Siemens MI291A Guide

Guarto
Multifunctional
Security System
Maintenance Info MI291a
MP3 - Service Release SR2
Building Technologies
Fire Safety & Security Products

Liefermöglichkeiten und technische Änderungen vorbehalten.
Data and design subject to change without notice. / Supply subject to availability.
Sous réserve de modifications techniques et de la disponibilité.
© 2009 Copyright by
Siemens Switzerland Ltd
Wir behalten uns alle Rechte an diesem Dokument und an dem in ihm dargestellten Gegenstand vor. Der Empfänger anerkennt diese
Rechte und wird dieses Dokument nicht ohne unsere vorgängige schriftliche Ermächtigung ganz oder teilweise Dritten zugänglich machen
oder außerhalb des Zweckes verwenden, zu dem es ihm übergeben worden ist.
We reserve all rights in this document and in the subject thereof. By acceptance of the document the recipient acknowledges these rights
and undertakes not to publish the document nor the subject thereof in full or in part, nor to make them available to any third party without our
prior express written authorization, nor to use it for any purpose other than for which it was delivered to him.
Nous nous réservons tous les droits sur ce document, ainsi que sur l'objet y figurant. La partie recevant ce document reconnaît ces droits et
elle s'engage à ne pas le rendre accessible à des tiers, même partiellement, sans notre autorisation écrite préalable et à ne pas l'employer
à des fins autres que celles pour lesquelles il lui a été remis.

Maintenance Info MI291a: Guarto MP3 SR2
1 Maintenance Info MI291a: Guarto MP3 SR2
The first edition of MP3 for Guarto was released in January 2003. See related Up-
data sheet UPe128. This release MP3 SR2 becomes available in January 2009.
MP3 is the common version for networked applications or standalone respectively.
Mind the special version YCD01503 for the integration into the management sta-
tion MM2000 with a relaxed check for the time synchronization via network.
This Service Release contains a new Real-Time-Clock driver with an auto-detect
function for the current RTC chip and the new respectively. The new RTC chip re-
places the current one which is not available anymore. Therefore, a new HW is
provided with a socket for holding the new RTC chip device.
1.1 Actual Compatibility
Guarto MP3 SR2 Version Memories Remark/Checksum
Actual compatibility
Software Tool
V5.0a
Maintenance System SWE6 Release MP3 SR1
V4.4
Standard Text Editor SWU6 Release MP3
Master Card E3X130
CCD005.03
Control Unit Program Empty EPROM: Type 27C4001
= part. No. 476 362 0001 $0AE2 /odd, $0D1E /even Bridges EPROM: X11, Y12
RAMs RAM: 512kx8
= part no. 484 794 Bridges RAM: X10
LON Adapter K3I070
BKD002.02
Empty EPROM: Type 27C256
= part. No. 390 477 $BC00
Terminal CT6M
V1.2
Index bb does not support
Cyrillic
V2.0
Index bc with new LCD-
Controller for Cyrillic
Terminal CT6C
CTD001.04
Firmware Empty EPROM: Type 27C512
= part. No. 417 745 $B4D6
Door Module DCU601
CFD003.03
Firmware Empty EPROM: Type 27C512
= part. No. 417 745 $7BD6
PFD002.00
PAL $457E
Dialer (IK601) K3D030
CK6_V16
Firmware Empty EPROM: Type 27C512
= part. No. 417 745 $DEC8
Tab. 1 Compatibility
3
Building Technologies MI291a.doc
Fire Safety & Security Products 01.2009

Maintenance Info MI291a: Guarto MP3 SR2
1.2 Fixed Application Problems
The current RTC chip is not available anymore. So, a new pin compatible device
with a new chip was produced in cooperation for Guarto and AlgoRex. This re-
quires the use of a new RTC driver, which supports the current chip as well as the
new device.
Therefore, a new HW version is provided too, where the current RTC chip is re-
moved from the board and a socket is mounted instead, so that the piggy-back de-
vice with the new RTC chip can be inserted.
1.3 Fixed Tool Problems
For the mentioned SR1 of MP3 an improved SWE6 tool V5.0a was provided.
The following problems were fixed:
zThe delay of remote transmission for 'Security-jeopardizing fault' and 'Major fault'
was not visible and configurable anymore
(new range for each remote transmission type 10..1800s)
zGeneration of CNAP profile adjusted that a data import of the management sys-
tem doesn't stop anymore because of a section without zone
zListing of configuration data (for sections) contained also the section number
and not only the numbers of the linked zones
Installation (Update V5.0):
– Uninstall SWE6 MP3 V5.0
– Install SWE6 MP3 V5.0
ÎWhen this message appears: click No
4
Building Technologies MI291a.doc
Fire Safety & Security Products 01.2009

Siemens Switzerland Ltd
Building Technologies Group
International Headquarters
Fire Safety & Security Products
Gubelstrasse 22
CH-6301 Zug
Tel. +41 41 – 724 24 24
Fax +41 41 – 724 35 22
www.sbt.siemens.com
Document no. A6V10235243 Manual CS6
Edition 01.2009 Section 2
