Sauder Pinwheel 421886 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-15
Français pg 16-17
Español pg 18-20
Lot # 507258 09/20/17
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
Kids Open Wardrobe
Pinwheel Collection | Model 421886
WARNING
CHOKING HAZARD - Small Parts
Not for children under 3 years.
Adult assembly required.

Table of Contents Assembly Tools Required
3
4
5-15
16-17
18-20
21-22
23
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
421886 www.sauder.com/servicesPage 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A END (2)
B SHELF (1)
C BOTTOM (1)
D UPRIGHT (1)
E SHELF MOLDING (2)
F ADJUSTABLE SHELF (2)
Now you know
our ABCs.
421886www.sauder.com/services Page 3
A
B
C
DF
E
F
E
A

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
421886 www.sauder.com/servicesPage 4
APPLIQUE CARD - 1
48P
11L WARNING LABEL - 1
(Refer to Step 10 for proper location and application)
WARNING AVERTISSEMENT ADVERTENCIA
Serious or fatal crushing injuries can
occur from furniture tipover.
To help prevent tipover:
• Install tipover restraint provided.
• Place heaviest items in the lower drawers.
• Unless specifically designed to
accommodate, do not set TVs or other
heavy objects on top of this product.
• Never allow children to climb or hang on
drawers, doors, or shelves.
• Never open more than one drawer at a time.
(OR)
• Do not defeat or remove the drawer
interlock system.
Use of tipover restraints may only reduce,
but not eliminate, the risk of tipover.
This is a permanent label. Do not remove.
Des blessures graves ou fatales par écrasement
peuvent survenir si le mobilier bascule. Pour
prévenir le basculement:
• Installer le dispositif anti-basculement fourni.
• Placer les articles plus lourds dans les tiroirs inférieurs.
• Sauf si le meuble a été conçu spécialement à
cette fin, ne pas mettre de téléviseur ou d’autre
objets lourds sur le dessus de ce meuble.
• Ne jamais laisser d’enfants grimper sur les
tiroirs, les portes ou les étagères ou s’y agripper.
• Ne jamais ouvrir plus d’un tiroir à la fois.
(OU)
• Ne pas démanteler ou enlever le système de
verrouillage pour tiroir.
L’utilisation de dispositifs anti-basculement peut
réduire le risque de basculement, mais pas l’éliminer.
Cette étiquette est permanente. Ne pas l’enlever.
Lesiones graves o fatales por aplastamiento, pueden
ocurrir por el volcar de los muebles. Para ayudar a
prevenir que se volqué:
• Instalar la contención brindada para evitar que se volqué.
• Coloque los artículos más pesados en los cajones
inferiores.
• A menos que sea específicamente diseñado para
acomodar, no establezca televisores u otros objetos
pesados en la parte superior de este producto.
• Nunca permita que los niños se suban o se cuelguen
de cajones, puertas o estantes.
• Nunca abra más de un cajón a la vez.
(O)
• No anule o elimine el sistema de bloqueo de los cajones.
El uso de la contención puede solamente reducir, pero
no eliminar, el riesgo de volcar.
Esta es una etiqueta permanente. No remover.
10/16 395783
SHELF SNAP - 8
8R
12F TWIST-LOCK®
FASTENER - 12
METAL PIN - 10
1R
HIDDEN CAM - 4
1F CAM DOWEL - 4 2F
BLACK 1-15/16" FLAT HEAD SCREW - 2
113S
KNOB - 2
159K
ROD - 1
27A
THREADED PIN - 2
12R

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å To begin assembly, push twelve SAUDER TWIST-LOCK®
FASTENERS (12F) into the large holes in the SHELF (B)
and BOTTOM (C).
421886www.sauder.com/services Page 5
12F
Do not tighten the TWIST-LOCK® FASTENERS in this step.
B
C
12F
12F
12F
12F
A tracking label will
be on this surface.
Please do not remove.

Step 2
å Push four HIDDEN CAMS (1F) into the SHELF MOLDINGS (E).
Then, insert the metal end of a CAM DOWEL (2F) into each
HIDDEN CAM.
421886 www.sauder.com/servicesPage 6
Insert the metal end of the CAM
DOWEL into the HIDDEN CAM.
Arrow
Arrow
1F
2F
(4 used)
E
E
Some assembly
(and snacks) required.

Step 3
421886www.sauder.com/services Page 7
E
E
å Fasten the SHELF MOLDINGS (E) to the SHELF (B).
Tighten four TWIST-LOCK® FASTENERS. How to use the SAUDER TWIST-LOCK® FASTENER
1. Insert the dowel end of the FASTENER into the
hole of the adjoining part.
NOTE: The dowel end of the FASTENER must
remain fully inserted in the hole of the adjoining
part while locking the FASTENER.
2. Tighten the FASTENER with a Phillips
screwdriver as tight as possible.
Dowel end
B
Surface with
TWIST-LOCK®
FASTENERS
Surface with
HIDDEN CAMS
Curved edge
Curved edge
Surface without
HIDDEN CAMS
Short edge

Step 4
å Fasten the SHELF (B) to one of the ENDS (A). Tighten two
TWIST-LOCK® FASTENERS.
å Fasten the SHELF MOLDINGS (E) to the END (A). Tighten
two HIDDEN CAMS.
421886 www.sauder.com/servicesPage 8
Start Tighten
Arrow
Minimum
190 degrees
Caution
Risk of damage or
injury. HIDDEN CAMS
must be completely
tightened. HIDDEN
CAMS that are not
completely tightened
may loosen, and parts
may separate. To
completely tighten:
Arrow
Maximum
210 degrees
E
E
B
Surface with
TWIST-LOCK®
FASTENERS
Surface with
more holes
A
This hole must be here.

å Insert two METAL PINS (1R) into the SHELF (B).
å Slide the UPRIGHT (D) onto the METAL PINS in
the SHELF (B).
Step 5
421886www.sauder.com/services Page 9
D
B
1R

Step 6
å Fasten the BOTTOM (C) to the END (A). Tighten two
TWIST-LOCK® FASTENERS.
å Fasten the BOTTOM (C) to the UPRIGHT (D). Use two
BLACK 1-15/16" FLAT HEAD SCREWS (113S).
421886 www.sauder.com/servicesPage 10
A
D
C
Surface with
TWIST-LOCK®
FASTENERS
BLACK 1-15/16" FLAT HEAD SCREW
(2 used in this step)
113S
