Siemens Cerberus PACE User manual

Cerberus PACE
Public Address and Controlled Evacuation
Operation Manual
A6V10430571_en--_c Smart Infrastructure
2020-06-30

Imprint
2 | 57 A6V10430571_en--_c
Imprint
Technical specifications and availability subject to change without notice.
Transmittal, reproduction, dissemination and/or editing of this document as
well as utilization of its contents and communication thereof to others without
express authorization are prohibited. Offenders will be held liable for payment
of damages. All rights created by patent grant or registration of a utility model
or design patent are reserved.
Issued by:
Siemens Switzerland Ltd.
Smart Infrastructure
Global Headquarters
Theilerstrasse 1a
CH-6300 Zug
Tel. [phone]
www.siemens.com/buildingtechnologies
Edition: 2020-06-30
Document ID: A6V10430571_en--_c
© Siemens Switzerland Ltd, 2018

A6V10430571_en--_c 3 | 57
Table of contents
1 About this document ............................................................................... 5
1.1 Applicable documents .......................................................................................8
1.2 Technical terms and abbreviations..................................................................9
1.3 Revision history ..................................................................................................9
2 Safety...................................................................................................... 10
2.1 Safety notes ......................................................................................................10
2.2 Safety regulations for the method of operation ...........................................11
2.3 System owner ...................................................................................................13
2.4 Function test / system acceptance / maintenance.....................................13
2.5 Standards and directives complied with .......................................................14
2.5.1 Multimedia equipment.....................................................................14
2.6 Cyber security disclaimer................................................................................15
3 Operating conditions ............................................................................. 16
3.1 Operating condition indicators .......................................................................16
4 Operating elements in the system........................................................ 17
4.1 Call stations ......................................................................................................17
4.2 Operating terminals .........................................................................................20
5 Access levels.......................................................................................... 22
6 Fire brigade call station (AT) PT2002-A1............................................. 23
6.1 Operating functions PT2002-A1.....................................................................24
6.2 Operation PT2002-A1 ......................................................................................25
7 Fire brigade call station (485, AT) PT2003-A1..................................... 26
7.1 Operating functions PT2003-A1.....................................................................27
7.2 Operation PT2003-A1 ......................................................................................28
8 Desk call station (19 buttons) PT2001-A1 ........................................... 29
8.1 Operating functions PT2001-A1.....................................................................29
8.2 Operation PT2001-A1 ......................................................................................30
8.3 Indicator PT2001-A1........................................................................................32
8.4 Display information PT2001-A1 .....................................................................33
9 Key switch for desk call station PTO2002/3-A1.................................. 34
9.1 Operating functions PTO2002/3-A1 ..............................................................34
9.2 Operation PTO2002/3-A1 ...............................................................................34
10 Desk call station (RS485, 8+1) PT2009-A1 and Call station extension
(RS485, 8) PTO2006-A1 ......................................................................... 35
10.1 Operating functions PT2009-A1.....................................................................35
10.2 Operation PT2009-A1 ......................................................................................36
10.3 Indicator PT2009-A1........................................................................................37
11 Desk call station (analog, 3+1) PT2008-A1 ......................................... 38
11.1 Operating functions PT2008-A1.....................................................................38
11.2 Operation PT2008-A1 ......................................................................................39
11.3 Indicator PT2008-A1........................................................................................40
12 System operating unit (19") PT2010-A1............................................... 41

4 | 57 A6V10430571_en--_c
12.1 Operating functions PT2010-A1 .................................................................... 41
12.2 Operation PT2010-A1...................................................................................... 42
12.3 Indicator PT2010-A1 ....................................................................................... 43
13 System status indicator (19") PT2004-A1............................................ 44
13.1 Operating functions PT2004-A1 .................................................................... 44
13.2 Operation PT2004-A1...................................................................................... 44
13.3 Indicator PT2004-A1 ....................................................................................... 45
14 System status display (door) PT2007-A1............................................. 46
14.1 Operating functions PT2007-A1 .................................................................... 46
14.2 Operation PT2007-A1...................................................................................... 46
14.3 Indicator PT2007-A1 ....................................................................................... 47
15 Alarm control panel (19") PT2005-A1................................................... 48
15.1 Operating functions PT2005-A1 .................................................................... 48
15.2 Operation PT2005-A1...................................................................................... 49
15.3 Indicator PT2005-A1 ....................................................................................... 49
16 Remote control panel PT2006-A1......................................................... 50
16.1 Operating functions PT2006-A1 .................................................................... 50
16.2 Operation PT2006-A1...................................................................................... 51
17 System acceptance on site ................................................................... 52
18 Commissioning and maintenance ........................................................ 53
Glossary............................................................................................................ 55
Index ................................................................................................................ 56

About this document
Applicable documents 1
A6V10430571_en--_c 5 | 57
1 About this document
Retention and availability
NOTICE
Missing information
Damage due to misuse
●This document must be available in a usable format throughout the entire
life cycle of the product. Keep the document for reference and ensure that
it can be accessed by target groups.
Should you require another copy of this document, please contact the Customer
Support Center, phone [phone].
Goal and purpose
This document describes the operation of a ↑Cerberus PACE voice alarm and
announcement system on the ↑voice alarm control and indicating equipment
(VACIE) and the additional operating elements of the voice alarm system.
The reader should learn about and understand the operating elements and the
key functions in the system as a whole. This knowledge will mean that they can
respond adequately in an emergency and will be able to operate other system
functions correctly.
Scope
The information contained in this document is valid for Cerberus PACE.
WARNING
The '
Cerberus PACE
' system is a Class A product which may cause radio
interference in a domestic environment in which case the user may be
required to take adequate measures.

About this document
Applicable documents
1
6 | 57 A6V10430571_en--_c
Target groups
The information in this document is intended for the following target groups:
Target group Activity Qualification
System owner ●According to EN 50110-1,
'nominated person with the overall
responsibility to ensure the safe
operation of the electrical
installation by setting rules and
organisation or framework.'
●'This person can be the owner,
employer, proprietor or a
delegated person.'
●'Some of these duties can be
delegated to others as required.
For large or complex electrical
installations or networks, the
duties can be delegated for parts
of the installations or the network.'
IT security officers ●Support companies when it comes
to assessing the security of
products, solutions, and services,
and defining and implementing
improvements.
●Are technical experts in all aspects
of IT security.
Commissioning personnel ●Configures the product at the
place of installation according to
customer-specific requirements.
●Checks the product operability and
releases the product for use by the
operator.
●Searches for and corrects
malfunctions.
●Has obtained suitable specialist
training for the function and for
the products.
●Has attended the training courses
for commissioning personnel.
Operating personnel ●Carries out procedures to correctly
operate the product.
●No particular basic training is
needed.
●Has been instructed by the
commissioning personnel.
Maintenance personnel ●Carries out all maintenance work.
●Checks that the products are in
perfect working order.
●Searches for and corrects
malfunctions.
●Has obtained suitable specialist
training for the function and for
the products.
Source language and reference document
●The source/original language of this document is German (de).
●The reference version of this document is the international version in
English. The international version is not localized.
Document identification
The document ID is structured as follows:
ID code Examples
ID_languageCOUNTRY_ modification index
-- = multilingual or international
A6V10215123_deDE_a
A6V10215123_en--_a
A6V10315123_----_a
Date format
The date format in the document corresponds to the recommendation of
international standard ISO 8601 (format YYYY-MM-DD).

About this document
Applicable documents 1
A6V10430571_en--_c 7 | 57
Conventions for text marking
Markups
Special markups are shown in this document as follows:
wRequirement for a behavior instruction
1.
2.
Behavior instruction with at least two operation sequences
◈Behavior instruction with one operation sequence
– Version, option, or detailed information for a behavior instruction
aIntermediate result of a behavior instruction
aEnd result of a behavior instruction
●Lists
[➙X] Reference to a page number
'Text' Quotation, reproduced identically
<Key> Identification of keys
>Relation sign and for identification between steps in a sequence,
e.g., 'Menu bar' > 'Help' > 'Help topics'
↑Text Identification of a glossary entry
Supplementary information and tips
The 'i' symbol identifies
supplementary information and tips for an easier way
of working.

About this document
Applicable documents
1
8 | 57 A6V10430571_en--_c
1.1 Applicable documents
You will find more information on the Cerberus PACE system and its
components in the following documents:
Title Document ID
IT security policies
Cerberus PACE – IT security policies A6V11439692
System documentation
Cerberus PACE – planning A6V11244536
'PACE-Design' – configuration A6V10429097
Cerberus PACE – mounting / installation A6V10430579
Cerberus PACE – operation A6V10430571
Data sheets
System data sheet A6V11243351
19" cabinets A6V10429243
Digital audio matrix A6V10430497
Power amplifier A6V10430515
Operating terminals A6V10430526
Call stations and extensions A6V10430544
Power supply and batteries A6V10430553
Accessories and options A6V10430563
Loop isolator (100V)
Loop isolator (100V) - technical manual A6V11571319
Environmental declaration
Cerberus PACE – environmental declaration A6V11948779
Download center
Related documents such as environmental declarations, CE declarations, etc.,
can be downloaded at the following Internet address:
http://siemens.com/bt/download

About this document
Technical terms and abbreviations 1
A6V10430571_en--_c 9 | 57
1.2 Technical terms and abbreviations
You will find details of technical terms and abbreviations in the 'Glossary'
chapter.
1.3 Revision history
The reference document's version applies to all languages into which the
reference document is translated.
The first edition of a language version or a country variant may, f
or example,
be version 'd' instead of 'a' if the reference document is already this version.
The table below shows this document's revision history:
Version Edition date Brief description
c 2020-06-30 New: 'Call stations [➙17]' for Fire brig call stat (485, AT) PT2003-A1;
'Operating terminals [➙20]' for System operating unit (19") PT2010-A1. 'Fire
brigade call station (485, AT) PT2003-A1 [➙26]'; 'Desk call station (RS485,
8+1) PT2009-A1 and Call station extension (RS485, 8) PTO2006-A1 [➙35]';
'Desk call station (analog, 3+1) PT2008-A1 [➙38]'; 'System operating unit
(19") PT2010-A1 [➙41]';
Updated: Chapter 'Desk call station (19 buttons) PT2001-A1 [➙29]';
'Operation PT2001-A1 [➙30]'; 'Operation PTO2002/3-A1 [➙34]'; 'Operating
functions PT2007-A1 [➙46]'; 'Operating functions PT2005-A1 [➙48]';
'Operation PT2005-A1 [➙49]'; 'Commissioning and maintenance [➙53]'.
b 2018-07-19 New: Target group 'IT security officers', chapter 'Function test / system
acceptance / maintenance [➙13]', 'Information technology equipment (ITE)',
'System acceptance on site [➙52]'
Updated: Chapter 'Commissioning and maintenance [➙53]', 'Operating
functions PT2003-A1 [➙27]', 'Operation PT2003-A1 [➙28]', 'Operating
functions PT2004-A1 [➙44]', 'System status display (door) PT2007-A1
[➙46]', 'Operation PT2005-A1 [➙49]'
a 2018-06-08 First edition

Safety
Safety notes
2
10 | 57 A6V10430571_en--_c
2 Safety
2.1 Safety notes
Comply with the following safety notes to protect life, limb, and property.
The safety notes in the document include the following elements:
●Symbol for hazard
●Signal word
●Type and source of hazard
●Consequences in the event the hazard occurs
●Measures or prohibitions to prevent the hazard
Symbol for hazard
This is the symbol for hazard. It warns you of Risks of injury.
Comply with all measures designated by this symbol to prevent injury or
death.
Additional hazard symbols
These symbols indicate general hazards, type of hazard, possible
consequences, measures and prohibitions, a sample of which is displayed in
the following table:
General hazard Potentially explosive
atmospheres
Voltage/electrical shock Laser light
Battery Heat
Signal word
The signal word classifies the hazard as defined in the following table:
Signal word Danger level
DANGER 'DANGER' identifies a dangerous situation, that results directly in death or
serious injuries, if you do not avoid this situation.
WARNING 'WARNING' identifies a dangerous situation, that can result in death or
serious injuries, if you do not avoid this situation.
CAUTION 'CAUTION' identifies a dangerous situation, that can result in minor or
moderate injuries, if you do not avoid this situation.
Note ' NOTE ' identifies a possible situation that may cause damage if not observed.
'
NOTE ' does not reference possible injury.

Safety
Safety regulations for the method of operation 2
A6V10430571_en--_c 11 | 57
Depiction of risk of injury
Notes on risk of injury is depicted as follows:
WARNING
Type and source of
hazard
Consequences in the event the hazard occurs
●
Measures/prohibitions to prevent the hazard
DEPICTION for possible damage to property
Notes on possible damage to property is depicted as follows:
NOTICE
Type and source of hazard
Consequences in the event the hazard occurs
●
Measures/prohibitions to prevent the hazard
2.2 Safety regulations for the method of operation
National standards, regulations and legislation
Siemens products are developed and produced in compliance with the relevant
European and international safety standards. Should additional national or local
safety standards or legislation concerning the planning, mounting, installation,
operation or disposal of the product apply at the place of operation, then these
must also be taken into account together with the safety regulations in the
product documentation.
Electrical installations
WARNING
Electrical voltage
Electric shock
●Work on electrical installations may only be carried out by qualified
electricians or by instructed persons working under the guidance and
supervision of a qualified electrician, in accordance with the
electrotechnical regulations.
●Wherever possible disconnect products from the power supply when
carrying out commissioning, maintenance or repair work on them.
●Lock volt-free areas to prevent them being switched back on again by
mistake.
●Label the connection terminals with external voltage using a
'DANGER External voltage' sign.
●Route mains connections to products separately and fuse them with their
own, clearly marked fuse.
●Fit an easily accessible disconnecting device in accordance with
IEC 60950-1 outside the installation.
●Produce earthing as stated in local safety regulations.

Safety
Safety regulations for the method of operation
2
12 | 57 A6V10430571_en--_c
CAUTION
Noncompliance with the following safety regulations
Risk of injury to persons and damage to property
●
Compliance with the following regulations is required.
●Specialist electrical engineering knowledge is required for installation.
●Only an expert is permitted to carry out installation work.
Incorrect installation can take safety devices out of operation unbeknown to a
layperson.
Mounting, installation, commissioning and maintenance
●If you require tools such as a ladder, these must be safe and intended for
the work in question.
●When starting the voice alarm system, make sure that no unstable states
can occur.
●Make sure that all points described in the 'Testing and checking the
functionality of the products' section below are observed.
●You may only put controls into normal operation once work to test and
check the functionality of the products has been completed and the site has
been handed over to the customer.
Testing and checking the functionality of the products
●Prevent incorrect triggering of the remote transmission.
●When you test building equipment or activate devices from third-party
companies, you must liaise with the people responsible for these.
●No one must be injured and no damage to the building equipment must
occur when voice alarm controls are activated for test purposes. The
following instructions must be observed:
– Use the correct potential for the activation; as a rule, this will be the
potential of the building equipment.
– Only check controls up to the interface (relay with blocking option).
– Make sure that only the controls to be tested are activated.
●Inform people before testing alarm devices and determine any potential
panic reactions.
●Inform people of any noise or mist which may occur.
●Inform the corresponding alarm and fault receiving centers before
performing a test remote transmission.
Modifications to the system design and the products
Modifications to the system and to individual products may lead to faults,
malfunctioning and safety risks. Written confirmation must be obtained from
Siemens and the corresponding safety bodies for modifications or additions.
Modules and spare parts
●Components and spare parts must comply with the technical specifications
defined by Siemens. Only use products specified or recommended by
Siemens.
●Only use fuses with the specified fuse characteristics.
●Wrong battery types and improper battery changing lead to a risk of
explosion. Only use the same battery type or an equivalent battery type
recommended by Siemens.
●Batteries must be disposed of in an environmentally friendly manner.
Observe national guidelines and regulations.

Safety
System owner 2
A6V10430571_en--_c 13 | 57
Disregard of the safety regulations
Before they are delivered, Siemens products are tested to ensure they function
correctly when used properly. Siemens disclaims all liability for damage or
injuries caused by the incorrect application of the instructions or the disregard
of danger warnings contained in the documentation. This applies in particular
to the following damage:
●Personal injuries or damage to property caused by improper use and
incorrect application
●Personal injuries or damage to property caused by disregarding safety
instructions in the documentation or on the product
●Personal injury or damage to property caused by poor maintenance or lack
of maintenance
2.3 System owner
According to EN 50110-1, the system owner must also ensure that the
commissioning personnel and the operating personnel – see 'Target groups
[➙6]' – have the necessary knowledge relating to the position of operating
terminals and call stations of a Cerberus PACE system.
WARNING
Lack of orientation in the event of an alarm
Delayed measures to prevent damage
●As the system owner, you must ensure that the members of the operating
personnel are aware of the position of all operating terminals and call
stations of the
Cerberus PACE
system.
2.4 Function test / system acceptance /
maintenance
WARNING
Failure to follow instructions and recommendations
Restricted alarms or no alarms, and personal injury in the case of evacuation.
●Read and follow the instructions and recommendations provided in the
chapters referred to
below.
Failure to follow the instructions and recommendations found in the chapters
'System acceptance on site [➙52]', and 'Commissioning and maintenance
[➙53]' may result in the system not being able to help protect the lives and
wellbeing of people at all or to its full potential, especially in the event that an
evacuation is required.

Safety
Standards and directives complied with
2
14 | 57 A6V10430571_en--_c
2.5 Standards and directives complied with
A list of the standards and directives complied with is available from your
Siemens contact.
2.5.1 Multimedia equipment
In the DIN EN 55032 standard (VDE 0878-32):2016-02; EN 55032:2015
'Electromagnetic compatibility of multimedia equipment – Emission
Requirements', the following information is provided on multimedia equipment
in section 4:
---- Start EN 55032 section 4 ----
4 Classification of equipment
This standard defines Class A equipment and Class B equipment associated
with two types of end-use environment.
Class A equipment is equipment which meets the requirements given in Table
A.2, Table A.3, Table A.9, and Table A.11, using the limitations defined in Table
A.1 and Table A.8.
Class B equipment is equipment which meets the requirements given in Table
A.4, Table A.5, Table A.6, Table A.7, Table A.10, Table A.12 and Table A.13,
using the limitations defined in Table A.1 and Table A.8.
The Class B requirements for equipment are intended to offer adequate
protection to broadcast services within the residential environment.
Equipment intended primarily for use in a residential environment shall meet
the Class B limits. All other equipment shall comply with the Class A limits.
Broadcast receiver equipment is class B equipment.
NOTE Equipment meeting Class A requirements may not offer adequate
protection to broadcast services within a residential environment.
---- End EN 55032 section 4 ----
WARNING
The '
Cerberus PACE
' system is a Class A product which may cause radio
interference in a domestic environment in which case the user may be
required to take adequate measures.
WARNING
Failure of external devices to comply with the permitted EMC classes
Personal injury and damage to property in an emergency due to a fault with
the system and complete failure of the alarm.
●Check the categorization of external devices in the same room or building
that may have an impact on the 'Cerberus PACE' system, following
DIN
EN
55032, section 4, 'Classification of equipment'.

Safety
Cyber security disclaimer 2
A6V10430571_en--_c 15 | 57
2.6 Cyber security disclaimer
Siemens provides a portfolio of products, solutions, systems and services that
includes security functions that support the secure operation of plants,
systems, machines and networks. In the field of Building Technologies, this
includes building automation and control, fire safety, security management as
well as physical security systems. In order to protect plants, systems, machines
and networks against cyber threats, it is necessary to implement – and
continuously maintain – a holistic, state-of-the-art security concept. Siemens’
portfolio only forms one element of such a concept.
You are responsible for preventing unauthorized access to your plants, systems,
machines and networks which should only be connected to an enterprise
network or the internet if and to the extent such a connection is necessary and
only when appropriate security measures (e.g. firewalls and/or network
segmentation) are in place. Additionally, Siemens’ guidance on appropriate
security measures should be taken into account. For additional information,
please contact your Siemens sales representative or visit
https://www.siemens.com/global/en/home/company/topic-areas/future-of-
manufacturing/industrial-security.html.
Siemens’ portfolio undergoes continuous development to make it more secure.
Siemens strongly recommends that updates are applied as soon as they are
available and that the latest versions are used. Use of versions that are no
longer supported, and failure to apply the latest updates may increase your
exposure to cyber threats. Siemens strongly recommends to comply with
security advisories on the latest security threats, patches and other related
measures, published, among others, under
https://www.siemens.com/cert/en/cert-security-advisories.htm.

Operating con
ditions
Operating condition indicators
3
16 | 57 A6V10430571_en--_c
3 Operating conditions
The ↑voice alarm control and indicating equipment (VACIE) or voice alarm
system has the following operating conditions:
●Quiescent condition
●Voice alarm condition
●Fault warning condition
3.1 Operating condition indicators
Indicating element colors
The light-emitting indicating elements display operating conditions as follows:
Color ↑Operating condition
Red ↑Voice alarm condition
Yellow ↑Fault warning condition
Green ↑Quiescent condition
VACIE is supplied with energy
Evacuation messages and alert messages
Automatic voice messages for evacuation messages and alert messages are
indicated as follows:
Color Operating condition
Red Evacuation messages
Yellow Alert messages
Fault warning condition and RSL
Causes of a fault being displayed are defined in the
↑
'RSL when the system
is configured with 'PACE-Design'.

Operating elements in the system
Call stations 4
A6V10430571_en--_c 17 | 57
4 Operating elements in the system
The operating elements in a Cerberus PACE voice alarm system are the call
stations and operating terminals with which you can make live announcements
and play emergency tones and recorded messages in a targeted manner.
In addition, you can carry out key system functions, read off the system state,
and also play music using these operating elements.
4.1 Call stations
PT2002-A1 'Fire brigade call station (AT)'
●Alarm call station with standard-compliant housing and control panel
●Full network participant in a Cerberus PACE system
●7 standardized and preconfigured buttons
●3 standardized and preconfigured displays
●Removable hand-held microphone with talk button
●Microphone and line monitoring
●Integrated audio amplifier (1 watt) and speaker
●Real-time audio transmission with constant latency: 4.6 ms analog-
in/analog-out
●Integrated industrial micro SD card reader/writer with max. 2 GB card
capacity for alarm messages
●Recording capacity: 256 files with a total duration of approx. 3 hours
●Provision of alarm announcements and alarm tones
●2x Ethernet LAN interfaces for connection to 'PACE-Net'
●One additional audio input (line) and one additional audio output
●Adapter module PTO2009-A1 for redundant connection to the control
panel
PT2003-A1 'Fire brigade call station (485, AT)'
●Alarm call station with standard-compliant housing and control panel
●7 standardized and preconfigured buttons
●3 standardized and preconfigured displays
●Removable hand-held microphone with talk button
●Microphone and line monitoring
●Symmetrical audio transmission, analog
●Audio output 0 dB (line volume)
●RS485 data transmission ('PACE-Bus')
●Connection to control panel via CAT5 cable (max. 500 m)
●Connection to control panel with RJ45 or screw terminal connector
●Adapter module PTO2008-A1 for connection to the control panel
●Addressable via 4-way SIP switch in device

Operating elements in the system
Call stations
4
18 | 57 A6V10430571_en--_c
PT2001-A1 'Desk call station (19 buttons)'
●Call station with electret condenser microphone and gooseneck
●Full network participant in a Cerberus PACE system
●2-line text display
●Buttons and status indicators to control and monitor the Cerberus PACE
system by users. The buttons are basically freely operable
●Insertable labels for custom button identification
●Monitored microphone
●Integrated audio amplifier (1 watt) and speaker
●1x additional audio input (line/mic) and 1x additional audio output
●4x digital inputs, 4x digital outputs, and 6x analog control inputs
●Live speech / real-time audio transmission and integrated real-time
recorder for delayed announcements
●Integrated micro SD card reader/writer with max. 2 GB card capacity for
alarm messages
●Recording capacity: 256 files with a total duration of approx. 3 hours
●Provision of alarm announcements and alarm tones
●2x Ethernet LAN interfaces for connection to 'PACE-Net'
●Can be extended with up to 4 additional button modules PTO2001-A1
●Can be extended with key switch module PTO2002-A1/PTO2003-A1 to
enable buttons to be released or locked
●Adapter module PTO2009-A1 for redundant connection to the control
panel
PTO2001-A1 'Desk call station extension (24 buttons)'
●Optional button extension for the desk call station PT2001-A1
●24 freely configurable buttons
●Up to 4x button extensions per desk call station PT2001-A1, offering a
total of 115 buttons
●Insertable labels for custom button identification
PTO2002-A1 'Desk call station extension (Kaba)'
●Call station extension for PT2001-A1 with key switch (Kaba)
●Enables call station operation
PTO2003-A1 'Desk call station extension (Nordic)'
●Call station extension for PT2001-A1 with key switch (Nordic)
●Enables call station operation

Operating elements in the system
Call stations 4
A6V10430571_en--_c 19 | 57
PT2009-A1 'Desk call station (RS485, 8+1)'
●Call station with 8 configurable, illuminated zone buttons plus talk button
●Buttons are freely operable
●Electret condenser microphone with gooseneck
●Monitored microphone
●Symmetrical audio transmission, analog
●RS485 data transmission ('PACE-Bus')
●Audio output 0 dB (line volume)
●Connection to control panel via CAT5 cable or above (max. 500 m) and
RJ45 connector
●Up to 5 call stations can be configured in a cascade 'daisy chain'
●Adapter module PTO2008-A1 for connection to the control panel
●Option to add up to three extension modules, each with 8 zone buttons
●Addressable via 8-way SIP switch in device
●Insertable labels for custom button identification
●Robust sheet steel housing
PTO2006-A1 'Call station extension (RS485, 8)'
●Optional button extension for desk call station PT2009-A1
●Up to 3 button extensions possible for desk call station PT2009-A1,
offering a total of 32 buttons
●8 configurable, illuminated zone buttons
●Insertable labels for custom button identification
PT2008-A1 'Desk call station (analog, 3+1)'*
●Call station with 3 configurable zone buttons plus talk button
●Buttons are freely operable.
●Electret condenser microphone with gooseneck
●Symmetrical audio transmission, analog
●Audio output 0 dB (line volume)
●Control signals for zones 1-3 and 'Talk'
●Connection to control panel via CAT5 cable or above (max. 150 m) and
RJ45 connector
●Supplied adapter module for connection to control panel
●Insertable labels for custom button identification
●Robust sheet steel housing
* The desk call station PT2008-A1' may only be used for standard applications
and not for alarm applications.

Operating elements in the system
Operating terminals
4
20 | 57 A6V10430571_en--_c
4.2 Operating terminals
PT2010-A1 'System operating unit (19")'
●EN 54-16-compliant indicator panel for visual and acoustic status
messages and control voice alarms
●Display of system status
●Control of voice alarms
●Fault warning with acoustic warning signal
●Color-coded visual indicators: operation, fault, and alarm
– Operation: green
– Fault: yellow
– Voice Alarm: red
●Color-coded control buttons: control of voice alarms, acknowledges
– <Start Voice Alarm>: red LED indicator button
– <Reset Voice Alarm>: black button
– <Silence Voice Alarm>: green LED indicator button
– Acknowledge faults: black button
– Acknowledge acoustic warning and LED test: black button
●8 predefined visual fault indicators: yellow
– Power fault
– Fuse fault
– Earth fault
– 'PACE-Net' fault
– 'PACE-Bus' fault
– Amplifier fault
– Microphone fault
– Speaker circuit fault
●8 user-configurable state indicators: yellow
●Potential-free fault contact
●Service socket
●RS485 data transmission ('PACE-Bus')
●Addressable via 4-way SIP switch for 'PACE-Bus' connection
●Design: 19", 2 HU
PT2004-A1 'System state indicator (19")'
●EN 54-16-compliant indicator panel for visual and acoustic status
messages
●Color-coded visual indicators: operation, fault, and alarm
– Operation: green
– Fault: yellow
– Voice Alarm: red
●Fault warning with acoustic warning signal
●Acknowledge acoustic warning and LED test: black button
●Potential-free fault contact
●Design: 19", 1 HU
