Solo 425-101 Installation and operation manual

WARRANTY:
US9425739 (08-17)
Operator’s Manual & Parts List
425, 425-101, 425-Prof, 475-B, 475-101, 475-Prof, 435, 485, 473-P, 473-D,
473-ECS
If you are missing parts, instructions or have questions, DO NOT return this unit
back to the store. Call 1-800-SOLO-INC (1-800-765-6462). Solo will send the missing
parts/information to youpromptly.
Solo backpack sprayers are covered by Solo’s 1-YEAR LIMITED WARRANTY. Solo manufactured parts which fail due to defective
material or workmanship will be repaired or replaced without charge. See page 5 for full details and complete warranty information.
MAINTENANCE TIP: The cap gasket (#4061345 or #4061346) is pre-
lubricated for improved sealing. Occasional lubrication with Solo Superior Grease
(#9850-P) or petroleum jelly isrecommended.
SAFETY PRECAUTIONS:
1. Beforeusingsprayerwithchemicals,fillsprayerwithfreshwatertoassure
that you have it properly assembled; pressurize and practice spraying.
Also, check for any leaks at this time. When thoroughly familiar with the
sprayer operation, follow normal operatingprocedures.
2. Ensure all pressure in the sprayer is relieved by locking the shut-off
valve in the open position.
3. Avoid contact with chemicals.
4. Always wear rubber gloves, safety goggles and appropriate
protective clothing.
5. Work in a well ventilated area.
6. Individuals should be trained in the proper use of this sprayer, chemical handling procedures, and first aid/emergency
care. Where training is not available, individuals should study and follow the procedures detailed in this manual.
WARNING:
Chemicals can be harmful to individuals and the environment if improperly used. In addition, some chemicals are caustic, corrosive or
poisonous and should be avoided. Read warnings and chemical manufacturers’ instructions. Solo high density polyethylene sprayers are
fittedwith chemicalresistantseals whicharecompatible toawidevarietyofagricultural andhousehold chemicals;however,care shouldbe
exercised to ensure that sprayer components are clean, functioning properly, and in a good state of repair before and during use.
If in doubt about a particular chemical, check the manufacturer’s instructions or call the manufacturer. If you suspect or observe
indications that the material may be unsafe in a Solo sprayer...STOP. DO NOT USE OR APPLY CHEMICAL. ALWAYS WEAR
RUBBER GLOVES, GOGGLES, AND APPROPRIATE PROTECTIVECLOTHING!
•Read and follow operatinginstructions.
•Do not fill with, use, or spray flammable materials, including Diesel Fuel.
•Do not modifysprayer.
•Never spray in the direction of humans, animals or property which might be injured or damaged by spray formula.
•Do not use disinfectants, solvents or impregnating agents unless first tested to ensure they are not harmful to the
environment orsprayer.
•Do not use liquids with a temperature above 110°F(43°C).
•Wear appropriate protective clothing to prevent contact with chemical agents.
•Rinseandcleansprayerthoroughlyafterusing.Disposalofcontaminatedrinseshouldbeinaccordancewithapplicable
ordinances. Observe the precautionary instructions of the chemical manufacturer.
•Do not use any acid (including citrus) or caustic chemicals. For bleach solutions, try our Solo 475-B or 475-
B Deluxe sprayers.
•Remember that a sprayer with liquid is a significant amount of weight (8 lbs. per gallon). Do not climb when wearing
the sprayer. Use caution when bending, leaning or walking. Bend at the knees rather than the waist.
•During sprayer operation, the pressure cylinder (#4400240) contains compressed air and liquid. Compressed air
and liquid under pressure are inherently dangerous. Before making adjustments on sprayers fitted with a pressure
regulating valve assembly (#4800182) located on the pressure cylinder or any other repair or inspection of any
sprayer, be sure to relieve pressure through the shut-off valve and wand.
Visit us on the web at us.solo.global
Troubleshooting and parts ordering available on-line.
CUSTOMER SERVICE COMMITMENT FROM SOLO’S SERVICE DEPARTMENT
In the event the sprayer you have purchased has missing or damaged parts, please call 1-800-765-6462, 9:00 AM - 5:00 PM EST.
In order to assist your service representative, please have the following information available: sprayer model number,
part description and part number.A parts list is included in your operator’s manual.
Solo is committed to your satisfaction and is continuing its efforts to earn your futurebusiness.
Piston
Diaphragm
STOP!

2
Setting #1 15 psi
#2 30 psi
#3 45 psi
#4 60 psi
REMOVING PLASTIC ADJUSTABLE NOZZLE
Unscrew the nozzle cap (1) from the nozzle body (3). This is best
accomplished while the retaining nut (2) is fastened tightly to the
elbow (5). Next, unscrew the retaining nut (2). Push the nozzle
body (3) out of the retaining nut (2). The filter with gasket (4) will
come out with the body. Toreinstall the nozzle, reverse theabove
1. Nozzle
2. RetainingNut
3. Nozzle Body
4. Filter with Gasket
➔
Screw Cap
Wand
instructions. 5. Elbow O-Ring Install Wand
ASSEMBLY INSTRUCTIONS FOR WAND
1. Insert wand into shut-off valve asshown.
2. Tighten the screw cap clockwise onto the shut-offvalve.
Gauge Mount➔
Shut-Off ➔
PUMP LEVER INSTALLATION: All hardware necessary for pump lever installation is included
with the sprayer. The pump lever (C) should be installed as follows: place lever handle (C) onto
theshaft(A).Alignboltholesandinstallthetwobolts(E)andwashers(F);thentighten. Toinstall pump
lever on the opposite side on a Diaphragm Pump sprayer, remove the stop plate (D) and washer,
install the pump lever as above. The stop plate (D) should be mounted on the inner bolt hole with
the closed end of the stop plate pointing downward on the opposite side of the pump shaft.
FOLD-AWAY PUMP HANDLE INSTALLATION (FOR SELECT MODELS ONLY):
1. Remove bolt and nut from pumphandle.
2. Slide handle assembly over the pump rod and align the holes so that the rear (elbow) portion
of the handle points up and slightly forward (approximately 45 degrees) and away from the
Solo logo. Reinstall bolt and locknut. Pump handle can be installed on the opposite side of
the sprayer for right hand pumping. (For Diaphragm Pump Sprayer, stop plate will need to be
relocated to the left side.)
3. The handle can be rotated to either down (pumping) or up (storage) positions. Note: The handle
swings away from the sprayer, then up or down as desired. The spray wand attaches to the
clamps on the handle assembly for storage (does not apply to the brass or stainless steel
wands).
SHOULDER STRAP INSTALLATION:
The top of the shoulder straps are pre-attached to the sprayer by means of a buckle or pin. The
lower end of the straps are attached byfastening the strap hooks to the metal frame between where
frame exits the plastic tank and where the frame makes abend.
REGULATING THE PRESSURE: (FOR DELUXE MODELS ONLY)
The Solo backpack sprayer is equipped with a built-in regulator to control output pressure. This
regulator is operator adjustable. Make adjustments prior to filling tank. To adjust the regulator,
remove the tank cap and the filter basket. Look inside the
spray tank; you will see the top of the regulator. There are 4 fingers on the regulator
knob. The finger farthest to the left is #1; to the right is #4. They are numbered 1, 2,
3, 4. 1 = 15 psi, 2 = 30 psi, 3 = 45 psi, 4 = 60 psi. The higher the pressure, the more
chemical applied from the sprayer in a given amount of time, but the droplets will be
smaller with more drift. If the spray pressure must be changed, excess pressure in
the pressure cylinder must be released back into the tank through the spray tube.
To adjust, push down on the knob and rotate to align the desired number with the
alignment pin. To operate the 425-Prof and 435 at higher than 60 psi, first release the
excess pressure and then replace the pressure control valve with the optional plug
(#4200215).
FILLING:
Mix the spray formula and the proper volume of water in a separate container. Pour
the mix through the filter basket in the tank opening. This keeps debris from entering
the sprayer. Pump the sprayer handle to prime the pump and pressurize the pressure cylinder. The volume of liquid in the
sprayer tank will appear to decrease as the pressure cylinder is pressurized. Remember that it’s not necessary to completely
fill the sprayer tank each time. Mix only the amount needed to get the job done. Chemicals should not be stored in the
sprayer.
Always read and carefully follow the manufacturer’s instructions printed on the product label. This can save money and help
prevent injury and crop and environmentaldamage.
B
A
D
C
F
FE
E
B
A

3
OPERATING FEATURES:
Nozzles - Your Solo sprayer can provide a variety of spray patterns with the standard and optional nozzle arrangements.
Item Application Part #
Flat spray nozzle Row treatment 4074263
Jet stream nozzle Spot & longer range 4074755
Jet stream nozzle and Shrubs and bushes 4074755
Swirl plate = hollow cone 4074756
Plastic adjustable Spot, shrubs & bushes 4900527
nozzle
Speed Tip Nozzle Row, spot, shrubs & bushes 4074666
*Brass adjustable nozzle and Speed Tip nozzle are not standard items on all Solo sprayers but each may be
purchased as an accessory. Spray tips should be assembled as above for desired spraypattern.
WARNING: Handling the brass parts of this product will expose you to lead, a chemical known by the State of
California to cause cancer and birth defects or other reproductive harm. Wash hands after handling. For more
information, go to www.P65Warnings.ca.gov.
SPRAYING:
Prime the pump with rapid pump strokes. When you feel very firm resistance, the pressure chamber is filling with
liquid. With repeated piston strokes, the air in the pressure chamber is slowly compressed. In a safe area, point
the wand upward and press the shut-off valve lever spraying for 10 seconds or until no air and only liquid is com-
ing out. This will bleed all of the air out of the hose and wand. By pressing the hand lever, the valve opens, and liquid is
forced through the nozzle. The shut-off valve has a retaining clip which keeps the valve in the “OPEN” position for
continuous operation. Pump using the end of the pump handle, as it is less fatiguing. The volume of liquid delivered varies
with the working pressure which should be as high as needed to ensure an adequate spray pattern for each individual
application.
NOTE: Should the pressure drop very quickly, drain the tank completely and pump without liquid. By this procedure, the air
chamber is refilled with the required volume of air. It is advisable to pump the tank completely empty from time to time.
WETTABLE POWDERS:
Avoid use in piston pump sprayers models 425, 425-Prof, 425-HD, 315-A, 435, 473-P! The Solo models 475-B, 475-Prof,
473-D, 473-ECS and 485 sprayers with a diaphragm pump are generally resistant to abrasive materials and are recommended
for this purpose. Note: If you use a wettable powder in your 425, 425-Prof, 425-HD, 315-A, 435 or 473-P sprayer, be sure that
it is thoroughly mixed in the formula solution. Immediately after use, be sure to remove the piston and clean and lubricate
the Viton® collar with Solo Superior Grease* or petroleum jelly. Thorough flushing of the sprayer will extend the life of its
working parts. If you use wettable powders in the piston pump sprayer, be sure to inspect regularly for seepage around the
piston, lubricate and/or repair accordingly.
CLEANING:
•After spraying, clean the tank thoroughly. If some spray liquid is left inside, drain tank completely.
•Pumping causes air to be taken in and the remaining liquid to be discharged. Pump until liquid and air are coming out
through the nozzle.
•Refill tank with a few quarts of clean, soapy water and pump the water out as explained above (if necessary, repeat this
procedure several times).
•If the shut-off valve is removed, the pump can be flushed quickly. Improper spray distribution is the result of a clogged
nozzle, which is easily removed and cleaned.
•Soap and water may also be used to clean tank.
•Do not use aggressive cleaning agents or abrasives.
•Follow the recommendations of the chemical manufacturer for disposal of waste water and chemicals.
•Activated charcoal in liquid or other form may be usedto absorb chemicals in tanks or spills.
NOTE: When cleaning the sprayer after working with hormone weed killers, follow the instructions of the herbicide
producers. Neutralize with activated charcoal. (Example: add 0.35 oz. /1 g. of activated charcoal to 1.7 pint/1 liter of water
and leave this detergent in the tank and the lines approximately for 24 hours.) This is very important if other chemicals will be
sprayed as the residues of the herbicide may damage susceptible plants. Cleaning after application of products containing
carbolineum, a coal tar wood preservative, is imperative. If the chemicals are not water soluble, cleaning should be done
with a 5% soda lye having a temperature of 104°F (40°C). Rinse with plenty of clean water.

4
MAINTENANCE AND STORAGE TIPS:
•After operation, the sprayer should be stored away from direct sunlight to prevent UV damage.
•After removing the pump or when mounting a new Viton® collar, treat both the collar and the piston with water- resistant
grease.*
•Before winter, drain all liquid in tank, lines and air chamber. (See “Cleaning.”) Leave shut-off valve locked in the
“open” position to prevent freezing.
•For service, visit our website to locate your nearest Solo dealer. Always insist on original Solo spare parts.
•Regularly inspect hose, wand, pump, tank and shut-off valve for wear, damage or leaks. Repair promptly.
•Occasionally lubricate cap gasket.*
Avoid excessive wear and prolong sprayer life by:
1) Regular lubrication of Viton® collar, cylinder and piston with water-resistant grease.*
2) Prompt and thorough cleaning and flushing of sprayer. Soap and water work well.
*Use Solo Superior Grease (#9850-P). Petroleum jelly may also be used
SOLO LIMITED WARRANTY
Solo Incorporated guarantees the original purchaser of Solo equipment that any failure of Solo manufactured parts due
to defects in material and workmanship, which occurs during the applicable warranty period, will be repaired or replaced
without charge for parts or labor, except for those items not covered by warranty.
CONSUMER LIMITED WARRANTY: Solo equipment purchased for consumer use is covered by this Limited Warranty
for a period of ONE (1) YEAR. Solo’s polyethylene tank is covered by this limited warranty for the life of the unit.
COMMERCIAL LIMITED WARRANTY: Solo equipment purchased for commercial use is covered by this Limited
Warranty for a period of ONE (1) YEAR.
OWNER’S OBLIGATION AND RESPONSIBILITY: Proof of purchase must be provided by the owner in order to obtain
warranty service. Should any failure covered by this Limited Warranty occur, deliver or ship the Solo products or parts to
an authorized Solo service center. Freight, packing and insurance costs, if any, will be borne by the owner. Follow normal
maintenance service to include applicable lubrication, operation and storage of the product as explained in the operator’s
manual.
ITEMS NOT COVERED BY WARRANTY: Provisions of the Limited Warranty will not apply to the following:
Any indirect or consequential damages that may result from the failure or malfunction of the Solo product.
Normal service requirements arising during the warranty period, such as cleaning, normal wear, lubrication, filter,
spray tips, etc.
Normal service work over and above the repair or replacement of defective parts. Any failure that results from an
accident, customer abuse, normal wear, neglect or failure to operate the product in accordance with the
instructions provided in the operator’s manual or provided with the product.
When an alteration or modification has been performed on a Solo product, Solo is responsible only for products as
originally furnished by Solo, provided the alterations or modifications do not adversely affect the product’s
operation, performance or durability. Parts or accessories that are incompatible with the product are not approved
by Solo.
Full disclosure of Solo’s Limited Warranty is available from your local Solo dealer or SOLO INCORPORATED, 5100
Chestnut Avenue, Newport News, Virginia 23605 (800-765-6462).
This Limited Warranty gives you specific legal rights and you may also have other rights, which vary from state to state.
Solo’s new Professional sprayers, Models 425-Prof and 475-Prof, are equipped with Solo’s Deluxe Shoulder Saver Harness
(part# 4300343C) (see below). With its wide, padded straps, chest belt, padded waist belt and lumbar support, this sprayer
will remain comfortable to wear even after hours of spraying.

5
SPARE PARTS LIST
Liste de pièces de rechange
Lista de piezas de recambio 96
55A
19 Deluxe Models Only
55A 107
26
38
Deluxe
and
Profess
ional
Models
Only
*Not standard on all models.
SPECIAL PARTS AND ACCESSORIES (Not shown in parts list)
Order No. Description
4900310N Conversion kit (from piston to diaphragm pump)
0610406-K Diaphragm pump repair kit includes 8, 11, 12, 20 (2 ea.), 24, 25, 66, 106
0610407-K Piston pump repair kit includes 8, 11-13, 20 (2 ea.), 24, 25, 44
4900200-V Piston pump repair kit (Viton®/FKM) includes 8, 11-13, 20 (2 ea.), 24, 25, 44
0610411-K Wand/Shut-Off Valve repair kit includes 7, 8, 10, 22, 26, 34, and 49,101,103
0610409-K Piston, rod & collar kit includes 41-44, 54
4400203 Pump assembly (Piston) includes 8, 11, 12, 13, 20 (2 ea.), 39, 40, 41, 42, 43, 44, 54, 107
4400221 Pump assembly (Diaphragm) includes 8, 11, 12, 20 (2 ea.), 39, 61, 63, 64 (12 ea.), 64A, 65, 66,
67, 106, 107

6
POS. # ORDER # FOR MODEL. DESCRIPTION FRANCAIS ESPAÑOL
2 00 10 165 Bolt Vis T.C. Tornillo cil.
3 00 12 185 Bolt ** Vis T.C. Tornillo cil.
4 00 30 131 Washer ** Rondelle Arandela
6 00 12 185 Bolt Vis T.C. Tornillo cil.
8 00 62 258 Gasket Joint de connection Junta de conexion
10 00 62 115 O-ring Joint bague Anillo O
11 00 62 291 O-ring Joint bague Anillo R
12 00 62 139 O-ring Joint bague Anillo R
13 00 62 140 O-ring Joint bague Anillo R
14 00 64 234 Hose 48” (item 26, 34, 49, 103 incl.) Tuyau (Pos. 26, 34, 49,103 incl.) Manguera (articulo 26, 34, 49, 103 incl.)
15 00 66 388 Hose clamp Collier cpl. Abrazadera
16 00 66 394 Clamp Collier cpl. Abrazadera
17 40 43 123 Stop plate ** Butêe Pieza de apoyo
18 40 35 111 Pump shaft Tuyau Tubo
20 40 61 257 Valve plate Joint de soupape Place de valvula
21 42 00 242 Red tank cap (item 48, 98 & 99 incl.) Couvercle Tapa del depôsito (roja)
—42 00 305 Heavy Duty Black tank cap (item 48, 98 & 99 incl.) Couvercle Tapa del depôsito (negra)
22 40 74 148 Retaining nut Ecrou de raccord Tuerca de manguito
23 40 74 323 Valve body Pièce de règlage Pieze de ajuste
24 40 74 350 Sealing plug Joint Junta
25 00 70 260 Compression spring Ressort de compréssion Resorte de presion
26 40 74 337 Retaining nut Ecrou de raccord Tuerca de manguito
27 40 74 344 Control knob Pièce de règlage Tapa de ajuste
28 40 74 410 Bushing Coussinet Cohinete
29 40 74 263 Flat spray jet Buse à diffusion large Tobera de chorroancho
30 40 74 756 Swirl plate Pièce girafoire Pieze de rayado
31 40 74 283 Jet filter tamis de gicleur Piltro de tobera
32 40 74 755 Jet cap Capuchon de gicleur Tapa de tobera
33 49 00 527 Plastic adjustable nozzle (Inc. a& b) Buse réglable en plastique Boquilla ajustable
33 4900207 425/475-101,DLX, Prof BrassAdj.spraynozzle Bouchier Boquilla ajustable
34 40 74 500 Clamp Pièce de serrage Pieze de retencion
35 40 74 527 Elbow Coude Code
36 42 00 162 425/475-All models Tank and frame assy., 4 gal. Support de rèservoir, 151 Soporte de depôsito, 151
42 00 293 435,485 Tank and frame assy., 5 gal. Support de rèservoir, 201 Soporte de depôsito, 201
40 71 305 473P, 473D Tank and frame assy., 3 gal. Entonnoir Embudo Filtro
37 42 00 106 Filter basket Le panier-filtre Filtro de canasta
38 43 00 315 Shoulder strap (item 73 incl.) Bretelle (Pos. 73 incl.) Correaje (articulo 73 incl.)
38 43 00 340 Deluxe Models Deluxe Shoulder Strap (Item 73 incl.) Bretelle deluxe (Pos. 73 incl.) Correaje de lujo (articulo 73 incl.)
39 44 00 240 Pressure cylinder (Deluxe Models) Cylindre cpl. Cilindro mont
44 00 240N Pressure cylinder
40 40 73 190 Cylinder, assy. (item 12, 13,20 incl.) Bielle sand tèton Biela
41 40 74 409 Connecting rod without stud Levier Palanca
42 40 74 262 Lever Piston Piston
43 40 73 558 Piston Manchette Viton Manguito Viton
44 44 00 189 Viton® collar Robinet d’arrêt Grifo de cierre, mont.
45 48 00 170 Shut-off valve, assy. Levier de pompe (pos. 75 incl.) Palanca de bomba (articulo 75 incl.)
45 48 00 249 475-B, 475-B Deluxe Shut-off valve,assy.(BleachResistant) Levier de pompe (pos. 75 incl.) Palanca de bomba (articulo 75 incl.)
45 38 00 502 315-A,475-Prof Shut-off valve,assy.(Viton/FKM) Levier de pompe (pos. 75 incl.) Palanca de bomba (articulo 75 incl.)
46 48 00 17325 Pump lever (item 75 incl.) Tuyau pulvèrisateur (500 mm) Tubo atomizador (500 mm)
47 49 00 230 Spray tube 20” (item 8, 26 incl.) Joint bague (pos. 8, 26 incl.) Anilio de junta (articulo 8, 26 included)
49 00 645 425-Prof,475-Prof Stainless Steel Wand (item 8, 26 incl.)
49 00 421 Brass Wand (item 8, 26 incl.)
48 40 61 345 Gasket Rondelle Arandela
49 00 31 356 Washer Coiffe protectrice Tapa protectora
51 40 74 680 Protective cover vis T.C. Tronillocil.
52 00 10 110 Bolt Ecrou. hex. Tuerca hex.
53 00 20 101 Hex. nut Bielle avec teton Biela
54 40 74 408 Connecting rod with stud Porte-bretelle Hebilla para correa
55 40 74 412 Strap Buckle (Pre 2013 Models) Carter de membrame Carter membrana
55A 40 74 425 Strap Pin (2013 and later Models) Chaveta Goujon
58 40 74 996 Wand retainer clip Retenue de la lance
60 40 73 411 Housing (diaphragm) Joint bague Anillo O
61 40 73 410 Flange Siège soupape (pos. 12, 20 incl.) Pieza rosada (articulo 12, 20 incl.)
63 44 00 222 Valve, assy. (item 12,20 incl.) Vis T.C. Tornillo cil.
64 00 18 275 Screw Plaque à membrane Chapa de membrana
64A 00 18 275 Diaphragmscrew Vis de diaphragme Tornillo de la diafragma
65 40 74 256 Plunger Membrane Membrana
66 40 74 246 475-All Models Diaphragm (Bleach Resistant) Bielle (Cloro resistente) Biela (Resistente au chlore)
67 40 74 255 Lever Goujon Perno
68 40 31 130 Wrist pin Levier 1 Palanca 1
69 40 74 243 “L” connecting bracket Levier 2 Palanca 2
70 40 74 234 “R” connecting bracket Vis T.C. Tornillo cil.
72 00 10 141 Bolt Accroche Gancho
73 40 74 837 Hook Crochet Gancho
75 40 74 392 Grip Poignée Apretón
97 40 74 295 Pin Goupille Perno
98 40 61 464 Vent plate Plaque de décompression Placa de la respiradora
99 40 74 123 Vent cap Capuchon de décompression Tapa de la respiradora
100 40 74 329 Lock clip Pince de verrouillage Sujetador de cerradura
101 40 74 336 Retaining nut Écrou de serrage Tuerca de retención
102 40 74 335 Lever Levier Palanca
103 00 62 271 O-ring Joint torique Anillo-O
106 00 62 324 O-ring Joint torique Anillo-O
107 48 00 182 Pressure Control Valve(item 8,23,24,25,27) Régulateur de Pression Valvula deControl
** ** Diaphragm Pump Sprayer Only
49 00 200-V 315-A,425-Prof Piston Pump Repair Kit (Viton/FKM)
49 00 201-V 475-Prof Diaphragm Pump Repair Kit (Viton/FKM)
ACCESSORIES
1 4200215 Plug(item8incl.) Bouchon (pos. 8 incl.) Tapón(articulo8incl.)
7 06 10 402-K Shut-off valve repair kit Pochette robinet d’arrét Juego rep. grifo de cierre
706 10 413-K 315-A, 475-B & Deluxe Shut-off valve repair kit (Viton) Pochette robinet d’arrét Juego rep. grifo de cierre
19 4073 725 Carrying Handle (Requires 2 x 4074425) Asa de transporte Poignee de transport
50 4900454 Fold-awayhandle(item4,56,57,58incl.) Poignéerabattable (réf.4,56,57,58compr.) Manillapliegue(articulo4,56,57,58incl.)
56 0020119 Nut Écrou Tuerca
57 0012192 Bolt Boulon Cerrojo
58 4074996 Clip Pince Sujetador
59 0065210 Heavy Duty Brass flat spray nozzle Buseàjetplatenlaiton Boquilla de pulverizador de latón plano
76 4900430 Drift guard Anti-dèrive Protectordeladeriva
80 4900477 Double spray nozzle Buseàdoublejet Boquilla doble de pulverizador
—4900528 Extension wand 60” (1250 mm) Rallongedelancede1,25m(60po) Varadeextensión(1250mm)
90 4900622 Pressure gauge w/connection parts Mandometro
—4900513 Extensiontube20” (500mm) Clapet anti-retour Tuba alargador (500 mm)
93 2700316 Heavy Duty Nodripcheckvalve Valvula de retencion
94 4074338 Retaining nut Tuerca de manguito
95 0062249 O-ring Joint torique Anillo O
96 4074666 Speed Tip Nozzle
—0610410-P Brass Adj. spray nozzle assy. Joit bague Tobera de allura,mont.
—4300343 425-Prof, 475-Prof Deluxe Shoulder Saver harness Buse longue protee, cpl.
—4200205 Reduction insert, gaskets incl. Reduceur avec jints Empaquetaduras
4900258N Elbownozzleassy.(item10,22,31,33,35incl.)Pochettejoints(10,22,31,33,35incl.) Juego paquetaduras(10,22,31,33,35)

7
8
ORDER FORM
You may order parts and accessories online at us.solo.global or from your local Solo dealer. If there is no local Solo dealer, use this form
to order or call us at 1-800-765-6462.
Item Names/Description
Part No.
Retail Price
Qty.
Total
Nozzles Flat spray nozzle - surface area & rowtreatment
Jet cap
Swirl plate
Filter - standard
Sprayer elbow and nozzle assortment
No-drift wide angle flat nozzles - .60 GPM
mainly for spraying herbicides at low pressure. .30 GPM
At 15 psi they deliver: .24 GPM
.12 GPM
Elbow nozzle assembly
Double spray nozzle - for double row application
spraying in two directionssimultaneously.
Brass adjustable spray nozzle kit - with jet filter and screw
cap for tree spraying (from fine misting to a jet stream).
Brass adjustable spray nozzle (same nozzle as kit above)
Plastic adjustable nozzle
Hollow cone nozzles - for shrubs & bushes: 1.4 mm
1.8 mm
Foam spray nozzle - for low drift & water saving
application of herbicides which tend tofoam.
No drip check valve - prevents spray tip from leaking
when not in use.
Speed Tip Nozzle - Change from a fine mist, or a jet stream or a
flat spray pattern with the twist of adial.
Nozzle assortment - includes flat, hollow cone, no drift,
and plastic adjustablenozzles.
Extension tubes and spraywands
20” spray wand
20” extension tube
21” stainless steel wand
20” brass spray wand
40” brass telescoping wand
48” carbon fiber wand
60” brass spray wand
4’ to 8’ Carbon Fiber Wand
Note: extension tubes attach to wands to extend length.
Spray wands attach to shut-off valveonly.
Spray booms
Spray booms - spray 2 or 4 rows at oncewith:
2-nozzle spray boom - handheld (total width33”)
distance between nozzles 24”. Includes 2 flat spray nozzles.
4-nozzle spray boom - mounts on rear of sprayer
(total width 49 3/4”; distance between nozzles 16”).
Includes 4 hollow conenozzles.
Specialty items
Shoulder Saver Harness - padded shoulder straps and
padded lumbar support reduces lower back fatigue.
Fits all models.
Pressure gauge kits - indicates spray pressure.
Use with shut-off valve 4800170. Fits allmodels.
Drift guard - complete control for herbicide applications in
berry, flower, vegetable, cotton & otherapplications.
40 74 263
40 74 755
40 74 756
40 74 283
06 10 408-P
40 74 513
40 74 514
40 74 386
40 74 385
49 00 258N
49 00 477
06 10 410-P
49 00 207
49 00 527
49 00 252
49 00 322
49 00 397
27 00 316
4074666
06 10 456-P
49 00 230
49 00 513
49 00 645-P
49 00 421
49 00 478
49 00 449
49 00 528
49 00 445
49 00 514
49 00 298
43 00 343
49 00 622
49 00 430
2.00
2.50
1.50
2.55
14.95
2.50
2.50
2.50
2.50
6.35
29.95
8.75
6.25
4.25
2.85
2.85
14.95
4.95
8.95
12.95
9.95
16.95
11.95
12.95
45.95
39.95
34.95
79.95
34.95
149.95
29.95
29.95
16.95
Prices and technical specifications are subject to change without notice.

7
8
Most Popular ItemNames/Description
Part No.
Retail Price
Qty.
Total
Pro spot drift guard. Controls spray to a 3” spot
49 00 626
5.95
Tank cap w/valve assembly
42 00 242
4.95
Filter basket
42 00 106
5.95
Hose - 48” long (120 psi)
00 64 234
5.95
Shut-off valve
48 00 170
15.95
Shut-off valve, spray wand & nozzle elbowassy.
49 00 170N
19.95
Pressure cylinder
44 00 240
19.95
Fold away pump handle
49 00 454
12.50
Complete piston pump assy w/pressure controlvalve
44 00 203-P
29.95
Complete diaphragm pump assy w/pressure controlvalve
44 00 221-P
29.95
Repair kits
Shut-off valve repair kit
Diaphragm pump repair kit
Piston pump repair kit
Piston Pump Repair Kit-Viton®/FKM (315-A, 425-Prof,425-HD)
Shut-off valve and wand repairkit
Piston, rod and collar kit
Conversion kit (from piston pump to diaphragmpump)
Plug - to operate at higher than 60 psi (PROF MODELS SEE PAGE 2)
Solo Superior Grease - (4oz.) used in the manufacture of all SoloParts
Sprayer service DVD - explains howtorepairthebackpack andhandheld
sprayers in non-technicallanguage.
06 10 402-K
6.50
06 10 406-K
19.95
06 10 407-K
19.95
4900200-V
22.95
06 10 411-K
9.95
06 10 409-K
19.95
49 00 310N
26.50
42 00 215
5.95
9850-P
5.95
998SPDVD
9.95
Mail or Fax to: Solo • 5100 Chestnut Avenue
Newport News, VA23605 • Phone: [phone] • Fax: [phone]
Order Online: us.solo.global E-mail: [e-mail]
Total from page 7
$
Total from page 8
$
Please do not send cash with this order. Make check or money order payable to Solo In-
Total
$
corporated. Youmay request C.O.D. shipment. Please call for current C.O.D. charges.
Form of Payment:
VAand WAresidents add applicable sales tax $
Credit Card
Check or Money Order
SHIPPING CHARGE
$ 10.95
C.O.D.
/ / / / / / / / / / / / / / / /
Grand Total
$
Credit CardNumber
Please allow 1-2 weeks fordelivery
/ / / /
Expiration Date Signature
Wecannot process your credit card purchase without a signature and expiration date.
Name:
Address:
City: State Zip Code
Phone #:
Email Address:
8
