Spectrum Industries InTouch 55449 User manual

0111414R2 Page 1 of 8
Assembly Instructions
Before you begin, please make sure all parts and proper quanti-
ties are included. Any parts damaged during shipment must be
reported within 15 days of receipt. To report information regarding
damages or if you have any questions, please call 1-800-235-1262.
To purchase parts or accessories, please contact us at
www.spectrumfurniture.com
1-800-235-1262
Thank you for purchasing Spectrum products!
Tools Required
Assembly Instructions
InTouch 20 Shelf w/ 4
Synchronizing USB Hubs
55449
1. Assemble Shelf
A. Orient the shelf and cord wrap bracket exactly as shown. Note orientation of shelf bends
(bends on ends of shelf will face the slotted-side of the cord wrap bracket.) Figure 1.
B. Align and attach the cord wrap bracket to the shelf with (4) 8-32 x 3/8” PHM screws.
C. Tighten screws securely.
Phillips Screwdriver
(1) 052741
7-outlet auxiliary
power strip
cord wrap
bracket
8-32 x 3/8” PHMS
(4) req’d
Figure 1
(4) 0110407
7-port USB hubs
(5) 0110254-5
3” x 2” self-adhesive
Velcro®pads
(15) 0102376
11” zip tie
(1) 0110565
shelf
(1) 0110564
cord wrap bracket
(6) 0100167
8-32 x 1/2” PH thread
cutting screw
(4) 052901
8-32 x 3/8” PHMS
shelf

0111414R2 Page 2 of 8
Figure 2A
2. Install USB Hubs to Shelf
“feeder“ USB
hub mounted
under shelf
A. Using the narrow slots as guides, apply (4) 3” x 2” adhesive Velcro®
pads (hook side) to the shelf as shown. Figure 2A.
B. Apply a 3” x 2” Velcro®pad (loop side) to the bottom of each USB hub.
Figure 2B
shelf
adhesive Velcro®
pads (hook side)
narrow slot
C. Attach 3 hubs to the top and 1 to the bottom of the shelf.
Figure 2B.
Note: The single feeder hub under the shelf will distribute the
data stream to the other 3 hubs.
adhesive Velcro®
pad (loop side)
adhesive Velcro®Pad
(hook side) centered on
the bottom of the shelf
shelf
Note: Mounting the feeder hub under
the shelf minimizes tampering with
wiring between hubs.
Hub #3
Hub #2
Hub #1

0111414R2 Page 3 of 8
Hub #3
Hub #2
Hub #1
shelf
USB cords to
hub #1, #2, #3
Figure 3A
3. Route USB Hub Wiring on Shelf
A. Route the USB cords as shown in the Figure 3A USB hub wiring diagram.
B. USB cords can be secured to the cord wrap bracket using the cord manage-
ment slots Figure 3B or bundled behind each hub with a zip tie.
cord
management slots
(wrap excess cord)
cord wrap
bracket
USB Hub Wiring Diagram
use cord open-
ings to route cords
through
USB hub power cords
(routed under shelf and down
side of cart to auxiliary power
strip on base panel)
cord management slotsexcess cord bundled
behind hub with zip tie
Figure 3B
cord wrap
USB hub #4
(feeder) cord
to worksurface
computer
Typical Wiring Recommendation
hub power
cord
USB hub #4
(feeder) cord
to worksurface
computer
“feeder“ USB
hub mounted
under shelf

0111414R2 Page 4 of 8
Figure 3C
cord wrap
bracket
route cords
through holes
Shelf Top View
Rear View of Shelf cord opening
for USB or
power plug
Figure 3E
Shelf Bottom View
feeder hub
Figure 3F
cord opening for
USB or power plug
bundled USB
cords
Figure 3D

0111414R2 Page 5 of 8
4. Attach Shelf to Cart
A. Open the instructor-side doors on the cart (outlet-side) install (4) 8-32 x 1/2” PH thread cutting screws in the divider
panel but do not tighten completely. Figure 4.
B. Set the shelf assembly onto the 4 screws as shown. Tipping the shelf slightly will help get it into the cart.
C. Secure the shelf to the side panels using the remaining (2) 8-32 x 1/2” PH thread cutting screws.
D. Tighten all screws securely.
divider panel
8-32 x 1/2” thread cutting
screw (4 req’d to attach
shelf to divider panel)
shelf assembly
8-32 x 1/2” thread cutting
screw (1 per side)
Figure 4

0111414R2 Page 6 of 8
5. Route Cords
A. On the instructor-side of the cart (outlet-side) route the USB cord from the
feeder hub under the shelf up the inside wall of the cart to the worksurface.
Figure 5A. The cord can be secured using the plastic cord clip inside the
cart.
B. Route the power cords from all the hubs down the inside wall of the cart.
Figure 5C. The cords can be secured using the plastic cord clip inside the
cart.
C. Mount the auxiliary power strip to the bottom of the cart with Velcro® and
switch off.
D. Plug the (4) USB hub power adapters into the auxiliary power strip. The
plugs will have to be staggered using every other outlet. Figure 5D.
Figure 5
cord reel
USB cord from
feeder hub
Auxiliary Power Strip attached to
base panel w/ Velcro®(shown w/
USB Hub Adapters plugged in)
USB hubs
plastic cord clip
Figure 5A
Figure 5B
Figure 5C
Figure 5D
“feeder” USB hub
outlets for tablet
chargers

0111414R2 Page 7 of 8
USB Hub Start-up
Note: The hubs can be reset if a power failure occurs or if any of
the hubs do not power up with the LED light on.
This reset procedure is for the synchronizing USB hubs included
only. For all other USB hubs, refer to your specic hub instructions
for further information.
USB Hub Reset Procedure
1. To reset the hubs, switch off the power strip and disconnect each hub’s USB
and power plug.
2. Let sit for 30 seconds.
3. Reconnect the hub USB and power plugs and switch the power strips on.
(If the hubs still do not power up, check the power supplies to make sure they are
operational)
1. Make sure all wires are connected as shown in Figure 3A. Each hub MUST be
plugged into the auxiliary power strip at the bottom of the cart.
2. Make sure the tablet USB cables are plugged in at the tablets and the hubs.
3. Make sure power strip is on, and plugged into either the cord reel or a live wall
circuit.
4. The LED on top of each hub will light up when the hub is receiving power. If the
LED does not light, check all connections.
5. If the LED still does not light, follow the reset procedure below.

Rear View
Front View
0111414R2 Page 8 of 8
925 First Avenue, PO Box 400, Chippewa Falls, WI 54729 Ph: 1-800-235-1262 Fax: [phone]
E-mail: [email protected] web: www.spectrumfurniture.com
Specications
USB Hub Specs
Standards
• USB specication version 2.0 1 (data rates of up to 480 Mbps)
• USB specication version 1.1 (data rates of up to 12 Mbps)
• OHCI
• UHIC
• VEHCI
Interfaces
• 1 upstream USB 2.0 Type B (female) port
• 7 downstream USB 2.0 Type A (female) ports (including 2 Fast
Charging ports)
Connectivity Rules
• Up to ve cascaded hubs
• Maximum cable length between each hub: 5m
• Up to 127 devices
Diagnostic LED
• Standard Mode (blue)
• Fast-Charge Mode (green)
Supplied Charging Current
• Standard Mode:
All seven USB ports - 0.5 A per port 2
• Fast-Charge Mode:
5 standard USB ports- 0.5 A per port 2
2 USB fast charging ports - 1.2 A per port 2
Power Input
• + 5 V / 3 A DC
Dimensions (L x W x H)
• + 3.94 x 2.2 x 0.9 inches (100 x 57 x 23 mm)
Weight
• 0.19 lbs (85 g)
Operating Temperature
• 32 to 104 °F (0 to 40 °C)
Storage Temperature
• -4 to 158 °F (-20 to 70 °C
Operating Humidity
• 5% to 95% (non-condensing)
Storage Humidity
• 0% to 95% (non-condensing)
Certications
• FCC
• CE
• C-Tick
• VCCI
• IC
• RoHS
Minimum System Requirements
• Computer with Windows® 7, Windows Vista®, Windows® XP SP2,
Windows® 2000 SP4
• Pentium 233-MHz or faster with 32MB RAM
• Computer with USB 1.1 Port
Note: The iPad®has a single cord for charging and syncing. This cord
must be moved from the power plug to the sync hub for syncing. Many
tablet devices use this same type of conguration. Some have a sepa-
rate power cord and separate USB cord to accomplish both syncing and
charging functions. Please consult the owners manual of your specic
device for further information.
