Siemens FDM1101-R Series User manual

FDM1101-Rx
Manual call point collective
Technical Manual
A6V10201150_d_en_--
Building Technologies
2018-12-19 Control Products and Systems

Imprint
2 | 32
Building Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
Imprint
Technical specifications and availability subject to change without notice.
Transmittal, reproduction, dissemination and/or editing of this document as well as
utilization of its contents and communication thereof to others without express
authorization are prohibited. Offenders will be held liable for payment of damages.
All rights created by patent grant or registration of a utility model or design patent
are reserved.
Issued by:
Siemens Switzerland Ltd.
Building Technologies Division
International Headquarters
Theilerstrasse 1a
CH-6300 Zug
Tel. [phone]
www.siemens.com/buildingtechnologies
Edition: 2018-12-19
Document ID: A6V10201150_d_en_--
© Siemens Switzerland Ltd, 2008

3 | 32
Building Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
Table of contents
1 About this document ............................................................................. 5
1.1 Applicable documents................................................................................. 7
1.2 Download center......................................................................................... 7
1.3 Technical terms and abbreviations.............................................................. 7
1.4 History of changes...................................................................................... 8
2 Safety .................................................................................................9
2.1 Safety instructions ...................................................................................... 9
2.2 Safety regulations for the method of operation ...........................................11
2.3 Standards and directives complied with......................................................13
2.4 Release Notes ...........................................................................................13
3 Structure and function ......................................................................... 14
3.1 Overview ...................................................................................................14
3.1.1 Product version ES .....................................................................15
3.1.2 Details for ordering......................................................................15
3.2 Setup.........................................................................................................16
3.2.1 Connections................................................................................16
3.2.2 Indication elements .....................................................................16
3.3 Function ....................................................................................................17
3.3.1 Danger levels..............................................................................17
3.3.2 Test mode...................................................................................17
3.4 Accessories ...............................................................................................18
3.4.1 Key.............................................................................................18
3.4.2 'NOT IN USE' label .....................................................................18
3.4.3 Plastic insert ...............................................................................18
3.4.4 Glass insert.................................................................................18
3.4.5 Optional accessories...................................................................19
3.4.5.1 Key FDMK295..............................................................19
3.4.5.2 Protective cover FDMC295...........................................19
3.4.5.3 Plastic inserts FDMP295-x ...........................................19
3.4.5.4 Glass inserts FDMG295-x ............................................20
3.4.5.5 Back box FDMH295-R .................................................20
3.4.5.6 Back box FDMH295-S..................................................20
3.4.5.7 Metal cable gland M20 x 1.5.........................................21
3.4.5.8 M20 x 1.5 metal counter nut .........................................21
3.4.5.9 Connection terminal DBZ1190-AB................................21
4 Project engineering............................................................................. 22
4.1 Compatibility..............................................................................................22
4.2 Ranges of application ................................................................................22
4.3 Installation site...........................................................................................22
4.4 Environmental influences ...........................................................................22

Building Technologies
A6V10201150_d_en_
--
Fire
Safety
2018
-
12
-
19
4 | 32
5 Mounting / Installation..........................................................................23
5.1 Installation .................................................................................................25
6 Commissioning ...................................................................................26
7 Maintenance / Repair ..........................................................................27
7.1 Performance check....................................................................................27
7.2 Testing detector with the key .....................................................................27
7.3 Replacing the glass insert..........................................................................28
7.4 Spare parts................................................................................................28
8 Specifications .....................................................................................29
8.1 Technical data ...........................................................................................29
8.2 Dimensions ...............................................................................................30
8.3 Environmental compatibility and disposal...................................................30
Index .........................................................................................................31

About this document
Applicable documents
1
5 |
32
Building Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
1 About this document
Goal and purpose
This document includes all information on the manual call points FDM1101-Rx.
Following the instructions consistently will ensure that the product can be used
safely and without any problems.
Target groups
The information in this document is intended for the following target groups:
Target group Activity Qualification
Product Manager ●Is responsible for information
passing between the manufacturer
and regional company.
●Coordinates the flow of information
between the individual groups of
people involved in a project.
●Has obtained suitable specialist
training for the function and for the
products.
●Has attended the training courses
for Product Managers.
Project Manager ●Coordinates the deployment of all
persons and resources involved in
the project according to schedule.
●Provides the information required to
run the project.
●Has obtained suitable specialist
training for the function and for the
products.
●Has attended the training courses
for Project Managers.
Installation personnel ●Assembles and installs the product
components at the place of
installation.
●Carries out a performance check
following installation.
●Has received specialist training in
the area of building installation
technology or electrical installations.
Commissioning personnel ●Configure the product at the place
of installation according to
customer-specific requirements.
●Check the product operability and
release the product for use by the
operator.
●Searches for and corrects
malfunctions.
●Has obtained suitable specialist
training for the function and for the
products.
●Has attended the training courses
for commissioning personnel.
Maintenance personnel ●Carries out all maintenance work.
●Checks that the products are in
perfect working order.
●Searches for and corrects
malfunctions.
●Has obtained suitable specialist
training for the function and for the
products.

About this document
Applicable documents
1
6 | 32
Building Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
Source language and reference document
●The source/original language of this document is German (de).
●The reference version of this document is the international version in English.
The international version is not localized.
Document identification
The document ID is structured as follows:
ID code Examples
ID_ModificationIndex_Language_COUNTRY
-- = multilingual or international
A6V10215123_a_de_DE
A6V10215123_a_en_--
A6V10315123_a_--_--
Date format
The date format in the document corresponds to the recommendation of
international standard ISO 8601 (format YYYY-MM-DD).
Conventions for text marking
Markups
Special markups are shown in this document as follows:
⊳Requirement for a behavior instruction
1.
2.
Behavior instruction with at least two operation sequences
– Version, option, or detailed information for a behavior instruction
⇨Intermediate result of a behavior instruction
⇨End result of a behavior instruction
●Numbered lists and behavior instructions with an operation
sequence
[➙X] Reference to a page number
'Text' Quotation, reproduced identically
<Key> Identification of keys
>Relation sign and for identification between steps in a sequence,
e.g., 'Menu bar' > 'Help' > 'Help topics'
↑Text Identification of a glossary entry
Supplementary information and tips
The 'i' symbol identifies supplementary information and tips for an easier way of
working.

About this document
Applicable documents
1
7 |
32
Building Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
1.1 Applicable documents
Document ID Title
A6V10201154 Installation Manual call point FDM1101-Rx, FDM1101-Rx (F),
FDM1101A-Rx
A6V10206486 Data sheet Manual call point FDM1101-Rx, FDM1101-Rx (F),
FDM1101A-Rx
008331 List of compatibility (for 'Sinteso™' product line)
1.2 Download center
You can download various types of documents, such as data sheets, installation
instructions, and license texts via the following Internet address:
http://siemens.com/bt/download
lEnter the document ID in the 'Find by keyword' input box.
You will also find information about search
variants and links to mobile
applications (apps) for various systems on the home page.
1.3 Technical terms and abbreviations
Term Explanation
EOL Line termination element (End Of Line)
Collective Unaddressed detector line

About this document
History of changes
1
8 | 32
Building Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
1.4 History of changes
The reference document's version applies to all languages into which the reference
document is translated.
The first edition of a language version or a country variant may, for example, be
version 'd' instead of 'a' if the reference document is already this version.
The table below shows this document's revision history:
Version Edition date Brief description
d 2018-12-19 ●Editorial adjustments
c 2017-10-31 ●DBZ1190-AB: Conductor cross-section adapted (0.5…2.5 mm2)
b 2017-02-06 ●'Source language and reference document', 'Applicable documents',
'Download center', 'Conventions for text marking', 'Technical terms', and
'Revision history' sections added in 'About this document' chapter
●'Product version ES' and 'Details for ordering' sub-chapters added in
'Structure and function' chapter
●VdS and LPCB approval details removed from 'Standards' section in
'Technical data' chapter
●Editorial adjustments
a 2008-06-06 ●First edition

Safety
Safety instructions
2
9 |
32
Building Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
2 Safety
2.1 Safety instructions
The safety notices must be observed in order to protect people and property.
The safety notices in this document contain the following elements:
●Symbol for danger
●Signal word
●Nature and origin of the danger
●Consequences if the danger occurs
●Measures or prohibitions for danger avoidance
Symbol for danger
This is the symbol for danger. It warns of risks of injury.
Follow all measures identified by this symbol to avoid injury or death.
Additional danger symbols
These symbols indicate general dangers, the type of danger or possible
consequences, measures and prohibitions, examples of which are shown in the
following table:
General danger Explosive atmosphere
Voltage/electric shock Laser light
Battery Heat
Signal word
The signal word classifies the danger as defined in the following table:
Signal word Danger level
DANGER DANGER identifies a dangerous situation, which will result directly in death or
serious injury if you do not avoid this situation.
WARNING WARNING identifies a dangerous situation, which may result in death or serious
injury if you do not avoid this situation.
CAUTION CAUTION identifies a dangerous situation, which could result in slight to
moderately serious injury if you do not avoid this situation.
NOTICE NOTICE
identifies possible damage to property that may result from non-
observance.

Safety
Safety instructions
2
10 | 32
Building Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
How risk of injury is presented
Information about the risk of injury is shown as follows:
WARNING
Nature and origin of the danger
Consequences if the danger occurs
●
Measures / prohibitions for danger avoidance
How possible damage to property is presented
Information about possible damage to property is shown as follows:
NOTICE
Nature and origin of the danger
Consequences if the danger occurs
●
Measures / prohibitions for danger avoidance

Safety
Safet
y regulations for the method of operation
2
11 |
32
Building Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
2.2 Safety regulations for the method of operation
National standards, regulations and legislation
Siemens products are developed and produced in compliance with the relevant
European and international safety standards. Should additional national or local
safety standards or legislation concerning the planning, mounting, installation,
operation or disposal of the product apply at the place of operation, then these
must also be taken into account together with the safety regulations in the product
documentation.
Electrical installations
WARNING
Electrical
voltage
Electric shock
●Work on electrical installations may only be carried out by qualified
electricians or by instructed persons working under the guidance and
supervision of a qualified electrician, in accordance with the electrotechnical
regulations.
●Wherever possible disconnect products from the power supply when carrying
out commissioning, maintenance or repair work on them.
●Lock volt-free areas to prevent them being switched back on again by mistake.
●Label the connection terminals with external voltage using a
'DANGER External voltage' sign.
●Route mains connections to products separately and fuse them with their own,
clearly marked fuse.
●Fit an easily accessible disconnecting device in accordance with IEC 60950-1
outside the installation.
●Produce earthing as stated in local safety regulations.
CAUTION
Noncompliance with the following safety regulations
Risk of injury to persons and damage to property
●
Compliance with the following regulations is required.
●Specialist electrical engineering knowledge is required for installation.
●Only an expert is permitted to carry out installation work.
Incorrect installation can take safety devices out of operation unbeknown to a
layperson.

Safety
Safety regulations for the method of operation
2
12 | 32
Building Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
Mounting, installation, commissioning and maintenance
●If you require tools such as a ladder, these must be safe and must be intended
for the work in hand.
●When starting the fire control panel ensure that unstable conditions cannot
arise.
●Ensure that all points listed in the 'Testing the product operability' section below
are observed.
●You may only set controls to normal function when the product operability has
been completely tested and the system has been handed over to the customer.
Testing the product operability
●Prevent the remote transmission from triggering erroneously.
●If testing building installations or activating devices from third-party companies,
you must collaborate with the people appointed.
●The activation of fire control installations for test purposes must not cause
injury to anyone or damage to the building installations. The following
instructions must be observed:
– Use the correct potential for activation; this is generally the potential of the
building installation.
– Only check controls up to the interface (relay with blocking option).
– Make sure that only the controls to be tested are activated.
●Inform people before testing the alarm devices and allow for possible panic
responses.
●Inform people about any noise or mist which may be produced.
●Before testing the remote transmission, inform the corresponding alarm and
fault signal receiving stations.
Modifications to the system design and the products
Modifications to the system and to individual products may lead to faults,
malfunctioning and safety risks. Written confirmation must be obtained from
Siemens and the corresponding safety bodies for modifications or additions.
Modules and spare parts
●Components and spare parts must comply with the technical specifications
defined by Siemens. Only use products specified or recommended by
Siemens.
●Only use fuses with the specified fuse characteristics.
●Wrong battery types and improper battery changing lead to a risk of explosion.
Only use the same battery type or an equivalent battery type recommended by
Siemens.
●Batteries must be disposed of in an environmentally friendly manner. Observe
national guidelines and regulations.
Disregard of the safety regulations
Before they are delivered, Siemens products are tested to ensure they function
correctly when used properly. Siemens disclaims all liability for damage or injuries
caused by the incorrect application of the instructions or the disregard of danger
warnings contained in the documentation. This applies in particular to the following
damage:
●Personal injuries or damage to property caused by improper use and incorrect
application
●Personal injuries or damage to property caused by disregarding safety
instructions in the documentation or on the product
●Personal injury or damage to property caused by poor maintenance or lack of
maintenance

Safety
Standards and directives complied with
2
13 |
32
Building Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
2.3 Standards and directives complied with
A list of the standards and directives complied with is available from your Siemens
contact.
2.4 Release Notes
Limitations to the configuration or use of devices in a fire detection installation with
a particular firmware version are possible.
WARNING
Limited or non
-
existent fire detection
Personal injury and damage to property in the event of a fire.
●Read the 'Release Notes' before you plan and/or configure a fire detection
installation.
●Read the 'Release Notes' before you carry out a firmware update to a fire
detection installation.
NOTICE
Incorrect planning and/or configuration
Important standards and specifications are not satisfied.
Fire detection installation is not accepted for commissioning.
Additional expense resulting from necessary new planning and/or configuration.
●Read the 'Release Notes' before you plan and/or configure a fire detection
installation.
●Read the 'Release Notes' before you carry out a firmware update to a fire
detection installation.

Structure and function
Overview
3
14 | 32
Building
Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
3 Structure and function
3.1 Overview
Figure 1: Overview of FDM1101-Rx
1 Key FDMK295 4 Switching unit
2 Cover cap 5 Supplied screws
3 Plastic insert or glass insert 6 Accessories:
Back box FDMH295-R or
back box FDMH295-S
The manual call points FDM1101-Rx are for manually activating alarms in the case
of fire. They consist of a cover cap and a switching unit. Two back boxes are
available as options for surface-mounted feed lines. Back box FDMH295-R does
not have pre-drilled holes for surface-mounted feed lines. Back box FDMH295-S
has two holes and grommets on its top and can be used for surface-mounted feed
lines with a cable diameter of 5 mm.
The activation button can either be actuated using a resettable plastic insert or a
breakable glass insert.
A protective cover can be optionally used to prevent unintentional alarm activation.
The manual call points have the following characteristics:
●Indication of the alarm status via LED
●Communication: Collective protocol
2
3
4
5
6
1

Structure and function
Overview
3
15 |
32
Building Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
3.1.1 Product version ES
The product version ES provides the technical status of a device in terms of
software and hardware. The product version is provided as a two-digit number.
You will find the details of your device's product version:
●On the packaging label
●On the product label or the type plate
Product version on the packaging label
Details of the product version can be found directly on the packaging label in the
barcode:
Figure 2: Example of a packaging label with details of the product version
Product version on the product label and the type plate
Details of the product version can be found after the device order number:
Figure 3: Example of a product label with details of the product version
Depending on the product and various
approvals, the product labels may differ in
terms of the information type and layout.
Look for your device's order number on the product label.
You will find the product version after the order number.
3.1.2 Details for ordering
The manual call points can be ordered in the following versions:
Type Order number Designation
FDM1101-RP S54371-F6-A2 Collective manual call point with plastic insert
FDM1101-RG S54371-F6-A1 Collective manual call point with glass insert
FDM1101-RP (F) S54371-F6-A6 Collective manual call point with plastic insert
for 'France'
FDM1101-RG (F) S54371-F6-A5 Collective manual call point with glass insert
for 'France'
ES
ES
04

Structure and function
Setup
3
16 | 32
Building
Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
3.2 Setup
3.2.1 Connections
The back of the manual call points FDM1101-Rx is fitted with 4 terminals for the
detector line. At the end of the collective detector line, a control-panel-specific end-
of-line element (EOL) must be connected to the terminals.
Figure 4: Connection diagram for FDM1101-Rx
EOL Line termination element (End Of Line)
3.2.2 Indication elements
The manual call points FDM1101-Rx have a red LED. Only the optical fiber can be
seen from the outside.
Figure 5: LED in manual call point FDM1101-Rx
1 Red LED for 'Alarm'
LED red Meaning
Off Normal operation
Flashes light in intervals of 1 s, or is
permanently on (depending on the control
panel)
'Alarm'
LINE
LINE
EOL
+ +
FDM1101-Rx
1

Structure and function
Function
3
17 |
32
Building Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
3.3 Function
3.3.1 Danger levels
The manual call point can transmit the following danger levels to the control panel:
Danger level Meaning
0 Normal state, no danger
3 Alarm
The evaluation of the danger level and the resulting measures (e.g. activation of
remote transmission) are configured on the control panel.
3.3.2 Test mode
The manual call points can also be tested with the key.
A test mode must be set on the control panel to test the manual call points. When
in test mode, alarms from the manual call points are not forwarded by the control
panel.
See also
2Testing detector with the key [➙27]

Structure and function
Accessories
3
18 | 32
Building
Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
3.4 Accessories
3.4.1 Key
A key is enclosed in the delivery of each manual call point.
See also
2Key FDMK295 [➙19]
3.4.2 'NOT IN USE' label
A 'NOT IN USE' label is enclosed in the delivery of each manual call point.
●Warning label for manual call points that are
not in use
●In different languages
●Compatible with
– manual call points FDM1101-Rx /
FDM1101A-Rx / FDM225 / FDM226
3.4.3 Plastic insert
A plastic insert 'UK' FDMP295 is enclosed in the delivery of each manual call point
FDM1101-RP.
A plastic insert 'France' FDMP295-F is enclosed in the delivery of each manual call
point FDM1101-RP (F).
See also
2Plastic inserts FDMP295-x [➙19]
3.4.4 Glass insert
A glass insert 'UK' FDMG295 is enclosed in the delivery of each manual call point
FDM1101-RG.
A glass insert 'France' FDMG295-F is enclosed in the delivery of each manual call
point FDM1101-RG (F).
See also
2Glass inserts FDMG295-x [➙20]
OUT OF ORDER
AUSSER BETRIEB
HORS SERVICE
FUORI SERVIZIO
FUERA DE SERVICIO
BUITEN GEBRUIK
A5Q00030603

Structure and function
Accessories
3
19 |
32
Building Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
3.4.5 Optional accessories
This chapter lists all spare parts with their ordering numbers, in addition to the
optional accessories. Detailed information on the accessories enclosed in the
delivery can also be found here.
3.4.5.1 Key FDMK295
●For testing and resetting manual call points
●For removing the housing cover from the back
box
●Compatible with:
– Manual call point FDM1101-Rx
– Manual call point FDM1101A-Rx
– Manual call point FDM225-Rx
– Manual call point FDM226-Rx
– Radio manual call point FDM275
●Order number: A5Q00013448
3.4.5.2 Protective cover FDMC295
●For protection against unintended alarm
activation
●Compatible with:
– Manual call point FDM1101-Rx
– Manual call point FDM1101A-Rx
– Manual call point FDM225-Rx
– Manual call point FDM226-Rx
– Radio manual call point FDM275
●Order number: A5Q00013440
3.4.5.3 Plastic inserts FDMP295-x
●For alarm activation and protection against
soiling
●Available in country-specific designs
●Compatible with:
– Manual call point FDM1101-Rx
– Manual call point FDM1101A-Rx
– Manual call point FDM225-Rx
– Manual call point FDM226-Rx
– Radio manual call point FDM275
●Order number for plastic insert FDMP295,
'Neutral': A5Q00013445
●Order number for plastic insert FDMP295-F,
'France': A5Q00013446

Structure and function
Accessories
3
20 | 32
Building
Technologies
A6V10201150_d_en_
--
Fire Safety
2018
-
12
-
19
3.4.5.4 Glass inserts FDMG295-x
●For alarm activation and protection against
soiling
●Available in country-specific designs
●Compatible with:
– Manual call point FDM1101-Rx
– Manual call point FDM1101A-Rx
– Manual call point FDM225-Rx
– Manual call point FDM226-Rx
– Radio manual call point FDM275
●Order number for glass insert FDMG295,
'Neutral': A5Q00013442
●Order number for glass insert FDMG295-F,
'France': A5Q00013443
3.4.5.5 Back box FDMH295-R
●For using manual call points with surface-
mounted cable entry
●No pre-drilled holes for the feed lines
●Color: Red
●Compatible with:
– Manual call point FDM1101-Rx
– Manual call point FDM1101A-Rx
– Manual call point FDM225-Rx
●Order number: A5Q00013437
3.4.5.6 Back box FDMH295-S
●For using manual call points with surface-
mounted cable entry
●With two openings and grommets on the top
●Grommets for cable with a diameter of
max. 5 mm
●Color: Red
●Compatible with:
– Manual call point FDM1101-Rx
– Manual call point FDM1101A-Rx
– Manual call point FDM225-Rx
●Order number: A5Q00013438
