Sega Derby Owners Club World Edition User manual

BEFORE USING THE PRODUCT, BE SURE TO READ THE FOLLOWING:
To maintain safety:
To ensure the safe operation of this product, be sure to read the following before usage.
The following instructions are intended for the users, operators and the personnel in charge of the
operation of the product. After carefully reading and sufficiently understanding the warning
displays and cautions, handle the product appropriately. Be sure to keep this manual close to the
product or in a convenient place for future reference.
Herein, explanations which require special attention are enclosed with dual lines. Depending on
the potentially hazardous degrees, the terms of DANGER, WARNING, CAUTION, etc. are used.
Be sure to understand the contents of the displays before reading the text.
Indicates that mishandling the
product by disregarding this
pictograph will cause severe
injury or death.
Indicates that mishandling the
product by disregarding this
warning will cause a potentially
hazardous situation which can
result in death or serious injury.
Indicates that mishandling the
product by disregarding this
caution will cause a slight
hazardous situation which can
result in personal injury and/or
material damage.
For the safe usage of the product, the following pictographs are used:
Indicates "HANDLE WITH CARE." In order to protect the human body and
equipment, this display is attached to places where the Owner's Manual, Serviceman
Manual and/or Service Manual should be referred to.
Indicates a "Protective Earth Terminal." Before operating the equipment, be sure to
connect it to the Ground.
(The step may be omitted for products in which a power cord with earth is used.)
❍Perform work in accordance with the instructions herein stated.
Instructions for work are explained by paying attention to the aspect of accident prevention.
Failing to perform work as per the instructions can cause accidents. In the case where only
those who have technical expertise should perform the work to avoid hazardous situation, the
instructions herein state that the site maintenance personnel should perform such work.
❍Be sure to turn off the power before working on the machine.
To prevent an electric shock, be sure to turn off the power before carrying out any work that
requires direct contact with the interior of the product. If the work is to be performed in the
power-on status, the Instruction Manual herein always states to that effect.
❍Be sure to ground the Earth Terminal.
(This is not required in the case where a power cord with earth is used.)
This product is equipped with the Earth Terminal. When installing the product, connect the
Earth Terminal to the "accurately grounded indoor earth terminal" by using an earth wire.
Unless the product is grounded appropriately, the user can be subject to an electric shock.
After performing repair, etc. for the control equipment, ensure that the Earth Wire is firmly
connected to the control equipment.
❍Ensure that the Power Supply used is equipped with an Earth Leakage Breaker.
This product does not incorporate the Earth Leakage Breaker. Using a power supply which is
not equipped with the Earth Leakage Breaker can cause a fire when earth leakage occurs.
❍Be sure to use fuses which meet the specified rating.
(Only for the machines which use fuses.)
Using fuses exceeding the specified rating can cause a fire and an electric shock.

❍Specification changes (removal of equipment, conversion and addition) not
designated by SEGA are not allowed.
The parts of the product include warning labels for safety, covers for personal protection, etc.
It is very hazardous to operate the product by removing parts and/or modifying the circuits.
Should doors, lids and protective parts be damaged or lost, refrain from operating the product,
and contact where the product was purchased from or the office herein stated.
SEGA shall not be held responsible for any accidents, compensation for damage to a third
party, resulting from the specifications not designated by SEGA.
❍Ensure that the product meets the requirements of appropriate Electrical
Specifications.
Before installing the product, check for Electrical Specifications. SEGA products have a
nameplate on which Electrical Specifications are described. Ensure that the product is
compatible with the power supply voltage and frequency requirements of the location. Using
any Electrical Specifications different from the designated Specifications can cause a fire and
an electric shock.
❍Install and operate the product in places where appropriate lighting is
available, allowing warning labels to be clearly read.
To ensure safety for the customers, labels and printed instructions describing potentially
hazardous situations are applied to places where accidents can be caused. Ensure that where
the product is operated has sufficient lighting allowing the warnings to be read. If any label is
peeled off, apply it again immediately. Please place an order with where the product was
purchased from or the office herein stated.
❍When handling the monitor, be very careful.
(Applies only to the product with a monitor.)
Some of the monitor (TV) parts are subject to high tension voltage. Even after turning off the
power, some portions are still subject to high tension voltage sometimes. Monitor repair and
replacement should be performed only by those technical personnel who have knowledge of
electricity and technical expertise.
❍Be sure to adjust the monitor/projector properly.
(Applies only to the product with a monitor/projector.)
Do not operate the product leaving on-screen flickering or blurring as it is. Using the product
with the monitor/projector not properly adjusted may cause dizziness or a headache to an
operator, a player, or the customers.
❍When transporting or reselling this product, be sure to attach this manual to
the product.
In the case where commercially available monitors and printers are used in this product, only
the contents relating to this product are explained herein. Some commercially available
equipment has functions and reactions not stated in this manual. Read this manual together
with the specific Instruction Manual of such equipment.
* Descriptions herein contained may be subject to improvement changes without notice.
* The contents described herein are fully prepared with due care. However, should any
question arise or errors be found, please contact SEGA.
INSPECTIONS IMMEDIATELY AFTER TRANSPORTING THE PRODUCT TO THE LOCATION
Normally, at the time of shipment, SEGA products are in a status allowing for usage immediately
after transporting to the location. Nevertheless, an irregular situation may occur during
transportation. Before turning on the power, check the following points to ensure that the product
has been transported in a satisfactory status.
❐Are there any dented portions or defects (cuts, etc.) on the external surfaces of the cabinet?
❐Are Casters and Adjusters damaged?
❐Do the power supply voltage and frequency requirements meet with those of the location?
❐Are all wiring connectors correctly and securely connected? Unless connected in the correct
way, connector connections can not be made accurately. Do not insert connectors forcibly.
❐Do power cords have cuts and dents?
❐Do the fuses used meet specified ratings? Is the Circuit Protector in an energized status?
❐Are all accessories available?
❐Can all Doors and Lids be opened with the Accessory Keys? Can Doors and Lids be firmly
closed?


TABLE OF CONTENTS



  
  
  
 
 
 
  
 
 
 
  
  
  
420-6680
E2-0512


INTRODUCTION OF THE SERVICE MANUAL
This manual provides information concerning the software operation of the product
DERBY OWNERS CLUB WORLD EDITION (hereafter referred to as "DOC WE".)
The manual is intended for the use of owners, administrators, and operators of this
product. Please read this manual and the Naomi Service Manual (No. 420-6455-01)
thoroughly to fully understand their contents before operating the product.
This product employs a Naomi Game Board. The Naomi Game Board system is
designed to allow other games to be operated by exchanging the installed ROM Board
Case. For this reason, the system's test mode is comprised of an automatic self-test for
devices that employ the same Naomi Game Board standard, a system test mode for item
such as coin settings, and a game test mode to test input and output for each product's
particular operation device and to set the level of difficulty.
This manual explains settings particular to the system test mode of this product. For
more information about the system test mode, please consult the Naomi Service
Manual. For details concerning mechanical and hardware maintenance, please read the
DOC WE Owner's Manual (No. 420-6679).
In the unlikely event that the product does not function correctly, DO NOT allow
anyone other than a technician to touch the internal system. Turn off power to the
machine, making sure to unplug the electrical cord from the outlet, and contact the
office listed below or the point-of-purchase for this product.
Useofthisproductisunlikelytocausephysicalinjuriesordamagestoproperty.However,
wherespecialattentionisrequiredthisisindicatedbyathickline,theword"IMPORTANT"
anditssigninthismanual.
Indicatesthatmishandlingtheproductbydisregardingthisdisplaycancausethe
product'sintrinsicperformancenottobeobtained,resultinginmalfunctioning.
SEGA AMUSEMENTS U.S.A. INC.
901 Cambridge Drive, Elk Grove Village, IL 60007, U.S.A.
TEL: [phone]
TOLL FREE: [phone]
FAX: [phone]


DEFINITION OF LOCATION'S MAINTENANCE MAN AND SERVICEMAN





Ensure that parts replacement, servicing & inspections, and troubleshooting are performed by the
location's maintenance man or the serviceman. It is instructed herein that particularly hazardous
work should be performed by the serviceman who has technical expertise and knowledge.
The location's maintenance man and serviceman are herein defined as follows:
"Location's Maintenance Man" :
Those who have experience in the maintenance of amusement equipment and vending machines,
etc., and also participate in the servicing and control of the equipment through such routine work
as equipment assembly and installation, servicing and inspections, replacement of units and
consumables, etc. within the Amusement Facilities and or locations under the management of the
Owner and Owner's Operators of the product.
Activities of Location's Maintenance Man :
Assembly & installation, servicing & inspections, and replacement of units & consumables as
regards amusement equipment, vending machines, etc.
Serviceman :
Those who participate in the designing, manufacturing, inspections and maintenance service of
the equipment at an amusement equipment manufacturer.
Those who have technical expertise equivalent to that of technical high school graduates as re-
gards electricity, electronics and or mechanical engineering, and daily take part in the servicing &
control and repair of amusement equipment.
Serviceman's Activities :
Assembly & installation and repair & adjustments of electrical, electronic and mechanical parts of
amusement equipment and vending machines.


1. GAME INFORMATION


























󰴤 


󰴥 

󰴦 


󰴧
󰴨




󰴩 


󰴪

󰴫

󰴬 


󰴭 




󰴮 

󰴯

󰴰


GAME FLOW
Play the game for the
first time. Breed a new
horse. (BREEDING FARM)
Press the Start Button.
1. Breed Your Horse (Thoroughbred)
-Select a sire
-Select a dam
2. Name Your Horse
3. Select Your Silks (Jockey's Uniform)
Start the game with a card.
Insert the card. TRAINING
RACE
REVIEW CONTINUE
RETIRE
SAVE ONTO CARD
Players can retire their horses and use them as
breeding cards when they have run over twenty
races. In DOC WE, the proficiencies inherited by
foals change (decrease) according to the number
of times the breeding cards have been used.
Horses that players have bred are
saved onto these cards. Players
can elect to use the cards to
continue in future games.









 

1. Breed Your Horse (Thoroughbred)








2. Name Your Horse












