SRC R-HM-V2-18-17-02 User manual

:
Installation / Parts List / Bill of Material for Mounting
:
1
2
NO. Description Quantity Torque*(N-M) Remarks**
10
Use Liquid Thread Locker
SRC Design uses Metric System of Measurement and all dimensions in Millimeters
Recommended to use the Torque specied in the table
Denotes Usage of Liquid Thread Locker in specied Locations
Crash bar LH
Crash bar RH
Sliders Guards
Bolte screw
Hex bolt gradeb M8x15
Socket button head screw M8x20
Socket head cap screw M10x170
Hex ange nut gradea M10
Washer M8
Washer M10
Himalayan 410 (2017-2022)
R-HM-V2-18-17-02
copyright By SRC
Design and Specication are subjected to change
Use Liquid Thread Locker
Use Liquid Thread Locker
34-36
34-36

copyright By SRC
Design and Specication are subjected to change

copyright By SRC
Design and Specication are subjected to change
A

copyright By SRC
Design and Specication are subjected to change
Mounting lnstructions
Remove the original bolts from
the motorcycle as shown
in the picture above.
Remove the original bolts from
the motorcycle as shown
in the picture above.
Bring the tube to the hole
that leads. plug o the frame
4

Mounting lnstructions
copyright By SRC
Design and Specication are subjected to change
Place parts(Crash bar LH)
as shown in the picture.
Then put (nut) and (Washer)
as shown in the picture.
Place parts(Crash bar RH)
as shown in the picture.
1
10
7
9
5
69
2

A
copyright By SRC
Design and Specication are subjected to change
A
Take parts (nut) and (washer)
as shown in the picture
above.
Then put (nut) and (Washer)
as shown in the picture.
9
6
8
59

1. We request you to pay attention to the Mounting Instructions in this document and follow the step-by-
step procedures.
2. This Mounting Instruction manual is a “Do It Yourself” (DIY) tment manual of the Accessory part to the
Vehicle. We have prepared this based on our experience and knowledge, related to the Vehicle, Part and
its functional aspects.
3. SRC cannot guarantee the interchangeability of the parts to any other manufacturer’s accessory part. It
is advised to the User, to inspect and ensure the original state of all other Vehicle parts.
4. We request you to bear in mind, that the Installed part can change the driving behaviour and/or the
stability during driving or any other dynamic conditions.
5. If you have the appropriate tools and another person to assist you in the mounting, it will help.
6. After Completion of the Mounting and before taking on a First ride, Ensure and Check all functions of
the Vehicle. It is always advised to check loosening of the fasteners after the rst 50 kilo meters of ride and
at regular intervals.
7. To the maximum extent possible, our design use the current Mounting/Fitment of the Original
Equipment, so that Installation of these accessories will not aect the Payload or Function of the Vehicle or
the Part on which it is mounted to protect it
8. If any additional modications are to be done, prior to the tment of the accessories, it will be explicitly
specied in the instruction sheets
