INSTRUCTIONS FOR:

MIG TORCH EURO CONNECTOR

PART Nos: MIG/N315, MIG/N325, MIG/N336,

MIG/N415, MIG/N425, MIG/N436

Thank you for purchasing a Sealey Product. Manufactured to a high standard this product will, if used according to these instructions and properly maintained, give you

years of trouble performance.

IMPORTANT: PLEASE READ THESE INSTRUCTIONS CAREFULLY. NOTE THE SAFE OPERATIONAL REQUIREMENTS, WARNINGS AND CAUTIONS.

USE THIS PRODUCT CORRECTLY AND WITH CARE FOR THE PURPOSE FOR WHICH IT IS INTENDED. FAILURE TO DO SO MAY CAUSE DAMAGE

AND/OR PERSONAL INJURY AND WILL INVALIDATE THE WARRANTY. PLEASE KEEP INSTRUCTIONS SAFE FOR FUTURE USE.

1. SAFETY INSTRUCTIONS

2. INTRODUCTION & SPECIFICATIONS

3. TIP & SHROUD REMOVAL

■ BEFORE USE, ALWAYS ENSURE THAT YOU ARE FAMILIAR WITH THE SAFETY WARNINGS AND INSTRUCTIONS FOR THE

WELDER TO WHICH THIS TORCH IS TO BE FITTED.

DO NOT exceed the rated current of the torch.

DO NOT use if any part of the torch, cable or connector is damaged in any way. Use only genuine Sealey replacement parts to effect

repairs.

DO NOT allow the cable to come into contact with any sharp or hot items.

 Alwaysusethecorrectpersonalprotectiveequipmentasspeciedinthewelderinstructions.

MIG/N315, MIG/N415 MIG/N336, MIG/N436

Professional MIG welding torches with contoured grip, hanging hook and heat-proof cable. Fitted with Euro connection enabling a quick and simple

plug connection to welder. No wiring means torch can be disconnected and stored safely when not being used.

Model No: .......MIG/N315........MIG/N325 ........MIG/N336.......MIG/N415 ...... MIG/N425 ....... MIG/N436

Rated Current: ....180A............230A............250A...........290A........... 340A ............350A

Wire Diameter:....0.6-1mm .........0.8-1.2mm .......0.8-1.2mm ......0.8-1.2mm ...... 0.8-1.6mm........1-2.4mm

Length:..........3mtr ............3mtr ............3mtr ...........4mtr ........... 4mtr.............4mtr

Torch Type: ......MB15 ...........MB25 ...........MB36 ..........MB15 .......... MB25 ...........MB36

MIG/N325, MIG/N425

ENSURE THAT THE TORCH IS COOL AND THAT THE WELDER IS DISCONNECTED FROM THE POWER SUPPLY.

3.1. MIG/N315, MIG/N415, MIG/N325, MIG/N425 (g.1)

3.1.1. To remove the shroud: turn the shroud clockwise and pull away.

3.1.2. To remove the tip: unscrew the tip in an anticlockwise direction.

3.1.3. To replace the tip: screw back in and tighten.

3.1.4. To replace the shroud: simply push the shroud back over the spring.

3.2. MIG/N336, MIG436 (g.2)

3.2.1. To remove the shroud: pull the shroud forward to release.

3.2.2. To remove the tip: unscrew the tip in an anticlockwise direction.

3.2.3. To replace the tip: screw back in and tighten.

3.2.4. To replace the shroud: push back over the torch head.

g.1

g.2

Original Language Version MIG/N315,MIG/N325,MIG/N336, Issue: 1- 28/02/14

MIG/N415,MIG/N425,MIG/N436

Jack Sealey Limited

WEEE Regulations.

Dispose of this product at the end of its working life in compliance

with the EU Directive on Waste Electrical and Electronic Equipment.

When the product is no longer required, it must be disposed of in an

environmentally protective way. Contact your local solid waste

authority for recycling information.

Environmental Protection.

Recycle unwanted materials instead of disposing of them as

waste. All tools, accessories and packaging should be sorted,

taken to a recycling centre and disposed of in a manner which

is compatible with the environment.

Ensure that the welder is disconnected from the power supply before connecting the torch.

4.1. Linethemaleandfemaleconnectorupcarefullyandinsertthetorchconnections.(g.3)

4.2. Screwtheoutercollararoundthetorchontotheweldertorchconnectortoxinplace.(g.4)

4.3. See the welder instructions for wire feed details.

4. COUPLING THE EURO CONNECTOR

g.3

g.4

NOTE: I

t is our policy to continually improve products and as such we reserve the right to alter data, specifications and component parts without prior notice.
