SOMFY RS485 Setting Tool User manual

1Copyright © 2013 Somfy SAS. All rights reserved - V0 - 02/2013
RS485 SETTING TOOL
Ref. 5101887A
EN
Installation guide

2Copyright © 2013 Somfy SAS. All rights reserved - V0 - 02/2013
CONTENTS
1. Introduction 2
2. Safety 2
3. Description & Installation 3
3.1. Description
3.2. Battery installation
4. Wiring 5
4.1. Connect the RS485 setting tool to
the RS485 product
5. Commissioning 5
5.1.Switch on the RS485 SETTING
TOOL
5.2. Somfy RS485 Node discovery
section
5.3. Setting tool parameters section
6. Tips & recommendations 9
7. Technical data 9
2. SAFETY
• This Somfy product must be installed by a professional motorisation and home
automation installer, for whom these instructions are intended.
• Before installation, check that this product is compatible with the associated equip-
ment and accessories.
• These instructions describe how to install, commission and use this product.
• Moreover, the installer must comply with current standards and legislation in the
country in which the product is being installed, and inform his customers of the
operating and maintenance conditions for the product.
• AnyuseoutsidethesphereofapplicationspeciedbySomfyisnotapproved.Such
use, or any failure to comply with the instructions given herein will invalidate the
warranty, and Somfy refuses to accept liability.
Subjecttotechnicalmodications.
1. INTRODUCTION
The RS485 SETTING TOOL is a smart digital system which enables the setting of
SOMFY RS485 products (Somfy RS485 motors and interfaces).
This was designed to ease the integration and settings for OEMs & façade makers,
but also to ease the installation and/or maintenance for installers thanks to fast
connection and intuitive tool thanks to its display.
Moreover,itsrmwarecanbeeasilyupdatedtoallowtohavethelatestcompatibility
version in hands.

3Copyright © 2013 Somfy SAS. All rights reserved - V0 - 02/2013
3. DESCRIPTION & BATTERY INSTALLATION
1
2
3
4
5
BACK
OPEN
STOP
CLOSE
OK
LIGHT
a: Ground e: Not used
b: Ground f: Not used
c: Not used g: RS485 -
d: Not used h: RS485 +
1: Navigation buttons 4: Battery compartment
2: Control buttons 5: On/Off
3: Backlight button 6: RJ45 socket
3.1. description
a b c d e f g h
6

4Copyright © 2013 Somfy SAS. All rights reserved - V0 - 02/2013
3.2. Battery installation
1) Remove the battery cover from the
back of the RS485 SETTING TOOL.
2) Insert the batteries following the
polarity indicated.
3) Replace the battery cover on the rear
of the RS485 SETTING TOOL.
Please separate the storage cells and batteries from other types of waste
and recycle them via your local collection facility.
1
2
3

5Copyright © 2013 Somfy SAS. All rights reserved - V0 - 02/2013
4. WIRING
4.1. Connect the RS485 SETTING TOOL to the RS485 product .
5. COMMISSIONING
5.1. Switch on the RS485 SETTING TOOL
1) Press the on/off button to switch on
the RS485 SETTING TOOL.
2) Choose the «Somfy RS485 node
discovery» fonction or the «setting tool
parameters» fonction by pressing the up
and down buttons.
3) Press the «ok» button to enter in the
chosen fonction.
BACK
OPEN
STOP
CLOSE
OK
LIGHT
BACK
OPEN
STOP
CLOSE
OK
LIGHT
BACK
OPEN
STOP
CLOSE
OK
LIGHT
SOMFY RS485
NODE DISCOVERY
SETTING TOOL
PARAMETERS
Use the «Up», «Down», «Back» & «Ok» buttons to naviguate in the menu.
Between the RS485 SETTING TOOL and the RS485 product, the cable
lenght should not exceed 10m.
Point to point settings only (this is not a network tool).

6Copyright © 2013 Somfy SAS. All rights reserved - V0 - 02/2013
5.2. Somfy RS485 node discovery section*
SOMFY RS485
NODE DISCOVERY
NODE ID : XXXXX
BACK
OPEN
STOP
CLOSE
OK
LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK
LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
**Select the preset position (1 to 16) with the buttons.
BACK
OPEN
STOP
CLOSE
OK LIGHT
*Example of setting for a RS485 motor

7Copyright © 2013 Somfy SAS. All rights reserved - V0 - 02/2013
MOTOR ROTATION
DIRECTION
PRESET POSITION
TESTING
BACK
OPEN
STOP
CLOSE
OK
LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
SET STANDARD
OK TO CONFIRM
PRESET : 01
XXX%
CALIBRATION
SETTING
SET CALIBRATION
OK TO CONFIRM
FACTORY DEFAULT
MOTOR RESET
BACK TO FACTORY
OK TO CONFIRM
PRESET POSITION
SETTING
PRESET : 01
XXX%
SET PRESET 01
OK TO CONFIRM
TEST PRESET 01
OK TO CONFIRM
PRESET POSITION
ERASING
PRESET : 01
XXX%
ERASE PRESET 01
OK TO CONFIRM
UP LIMIT
SETTING
SET UP LIMIT
OK TO CONFIRM
SET REVERSED
OK TO CONFIRM
DOWN LIMIT
SETTING
SET DOWN LIMIT
OK TO CONFIRM
BACK
OPEN
STOP
CLOSE
OK
LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK
LIGHT
BACK
OPEN
STOP
CLOSE
OK
LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK
LIGHT
BACK
OPEN
STOP
CLOSE
OK
LIGHT
BACK
OPEN
STOP
CLOSE
OK
LIGHT
BACK
OPEN
STOP
CLOSE
OK
LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
**
**
**

8Copyright © 2013 Somfy SAS. All rights reserved - V0 - 02/2013
5.3. Setting tool parameters section
SETTING TOOL
PARAMETER
***Please contact your local Somfy retailer for the informations about the Software
update.
BATTERY LEVEL
XXX%
TOOL SOFTWARE
SOFTWARE
UPDATE
TOOL NODE ID
XXX
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK
LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
BACK
OPEN
STOP
CLOSE
OK LIGHT
SOFTWARE UPDATE:
OK TO CONFIRM
***
BACK
OPEN
STOP
CLOSE
OK
LIGHT

9Copyright © 2013 Somfy SAS. All rights reserved - V0 - 02/2013
Power supply 9Vdc
Type ANSI : 1604A
IEC : 6LR61
Operating temperature -10°C to +60°C
Protection rating IP30
Battery life time 1000 motors setting
7. TECHNICAL DATA
6. TIPS AND RECOMMENDATIONS
Questions on the RS485 SETTING TOOL
Observations Possible causes Solutions
The blind does not
operate.
The wiring is incorrect. Check the wiring and modify it if
necessary.
The RS485 SETTING TOOL
battery is low.
Check whether the battery is
weak and replace it if necessary.
The RS485
SETTING TOOL
do not switch on.
The RS485 SETTING TOOL
battery is low.
Check whether the battery is
weak and replace it if necessary.
