedures may be valid in your area.
• Keep all flame and heat sources away from the tent fabric. This tent is made with fabric that meets CPAI-84 specifications for
flame resistance. It is not fire proof. The fabric will burn if right in continuous contact with any flame source. The application of
any foreign substance to the tent fabric may render the flameresistant properties ineffective.
• If any scratch paint, please touch up to prevent rusting
• For outdoor use only.
WARRANTY:
WARNINGS:
• Steel components for this gazebo are treated with rust inhibiting paint that protects it from rusting. However, due to the nature
of steel, surface oxidation (rusting) will occur if these protective coatings are scratched. This is not a defect and thus not covered
by the warranty.
• To minimize this condition, it is recommended to use care when assembling and handling the product to prevent scratching the
paint. Should any scratching or damage occur, it is recommended to cover the scratch immediately with rust inhibiting paint
(not included).
•Surface rust can also be easily removed with a very light application of regular cooking oil or WD-40. If surface oxidation (rusting)
occurs and if no measure is taken to prevent this, the oxidation may start dripping onto deck or patio and caused damaging
stains, which may be difficult to remove. This can be prevented if the above-mentioned measures are taken to keep the product
from oxidizing.
• Do not use bleach, acid, or other abrasive cleaners on the roof or frame parts.
• Keep instruction manual for future reference.
• Keep the original packaging to store the gazebo.
• Periodically check and ensure that all bolts are well-tighten during use
MAINTENANCE
GENERAL BEST PRACTICES FOR ASSEMBLY:
WHAT IS COVERED ?
The limited warranty is extended to the original purchaser and applies to material and manufacturer’s defect provided
the item is maintained with care and used only for personal, residential purposes.
Warranty: 1 Year
2/19

PARTS LIST
Label Part Number Description Qty Part Image
A1 P000200558 Top post 8
A2 P000200559 Bottom post 1 4
A3 P000200560 Bottom post 2 4
B1 P000401084 Left long
screen
2
B2 P000401085 Right long
screen 2
C P000401086 Short screen 6
D1 P000601864 Upper Beam 8
D2 P000601865 Beam 8
D3 P005700791 Adjust tube 8
E1 P000601862 Big roof short
tube 2
E2 P000601863 Big roof long
tube
2
F P000501520 Big roof
connection tube
4
G P000601861 Small roof beam 8
HP000501519 Small roof
connection tube 1
I P005800001 Hook 1
L2 P006200018 Panel 4
3/19

HARDWARE LIST
Label Part Number Description Qty Add Part Image
AA H010020011 M6*15 Bolt 40 2
BB H010020012 M6*20Bolt 16 1
CC H050030001 Flat washer
M6 60 3
DD H050020017 Spring
washer M6 34 2
EE H070010003 Stake
Φ8*180 16 0
FF P005100264 Ring 52 3
GG H010020026M6*50 Bolt 2 1
HH H040010004 Nut M6 2 1
Z1 H090010017 Wrench M6 2 0
M P001100632 Small roof
canopy
1
N P001100633 Big roof
canopy
1
O P001200253 mosquito 1
4/19

HELPFUL HINTS
• Tools needed and not included
• Separating parts before starting
Provided in hardware pack
How many people needed for the installation work
5/19

STEP 1
Assembled View:
Insert the Bottom post(A2/A3) to the Top
post(A1),fixed with Bolt(AA) and Flat
washer(CC) by Wrench(Z1)
6/19

STEP 2
Assembled View:
Fixed Short screen(C） to the Top post(A1)
with Bolt(AA),Flat washer(CC) and Spring
washer(DD), then fixed Panel(L2) to the
Bottom post(A2/A3）with Bolt(BB) and
Flat washer(CC) ，tighten by Wrench(Z1).
7/19

STEP 3
Assembled View:
Fixed Left long screen(B1) to Right long
screen(B2) with Bolt(GG),Flat washer(CC)
Spring washer(DD) and Nut(HH), tighten by
Wrench(Z1).
8/19

STEP 4
Assembled View:
Fixed assembled Long screen (B1/B2) and
Short screen(C) to the Top post(A1) with
Bolt(AA),Flat washer(CC) and Spring
washer(DD), tighten by Wrench(Z1).
9/19

STEP 5
Assembled View:
Lock the Big roof short tube(E1),Big roof
long tube(E2) and Big roof connection
tube(F) with a snap.
10/19

STEP 6
Assembled View:
Lock the Upper Beam(D1) and Beam(D2)
with a snap, then lock Beam(D2) and Adjust
tube(D3) with a snap.
11/19

STEP 7
Assembled View:
Lock Upper Beam(D1) and Big roof connection
tube(F) with a snap, then insert the Beam(D2)
to Top post(A1)
12/19

STEP 8
Assembled View:
Spread the Big roof canopy(N) to big roof, do
not tighten the canopy first.
13/19

STEP 9
Assembled View:
Lock Small roof beam(G) and Small roof
connection tube(H) with a snap.
14/19

STEP 10
Assembled View:
Spread Small roof canopy(M) to the Small
roof beam(G), tighten it
15/19

STEP 11
Assembled View:
Attach the assembled small roof on the big
roof, Lock Small roof beam(G) and Big roof
connection tube(F) with a snap, then attach the
Hook(I) to Small roof connection tube(H).
16/19

STEP 12
Assembled View:
Attach the Big roof canopy(N)'s corner
(without belt) to Adjust tube(D3),then attach
the final canopy corner(with belt) to Adjust
tube(D3),tighten them.
17/19

STEP 13
Hang the mosquito(O) to netting tube with
Ring(FF). Tie the netting to post with a
bandage.
1
1
Please do the matching of
zippers for different panels
as showing the picture
Assembled View:
18/19

STEP 14
Assembled View:
Fix the Bottom post(A2/A3) to the ground by
Stake(EE)
