Reer SAFEGATE M SG BOX RST User manual

www.reersafety.com
M SG BOX RST
8 8541290 01 • 24/03/2020 • Rev.0
INTERCONNECTION MODULES
SAFEGATE M SG BOX RST
GENERAL
The SAFEGATE M SG BOX RST modules are accessory devices designed to make the wiring of the
SAFEGATE S / SAFEGATE TRX-S, barriers fast and safe, as well as provide the main controls
necessary for their operation close to the protected gate.
In addition to the safety relays with guided contacts piloted and monitored by the light curtain, terminal
blocks for connecting the cables, jumpers and dip-switches for the configuration of the barrier itself.
DESCRIPTION
M SG BOX RST is characterized by:
Luminous push-button for restart and output status indication.
Connectors for wiring the box to the barrier:
12 M12-8 poles male for TRX-S Active Element (or SAFEGATE S Receiver);
12 M12-5 poles female for SAFEGATE S Emitter.
Fairlead for the connections toward the machine of:
power supply;
connection with the output contacts of the internal safety relays and relative EDM;
output signals which indicate the status of the safety light curtain.
Figure 4 - M SG BOX RST –Connections and signals
KEY SELECTOR FOR
OVERRIDE
CABLE
FAIRLEAD
CONNECTOR
EMITTER
(SAFEGATE S)
CONNECTOR
ACTIVE ELEMENT
(SAFEGATE TRX-S)
RECEIVER
(SAFEGATE S)

M SG BOX RST
www.reersafety.com
8541290 01 • 24/03/2020 • Rev.0 9
CONFIGURATION
The configuration of the operating modes is described below.
This configuration is performed following the descriptions of the tables below, by setting the various
jumper, connectors and dip-switches located on the main board.
Figure 5 –Main board

www.reersafety.com
M SG BOX RST
10 8541290 01 • 24/03/2020 • Rev.0
SELECTION OF OPERATION MODES (DIP-SWITCH SW1-SW2)
Automatic Mode
Automatic Mode without EDM
DIP-SWITCH
SW1
1
2
3
4
5
6
7
8
on
█
█
off
█
█
█
█
█
█
DIP-SWITCH
SW2
1
2
3
4
5
6
7
8
on
█
off
█
█
█
█
█
█
█
Automatic Mode with EDM internal relays
DIP-SWITCH
SW1
1
2
3
4
5
6
7
8
on
█
█
off
█
█
█
█
█
█
DIP-SWITCH
SW2
1
2
3
4
5
6
7
8
on
█
█
off
█
█
█
█
█
█
Automatic Mode with EDM exernal relays
DIP-SWITCH
SW1
1
2
3
4
5
6
7
8
on
█
█
off
█
█
█
█
█
█
DIP-SWITCH
SW2
1
2
3
4
5
6
7
8
on
█
█
off
█
█
█
█
█
█

M SG BOX RST
www.reersafety.com
8541290 01 • 24/03/2020 • Rev.0 11
SELECTION OF OPERATION MODES (DIP-SWITCH SW1-SW2)
Modalità Manuale
Manual Mode without EDM
DIP-SWITCH
SW1
1
2
3
4
5
6
7
8
on
█
█
off
█
█
█
█
█
█
DIP-SWITCH
SW2
1
2
3
4
5
6
7
8
Manual Mode without EDM internal relays
DIP-SWITCH
SW1
1
2
3
4
5
6
7
8
on
█
█
off
█
█
█
█
█
█
DIP-SWITCH
SW2
1
2
3
4
5
6
7
8
on
█
█
off
█
█
█
█
█
█
Manual Mode without EDM external relays
DIP-SWITCH
SW1
1
2
3
4
5
6
7
8
on
█
█
off
█
█
█
█
█
█
DIP-SWITCH
SW2
1
2
3
4
5
6
7
8
on
█
█
off
█
█
█
█
█
█
Range Selection (SAFEGATE S)
DIP-SWITCH
SW2
5
6
Low range
on
█
off
█
5
6
on
█
High range
off
█
5
6
on
TEST
off
█
█
SELECTION STATIC OUTPUTS / RELAYS (CJ12)
JUMPER
PIN
DESCRIPTION
SELECTION PRESET
1A <–> 2A
1B <–> 2B
Static outputs
Internal Relays
2A <–> 3A
2B <–> 3B
Internal Relays

www.reersafety.com
M SG BOX RST
12 8541290 01 • 24/03/2020 • Rev.0
INSTALLATION AND ELECTRIC CONNECTIONS
The M SG BOX RST modules can be fixed to the wall, using the proper plastic brackets inserted in
the holes placed on the box rear side corners. These brackets can easily rotate to reach 90°.
The light curtain must be connected to the respective connectors M12 (Fig.1) using the dedicated
cables.
The cables coming out from the cable gland (PG11) must be connected - depending on its
utilization - to the connectors CJ1, CJ2 and CJ3. Terminal tightening torque: 4,4lb-in (0,5 Nm) is
mandatory.
Use 60/75°C copper (Cu) conductor only. Wire size range: AWG 12÷30, (solid/stranded) (UL).
Terminal board CJ1
CLAMP
NAME
DESCRIPTION
1
NA2_B
Ends of the contact normally open n. 2
2
NA2_A
3
NA1_B
Ends of the contact normally open n. 1
4
NA1_A
5
NCB
Ends of contacts normally closed, in parallel
6
NCA
Figure 6 –M SG BOX RST connection sample
Terminal board CJ2
CLAMP
NAME
DESCRIPTION
1
+24Vdc
24 20%
2
0V
0 Vdc
3
PE
Protective Earth
4
-
-
Terminal board CJ3
CLAMP
NAME
DESCRIPTION
1
OSSD1
Safety status output 1
2
OSSD2
Safety status output 2
3
K1_K2
Feedback external relays K1/K2 input
4
-
-
5
SEL_A
Operation mode selection
6
SEL_B
Operation mode selection

M SG BOX RST
www.reersafety.com
8541290 01 • 24/03/2020 • Rev.0 13
SIGNALS
SIGNAL
CONDITION
MEANING
OUTPUT STATUS
(White)
ON
Outputs active
OFF
(Low intensity blinking)
Light curtain occupied: outputs disabled
SAFETY RELAYS TECHNICAL DATA
The M SG BOX RST module uses two safety relays with guided contacts for the output circuit.
These relays are specified by the manufacturer for voltages and currents greater than those indicated
in the technical data; nevertheless to guarantee correct insulation and avoid damage or premature
aging, protect each output line with a 3.15 A delayed fuse and verify that the features of the load
conform to the indications on the following table.
TECHNICAL DATA
Number of contacts
2N.A. - 1N.C.*
Relay category (according to
EN60947-5-1)
AC15 / DC13
Max commutable voltage
250Vac, 24Vdc
Min commutable voltage
10Vac/10Vdc
Max commutable current
2A
Min commutable current
10mA@24Vdc
Number of commutations (life)
> 50 x 103 (el) / > 40 x 106 (mech)
* 1N.C. = DO NOT USE AS A SAFETY CONTACT
MECHANICAL DIMENSIONS
All dimensions are expressed in mm

www.reersafety.com
M SG BOX RST
14 8541290 01 • 24/03/2020 • Rev.0
INDICATIONS AND INFORMATION FOR ENVIRONMENTAL PROTECTION
Dispose of the product in an eco-compatible manner and in accordance with national legislation.
For Countries in the European Union:
Pursuant to the Directive no. 2012/19/EU on waste electrical and electronic equipment (WEEE)
The crossed out wheelie-bin symbol on the equipment or its packaging means that when the product
reaches the end of its useful life it must be collected separately from other waste.
Proper separate collection of the discarded equipment for later environment-friendly recycling,
processing and disposal, helps to avoid any negative impact on the environment and health and
encourages re-use and recycling of the materials the equipment is made of.
In each individual Member State of the European Union this product is required to be disposed of in
accordance with Directive 2012/19/EU as implemented in the Member State where the product is
disposed of.
For further information please contact ReeR or your local dealer.
Precise, complete compliance with all standards, instructions and warnings in this handbook is essential for the
correct operation of the device.
ReeR S.p.A. therefore declines any responsibility for all and anything resulting from failure to comply with all or
some of the aforesaid instructions.
Characteristics are subject to change without prior notice. No part of this document may be reproduced unless authorised by ReeR.

www.reersafety.com
M SG BOX RST
16 8541290 01 • 24/03/2020 • Rev.0
All REER Safegate manuals and configuration software are available at
www.reersafety.com/download/safegate
