Sauder Worksense MASON PEAK 427835 User manual

sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE RETAILER.
Sauder.com
Share your journey!
How can we help you? To reach our customer service, visit sauder.com/oceservice to chat with a
live rep or email us.
Prefer the phone? Give us a rin at
877-996-7539 .
Our award-winnin team is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays).
Lot # 561666 03/11/21
Purchased: __________________
Enlish p 1-26
Français p 27-29
Español p 30-32
Library Base
Prime Oak finish | Model 427835
MASON PEAK COLLECTION

Table of Contents Assembly Tools Required
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Part Identification
Hardware Identification
Optional Accessories
Hardware Usae Guide
Assembly Steps
Français
Español
Safety
Warranty
3
4-5
6
7
8-26
27-29
30-32
33-34
35
427835 www.sauder.com/oceservicePae 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
427835www.sauder.com/oceservice Pae 3
A RIGHT END (1)
B LEFT END (1)
B57 DRAWER BOTTOM (1)
C TOP MOLDING (1)
D DRAWER FRONT (1)
D569 RIGHT DRAWER SIDE (1)
D570 LEFT DRAWER SIDE (1)
D571 DRAWER BACK (1)
D572 DRAWER BOX FRONT (1)
E ADJUSTABLE SHELF (1)
F ADJUSTABLE SHELF MOLDING (1)
G BOTTOM (1)
H BASE (1)
J BACK (1)
K TOP (1)
L LEFT DOOR (1)
M RIGHT DOOR (1)
N DRAWER BRACE (1)
A
B
C
D
E
F
G
H
J
K
L
M
N
B57
D569
D570
D571
D572

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
427835 www.sauder.com/oceservicePae 4
RLEFT DRAWER
SLIDE - 1
LEFT CABINET
RAIL - 1
P
RIGHT CABINET
RAIL - 1
ORIGHT DRAWER
SLIDE - 1
Q
31G CORNER
BRACKET - 2
BACK
CONNECTOR - 8
39F METAL
BRACKET - 6
4G 42H HINGE - 4
MAGNETIC CATCH - 2
2I STRIKE PLATE - 2 6I 191K PULL - 3
METAL PIN - 4
1R RUBBER SLEEVE - 4
2R
105P TWIST-LOCK®
FASTENER COVER - 8
CAM SCREW - 1
8F WOOD DOWEL - 8 15F
HIDDEN CAM - 1
1F 37F TWIST-LOCK®
FASTENER - 8

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
427835www.sauder.com/oceservice Pae 5
GRAY 1-3/8" MACHINE SCREW - 2
39S
BLACK 7/8" LARGE HEAD SCREW - 2
17S
BLACK 1/2" FLAT HEAD SCREW - 2
11S
BLACK 7/8" MACHINE SCREW - 4
37S
30S BLACK 1-9/16" FLAT HEAD SCREW - 5
BLACK 9/16" LARGE HEAD SCREW - 40
1S 3S GOLD 5/16" FLAT HEAD SCREW - 8

å This piece of furniture accommodates one or more of the following optional accessories (sold separately).
Optional Accessories (sold separately)
å Powered Grommet (Item 427829)
The powered grommet is designed to replace any existing grommet provided with your furniture.
å To purchase the Powered Grommet, scan this QR code. (Or go to sauder.com)
å LED Light (Item 426494)
The LED Light is designed to be fastened to the underside of a hutch.
å To purchase the LED Light, scan this QR code. (Or go to sauder.com)
427835 www.sauder.com/oceservicePae 6

Hardware Usage Guide
1. Insert the dowel end of the FASTENER into the
hole of the adjoining part.
NOTE: The dowel end of the FASTENER must
remain fully inserted in the hole of the adjoining
part while locking the FASTENER.
2. Tighten the FASTENER with a Phillips
screwdriver as tight as possible.
Dowel end
2.
Push a TWIST-LOCK® FASTENER
into the large hole in the part.
1.
HOW TO USE A TWIST-LOCK®FASTENER
Cam Screw
Hidden Cam
Arrow
Push a HIDDEN CAM into
the part. The arrow in the
HIDDEN CAM must point
toward the hole in the
edge of the board.
Hole
2. 3.
1
2
Insert the CAM SCREW into the HIDDEN CAM.
Tighten the HIDDEN CAM.
HOW TO USE A HIDDEN CAM & CAM SCREW
Turn the CAM SCREW until
the shoulder is against the
surface of the part.
1.
427835www.sauder.com/oceservice Pae 7

Step 1
427835 www.sauder.com/oceservicePae 8
Look for this icon. It means a video assembly tip is
available at www.sauder.com/service/tips
Find the numbered video or scan the QR code.
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratchin your unit or the floor.
å To bein assembly, push four SAUDER TWIST-LOCK®
FASTENERS (37F) into the lare holes in the ENDS (A and B).
å Insert four WOOD DOWELS (15F) into the ENDS (A and B).
A
B
37F
Do not tihten the TWIST-LOCK® FASTENERS in this step.
15F
Just think. The sooner
you do this, the sooner
you do somethin else.
Meet Parts (A and B). These components
have been enineered to be lihter,
stroner, faster… well ok. Not technically
faster. But definitely makes for a sturdier
Library Base that’s easier to assemble and
friendlier to the environment.
2

Step 2
427835www.sauder.com/oceservice Pae 9
å Fasten the RIGHT CABINET RAIL (O) to the RIGHT END (A) and
the LEFT CABINET RAIL (P) to the LEFT END (B). Use four GOLD
5/16" FLAT HEAD SCREWS (3S) throuh holes #1 and #3.
A
B
5
O
P
Roller end
1
2
3
3
2
1
GOLD 5/16" FLAT HEAD SCREW
(4 used in this step)
3S
Roller end
Groove

Step 3
427835 www.sauder.com/oceservicePae 10
å Push four SAUDER TWIST-LOCK® FASTENERS (37F) into
the lare holes in the BOTTOM (G).
å Insert four WOOD DOWELS (15F) into the BOTTOM (G).
G
15F
37F
Do not tihten the TWIST-LOCK® FASTENERS in this step.
37F
15F
2

Step 4
427835www.sauder.com/oceservice Pae 11
å Fasten two METAL BRACKETS (4G) to the BOTTOM (G).
Use two BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the BRACKETS are even with the ede of
the BOTTOM.
å Fasten two CORNER BRACKETS (31G) to the BOTTOM (G).
Use four BLACK 9/16" LARGE HEAD SCREWS (1S).
G
4G
31G
31G
BLACK 9/16" LARGE HEAD SCREW
(6 used in this step)
1S

Step 5
427835 www.sauder.com/oceservicePae 12
2
å Fasten the ENDS (A and B) to the BOTTOM (G). Tihten
four TWIST-LOCK® FASTENERS.
å NOTE: Be sure the WOOD DOWELS in the BOTTOM
insert into the ENDS.
å Fasten the ENDS (A and B) to the CORNER BRACKETS
on the BOTTOM (G). Use four BLACK 9/16" LARGE
HEAD SCREWS (1S).
A
B
G
Roller end
Roller end
These brackets must be here.
BLACK 9/16" LARGE HEAD SCREW
(4 used in this step)
1S
Groove
Groove

Step 6
427835www.sauder.com/oceservice Pae 13
å Slide the BACK (J) into the grooves in the ENDS (A and B)
and BOTTOM (G).
å NOTE: Be sure the BACK inserts into the BOTTOM roove.
JA
BG
With the palm of your
hand, tap the BACK
down into the roove.
Finished surface - if
placin unit aainst
a wall
Unfinished surface -
if placin unit out in
a room

Step 7
427835 www.sauder.com/oceservicePae 14
2
J
A
B
K
å Fasten the TOP (K) to the ENDS (A and B). Tihten four
TWIST-LOCK® FASTENERS.
å NOTE: Be sure the BACK (J) inserts into the TOP roove.
å NOTE: Be sure the WOOD DOWELS in the ENDS insert into the TOP.
Groove

Step 8
427835www.sauder.com/oceservice Pae 15
å Fasten four METAL BRACKETS (4G) to the TOP MOLDING (C).
Use four BLACK 9/16" LARGE HEAD SCREWS (1S).
å NOTE: Be sure the BRACKETS are even with the ede of the
TOP MOLDING.
å Fasten the TOP MOLDING (C) to the TOP (K). Use four
BLACK 9/16" LARGE HEAD SCREWS (1S) throuh the METAL
BRACKETS on the TOP MOLDING and into the holes
in the TOP.
K
C
C
4G
BLACK 9/16" LARGE HEAD SCREW
(8 used in this step)
1S

Step 9
427835 www.sauder.com/oceservicePae 16
å Fasten the BASE (H) to the ENDS (A and B) and BOTTOM (G).
Use six BLACK 9/16" LARGE HEAD SCREWS (1S) throuh the
METAL BRACKETS and CORNER BRACKETS on the ENDS
and BOTTOM and into the holes in the BASE.
H
G
A
B
BLACK 9/16" LARGE HEAD SCREW
(6 used in this step)
1S
Anled ede
Now miht be a
ood time to refresh
your drink.

Step 10
427835www.sauder.com/oceservice Pae 17
å Carefully turn your unit onto its front edes.
å Fasten eiht BACK CONNECTORS (39F) to the
ENDS (A and B), BOTTOM (G), TOP (K), and BACK (J).
Tihten the SCREW in each BACK CONNECTOR.
G
A
B
J
K
Screw
Lip
Lip
3" 2"
Slide the lip into
the roove, then
tihten the screw.
Screw
Lip
Lip
39F
39F
39F
39F
Screw
Screw

Step 11
427835 www.sauder.com/oceservicePae 18
å Carefully stand your unit upriht.
å Usin your hammer, ently tap a TWIST-LOCK® FASTENER COVER (105P)
onto each visible TWIST-LOCK® FASTENER.
å Push two MAGNETIC CATCHES (2I) into the BOTTOM (G).
G
2I
A
B
105P

Step 12
427835www.sauder.com/oceservice Pae 19
å Slide the ADJUSTABLE SHELF MOLDING* (F) onto the
notched ede of the ADJUSTABLE SHELF (E).
å Push the RUBBER SLEEVES (2R) over one end of the
METAL PINS (1R). Insert the METAL PINS into the hole
locations of your choice in the ENDS (A and B). Set the
ADJUSTABLE SHELF (E) onto the METAL PINS.
å *U.S. Patent No. 5,499,886
2R
1R
A
B
E
(4 used)
E
F
Slide the ADJUSTABLE SHELF
MOLDING (F) onto the notched ede.
Notched ede
The roove
is closer to
this ede.
These surfaces
should be even.

Step 13
427835 www.sauder.com/oceservicePae 20
å Fasten the HINGES (42H) to the DOORS (L and M). Use
eiht BLACK 9/16" LARGE HEAD SCREWS (1S).
å Fasten the STRIKE PLATES (6I) to the DOORS (L and M).
Use two BLACK 1/2" FLAT HEAD SCREWS (11S).
L
M
42H
42H
BLACK 9/16" LARGE HEAD SCREW
(8 used for the HINGES)
1S
6I
BLACK 1/2" FLAT HEAD SCREW
(2 used for the STRIKE PLATES)
11S
Indented holes
