Seaga Quick Break Combo QB218 User manual

1QB218 6.1.2019 vers 1.0
SERVICE and PARTS MANUAL
700 Seaga Drive, Freeport, IL 61032, U.S.A. | visit: seaga.com | email: [email protected]
Quick Break Combo
QB218
with oponal Entree Unit

2QB218 6.1.2019 vers 1.0
INTRODUCTION
Congratulaons on the purchase of your Quick Break Combo, QB218. This machine has been designed to give
you many years of dependable service. It requires lile maintenance and is easy to set up and operate.
READ THIS MANUAL COMPLETELY
Your machine is designed to operate simply and reliably, but to take full advantage of your vendor, please read
this owner’s manual thoroughly. It contains important informaon regarding installaon and operaons, as
well as a brief trouble- shoong guide.
EQUIPMENT INSPECTION
Aer you have received your vendor and have it out of the box, place it on a secure surface for further
inspecon. Note: Any damages that may have occurred during shipping must be reported to the delivery
carrier immediately. Reporng damages and the seeking of restuon is the responsibility of the equipment
owner. The factory is willing to assist you in this process in any way possible. Feel free to contact our Customer
Care Department with quesons you may have on this process.
It is important that you keep the original packaging for your vending machine at least through the warranty
period. If your machine needs to be returned for repair, you may have to purchase this packaging if it is not
retained.
Once you have your vendor located, we suggest that you keep this manual for future reference, or you
can view this manual online at www.seaga.com. Should any problems occur, refer to the secon entled
“TROUBLESHOOTING”. It is designed to help you quickly idenfy a problem and correct it.
seaga.com
Seaga Manufacturing, Inc.
700 Seaga Drive Freeport, IL 61032 U.S.A.
815.297.9500 Opon 1
815.297.1758 Fax
email: [e-mail]
Seaga India Pvt Ltd. Plot No.2, Sector 4-B
Industrial Estate, HSIIDC Bahadurgarh 124507 Haryana, India
[phone]
email: ser[email protected]m

3QB218 6.1.2019 vers 1.0
Table of Contents
Introducon .......................................................................................................................................2
Preliminary Informaon ......................................................................................................................4
Inial Setup .........................................................................................................................................6
Equipment Setup ................................................................................................................................9
Loading Snack Trays ............................................................................................................................9
Removing Snack Trays .......................................................................................................................11
Adjusng Coils ...................................................................................................................................12
Replacing Snack Motors ....................................................................................................................13
Loading Product Lanes .......................................................................................................................14
Customer Interface ............................................................................................................................20
Seng Up And Loading The Payment Systems ..................................................................................21
Coin Changer ......................................................................................................................................21
Loading Changer ................................................................................................................................21
Coin Retrieval .....................................................................................................................................21
Clearing Coin Jams .............................................................................................................................22
Removal Of Coin Changer ..................................................................................................................23
Bill Validator .......................................................................................................................................24
Bill Validator Capacity ........................................................................................................................24
Bill Retrieval .......................................................................................................................................24
Removing Bill Validator ......................................................................................................................26
Clearing Bill Jams ................................................................................................................................27
Programming ......................................................................................................................................28
Service Mode Navigaon ....................................................................................................................28
Service Mode ......................................................................................................................................29
Error Code Messages ...........................................................................................................................64
Refrigeraon ........................................................................................................................................66
Refrigeraon Status Display ..................................................................................................................67
Troubleshoong ....................................................................................................................................68
Frequently Asked Quesons .................................................................................................................69
Wiring Diagram .....................................................................................................................................71

4QB218 6.1.2019 vers 1.0
Preliminary Informaon
Figure 1 – The QB218 Vending System
Main Unit - VMC Aux Unit
oponal
Display
Window
Aux. Display
Window
Display
Product Delivery
Door
Main Door
Handle and Lock
Display
Window
Product Delivery
Door
Aux Product Delivery
Door
Aux. Door
Handle and Lock
keypad

5QB218 6.1.2019 vers 1.0
Figure 2 - Interior of machine and controls
Machine Descripon Main Unit Aux. Unit
Height (in) 73.5 73.5
Width (in) 34 16
Depth (in) 28.25 28.25
Volts (V) 115 --
Frequency (Hz) 60 --
Was (W) 350 --
Current (A)* 3.8 --
Vercal Drop Door
Hasps
Display
VMC
Bill Validator
Beverage Harness
Coin Changer

6QB218 6.1.2019 vers 1.0
Power Requirements
The wall receptacle used for your vendor must be properly polarized, grounded and of the correct voltage.
Operang the QB218 system from a source of low voltage will VOID YOUR WARRANTY. Each QB218 system
should have its own 15 Amp electrical circuit that is protected by a circuit breaker or fuse conforming to local
power safety regulaons.
Unpacking the Vending System
Remove all packing materials from the interior of the vending machine. Keep all documents found packed
inside which include payment system and accessory manuals as appropriate. Keep and set aside any accessory
kits.
Controls and Indicators
Display
The Display is how the vending system communicates with your customers while they are in front of the ma-
chine. The customer may see messages about how much an item costs, when a selecon is sold out, and other
communicaon. The Display also shows you, the operator, the programming mode and can show you errors or
other important diagnosc informaon.
Keypad
The customer uses these buons to make selecons. The operator uses these buons to program and/or test
the system.
Coin Return Buon
Pressing this buon returns any credit that has been paid in to the vending machine prior to a vend unless
Forced Vend is turned on.
Bill Acceptor
Accepts bills in various denominaons depending upon the conguraon of the bill validator unit.
VMC
The VMC is the Vending Machine Controller and is the heart of the vending system. The VMC is where the
Menus buon is located to put the system into programming mode.
Inial Setup
Moving the Vending System
Your QB218 system should never be moved with product or coins loaded, it should be completely empty and
any moving parts must be secured.
The system can be located as close as 2 inches to the back wall but requires 6 inches clearance on either side
for the doors to open properly while you service the machine.
Aer locang your vending system, plug in the power cord and the system will turn on.

7QB218 6.1.2019 vers 1.0
Front Door
Unlocking – Insert the key into the lock and turn the key clockwise unl the T-Handle pops out – then turn the
T-Handle counter-clockwise 3 or more revoluons unl the door can be pulled open.
Locking – Close the door rmly. Turn the lock housing one revoluon clockwise and pull to test that the lock
spear has engaged with the locking mechanism. If the door does not open, push the lock housing into its
seated posion in the door.
Locaon Requirements
The IQ380 is meant for operaon indoors only – which not only means physical protecon from the elements
of sun, rain, etc. but also means a climate controlled environment. Locaon of the IQ380 in excessively hot,
cold, humid or dirty locaons will VOID YOUR WARRANTY.
Tool Kit
Suggested tools for your tool kit are:
Phillips screwdrivers
Adjustable pliers
Needle Nose pliers
Socket Set including 5.5 mm, 7 mm and 10 mm
Installing the QB218
1. Remove all shipment/packing materials, inspect unit for damage.
2. Place the Entrée Unit on the right side of the main unit and open the front door. Align the mounng holes
on the inside of the unit with the holes in the main unit. Using the bolts and washers provided, (2 each)
aach the Entree Unit to the main unit (Fig. 3).
Leg Levelers
Leg Levelers have been provided in your parts pack as it is essenal for proper operaon to have a level
vending machine. Installaon requires two people; one to slightly lt the machine while the other installs the
leveler by screwing it in to the base of the machine on all four corners.
Note: Care should be taken not to p the vending machine more than a few degrees. Excessive pping of the
machine can ruin your refrigeraon system and void your warranty.

8QB218 6.1.2019 vers 1.0
Figure 3 – Auxilary Unit Bolts
Aach with
provided bolts
and washers
3.) Disconnect power from Main Unit.
4.) Connect Wire Harness from the Entree Unit to the Main Unit. (Figure 4)
5.) Reconnect power to Main Unit.
Figure 4 – Wire Harnesses
IQ380 Aux Unit IQ380 Main Unit
Aux. Unit
Wire Harness
Light Harness
Light Harness

9QB218 6.1.2019 vers 1.0
Theory of Operaon for Snack & Entree Trays
When a snack vends, power is sent to the motor (that drives the coil) and it
turns unl the motor hub is back to the internal “home switch” then it stops
and the vend is considered to be complete. The motor simply rotates 360
degrees and stops.
Equipment Setup
Loading Snack Trays
Each snack tray has a release lever located on the right side. To place the
tray in load posion, hold down on the release lever and li the tray up
slightly; slide the tray forward (toward you) unl the roller hits the stop built
into the side rail. Gently lower the front of the snack tray unl it is lted
down and all coils are exposed (Figure 5).
Figure 5 – Snack Tray in Load Posion
IMPORTANT: Make sure front
wheels on both sides are
properly engaged in side rails
when placing tray back in sales
posion. Each tray has a
Release Lever
Tray in Load
Posion
When loaded, li the tray front up so that the tray is level and push back into posion. NOTE: Make sure the
wheels on the front of the tray are engaged properly in the side rails and the release lever is in the forward
posion.

10QB218 6.1.2019 vers 1.0
Products
Make sure your products are appropriate for the column and coil you are placing them in. Do not force
products that are too wide into a narrow tray or too ght coil as this will cause vend problems for your
customers. The product must also pass under the tray immediately above the one you are loading and should
not touch products on either side.
Once you have the appropriately sized products for each selecon, correct loading of the products should be
between the coils and resng on the product tray itself. See Figures 6 and 6a:
Figure 6 – Load products properly and neatly
Figure 6a –Properly loaded products sell more and vend consistently
Incorrect Correct Incorrect
You should insure that the products are loaded like a retail store shelf to ence customers and give a neat,
professional appearance. Make sure packages are upright, facing front and in good condion.

11QB218 6.1.2019 vers 1.0
Removing Snack Trays
It is somemes necessary to replace a snack tray or you may nd it easier to work on certain elements of a tray
if it is removed from the vending system cabinet.
Figure 7 – Tray Harnesses
Tray 110 Harness
Tray 120 Harness
Tray 130 Harness
Squeeze tabs and pull
Tray Harness connector
free.
To remove a snack tray:
1. Remove all product from the tray you want to remove.
2. Reach in and squeeze the two cable release tabs on the top and boom of the connector and unplug the
proper tray harness.
3. Rest the tray harness on top of the tray you are removing to keep it out of the way.
4. Flip the release lever on the right side of the tray to face toward the back of the machine and raise the
front wheels out of the side rails unl you feel the roller come to the built in rail stop.
5. With a rm hold on the tray, li up to release the roller from the rails on the sides of the cabinet.
6. Pull the tray free and place it on a sturdy, at surface to complete your work.

12QB218 6.1.2019 vers 1.0
Figure 8 – Remove the tray
Tray 130 Harness
Li tray free
Adjusng Coils
If you are required by a locaon to vend a product of a non-standard size, you may need to order a dierent
coil and install it. Replacing a coil is easier with the tray removed, as described in the last secon. To replace a
coil:
1. Remove the coil from the coil driver by liing the back of the coil up o the coil driver. You will need to
move the boom of the coil clear of the coil driver to completely remove the coil. See Figure 9
2. Align the new coil end with the front of the product tray, which gives the coil beer contact with the prod-
uct. The posion of the coil in the coil driver is adjustable to assist you in aligning the new coil at the front
of the product tray. See Figure 9.
This coil adjustment can be done for all the selecons on snack or entree product trays. See Figures 6 and 6a
for examples of the locaon of home posion on the coils.
Figure 9 – Removing and Aligning a Coil
Apply pressure to the
straight part of the coil
that is inserted into the
Coil Driver. Li up the
Coil to remove.
Coil Driver with
three (3) adjustment
opons
Back of Product Tray
Li Coil

13QB218 6.1.2019 vers 1.0
If you are experiencing vending issues with certain products, you may need to adjust the coil rotaon to beer
provide the momentum to push the snack o the tray and into the delivery area. To adjust the coil rotaon:
1. Squeeze the two tabs on the back of the coil driver and pull the coil driver and coil toward the front of the
tray to remove it.
2. Turn the coil clock-wise 1/8 of a rotaon.
3. Reinsert the coil driver with coil aached back into the motor, through the back wall of the tray.
4. Load the tray and perform at least 5 (ve) test vends to insure a proper vend.
5. If the item does not vend consistently, repeat another 1/8 of a rotaon unl you are condent of consistent
vend funcon.
Figure 10 – Coil Rotaon Adjustment
Squeeze two tabs on
the back of the Coil
Driver
Pull the Coil Driver
and Coil forward;
Rotate 1/8 of a turn
and reinsert back
into product tray.
Replacing Snack Motors
As one of the moving parts of the vending system, vend motors experience regular wear and may need to be
replaced on occasion. To replace a vend motor, remove the tray as instructed in the Remove Trays secon of
this manual and then remove the coil driver and coil as shown in Figure 11.
1. Unplug motor harness.
2. Unscrew the two screws as shown in Figure 11.
3. Replace motor and plug motor harness back in.
4. Reinstall coil driver so that coil is in home posion
(see Figures 6 and 6a for coil home posion examples).
5. Perform at least 5 (ve) test vends to insure a proper vend.
Unplug motor
harness
Figure 11 –Motor on Snack Tray
Unscrew two
screws
Squeeze to
remove coil
driver

14QB218 6.1.2019 vers 1.0
Theory of Operaon of Beverage Vending
The beverage secon uses (2) Drop Sensors (vibraon sensors) to detect the product drop. In normal
operaon, the auger will rotate counter clockwise to drop a product onto the delivery chute. Upon detecon
of the product drop by these sensors, the motor (driving the auger) will stop and the vend is considered
complete.
Loading Product Lanes
The Product Columns in your machine use an Auger that rotates counter-clockwise to drop the drink into the
Product Bin.
1. Load products horizontally (laying down). Grasp Locking Tab and slide up to allow Retainer to move forward
into Load Posion.
Drop Sensors
Figure 12 – Retainer
Retainer
Locking Tab

15QB218 6.1.2019 vers 1.0
Figure 13 – Retainer in Load Posion
Retainer
2. 20 oz/591 ml Boles are loaded laying down, two deep in each column. Load the rst bole so that the top
touches the back of the column. The next bole should also be loaded with the top toward the back of the
column, posioned against the boom of the rst bole.
3. 12 oz/355 ml Cans (not slim cans) are loaded laying down, three deep in each column. Load cans with the
top of the rst can touching the back of the column. The boom of the next can should be touching the
boom of the rst can. The third can should be loaded with the top touching the top of the second can.
4. Finish loading to the top of the column, not exceeding maximum capacity (see chart), making sure the
items are not lted or skewed in the column.
5. With column loaded, li the Retainer Gate back into sales posion using the Locking Tab and push down to
lock.
Figure 14 – Loaded Product with Retainers Secured
Retainer
Adjusted within ½” of
product
Locking Arm Secured

16QB218 6.1.2019 vers 1.0
Note: There are many variaons of packaging. These instrucons are meant to be a guideline. If you have
packaging that isn’t menoned or shown, setup and tesng will be necessary to ensure proper vending.
Below is an overhead view of several product types loaded and an illustraon of accessory placement:
Figure 15 – Factory setup for your machine.
Back of Machine
Front of Machine
Your vending machine has been set by the factory for the following products and groups (see chart):
Selecon 140 – Dasani Water, 16.9 oz. Bole – Group 10
Selecon 141 – Monster, Rock Star, etc., 16 oz. Cans – Group 4
Selecon 142 – Monster, Rock Star, etc., 16 oz. Cans – Group 4
Selecon 143 – Gatorade 20 oz. Bole – Group 3
Selecon 144 – Vitamin Water 20 oz. Bole – Group 3
Selecon 145 – 12 oz. Can – Group 5
Selecon 146 – 12 oz. Can – Group 5
Selecon 147 – 12 oz. Can – Group 5

17QB218 6.1.2019 vers 1.0
*Note: see list below for Loading Group by Selecon; this illustraon is not of your machine set up
Back of Machine
Front of Machine
To accommodate a wide variety of packaging, spacers and other accessories are provided to assist with
vending performance. Any necessary accessories should be installed prior to loading the column.
For 12 oz. cans, small cans, some boles and glass boles, (see chart), use the Large Side Spacer, and/or the
Auger Insert and/or Small Back Spacer. Refer to chart for products requiring Accessories.
Size Descripon Product Setup/Accessory Load Capacity Group
20 oz
519 ml
Bole Aquana
Water, Coun-
try Time
Lemonade,
Lipton Iced
or Green Tea,
Coke, Pepsi,
and Various
Brands
Side Spacer, Small, LH Tops to Back 10 1
14 oz
414 ml
Bole Nesquik Side Spacer, Small, LH Tops to Back 10 1
18.5 oz
547 ml
Bole Pure Leaf Tea Side Spacer, Small, LH Alternate top and
boom
10 2
20 oz
519 ml
Bole Gatorade,
Sobe, Vitamin
Water
Not Required Tops to Back 10 3
16 oz
473 ml
Can Monster, Rock
Star
Side Spacer, Small, LH
Back Spacer
Alternate top and
boom
10 4

18QB218 6.1.2019 vers 1.0
Figure 16– Side Spacer, Small, LH, Side Spacer, Large, LH and Side Spacer, RH
Side Spacer, Small, LH Side Spacer, Large, LH
Side Spacer, RH
Part # SA846
Part # ST691
Part # SA698
15 oz
443 ml
Can Starbucks
Doubleshot
Coee
Side Spacer, Small, LH
Back Spacer
Alternate top and
boom
10 4
12 oz
355 ml
Can Most Brands,
Standard Size
Cans
Side Spacer, large, LH Alternate top and
boom
15 5
13.7 oz
405 ml
Glass Bole Starbucks
Frappuccino
Side Spacer, large, LH Alternate top and
boom
10 5
12 oz
355 ml
Bole Gatorade Side Spacer,Small, LH
Back Spacer, Auger
Insert, Large
Tops to Front 10 6
9.5 oz
218 ml
Glass Bole Starbucks
Frappuccino
Side Spacer, Small, LH
Auger Insert, Large
Tops to Back 10 7
11 oz
325 ml
Glass Bole Starbucks
Iced Coee
Side Spacer, Large, LH
Auger Insert, Large
Tops to Back 10 8
12 oz
355 ml
Slim Can Lipton or
Aquana
Sparkling,
Starbucks
Refreshers
Side Spacer, large, LH
Side Spacer, RH, Back
Spacer, Auger Insert,
Large
Alternate top and
boom
14 9
16.9 oz
500 ml
Bole Dasani Water Side Spacer, large, LH
Auger Insert, large
Tops to Back 12 10
15.2 oz
450 ml
PET Bole Naked Juice Side Spacer, Small, LH
Side Spacer, RH
Tops to Back 12 11

19QB218 6.1.2019 vers 1.0
Figure 17 – Auger Inserts
Auger Insert, Large Auger Insert, Narrow Product
Part # PLI2182 Part # PLI2206
Figure 18 –Back Spacer
Part # SA484
Unlike the snack secon of the vending system, the products that will vend are not viewable by your customers
when they are posioned in the vercal drop columns. To provide a live display, a product display shelf has
been provided. Take care to use packaging that is in perfect condion and products that are sll within their
expiraon date to present the best possible retail store front to your potenal customers. To load the live
product display:
1. Remove the Drink Display Back Panel by loosening and removing the thumb screws located on either side
of the panel.
2. Place each beverage, in order of selecon, in the display window taking care to make them evenly spaced
and oriented properly toward the front of the machine where the customer will see them.
3. Reinstall the beverage back panel.
Figure 19 – Live Drink Display
Thumb Screw Thumb Screw

20QB218 6.1.2019 vers 1.0
Loading Entrees
Entrees are loaded in spiral equipped columns very similar to the snack secon of the IQ380 vending system.
Please review the procedures in that secon of the manual to assist you with loading the entrees.
Customer Interface
Display
The LCD Display (Fig. 20) is a two line, 40 character text display panel located on the front of your vending
machine. The display interacts with the customer to show the amount of money entered into the vendor and
the cost of their selecon among other informaon as programmed. The display also shows the operator the
Service Mode funcons for seng the vendor.
Fig. 20 – LCD Display in Sales Mode
Display Formats When in Sales Mode Display Reads
Normal Operaon, no credit available WELCOME! Please insert money and
make a selecon..;
Normal Operaon, some credit available $00.01 – 99.99
Aer Pressing a selecon, if there is no
credit or the credit is less than the selec-
on’s price, the price of the selecon is
displayed for a few seconds before re-
verng to one of the above credit display
formats.
(If a coin or other payment is made the
display reverts immediately to display the
credit available)
Price $00.01 – 99.99
Free Vend Mode (all prices set to zero) Free Vend
If a selecon is out of stock when a selec-
on is pressed – this is displayed for a few
seconds
Sold Out
All Items out of stock Sold Out
Machine Out Of Order Out of Order
During a Vend (Progress bar, dashes) --------------
Exact Change required Exact Change Only
Temperature Display
Press the # buon to display Temp T1* nnF (C)
If a calorie value is set for a selecon, the value will be displayed when the product selecon is made without
any credit.
