SRC K-VS1000-19-17-01-SL User manual

Copyright By SRC
Design and Specification are subjected to change
Page 1
Scope of Supply/Bill of Material & Mounting Drawings
Part Number: K-VS1000-19-17-01-SL / K-VS1000-19-17-02
Part Description: Crash Bar –KAWASAKI VERSYS 1000 / 2019-2021
Applicable to both Stainless Steel and Steel Versions
Installation / Parts List / Bill of Material for Mounting

Copyright By SRC
Design and Specification are subjected to change
Page 2

Copyright By SRC
Design and Specification are subjected to change
Page 3
Mounting Instructions
Step: 1
Before starting to mount the Top
Bracket
The Original Hole for mounting the Top
Bracket can be found in-between the
front forks and positioned inside
And move the 2 original screws in
motorbike (as show)
Step: 2
Orient, Mount and Fit the Top Bracket (3) to the Motorbike Chassis frame (as show)
Use M8 x 40 Screw (9) –2 off and Washer M8 (17) –2 off, as shown in the BOM table and
the drawing.

Copyright By SRC
Design and Specification are subjected to change
Page 4
Step: 3
Use the Nut M8 (12) - 2 off as shown in
the BOM table and the drawing.
Do not tighten the screws fully.
Step: 4
Slip - in The Top Hollow end of Crash Bar RH&LH, has to be aligned to the Upper
Bracket (3) as shown, and slip-in the screw M6x15 (8)-2 off, the washer M6 (16)-2 off

Copyright By SRC
Design and Specification are subjected to change
Page 5
Step: 5
Before starting to mount the Bracket we have to unscrew the Mounting –4 Original
Screw in Motorbike. (As shown)
Step: 6
Orient the Plate (4) the Crash Bar LH (1) And Slide-in Washer M10 (18) –1 off Screw M10x65 (11) –1 off
and through the Mounting hole in the motorbike (as show red color)
Slide-in the Screw M10 x 40 (10) –1 off,
the long screw M10 x 330 (13) –1 off, and through the
Mounting hole in the Crash Bar Lower LH (1) to the motorbike ( as show red color )

Copyright By SRC
Design and Specification are subjected to change
Page 6
Step: 7
Orient the Bush spacer 25x15 (7) the Plate (4) the Crash Bar RH (2) And Slide-in Washer M10 (18) –1
off Screw M10x80 (12) –1 off and through the Mounting hole in the motorbike (as show red color)
Slide-in the Screw M10 x 40 (10) –1 off,
the Nut M10 (15) –1 off , and through the Mounting hole in
the Crash Bar Lower RH (2) to the motorbike ( as show red color )
Step: 8
Align the Lower Crash Bar
LH&RH, as shown, and slide-
in Washer M6 (16) –2 off
Screw M6 x 15 (8) –2 off
and secure the threads in
the other end of the Pin
pipe (5).

Copyright By SRC
Design and Specification are subjected to change
Page 7
Step: 9
Mount the Slider Guards (4) on each of the
Crash bar (2) and (3), and tighten the screws
fully
Use the Slider Bar as the Virtual Orientation
and looking from the front side of the
Motorbike, make one final Positioning and
Alignment of the Crash bars
Ensure mounting symmetry of the Slider Bars
visually (it must not be offset or shifted
visually when seen from the front side and
back side)

Copyright By SRC
Design and Specification are subjected to change
Page 8
General Information
1. Crash Bar is directly mounted to the Chassis of the Motorbike, with the Two halves ( Left Hand and
Right Hand ) mounted and joined using the Side Brackets & Top bracket with a Welded Cylindrical block, as
shown in the subsequent drawings
2. SRC’s Crash Bar protects the user, in the event of a fall or skidding of the vehicle.
3. We request you to pay attention to the Mounting Instructions in this document and follow the step-
by-step procedures.
4. This Mounting Instruction manual is a “Do It Yourself” (DIY) fitment manual of the Accessory part to
the Vehicle. We have prepared this based on our experience and knowledge, related to the Vehicle, Part
and its functional aspects.
5. SRC cannot guarantee the interchangeability of the parts to any other manufacturer’s accessory part.
It is advised to the User, to inspect and ensure the original state of all other Vehicle parts.
6. We request you to bear in mind, that the Installed part can change the driving behaviour and/or the
stability during driving or any other dynamic conditions.
7. If you have the appropriate tools and another person to assist you in the mounting, it will help.
8. After Completion of the Mounting and before taking on a First ride, Ensure and Check all functions of
the Vehicle. It is always advised to check loosening of the fasteners after the first 50 kilo meters of ride and
at regular intervals.
The Mounting Instructions can also be downloaded from SRC Website.
