SRC H-CB500X-02-01-SL User manual

Copyright By SRC
Design and Specification are subjected to change
Page 1
Scope of Supply/Bill of Material & Mounting Drawings
Part Number: H-CB500X-02-01-SL / H-CB500X-02-02
Part Description: Radiator Guard –HONDA CB500 X
Installation / Parts List / Bill of Material for Mounting

Copyright By SRC
Design and Specification are subjected to change
Page 2
MOUNTING DRAWINGS

Copyright By SRC
Design and Specification are subjected to change
Page 3
Mounting Instructions
Step 1:
For mounting the Radiator
Guard, remove the Mounting
bolt holding the top of the
Radiator, as shown in the
drawing.
Step 2:
Orient the Radiator Guard, in-
line with the mounting hole and
slide-in the OE Bolt, and secure
the threads in the frame bracket,
holding the Radiator.

Copyright By SRC
Design and Specification are subjected to change
Page 4
Step 3:
Through the bottom side holes of the
Radiator Guard, slide-in the Washer
M6 (2) and Screw M6 x 20 (3), and
secure the threads on the mounting
holes, near the bottom of the Radiator.
Step 4:
Ensure the Guard is not fouling with
any outside surfaces of the Radiator
and on the outside with the Twin
frames, and tighten the screws to
the torque, as shown in the BOM
table.
Radiator Guard is shown in “Final
Mounted condition”

Copyright By SRC
Design and Specification are subjected to change
Page 5
General Instructions
1. We request you to pay attention to the Mounting Instructions in this document and follow
the step-by-step procedures.
2. This Mounting Instruction manual is a “Do It Yourself” (DIY) fitment manual of the
Accessory part to the Vehicle. We have prepared this based on our experience and knowledge,
related to the Vehicle, Part and its functional aspects.
3. SRC cannot guarantee the interchangeability of the parts to any other manufacturer’s
accessory part. It is advised to the User, to inspect and ensure the original state of all other
Vehicle parts.
4. We request you to bear in mind, that the Installed part can change the driving behaviour
and/or the stability during driving or any other dynamic conditions.
5. If you have the appropriate tools and another person to assist you in the mounting, it will
help.
6. After Completion of the Mounting and before taking on a First ride, Ensure and Check all
functions of the Vehicle. It is always advised to check loosening of the fasteners after the first
50 kilo meters of ride and at regular intervals.
7. We are showing here the Scope of Supply/ Installation/Parts list & BOM from SRC
8.To the maximum extent possible, our design use the current Mounting/Fitment of the
Original Equipment, so that Installation of these accessories will not affect the Payload or
Function of the Vehicle or the Part on which it is mounted to protect it
9.If any additional modifications are to be done, prior to the fitment of the accessories, it
will be explicitly specified in the instruction sheets.
