Sauder Original Cottage Collection 414684 User manual

PLEASE CONTACT US
BEFORE RETURNING
YOUR UNIT TO THE STORE
1-800-523-3987
www.sauder.com
Made in the USA
Archbold, OH
NOTE: THIS INSTRUCTION BOOKLET CONTAINS
IMPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
English.................... Page 1-19
Français...............Pages 20-22
Espanol.............Páginas 23-25
Lot #: 351312 03 / 05 / 13
Date Purchased: ____________________
414684
Side Table
Original Cottage Collection

ASSEMBLY TOOLS REQUIRED
Hammer
No. 2 Phillips Screwdriver
Tip Shown Actual Size
ADULT ASSEMBLY REQUIRED
TABLE OF CONTENTS
Part Identification.......................3
Hardware Identification .............4
Assembly Steps....................5-19
Français..............................20-22
Espanol...............................23-25
Safety .......................................26
Warranty...................................27
Page 2 www.sauder.com/services 414684

PART IDENTIFICATION: While not all parts are labeled, some of the parts will have a label or an inked
letter on the edge to help distinguish similar parts from each other. Use this PART IDENTIFICATION to help
identify similar parts.
A RIGHT END 1
B LEFT END 1
C TOP 1
D BOTTOM 1
E BACK 1
F ADJUSTABLE SHELF 1
G RIGHT FRONT/LEFT REAR LEG 2
H LEFT FRONT/RIGHT REAR LEG 2
I SKIRT 2
J DRAWER FRONT 1
K DRAWER FRONT MOLDING 1
L SIDE MOLDING 2
D110 DRAWER SIDE 2
D111 DRAWER BOX FRONT 2
D718 DRAWER BOTTOM 1
Page 3
www.sauder.com/services414684
A
B
C
D
E
F
G
H
I
J
K
L
D718
D110
D110 D111
D111
G
H
I
L

HARDWARE IDENTIFICATION
Screws are shown actual size. You may receive extra hardware with your unit.
Page 4 www.sauder.com/services 414684
RIGHT CABINET RAIL - 1
MLEFT CABINET RAIL - 1 N O RIGHT DRAWER SLIDE - 1
PLEFT DRAWER SLIDE - 1 HIDDEN CAM - 22
1F CAM SCREW - 12 8F
CAM DOWEL - 10
2F
BLACK 9/16" FLAT HEAD SCREW - 4
32S
KNOB - 1
63K
BLACK 9/16" LARGE HEAD SCREW - 12
1S
GOLD 5/16" FLAT HEAD SCREW - 4
3S
METAL PIN - 4
1R
METAL BRACKET - 2
4G
BLACK 1-5/8” PAN HEAD SCREW - 1
27S
BLACK 1-7/8" FLAT HEAD SCREW - 2
2S
BLACK 7/8" LARGE HEAD SCREW - 2
17S
RUBBER SLEEVE - 4
2R
BLACK 1-15/16" FLAT HEAD SCREW - 2
4S
19G LARGE METAL BRACKET - 4 CAM COVER - 4 33P
SILVER 1/2" FLAT HEAD SCREW - 4
78S
BLACK 1-9/16" FLAT HEAD SCREW - 8
30S

Look for this icon. It means a video
assembly tip is available at:
www.sauder.com/services/tips
1
1
S
t
e
p
Page 5
www.sauder.com/services414684
Assemble your unit on a carpeted floor or on the empty carton to avoid scratching your unit or the floor.
Push twenty-two HIDDEN CAMS (1F) into the ENDS (A and B), BOTTOM (D), and BACK (E). Then, insert the metal end of the
CAM DOWELS (2F) into the HIDDEN CAMS, except in the long edges of the ENDS.
Do not insert CAM
DOWELS into these edges.
Arrow
Hole
A
B
D
E
Do not tighten the HIDDEN CAMS in this step.
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Arrow
1F
Arrow
1F
Arrow
(10 used)
(22 used) 1F
2F

2
2
S
t
e
p
Page 6 www.sauder.com/services 414684
Turn twelve CAM SCREWS (8F) into the LEGS (G and H).
8F
(12 used)
H
H
G
G

3
3
S
t
e
p
Page 7
www.sauder.com/services414684
Turn four BLACK 9/16" FLAT HEAD SCREWS (32S) into the ENDS (A and B) until the shoulder of the SCREWS rest on the
surface of the ENDS.
Slide the SIDE MOLDINGS (L) onto the ENDS (A and B). Line up the groove in the MOLDINGS over the head of the SCREWS in
the ENDS.
These edges
should be even. BLACK 9/16" FLAT HEAD SCREW
(4 used in this step)
32S
Shoulder
Apply pressure with your hands as
you guide the MOLDINGS over
the SCREWS and onto the ENDS.
L
L
A
B
Surface without
HIDDEN CAMS
Surface without
HIDDEN CAMS

4
4
S
t
e
p
Page 8 www.sauder.com/services 414684
Fasten the LEGS (G and H) to the ENDS (A and B). Tighten twelve HIDDEN CAMS.
A
B
Surface with
HIDDEN
CAMS
Surface with
HIDDEN
CAMS
G
H
G
H
These edges
should be even.
These edges
should be even.

5
5
S
t
e
p
Page 9
www.sauder.com/services414684
Fasten the CABINET RAILS (M and N) to the ENDS (Aand B). Use four GOLD 5/16" FLAT HEAD SCREWS (3S).
NOTE: The CABINET RAILS are marked “CR” and “CL” for easy identification.
A
B
G
H
Roller end
Roller end
M
N
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S

Fasten the LEFT END (B) to the TOP (C). Tighten two HIDDEN CAMS.
6
6
S
t
e
p
Page 10 www.sauder.com/services 414684
Caution
Risk of damage or
injury. Hidden Cams
must be completely
tightened. Hidden
Cams that are not
completely tightened
may loosen, and parts
may separate.
To completely tighten:
Start Tighten
Arrow
Arrow
Maximum
210 degrees
Minimum
190 degrees
BH
C
Surface with holes
Surface with
HIDDEN CAMS
Roller end
These holes
must be here.
