Sauder 429430 User manual

sauder.com
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-18
Français pg 19-21
Español pg 22-24
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE STORE.
sauder.com
CONTACT US FIRST
BEFORE MAKING ANY RETURNS TO THE RETAILER.
Visit sauder.com/service to order replacement parts, view video assembly tips, or chat with a live rep.
Prefer the phone? Give us a ring at 1-800-445-1527.
Customer Service is available Monday-Friday - 9 a.m. to 5:30 p.m. EST (except holidays)
Sauder.com
Share your journey! Lot # 559158 01/11/21
Purchased: __________________
Storage Cabinet
Model 429430 / Sku 168-0094-8
Store behind
closed doors.

Part Identification
Hardware Identification
Assembly Steps
Français
Español
Safety
Warranty
Hammer
Not actual size
No. 2 Phillips Screwdriver
Tip Shown Actual Size
Assembly Tools RequiredTable of Contents
2-3
4
5-18
19-21
22-24
25-26
27
A RIGHT END (1)
B LEFT END (1)
C UPRIGHT (1)
D TOP (1)
E BOTTOM (1)
F SHELF (1)
H RIGHT DOOR (1)
J ADJUSTABLE SHELF (4)
K VALANCE (2)
L SKIRT (1)
M BACK (1)
N LEFT DOOR (1)
åWhile not all parts are labeled, some of the parts will have a label or an inked letter on the edge
to help distinguish similar parts from each other. Use this part identification to help identify similar parts.
Now you know
our ABCs.
Part Identification
Tape Measure
Page 2 www.sauder.com 429430 / 168-0094-8
Electric drill with 1/8" or 3/8" bit
(ONLY in indicated step)
Pencil

Part Identification
A
B
C
D
E
F
H
N
J
K
L
J
J
J
K
Page 3www.sauder.com429430 / 168-0094-8
M

Hardware Identification
åScrews are shown actual size. You may receive extra hardware with your unit.
1/2" PAN HEAD SCREW - 8
18
1/2" FLAT HEAD SCREW - 12
17
APPLIQUE - 30
7METAL BRACKET - 2 8BOTTOM BRACKET - 1 9
NAIL - 36
12
DOOR BRACKET - 1
10 SHELF SUPPORT - 16
11 FELT DISC - 4 20
LARGE 1/2" PAN HEAD SCREW - 10
19 FURNITURE TIPPING
RESTRAINT KIT - 1
96
ANGLE BRACKET - 5
1HINGE - 6 2HINGE BRACKET - 6 3PULL - 2 4
1-3/8" FLAT HEAD SCREW - 40
13 7/8" MACHINE SCREW - 4 15
Page 4 www.sauder.com 429430 / 168-0094-8

Step 1
å Assemble your unit on a carpeted floor or on the empty
carton to avoid scratching your unit or the floor.
å Fasten five ANGLE BRACKETS (1) to the SKIRT (L). Use
five LARGE 1/2" PAN HEAD SCREWS (19).
å NOTE: Be sure the edges of the ANGLE BRACKETS are
even with the edges of the SKIRT.
å Fasten the BOTTOM BRACKET (9) to the BOTTOM (E).
Use two 1/2" PAN HEAD SCREWS (18).
1
1/2" PAN HEAD SCREW
(2 used in this step)
18
L
1
1
E
9
The molding on the other surface
of the BOTTOM should be here.
LARGE 1/2" PAN HEAD SCREW
(5 used for the ANGLE BRACKETS)
19
Look for this icon. It means a video assembly tip is
available at www.sauder.com/service/tips
Find the numbered video or scan the QR code. 0
Page 5www.sauder.com429430 / 168-0094-8

å Fasten the SKIRT (L) to the BOTTOM (E). Use three
LARGE 1/2" PAN HEAD SCREWS (19) through the ANGLE
BRACKETS on the SKIRT and into the BOTTOM.
Step 2
L
E
The molding on the
BOTTOM should be here.
LARGE 1/2" PAN HEAD SCREW
(3 used in this step)
19
Page 6 www.sauder.com 429430 / 168-0094-8

RRTT
FF OONN
FF
RR
OO
N
N
T
T
å Fasten the VALANCES (K) to the TOP (D). Use eight
1-3/8" FLAT HEAD SCREWS (13).
Step 3
D
K
Some assembly
(and snacks) required.
K
D
Unfinished surface
1st
2nd
This arrow should
be pointing up.
This arrow should
be pointing down.
Finished surface
1-3/8" FLAT HEAD SCREW
(8 used in this step)
13
Page 7www.sauder.com429430 / 168-0094-8

Step 4
å Fasten two METAL BRACKETS (8) to the UPRIGHT (C).
Use two 1/2" PAN HEAD SCREWS (18).
å NOTE: Be sure the edges of the METAL BRACKETS are
even with the top edge of the UPRIGHT.
å Fasten the BOTTOM (E) to the UPRIGHT (C). Use two
1-3/8" FLAT HEAD SCREWS (13).
E
L
C
8
1/2" PAN HEAD SCREW
(2 used in this step)
18
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
Top edge
1-3/8" FLAT HEAD SCREW
(2 used in this step)
13
Page 8 www.sauder.com 429430 / 168-0094-8

Step
å Finish fastening the BOTTOM (E) to the SKIRT (L). Use
two 1-3/8" FLAT HEAD SCREWS (13).
å Fasten the SHELF (F) to the UPRIGHT (C). Use two 1-3/8"
FLAT HEAD SCREWS (13).
å Finish fastening the SHELF (F) to the UPRIGHT (C). Use
two 1/2" PAN HEAD SCREWS (18) through the METAL
BRACKETS on the UPRIGHT and into the SHELF.
å Then, peel four APPLIQUES (7) from the applique card
and stick them over the heads of the SCREWS (13).
Step 5
E
C
F
Peel the APPLIQUES
from the applique card.
7
L
7
The molding on the
SHELF should be here.
1/2" PAN HEAD SCREW
(2 used in this step)
18
7
1-3/8" FLAT HEAD SCREW
(4 used in this step)
13
Page 9www.sauder.com429430 / 168-0094-8

Step
å Fasten the HINGE BRACKETS (3) to the ENDS (A and B).
Use the SCREWS in the HINGE BRACKETS.
å NOTE: The arrow on the HINGES should face towards the
edge of the ENDS.
Step 6
B
A
3
3
3
Page 10 www.sauder.com 429430 / 168-0094-8

Step 7
Edge with
HINGE BRACKETS
å Fasten the ENDS (A and B) to the TOP (D), BOTTOM (E),
SHELF (F), VALANCES (K), and SKIRT (L). Use twenty six
1-3/8" FLAT HEAD SCREWS (13).
å Finish fastening the ENDS (A and B) to the SKIRT (L). Use
two LARGE 1/2" PAN HEAD SCREW (19) through the
ANGLE BRACKET on the SKIRT and into the RIGHT END.
A
K
F
D
K
L
E
Edge with
HINGE BRACKETS
B
LARGE 1/2" PAN HEAD SCREW
(2 used for the ANGLE BRACKETS)
19
Finished surface
Hey! It's starting to look
like something!
1-3/8" FLAT HEAD SCREW
(26 used in this step)
13
Page 11www.sauder.com429430 / 168-0094-8

Step 8
å Carefully turn your unit over onto its front edges. Unfold
the BACK (M) and lay it over your unit.
å Make equal margins along all four edges of the BACK (M).
Push on opposite corners of your unit if needed to make
it "square".
å Using your hammer, fasten the BACK (M) to your unit
using the NAILS (12).
å NOTE: Be sure to tap NAILS into the holes that line up
over the UPRIGHT (C).
å Peel the backing o of each FELT DISC (20) and stick
them on the edge of the ENDS (A and B).
å NOTE: Be sure the FELT DISCS are placed approximately
1/8" in from the front edge of the ENDS.
Do not stand the unit upright without the
BACK fastened. The unit may collapse.
Caution
NAIL
(36 used in this step)
12
M
Unifinished
surface
These holes must line up
over the UPRIGHT (C).
A
B
20
This FELT DISC should set in 1/8"
from the front edge of the ENDS.
This FELT DISC should set in 1/8"
from the front edge of the ENDS.
8
This arrow should
be pointing up.
UP
Page 12 www.sauder.com 429430 / 168-0094-8

å Fasten the HINGES (2) to the DOORS (H and N). Use
twelve 1/2" FLAT HEAD SCREWS (17).
å Fasten the DOOR BRACKET (10) to the LEFT DOOR (N).
Use two 1/2" PAN HEAD SCREWS (18).
Step 9
H
N
2
2
2
1/2" FLAT HEAD SCREW
(12 used for the HINGES)
17
10
1/2" PAN HEAD SCREW
(2 used for the DOOR BRACKET)
18
Page 13www.sauder.com429430 / 168-0094-8

å Carefully stand your unit upright.
å Fasten the DOORS (H and N) to the ENDS (A and B). Slide the HINGES
on the DOORS onto the HINGE BRACKETS on the ENDS. Secure the
DOORS with the mounting screw on the HINGE BRACKET.
å See the enlarged diagrams for adjustments.
å Fasten the PULLS (4) to the DOORS (H and N). Use four 7/8"
MACHINE SCREWS (15).
Step 10
H
N
A
B
Mounting
screw
HINGE BRACKET
4
4
17
7/8" MACHINE SCREW
(4 used for the PULLS)
15
Page 14 www.sauder.com 429430 / 168-0094-8

Step 11
å Insert the SHELF SUPPORTS (11) into the hole locations of
your choice in the ENDS (A and B) and UPRIGHT (C). Set the
ADJUSTABLE SHELVES (J) onto the SHELF SUPPORTS.
å NOTE: The lips of the ADJUSTABLE SHELVES can face
either up or down in your unit.
A
B
C
J
J
J
J
If you're doing this to
help a friend, don't
leave without a bite.
(16 used)
11
Finished edge
Finished edge
Page 15www.sauder.com429430 / 168-0094-8

StepStep 12
å Place your unit in its final location.
å 1st - Use the FURNITURE TIPPING RESTRAINT KIT (96) for added stability. Fasten the SAFETY STRAP to the TOP (D)
using the SHORT SCREW.
å The following instructions show your unit being fastened to a wall stud. If you are not fastening your unit to a wall stud,
go to the next step now.
å 2nd- Locate the center of a stud in your wall near your unit and mark it with a pencil.
å 3rd- Drill a 1/8" hole on the mark and into the stud in your wall.
å 4th-
Fasten the unit to the wall. Use the LONG SCREW through the other end of the SAFETY STRAP and into the 1/8" hole.
D
96
Electric drill with 1/8" bit
3rd
Use the short screw through the hole
in the strap and into the TOP (D).
1st
4th
Mark and drill
a 1/8" hole into
the wall stud.
2nd
FRFRONTONT
Page 16 www.sauder.com 429430 / 168-0094-8

Step
å 1st- With your pencil, strike a mark through the center of the hole in the SAFETY STRAP.
å 2nd- Drill a 3/8" hole on the mark.
å 3rd- While you squeeze the wings together, gently tap the WALL ANCHOR from the FURNITURE TIPPING RESTRAINT
KIT (96) into the hole until it is even with the surface of the wall.
å 4th- Turn the LONG SCREW through the hole in the SAFETY STRAP and into the WALL ANCHOR.
å NOTE: You will need to turn the LONG SCREW multiple turns to completely tighten and secure your unit to the wall.
Step 13
4th
96
1st
Electric drill with 3/8" bit
2nd
3rd
Mark and drill
a 3/8" hole
into the wall.
FRONT
Page 17www.sauder.com429430 / 168-0094-8

FRONT
Step 14
å Peel twenty-six APPLIQUES (7) from the applique card and stick them over the heads of the
SCREWS in the ENDS (A and B).
å NOTE: Please read the back pages of the instruction booklet for important safety information.
å This completes assembly. Clean with a damp cloth. Wipe dry.
No load
Weight Limits:
Top Shelf - 50 lbs.
Adjustable Shelf - 25 lbs. each
Bottom - 50 lbs. total
Peel the APPLIQUES
from the applique card.
A
B
(26 used) 7
And to celebrate, why not share your success story at sauder.com or
Page 18 www.sauder.com 429430 / 168-0094-8

LISTE DE PIÈCES
REFERENCE DESCRIPTION QUANTITÉ
LISTE DE PIÈCES
REFERENCE DESCRIPTION QUANTITÉ
NOUS SOMMES LA POUR VOUS AIDER!
Nous faisons de notre mieux pour nous assurer que votre meuble
arrive dans d’excellentes conditions. Nos représentants du service
Clientèle sont aimables et prêts à vous aider au cas où une pièce
aurait été endommagée ou manquerait (ou si vous aviez besoin
d’aide pour l’assemblage). NE RAMENEZ PAS LE MEUBLE AU
MAGASIN. Au Canada, composez ce numéro d’appel gratuit:
1-800-445-1527
Du lundi au vendredi, de 9 heures du matin à
5:30 heures du soir (horaire Côte Est)
(sauf jours fériés)
Si une pièce a besoin d’être remplacée, la pièce de remplacement
sera envoyée dans les 48 heures. (Sauf week-ends et jours fériés)
Utilisez les instructions d’assemblage en français avec les
schémas étape par étape du manuel d’instruction en anglais.
Chaque étape en français correspond à la même étape
en anglais. La pièce devant être attachée à l’élément est
représentée en gris sur les schémas de chaque étape pour plus
de précision. Comparer la “Liste de pièces” ci-dessous avec
la “PART IDENTIFICATION” du manuel en anglais pour vous
familiariser avec les pièces avant l’assemblage.
REMARQUE : CE MANUEL D’INSTRUCTIONS CONTIENT
D’IMPORTANTES INFORMATIONS RELATIVES À LA SÉCURITÉ.
À LIRE ET CONSERVER POUR TOUTE RÉFÉRENCE FUTURE.
Noter la date d’achat
de cet élément et
conserver le livret pour
future référence. Pour
contacter Sauder en
ce qui concerne cet
élément, faire référence
au numéro de lot et
numéro de modèle en
appelant notre numéro
sans frais.
Lot nº : ____________
Date de
l'achet : ____________
1 CONSOLE À ÉQUERRE.........................................5
2 CHARNIÈRE.....................................................................6
3 CONSOLE DE CHARNIÈRE.................................6
4 POIGNÉE............................................................................2
7 AUTO-COLLANT ....................................................30
8 CONSOLE EN MÉTAL.............................................2
9 CONSOLE DE DESSOUS.................................... 1
10 CONSOLE DE PORTE............................................ 1
11 SUPPORT DE TABLETTE...................................16
12 CLOU ................................................................................36
20 TAMPON EN FEUTRE..............................................4
13 VIS TÊTE PLATE 35 mm...................................40
15 VIS À MÉTAUX 22 mm...........................................4
17 VIS TÊTE PLATE 13 mm......................................12
18 VIS TÊTE GOUTTE DE SUIF 13 mm............8
19 GRAND VIS TÊTE GOUTTE
DE SUIF 13 mm.........................................................10
96 KIT DE RETENUE ANTI-BASCULEMENT
POUR MOBILIER...........................................................1
A EXTRÉMITÉ DROITE..................................................1
B EXTRÉMITÉ GAUCHE...............................................1
C MONTANT ........................................................................1
D DESSUS...............................................................................1
E DESSOUS...........................................................................1
F TABLETTE..........................................................................1
H PORTE DROITE .............................................................1
J TABLETTE RÉGLABLE............................................4
K LAMBREQUIN................................................................2
L PLINTHE..............................................................................1
M ARRIÈRE ..............................................................................1
N PORTE GAUCHE..........................................................1
Meuble de rangement
Modèle
429430 / 168-0094-8
Page 19www.sauder.com429430 / 168-0094-8

ÉTAPE 6
Fixer les CONSOLES DE CHARNIÈRE (3) aux EXTRÉMITÉS (A et B).
Utiliser les VIS dans les CONSOLES DE CHARNIÈRE.
REMARQUE : La flèche sur les CHARNIÈRES doit être dirigée
vers le chant des EXTRÉMITÉS.
ÉTAPE 5
Finir de fixer le DESSOUS (E) à la PLINTHE (L). Utiliser deux VIS
TÊTE PLATE 35 mm (13).
Fixer la TABLETTE (F) au MONTANT (C). Utiliser deux VIS TÊTE
PLATE 35 mm (13).
Finir de fixer la TABLETTE (F) au MONTANT (C). Utiliser deux VIS
TÊTE GOUTTE DE SUIF 13 mm (18) à travers les CONSOLES EN
MÉTAL sur le MONTANT et dans la TABLETTE.
Ensuite, décoller quatre AUTO-COLLANTS (7) de la fiche d'auto-
collants et les coller sur les têtes des VIS (13).
ÉTAPE 4
Attention: Ne pas relever l'élément dans sa position verticale
avant d'avoir fixé l’ARRIÈRE. L'élément risque de s'eondrer.
Fixer deux CONSOLES EN MÉTAL (8) au MONTANT (C). Utiliser
deux VIS TÊTE GOUTTE DE SUIF 13 mm (18).
REMARQUE : S'assurer que les chants des CONSOLES EN
MÉTAL sont à fleur des chants du MONTANT.
Fixer le DESSOUS (E) au MONTANT (C). Utiliser deux VIS
TÊTE PLATE 35 mm (13).
ÉTAPE 3
Fixer les LAMBREQUINS (K) au DESSUS (D). Utiliser huit VIS
TÊTE PLATE 35 mm (13).
ÉTAPE 2
Fixer la PLINTHE (L) au DESSOUS (E). Utiliser trois GRAND VIS
TÊTE GOUTTE DE SUIF 13 mm (19) à travers les CONSOLES À
ÉQUERRE sur le LAMBREQUIN et dans le DESSOUS.
ÉTAPE 1
Assembler l'élément sur un sol à moquette ou sur le carton vide
pour éviter d'endommager l'élément ou le sol.
Fixer cinq CONSOLES À ÉQUERRE (1) à la PLINTHE (L). Utiliser
cinq GRAND VIS TÊTE GOUTTE DE SUIF 13 mm (19).
REMARQUE : S'assurer que les chants des CONSOLES À
ÉQUERRE sont à fleur des chants de la PLINTHE.
Fixer la CONSOLE DE DESSOUS (9) au DESSOUS (E). Utiliser
deux VIS TÊTE GOUTTE DE SUIF 13 mm (18).
ÉTAPE 7
Fixer aux EXTRÉMITÉS (A et B) au DESSUS (D), au DESSOUS (E), à
la TABLETTE (F), aux LAMBREQUINS (K) et au PLINTHE (L). Utiliser
vingt-six VIS TÊTE PLATE 35 mm (13).
Finir de fixer l'EXTRÉMITÉ GAUCHE (B) à la PLINTHE (L). Utiliser deux
GRAND VIS TÊTE GOUTTE DE SUIF 13 mm (19) à travers la CONSOLE
À ÉQUERRE sur la PLINTHE et dans l'EXTRÉMITÉ GAUCHE.
Page 20 www.sauder.com 429430 / 168-0094-8
