SKF Multilog On-line System IMx-T 1-5
Introduction
Important Messages and Requirements
User Manual, Revision F
Introduction
1
Important Messages and Requirements
The following messages are important information which require special care in order
to have a safe and reliable IMx-T system.
Important messages, instructions and information in this manual must be
carefully followed. Otherwise, harm might occur to equipment and/or personnel.
In order to ensure a safe system, installation, configuration and maintenance of
the system must be done by trained personnel only.
IMx-T unit contains circuit boards that are static sensitive. Therefore, use
appropriate precautions to prevent ElectroStatic Discharge (ESD) when handling
circuit boards.
Different types of card must be positioned correctly in the rack. The positions of
the different types of cards are shown in Front Panel with Labels within
Drawings and Connections section.
In general, all signal cables must be routed as far away as possible from the high
voltage cables.
It is recommended to always use high quality shielded cables and care must be
taken to ensure shield is properly connected to eliminate interference and noise.
Grounding procedure must be handled with special care to prevent ground loops.
In general, it is recommended to connect shield to ground in only one side of the
senor/signal cable to avoid ground loops to occur.
IMx-T must be connected to protective earth since surge suppressors are
connected between network terminals and protective earth.
Make sure that protective earth is properly connected before connecting any of
the input or output terminals of the unit.
IMx-T unit must be situated in a cabinet with a metal bottom or plastic bottom
with flammability classification of at least V-1. The cabinet must fulfill at least IP
20.
All wires and cables connected to input and output terminals shall have a
flammability rating VW-1, FT-1 or fulfill the requirements according to IEC
60332-1-2 or IEC 60332-2-2.
Because of the redundant power supply, both supply circuits must be
disconnected before maintenance.

Introduction
Important Messages and Requirements
SKF Multilog On-line System IMx-T1-6
User Manual, Revision F
DIP switch settings must be handled with special care to prevent any damage to
IMx-T unit:
·Do NOT change DIP switch settings while the IMx-T unit is powered-up, as
this may cause damage and void warranty.
·Before powering up the IMx-T unit, make sure that DIP switch settings are
properly set to match the recommendations for the connected sensors.
Incorrect settings may cause permanent damage to the IMx-T unit.
IMx-T is a Class A equipment intended for use in an industrial environment.

SKF Multilog On-line System IMx-T 1-7
Introduction
System Overview
User Manual, Revision F
System Overview
IMx-T is a part of the SKF Multilog On-line System product range. IMx-T is the next
generation of powerful, cost-effective solutions for a variety of condition monitoring
applications.
In conjunction with SKF @ptitude Observer or Analyst software, Multilog IMx-T provides
a complete system for early fault detection and prevention, automatic advice for
correcting existing or impending conditions and advanced condition-based maintenance
to improve machine reliability, availability and performance.
Figure 1-1: System overview, IMx-T with @ptitude Observer/Analyst
The picture above illustrates how IMx-T units are linked together in a network that is
connected via a LAN (it can also be a modem or GPRS router) to a @ptitude Observer
Monitor or Analyst IMx Service. The @ptitude Observer Monitor or Analyst IMx Service
in turn can be connected to e.g. a LAN network making it possible for several of
@ptitude Observer or Analyst clients to link to this network.
@ptitude Observer or Analyst clients can also be installed on the same computer as
@ptitude Observer Monitor or Analyst IMx Service login software. Through a general
interface, also known as ODBC (open database connectivity), it is possible to link
@ptitude Observer Monitor or Analyst IMx Service login computer to an existing
database for an existing control or processing system, if desired. The @ptitude
Observer Monitor or Analyst IMx Service, @ptitude Observer or Analyst clients and the
database can be separated from each other as long as they are on the same network
where ODBC calls can travel freely.
It is also possible to connect different types of on-line units in the same network, for
example, IMx-T together with IMx-S and/or MasCon systems.

Introduction
IMx-T Unit
SKF Multilog On-line System IMx-T1-8
User Manual, Revision F
IMx-T Unit
Figure 1-2: SKF Multilog On-line System IMx-T
The above picture shows a SKF Multilog On-line System IMx-T with two redundant
power supplies and two CPU/IO pair cards mounted.
Designed to fit into a 19" rack enclosure, a Multilog IMx-T is equipped with the following
components:
Power supply units
·Two redundant power supply units
CPU/IO pairs
·Up to four pairs of CPU/IO cards
·Analogue channels
16 to 64 analogue signal inputs.
The dynamic signal inputs are configurable for a side variety of sensors.
Signals, such as acceleration, velocity and displacement or other
parameters are easily adopted. Each input can be configured for standard
accelerometers, 4–20 mA or ±25 V.
Several measurement points may be attached to one channel and both AC
and DC measurements can be measured on the same channel
·Digital channels
8 to 32 digital channels which may be used for measuring speed, trigger or
digital status e.g. indicating when a measurement can take place.
Storage Capacity
Each IMx-T unit has 8 MB flash memory used for the following:
·2 MB for firmware, configuration files, etc.
·2 MB for trend value buffer
üAbout 13 000 vibration trend values can be buffered
üSpeed and process data use half the space of vibration
·4 MB for spectra and time signal buffer
üAbout 250 spectra using 1 600 lines with phase and time signal can
be buffered

SKF Multilog On-line System IMx-T 1-9
Introduction
IMx-T Unit
User Manual, Revision F
üIf you use more lines, the number of spectrum is reduced.
üIf you use less lines, the number of spectrum is increased
·When the buffer gets full, the oldest data is thrown away.
IMx-T's Unique Features
·Individual conditions for alert and danger may be set for each
measurement point.
·Each channel has indicators for alert and danger. Alert and danger levels
may be controlled by machine speed or load. However, it is also possible to
manually bypass the alert and danger functionality.
·The unit's unique built-in hardware auto-diagnosis system continuously
checks all sensors, cabling and electronics for any faults, signal
interruption, short circuits or power failure.
Initiating IMx-T
Initiating an IMx-T is simple to carry out.
·This is done through an initiating program, @ptitude Observer or Analyst
software, and a (portable) computer using RS232 serial interface.
·All initial network configuration parameters, such as IP address, IMx
identification number, etc. are stored first in a separate configuration file,
then transferred to the IMx-T memory.
·The configuration is retained in the event of power losses, so that the
IMx-T can start automatically when power returns.

Introduction
LED Indicators
SKF Multilog On-line System IMx-T1-10
User Manual, Revision F
LED Indicators
Power Supply
Figure 1-3: Power supply LED indicators
Green LEDs V1, V2 and V3 of each slot indicate
the power presence.
LED
Indicator
Behaviour
Description
V1
On
+5 V power Ok
V2
On
+12 V power Ok
V3
On
-12 V power Ok
DV1
On
5 V adjustment
Table 1-1: Power supply LED indicators
Important - Because of the nature of the redundant power supply system, it is normal to
have only one side of power indicator (V1) on. However, if you have any concerns about
the power presence indicator, contact the SKF IMx-T team or personnel from SKF
Condition Monitoring Center Luleå.
CPU Card
Figure 1-4: CPU card LED
indicators
LED
Indicator
Behaviour
Description
SYSTEM
Red on
Internal system error
+5V
Green on
Power is Ok
LINK1,
LINK2
Green on
Ethernet link connected
ACT1,
ACT2
Yellow flash
Traffic on the network
Table 1-2: CPU card LED indicators

SKF Multilog On-line System IMx-T 2-11
Installation
User Manual, Revision F
Installation
2
Figure 2-5: Mx-T front view
The installation of an IMx-T must be carried out according to the instructions and advice
given in this manual. Any deviation from these directions can be made only after
consulting with the SKF Condition Monitoring Center Luleå. Installation errors can lead
to a situation where the system does not work as intended and machinery faults go
undetected. Therefore, contact the IMx-T application engineer at the slightest doubt
during the installation.
Important - Installation errors which require the involvement of SKF Condition Monitoring
Center Luleå personnel in order to rectify the start-up of the system, might be debited.
Important - In order to ensure a safe system, installation, configuration and
maintenance of the system must be done by trained personnel only.

Installation
Scenario
SKF Multilog On-line System IMx-T2-12
User Manual, Revision F
Scenario
It is important to assess and evaluate the current site where the system is to be
installed.
Before getting started, draw a plan on a piece of paper how you would like this
installation to look like after it is completed, then consider if it is possible to achieve.
The following diagrams are examples of general installation overview of scalable plant
wide solutions for machinery monitoring, one for non-hazardous area and the other for
hazardous area.
Scalable plant wide solution for machinery monitoring - An example of typical
non-hazardous area installation
Figure 2-6: Example of typical non-hazardous area installation

SKF Multilog On-line System IMx-T 2-13
Installation
Scenario
User Manual, Revision F
Scalable plant wide solution for machinery monitoring - An example of typical
hazardous area installation
Figure 2-7: Example of typical hazardous area installation
Among other things, consider lengths of cables, where electrical power to the IMx-T
units can be connected, where should @ptitude Observer Monitor or Analyst IMx Service
be installed and positioned and who should analyse the data measured. Good and
thorough planning is the basis for a successful solution and installation.
Make a detailed layout of the equipment, the network, and distances between
components. Include specifically the IMx-T units, the @ptitude Observer Monitor or
Analyst IMx Service computer, the database server computer and all hubs/routers in the
network. Specify network configuration of each components, such as IP addresses and
subnet masks. SKF application engineers and service engineers need these information
in order to assist.
Note that a CAT5/6 twisted pair (TP) Ethernet cable has maximum working distance of
100 m. If longer cable lengths are needed, fibre optic cables may be used along with
needed converters such as converters for fibre optic to CAT5/6 (TP) Ethernet and vice
versa.
When GPRS is used, the GPRS routers should be reconfigured as a part of the
application to run a lifeline connection with the @ptitude Observer Monitor or Analyst
IMx Service computer.
Warning - Failure of this communication path will force the GPRS router to reboot itself
constantly, and can hamper the success of the application. This is especially valuable to
consider when the GPRS forms a part of the customers internal IP network (VPN). In
such case, SKF must be informed of this before ordering the GPRS, so that SKF can
disable the lifeline functionality of the GPRS router.

Installation
Unit / Cabinet
SKF Multilog On-line System IMx-T2-14
User Manual, Revision F
Unit / Cabinet
IMx-T unit contains circuit boards that are static sensitive. Therefore, use
appropriate precautions to prevent ElectroStatic Discharge (ESD) when handling circuit
boards.
The following are some of the ways to prevent ESD:
·Use an ESD wrist strap when handling circuit boards
·Use a grounding mat when handling circuit boards
·Use correct packaging materials such as antistatic bags when transferring
circuit boards
The IMx-T unit should be mounted inside a cabinet at a location where it is not exposed
to unnecessary radiant heat or strong magnetic fields.
Mount the IMx-T unit and make sure that it is firmly attached.
The ambient temperature is found in Environmental within Technical Data.
Important - IMx-T unit contains circuit boards that are static sensitive. Therefore,
use appropriate precautions to prevent ESD when handling circuit boards.
Important - Different types of card must be positioned correctly in the rack. The
positions of the different types of cards are shown in Front Panel with Labels in Drawings
and Connections chapter.
Important - IMx-T unit must be situated in a cabinet with a metal bottom or
plastic bottom with flammability classification of at least V-1. The cabinet must fulfill at
least IP 20.

SKF Multilog On-line System IMx-T 2-15
Installation
Electrical Interface
User Manual, Revision F
Electrical Interface
Important - All wires and cables connected to input and output terminals shall
have a flammability rating VW-1, FT-1 or fulfill the requirements according to IEC
60332-1-2 or IEC 60332-2-2.
Sensor Cables
When routing a sensor cable, it is important that the cable is firmly fixed. The cable may
never be allowed to vibrate or oscillate, since this effects the capacitance of the cable,
and thereby the measurement result.
The sensor cable may not be routed or bundled together with supply cables since doing
so can generate strong magnetic fields.
To connect IMx-T to sensors, the following cable type is recommended:
·Shielded, twisted pair 2 ´2 ´0,5 mm2(FKAR-PG 2 ´2 ´0,50 mm2, DUE
4002 or corresponding)
·Cable type shall have a flammability rating VW-1, FT-1 or fulfill the
requirements according to IEC 60332-1-2 or IEC 60332-2-2.
Important - In general, all sensor cables must be routed as far away as possible
from the high voltage cables. If this cannot be done, care should be taken to use high
quality shielded cables.
Important - Grounding procedure must be handled with special care to prevent
ground loops. In general, it is recommended to connect shield to ground in only one side
of the senor/signal cable to avoid ground loops to occur.
Signal Isolation
Electrical isolated parts, differential inputs:
·Analogue inputs are differential inputs and support common mode up to ±25 V
relative to IGND.

Installation
Electrical Interface
SKF Multilog On-line System IMx-T2-16
User Manual, Revision F
Mains Power
Figure 2-8: Power connection inlets, one for each redundant power supply
An IMx-T unit has two power connectors available, one for each redundant power
supply unit. Each power supply unit is independently capable of supplying power for
entire monitor system including sensors.
The unit is grounded through the protective earth lead of the power cable. Therefore, it
is important to make sure that the earth terminal of the power cable is properly
connected to the protective earth lead before connecting any of the input or output
terminals of the unit.
Surge suppressors are connected between network terminals and protective earth.
Therefore, equipment must be connected to an earthed mains socket-outlet.
In order to attach power cable to the mains power grid, follow the direction below.
Figure 2-9: Power cable connection
1. First connect the (green-yellow) protective earth wire to the PE terminal.
2. Connect the (blue) neutral wire to the N terminal.
3. Connect the (brown or black) live wire to the L terminal.
Refer to Power Supply in Technical Data section for power requirements.
Important - In some countries, you have to be certified in order to connect IMx-T
to the power grid.
Important - IMx-T Mains Power Connectors must not be used as a mains power
disconnect device.
Important - Make sure that the power is turned off, before touching the power
cable. Touching the leads of a powered cable can cause serious injuries.

SKF Multilog On-line System IMx-T 2-17
Installation
Electrical Interface
User Manual, Revision F
Important - For permanently connected IMx-T an external all pole power switch
must be installed in order to be able to disconnect the IMx-T from the mains power grid.
The switch must be labeled "IMx-T” or similar. On/Off position must be clearly marked.
The switch must be located close to the IMx-T, within operator's easy reach. If two
switches are used, one for each power supply unit, they must be placed close to each
other.
Important - Since the unit is grounded through the protective earth lead of the
power cable, make sure that the earth terminal of the power cable is properly connected
to the protective earth lead before connecting any of the input or output terminals of the
unit.
Important - All wires and cables connected to input and output terminals shall
have a flammability rating VW-1, FT-1 or fulfill the requirements according to IEC
60332-1-2 or IEC 60332-2-2.
Important - Because of the redundant power supply, all supply circuits must be
disconnected before maintenance.
Power Fuses
The power fuse is slow blow 4.0 A (4.0 AT 250 V, 5 X 20 mm).
Supply Cable
To connect IMx-T to the main power grid (110 V AC or 220 V AC), use the following:
·FKLK 3 ´1,5 mm2 (16 AWG) or EKLK 3 ´1,5 mm2(16 AWG) or corresponding,
with minimum voltage requirement 300 V and minimum temperature -40 ºC.
·Cable type shall have a flammability rating VW-1, FT-1 or fulfill the
requirements according to IEC 60332-1-2 or IEC 60332-2-2.
It is required that the IMx-T must be connected to protective ground/earth (PE). Refer
to Mains Power for attaching power cable to the mains power/power grid.
Important - The cross section area of the PE wire must be equal or greater than
the cross section area of the power wires. The PE wire should be color labeled
green/yellow. However, in some countries, other cable requirements may apply.
Sensor Power Output
Each channel, both analog and digital, has built-in individual 24 V (22-26 V) sensor
power supply.
The maximum current output is 30 mA per channel.

Installation
Electrical Interface
SKF Multilog On-line System IMx-T2-18
User Manual, Revision F
Communication Cable
For lengths up to 15 metres, it is recommended to use pre-fabricated Ethernet twisted
pair cable FTP type, CAT5/6.
For longer cable lengths, it is recommended to use S-FTP (screened shielded twisted
pair) Ethernet cable CAT5/6.
Note that a CAT5/6 twisted pair (TP) Ethernet cable has maximum working distance of
100 m. If longer cable lengths are needed, fibre optic cables may be used along with
needed converters such as converters for fibre optic to CAT5 Ethernet and vice versa.
Data Communication
IMx-T unit communications are compliant with the Ethernet standard 10/100 Mbit
(half- and full-duplex).
IMx-T has two Ethernet ports which work like an internal network switch.
Ethernet Cable
The Ethernet TP cable on the IMx-T is connected at one of the standard Ethernet RJ45
connectors, labeled J1 and J2.
Both Ethernet ports have auto detection of crossover or straight through Ethernet cable
connection. Basically, IMx-T has a built-in Ethernet switch.
It is possible to connect IMx-T in a daisy chain up to 8 units in a single cable layout.
Figure 2-10: IMx-T Ethernet ports
J1
RJ45 Ethernet 1
J2
RJ45 Ethernet 2
Table 2-3: IMx-T Ethernet connectors
There are two LEDs on a RJ45 connector.
·Yellow LED is the Ethernet traffic indicator which flickers whenever there is
traffic on the network.
·Green LED is the Ethernet link indicator which lights up when the system is
correctly connected to another network device.

SKF Multilog On-line System IMx-T 3-19
Unit Configuration
User Manual, Revision F
Unit Configuration
3
Mount the IMx-T unit and make sure that it is firmly attached. The IMx-T unit should be
mounted inside a cabinet at a location where it is not exposed to unnecessary radiant
heat or strong magnetic fields.
The ambient temperature is found in Environmental under Technical Data.
In general, when referring to DIP switch settings 0 means Off and 1 means On.
DIP Switch Setting
Definition
0
OFF
1
ON
Table 3-4: DIP switch setting definition

Unit Configuration
Analogue Inputs
SKF Multilog On-line System IMx-T3-20
User Manual, Revision F
Analogue Inputs
There are three positions (P, A, B) available for each analogue sensor (Ch1 to Ch16) for
connecting sensor cables to the IMx-T. However, depending on the sensor type, two or
three positions are used. The terminal list is found in Terminal List under Summary
chapter.
Important - Do NOT change DIP switch settings while the IMx-T unit is
powered-up, as this may cause damage and void warranty.
Important - Before powering up the IMx-T unit, make sure that DIP switch
settings are properly set to match the recommendations for the connected sensors.
Incorrect settings may cause permanent damage to the IMx-T unit.
The DIP switch settings for analogue sensors must be applied according to the table
below. The DIP switches are labeled as ANA1 to ANA16 on the IMx-T I/O board.
Signal
Terminal
DIP switch settings for
analogue sensor 1 to 16
(ANA1 to ANA16)
Position:
123456
Standard accelerometer
(ICP)
N.C.
+ Signal/Pwr
Com.
P
A
B
100110
Voltage source
N.C.
+ Signal
Com.
P
A
B
000000
4–20 mA source
N.C.
+ Signal
– Signal
P
A
B
000001
B-Sensor
(4–20 mA output)
+24 V
Signal
Com.
P
A
B
100101
Eddy probe
(–24 V)
–24 V
Signal
Com.
P
A
B
011000
Voltage powered sensor
+24 V
Signal
Com.
P
A
B
100100
4–20 mA (IMx powered)
+ Signal
– Signal
N.C.
P
A
B
100101
Table 3-5: Analogue sensor terminal positions and DIP switch settings
N.C. = Not Connected
