Sauder 417886 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-18
Français pg 19-21
Español pg 22-24
Lot # 369714 03/06/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
4-Drawer Chest
Primary Street Collection | 417886
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
WARNING
CHOKING HAZARD - Small Parts
Not for children under 3 years.
Adult assembly required.

Table of Contents Assembly Tools Required
3
4
5-18
19-21
22-24
25-26
27
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
417886 www.sauder.com/servicesPage 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C TOP (1)
D BOTTOM (1)
E BACK (2)
F BRACE (1)
G BASE (1)
H RED DRAWER FRONT (1)
I YELLOW DRAWER FRONT (1)
J GREEN DRAWER FRONT (1)
K BLUE DRAWER FRONT (1)
L DRAWER BRACE (4)
D36 DRAWER RIGHT SIDE (4)
D37 DRAWER LEFT SIDE (4)
D79 DRAWER BACK (4)
D984 DRAWER BOTTOM (4)
Now you know
our ABCs.
417886www.sauder.com/services Page 3
A
B
C
D
E
F
G
H
L
D36
D984
D79
D37
E
J
I
K
or
or

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
DRAWER FRONT
BRACKET - 4
9G 5L WARNING LABEL - 4
(Refer to the last step for proper
location and application)
WARNING
Serious or fatal crushing injuries can occur
from furniture tip-over. To help prevent
tip-over:
• Place heaviest items in the lowest drawers.
• Unless specifically designed to accommodate, do not
set TVs or other heavy objects on top of this product.
• Never allow children to climb or hang on drawers,
doors, or shelves.
• Never open more than one drawer at a time.
• If equipped with a drawer interlock system, do not
defeat or remove it.
Use of tip-over restraints may only reduce, but not
eliminate, the risk of tip-over.
This is a permanent label. Do not attempt to remove!
04/10 332296
SAFETY STRAP - 1
Locate this nylon SAFETY
STRAP (60M) to be used
later in assembly. Do not
accidentally throw away.
60M SAFETY DRYWALL
ANCHOR - 1
61M
35AA UNIVERSAL CABINET RAIL - 8 35AC DRAWER RIGHT - 4 35AD DRAWER LEFT - 4
WASHER - 1
13M
SILVER 1/2" MACHINE SCREW - 16
38S
METAL
BRACKET - 4
4G
BLACK 9/16" LARGE HEAD SCREW - 9
1S BLACK 1-7/8" FLAT HEAD SCREW - 4 2S
3S GOLD 5/16" FLAT HEAD SCREW - 32
METAL PIN - 6
1R
CAM SCREW - 4
8F
HIDDEN CAM - 14
1F
CAM DOWEL - 10
2F
30S BLACK 1-9/16" FLAT HEAD SCREW - 20
SMALL WASHER - 16
77M
417886 www.sauder.com/servicesPage 4

417886www.sauder.com/services Page 5
Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty carton
to avoid scratching your unit or the floor.
å Push fourteen HIDDEN CAMS (1F) into the ENDS (A and B),
BOTTOM (D), BRACE (F), and DRAWER BRACES (L). Then,
insert the metal end of a CAM DOWEL (2F) into each HIDDEN
CAM, except in the DRAWER BRACES (L).
(14 used)
(10 used)
Arrow
1F
2F Do not tighten the HIDDEN CAMS in this step.
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
A
B
D
F
L
L
L
L
Do not insert
CAM DOWELS
into these parts.
Arrow
The arrow in the HIDDEN
CAM must point toward the
hole in the edge of the board.
Hole

417886 www.sauder.com/servicesPage 6
Step 2
å Turn four CAM SCREWS (8F) into the
DRAWER FRONTS (H, I, J, and K).
H
J
I
K
8F
Remember:
Righty tighty.
Lefty loosey.

å Fasten the UNIVERSAL CABINET RAILS* (35AA) to
the ENDS (A and B). Use sixteen GOLD 5/16" FLAT
HEAD SCREWS (3S) through holes #1 and #3.
å *patent pending glide system
Step 3
417886www.sauder.com/services Page 7
A
B
Finished edge
Surface with
HIDDEN CAMS
Surface with
HIDDEN CAMS
GOLD 5/16" FLAT HEAD SCREW
(16 used in this step)
3S
3
2
1
1
2
3
Finished edge
Glide end
Glide end
3
2
13
2
13
2
1
1
2
31
2
31
2
3

417886 www.sauder.com/servicesPage 8
Step 4
å Fasten the LEFT END (B) to the TOP (C). Tighten two
HIDDEN CAMS.
Start Tihten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
B
Surface
with
HIDDEN
CAMS
Finished edge
Finished edge
Surface with holes
C

å Insert four METAL PINS (1R) into the holes in the TOP (C).
å Push the BACKS (E) onto the METAL PINS in the TOP (C).
Step 5
417886www.sauder.com/services Page 9
C
E
E
1R
Printed information on one of the
BACKS (E) must be facing down.

417886 www.sauder.com/servicesPage 10
Step 6
å Fasten the BOTTOM (D) to the LEFT END (B). Tighten two
HIDDEN CAMS.
å Fasten the BOTTOM (D) to the BACKS (E). Use four
BLACK 1-7/8" FLAT HEAD SCREWS (2S).
BLACK 1-7/8" FLAT HEAD SCREW
(4 used in this step)
2S
Arrow
Minimum
190 degrees
Maximum
210 degrees
Surface with HIDDEN CAMS
These holes
must be here.
BE
E
D
