Sauder Via Series 401446 User manual

NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-26
Français pg 27-31
Español pg 32-36
Lot # 376056 07/27/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987
Desk Return
Via Collection | 401446
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
sauder.com
For left and right
brains, alike.

Table of Contents Assembly Tools Required
3
4
5-26
27-31
32-36
37-38
39
Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Skip the power trip.
This time.
401446 www.sauder.com/servicesPage 2

Part Identification
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
A RIGHT END (1)
B LEFT END (1)
C LARGE END (1)
D2 TOP (1)
E BACK (1)
Now you know
our ABCs.
401446www.sauder.com/services Page 3
A
B
C
D2
E

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
401446 www.sauder.com/servicesPage 4
BLACK 7/8" LARGE HEAD SCREW - 16
SBLACK 9/16" LARGE HEAD SCREW - 2 T
CONNECTOR PLATE - 2
H
PROPEL NUT - 3
M
TOUCH-UP PEN - 1
R
FTWIST-LOCK®
FASTENER - 19
GROMMET CAP - 1
1P GROMMET - 1 10P
GTWIST-LOCK®
FASTENER COVER - 19
KHALF GROMMET - 1 LHALF GROMMET
CAP - 1
NLEVELER - 3 OLEVELER
BRACKET - 3 PCORD MANAGER - 2
HOLE PLUG - 4
Q

Step 1 Look for this icon. It means a
video assembly tip is available at
www.sauder.com/services/tips
å You have the choice of assembling this unit six ways:
å 1. If attaching the 401446 Desk Return to the right or left side of the 401447 Executive
Desk and 401448 Credenza (for a U-Shape configuration) continue with step 2.
å 2. If attaching the 401446 Desk Return to the right or left side of the 401447 Executive
Desk (for an L-Shape configuration) continue with step 7.
å 3. If attaching the 401446 Desk Return to the right or left side of the 401448 Credenza
(for an L-Shape configuration) continue with step 15.
401446www.sauder.com/services Page 5
401446
401447
401448
401446
401447
401448
401446
401448
401446
401448
401446
401447
401446
401447
U-Shape Assembly
L-Shape Assembly
(Continue with Step 2 now)
(Continue with Step 7 now) Continue with Step 15 now)

Step 2
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å To begin assembly, push a SAUDER TWIST-LOCK®
FASTENER (F) into the large holes in the ENDS (A
and B) and BACK (E).
å NOTE: The LARGE END (C) is not used in the
U-Shape assembly.
401446 www.sauder.com/servicesPage 6
Do not tighten the TWIST-LOCK® FASTENERS in this step.
F
F
F
A
B
E
Do not tap TWIST-LOCK® FASTENERS into the
other surfaces of the ENDS (A and B) at this time.
U-Shape Assembly

å Push two LEVELER BRACKETS (O) over the holes in the bottom edges
of the ENDS (A and B).
å Use a hammer to drive a PROPEL NUT (M) into the holes in the
LEVELER BRACKETS (O) and ENDS (A and B). Now, turn a LEVELER (N)
into each PROPEL NUT.
å NOTE: To raise a corner of the unit, turn the LEVELER counter-clockwise.
To lower a corner, turn the LEVELER clockwise.
Step 3
401446www.sauder.com/services Page 7
A
B
O
N
M
U-Shape Assembly

Step 4
å Insert the dowel end of four TWIST-LOCK® FASTENERS (F) into the 401447
Left End and 401448 Right End as shown in the enlarged diagram.
å NOTE: If you already pushed TWIST-LOCK® FASTENERS into the holes in the
ENDS (A and B), pull the FASTENERS back out of the holes. Pull at the front
and back edges, slowly working the FASTENERS out of the holes.
å Push the ENDS (A and B) onto the TWIST-LOCK® FASTENERS in the 401448
Right End and 401447 Left End. Now, tighten eight TWIST-LOCK® FASTENERS.
401446 www.sauder.com/servicesPage 8
U-Shape Assembly
401447 Desk Top
401448
Credenza Top
401447
Left End
401448
Right End
A
B
Finished edge
How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoining part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoining part while locking
the FASTENER.
2. Tighten the FASTENER with a Phillips screwdriver as tight
as possible.
Dowel end

å NOTE: Before beginning this step, separate the BLACK
7/8" LARGE HEAD SCREWS (S) and BLACK 9/16" LARGE
HEAD SCREWS (T). Do not confuse these SCREWS.
å Fasten the BACK (E) to the ENDS (A and B). Tighten eight
TWIST-LOCK® FASTENERS.
å Fasten two CORD MANAGERS (P) to the BACK (E). Use
two BLACK 9/16" LARGE HEAD SCREWS (T).
Step 5
401446www.sauder.com/services Page 9
U-Shape Assembly
401447
401448
A
E
P
Surface with
TWIST-LOCK®
FASTENERS
Edge with TWIST-LOCK® FASTENERS
B
BLACK 9/16" LARGE HEAD SCREW
(2 used for the CORD MANAGERS)
T

Step 6
å Fasten two CONNECTOR PLATES (H) to the 401447
Desk Top and 401448 Credenza Top. Use eight BLACK
7/8" LARGE HEAD SCREWS (S).
å Fasten the TOP (D2) to the BACK (E). Tighten three
TWIST-LOCK® FASTENERS.
å Fasten the TOP (D2) to the 401447 Desk Top and
401448 Credenza Top. Use eight BLACK 7/8" LARGE
HEAD SCREWS (S) through the CONNECTOR PLATES
and into the TOP.
å Go to the last step now.
401446 www.sauder.com/servicesPage 10
U-Shape Assembly
401447 Desk Top
401448
Credenza Top
BLACK 7/8" LARGE HEAD SCREW
(16 used for the CONNECTOR PLATES)
S
H
H
E
D2
Long finished edge

Step 7
401446www.sauder.com/services Page 11
L-Shape Assembly
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å To begin assembly, push a SAUDER TWIST-LOCK®
FASTENER (F) into the large holes in the RIGHT END (A),
LARGE END (C), and BACK (E).
å NOTE: If attaching your unit to the right side of the
401447 Executive Desk, you will use the LEFT END (B)
instead of the RIGHT END (A).
Do not tighten the TWIST-LOCK® FASTENERS in this step.
F
F
F
A
C
E
Do not tap TWIST-LOCK® FASTENERS into
the other surface of the END (A) at this time.

Step 8
401446 www.sauder.com/servicesPage 12
L-Shape Assembly
å Push three LEVELER BRACKETS (O) over the holes in the bottom edges
of the ENDS (A and C).
å Use a hammer to drive a PROPEL NUT (M) into the holes in the
LEVELER BRACKETS (O) and ENDS (A and C). Now, turn a LEVELER (N)
into each PROPEL NUT.
å NOTE: To raise a corner of the unit, turn the LEVELER counter-clockwise.
To lower a corner, turn the LEVELER clockwise.
A
C
O
N
M

å NOTE: Before beginning this step, separate the BLACK
7/8" LARGE HEAD SCREWS (S) and BLACK 9/16" LARGE
HEAD SCREWS (T). Do not confuse these SCREWS.
å Fasten the LARGE END (C) to the BACK (E). Tighten four
TWIST-LOCK® FASTENERS.
å Fasten two CORD MANAGERS (P) to the BACK (E). Use
two BLACK 9/16" LARGE HEAD SCREWS (T).
Step 9
401446www.sauder.com/services Page 13
L-Shape Assembly
E
P
Surface with
TWIST-LOCK®
FASTENERS
BLACK 9/16" LARGE HEAD SCREW
(2 used for the CORD MANAGERS)
T
C
Surface with TWIST-LOCK® FASTENERS
How to use the SAUDER TWIST-LOCK®FASTENER
1. Insert the dowel end of the FASTENER into the hole of the
adjoining part.
NOTE: The dowel end of the FASTENER must remain fully
inserted in the hole of the adjoining part while locking
the FASTENER.
2. Tighten the FASTENER with a Phillips screwdriver as tight
as possible.
Dowel end
Edge with
TWIST-LOCK®
FASTENERS
Notch

Step 10
å Insert the dowel end of two TWIST-LOCK® FASTENERS (F) into the
401447 Left End as shown in the enlarged diagram.
å NOTE: If you already pushed TWIST-LOCK® FASTENERS into
the holes in the RIGHT END (A), pull the FASTENERS back out
of the holes. Pull at the front and back edges, slowly working the
FASTENERS out of the holes.
å Push the RIGHT END (A) onto the TWIST-LOCK® FASTENERS in
the 401447 Left End. Now, tighten four TWIST-LOCK® FASTENERS.
401446 www.sauder.com/servicesPage 14
L-Shape Assembly
401447 Desk Top
401447
Left End
A
Dowel end
Finished edge

å Fasten the BACK (E) to the RIGHT END (A). Tighten four
TWIST-LOCK® FASTENERS.
Step 11
401446www.sauder.com/services Page 15
L-Shape Assembly
E
A
Edge with TWIST-LOCK® FASTENERS
C

Step 12
å Fasten a CONNECTOR PLATE (H) to the 401447 Desk
Top. Use four BLACK 7/8" LARGE HEAD SCREWS (S).
401446 www.sauder.com/servicesPage 16
U-Shape Assembly
401447 Desk Top
BLACK 7/8" LARGE HEAD SCREW
(4 used in this step)
S
H

å Insert the HALF GROMMET (K) and HALF GROMMET CAP (L)
into the notch in the top edge of the LARGE END (C).
å Fasten the TOP (D2) to the 401447 Desk Top. Use four BLACK
7/8" LARGE HEAD SCREWS (S) through the CONNECTOR
PLATE (H) and into the TOP.
å Fasten the TOP (D2) to the LARGE END (C) and BACK (E).
Tighten five TWIST-LOCK® FASTENERS.
Step 13
401446www.sauder.com/services Page 17
BLACK 7/8" LARGE HEAD SCREW
(4 used in this step)
S
401447 Desk Top
C
E
D2
K
L
H
Long finished edge
L-Shape Assembly

Step 14
å Push a GROMMET CAP (1P) and GROMMET (10P) into the large hole in the TOP (D2).
å Insert a HOLE PLUG (Q) into any unused holes.
å Push a TWIST-LOCK® FASTENER COVER (G) onto any visible TWIST-LOCK FASTENER®.
å For long term maintenance of your unit, you may touchup the edges with the TOUCH-UP PEN (R).
å NOTE: Please read the back pages of the instruction booklet for important safety information.
å This completes assembly. To clean your unit, dampen a cloth with tap water and wipe.
401446 www.sauder.com/servicesPage 18
G
D2
1P
10P
Q
R
And to celebrate, why not share your success story?
To cover TWIST-LOCK® FASTENERS
To cover unused screw holes
L-Shape Assembly
50 lbs.

Step 15
401446www.sauder.com/services Page 19
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å To begin assembly, push a SAUDER TWIST-LOCK®
FASTENER (F) into the large holes in the RIGHT END (A),
LARGE END (C), and BACK (E).
å NOTE: If attaching your unit to the right side of the
401448 Credenza, you will use the LEFT END (B) instead
of the RIGHT END (A).
Do not tighten the TWIST-LOCK® FASTENERS in this step.
F
F
F
A
C
E
Do not tap TWIST-LOCK® FASTENERS into
the other surface of the END (A) at this time.
L-Shape Assembly

Step 16
401446 www.sauder.com/servicesPage 20
L-Shape Assembly
å Push three LEVELER BRACKETS (O) over the holes in the bottom edges
of the ENDS (A and C).
å Use a hammer to drive a PROPEL NUT (M) into the holes in the
LEVELER BRACKETS (O) and ENDS (A and C). Now, turn a LEVELER (N)
into each PROPEL NUT.
å NOTE: To raise a corner of the unit, turn the LEVELER counter-clockwise.
To lower a corner, turn the LEVELER clockwise.
A
C
O
N
M
