ST EVAL-L9963E-MCU User manual

Introduction
The EVAL-L9963E-MCU is a hardware tool for evaluation and development and is ideal for rapid prototyping of a 48 V battery
management system (BMS) or as lower stage of a distributed BMS. This board can be used to evaluate the features of the
L9963E device and L9963T.
The EVAL-L9963E allows the user to connect up to 14 channels for cell voltage sensing, one channel for current sensing, and
up to 4 channels for temperature sensing (plus an additional on-board NTC to sense PCB temperature). The board provides an
onboard microcontroller with preloaded firmware intended to be used with STSW-L9963E GUI (graphical user interface).
EVAL-L9963E-MCU evaluation board
UM2846
User manual
UM2846 - Rev 1 - March 2021
For further information contact your local STMicroelectronics sales office.
www.st.com

1Hardware description
The EVAL-L9963E-MCU board provides maximum flexibility, giving access to all pins to simplify the evaluation
and debug phase of the device.
1.1 Block diagram
Figure 1. EVAL-L9963E-MCU block diagram
1
FTDI
(VCP)
USB
RS232
JTAG uC
L9963T
Tranceiver
L9963T
Tranceiver
Up to
14 cells
LI-Ion
battery
L9001
Power
supply
ISO communication
ISO communication
BMS
L9963E
1.2 Featured components
The EVAL-L9963E-MCU can be considered a reference design for a 48 V BMS or as a first layer of a distributed
BMS system. In the following table there is a short description of all the ST featured components.
Table 1. Featured components
Name Description
L9963E Automotive chip for battery management applications
L9963T Automotive SPI to isolated SPI transceiver
L9001 Automotive power supply IC with multiple voltage regulators
SPC574S64E3 32-bit Power Architecture MCU for automotive chassis and safety applications
UM2846
Hardware description
UM2846 - Rev 1 page 2/23

1.3 Board description
Figure 2. Board top view
Figure 3. Main components and connectors
UM2846
Board description
UM2846 - Rev 1 page 3/23

2Jumpers and connectors
2.1 Mother board jumpers and connectors
Table 2. Motherboard jumpers and connectors
Name Description Type
X1 External power supply connector Jack
P1 USB connector for PC communication Mini USB connector
ISOPORT 1
Isolated serial communication port:
USB type A connector
1- VBAT
2- ISOH- (From L9963E)
3- ISOH+ (From L9963E)
4- FaultH
ISOPORT 2
Isolated serial communication port:
USB type A connector
1- N.C.
2- ISO- (from L9963T)
3- ISO+ (from L9963T)
4- N.C.
P2
Battery connector:
Multi pin connector
1- cell 14
2- cell 12
3- cell 10
4- cell 8
5- cell 6
6- cell 4
7- cell 2
8- cell 0
9- ground
10- current sensor resistor negative pin
11- NTC1-
12- NTC2-
13- NTC3-
14- NTC4-
15- VBAT
16- cell 13
17- cell 11
18- cell 9
19- cell 7
20- cell 5
UM2846
Jumpers and connectors
UM2846 - Rev 1 page 4/23

Name Description Type
P2
21- cell 3
Multi pin connector
22- cell 1
23- ground
24- current sensor resistor positive pin
25- NTC1+
26- NTC2+
27- NTC3+
28- NTC4+
JP2 L9963T (U16) ISO- output selection 1-2 ISO- redirected to ISOPORT 1_1
2-3 ISO- redirected to L9963E
JP3 L9963T (U16) TX amplitude selection
1-2 high amplitude/high threshold (1)
2-3 low amplitude/low threshold (1)
Unconnected : highamplitude/high threshold
JP4 L9963T (U16) SPI master clock selection
1-2 minimum frequency (1)
2-3 maximum frequency (1)
Unconnected: minimum frequency
JP5 L9963T (U16) transmitter enable signal
1-2 enable the TX activity (1)
2-3 disable the TX activity (1)
Unconnected : controlled by μc (PD9)
JP6 L9963T (U16) ISO+ output selection 1-2 ISO- redirected to ISOPORT 1_1
2-3 ISO- redirected to L9963E
JP7 L9963T (U18) TX amplitude selection
1-2 high amplitude/high threshold (1)
2-3 low amplitude/low threshold (1)
Unconnected: high amplitude/high threshold
JP8 L9963T (U18) SPI master clock selection
1-2 minimum frequency (1)
2-3 maximum frequency (1)
Unconnected: minimum frequency
JP9 L9963T (U18) transmitter enable signal
1-2 enable the TX activity (1)
2-3 disable the TX activity (1)
Unconnected: controlled by μc (PD8)
JP12 L9001 (U26) watchdog disable (2) Connected: watchdog disabled
Unconnected: watchdog enabled
JP13 L9001 (U26) wake signal Connected: L9001 enabled
Unconnected :L9001 disabled
JP14 3.3 V - 5 V voltage selector 1-2 5 V
2-3 3.3 V
JP15 5 V selector 1-2 5 V from L9001
2-3 5 V from USB
JHot Hot plug voltage selector 1-2 VTREF
2-3 Vreg
1. See L9963T datasheet.
2. See L9001 datasheet.
UM2846
Mother board jumpers and connectors
UM2846 - Rev 1 page 5/23

Figure 4. P2 Battery connector
2.2 Default jumpers setting
Table 3. Jumpers configuration
Name Description Configuration
JP2 L9963T (U16) ISO- output selection 2-3 ISO- redirected to L9963E
JP3 L9963T (U16) TX amplitude selection 1-2: high amplitude/high threshold
JP4 L9963T (U16) SPI master clock selection Unconnected: minimum frequency
JP5 L9963T (U16) transmitter enable signal Unconnected: controlled by μc (PD9)
JP6 L9963T (U16) ISO+ output selection 2-3 ISO- redirected to L9963E
JP7 L9963T (U18) TX amplitude selection 1-2: high amplitude/high threshold
JP8 L9963T (U18) SPI master clock selection Unconnected: minimum frequency
JP9 L9963T (U18) transmitter enable signal Unconnected: controlled by μc (PD8)
JP12 L9001 (U26) watchdog disable (2) Connected: watchdog disabled
JP13 L9001 (U26) wake signal Connected: L9001 enabled
JP14 3.3 V - 5 V voltage selector 1-2 5 V
JP15 5 V selector 1-2 5 V from L9001
JHot Hot plug voltage selector 1-2 VTREF
UM2846
Default jumpers setting
UM2846 - Rev 1 page 6/23

2.3 Hot plug protection
Figure 5. Hot plug protection circuit
The structure shown in the Figure 5 on the GND path will help withstanding the hot plug by limiting the inrush
current incoming from any L9963E pin connected to the centralized clamp.
Working principle is the following:
When L9963E is OFF and no cell is connected, the VTREG regulator is shut down and MHOT is safely kept off by
the RPD pull down resistor.
Upon the first hot plug event, inrush current incoming from the centralized clamp is forced to flow into RHOT
resistor, which offers proper limiting.
Any VDS voltage spike on MOSFET during hot plug could be coupled to the gate via the parasitic Miller
capacitance. Unwanted turn-on is safely filtered by CGS, that helps keeping VGS below the threshold voltage.
Hence the MOSFET will stay OFF during hot plug.
If the hot plug voltage is enough to guarantee L9963E powerup the MOSFET will be turned on by VTREG
regulator with a proper delay, obtained through RG gate resistor.
Finally, during L9963E normal operation the MOSFET will be ON, thus guaranteeing a very low impedance path
(few mΩ) on the analog GND (GND_B) line.
Such a small shift between L9963E GND and battery pack GND will not alter cell measurement at all, since cell
ADCs are fully differential. Hence, both cell and sum of cells measurements will be accurate.
Moreover, since L9963E only drains few mA from the battery pack, error introduced on the VBAT stack
measurement via internal voltage divider will be negligible.
Also the CSA used for Coulomb counting features a fully differential architecture, thus being immune to such a
small common mode shift.
UM2846
Hot plug protection
UM2846 - Rev 1 page 7/23

3Getting started
3.1 System requirements
• EVAL-L9963E-MCU
• Mini USB to USB type A cable
• Power supply (at least 3 output 0 – 30 V, if possible 60 V):
– 1 output to power L9963E (0:60 V)
– 1 output to simulate cells common mode voltage (0:60 V)
– 1 output to simulate cell voltage (0:5 V)
– 12 V power supply with 2.1 mm jack output, internal pin +
• L9963E evaluation GUI (please check STSW-L9963E user manual)
3.2 EVAL-L9963E-MCU board setup
3.2.1 Low voltage power supply
The 12 V power supply must be connected to X1 connector in order to properly supply the low voltage portion of
the EVAL-L9963E-MCU board.
Figure 6. Low voltage power supply
Jumper settings:
JP14 1-2 (L9001 output 5V)
JP15 1-2 (5V from L9001)
JP12 – JP13 closed (L9001 active)
If the power supply is properly working LED D10 and D3 will be switched ON when USB is connected to PC
UM2846
Getting started
UM2846 - Rev 1 page 8/23

3.2.2 L9963E external connection and power supply
Figure 7. L9963E external connection and power supply
3.2.3 Transceiver settings
Figure 8. Transceiver settings
UM2846
EVAL-L9963E-MCU board setup
UM2846 - Rev 1 page 9/23

3.2.4 USB to PC connection
Figure 9. USB to PC connection
3.2.5 Possible connection for battery simulation
In case a real battery is not available, it’s possible to use the following circuit to simulate the battery pack.
Figure 10. Battery simulation
UM2846
EVAL-L9963E-MCU board setup
UM2846 - Rev 1 page 10/23

4Board schematics
Figure 11. Board schematic (1/5)
R26
100
R29
100
R33
100
R36
100
R41 100
R45
100
R51 100
R56
100
R61 100
R66
100
R72 100
R75
100
R84 100
R89 100
R92 100
C29 10nF C37 10nF
R27 39
R31 39
R34 39
R38 39 R42 39 R48 39 R52 39 R59 39 R63 39 R69 39 R73 39 R82 39 R87 39
R90 39
C41 10nF C46 10nF C49 10nF C52 10nF C58 10nF C60 10nF C63 10nF C65 10nF C68 10nF C70 10nF C72 10nF C87 10nF
C28
47nF
C36
47nF
C40
47nF
C45
47nF
C48
47nF
C51
47nF
C56
47nF
C59
47nF
C62
47nF
C64
47nF
C67
47nF
C69
47nF
C71
47nF
C86
47nF
C88
47nF
GND_B
C25 100nF
GND_B
C31
220nF
C32
2.2uF
Not Assembled
C34 100nF
C33
2.2uF Not Assembled
C35
100nF
GND_B
Not Assembled
C30
100nF
VCOM
VTREF
C39
1uF
C21 2.2uF C27
100nF
GND_B
D6
SMA6T68AY
R37 60.4
R39
60.4
C42
10nF
GND_B
I/O1
1
GND
2
I/O2
3I/O2 4
Vbus 5
I/O1 6
U14 USBLC6-2SC6Y
C44
1uF
GND_B
VCOM
D7
SZMM3Z4V7T1G
R62 18k
C61
2.2nF
GND_B
GND_B
R68
10k
VBAT
62
C14
61
S14
60
B14_13
59
S13
58
C13
57
C12
56
S12
55
B12_11
54
S11
53
C11
52
C10
51
S10
50
B10_9
49
S9
48
C0
26
C1
27
S1
28
B2_1
29 S2 30
C2
31
C3
32
S3
33
B4_3
34 S4 35
C4
36
C5
37
S5
38
B6_5
39 S6 40
C6
41
C7
42
S7
43
B8_7
44 S8 45
C8
46
C9
47
ISOHp 7
ISOHm 8
ISOLp_SDI 3
ISOLm_NCS 4
GPIO8_SCK 1
GPIO9_SDO 2
DGND
9
VCOM 5
CGND
6
GPIO1_FAULT_H 10
GPIO2_FAULT_L 11
GPIO3 12 GPIO4 13 GPIO5 14 GPIO6 15
GPIO7_WAKEUP 16
NPNDRV 17
VREG 18
VTREF 19
SPIEN 20
VANA 21
AGND
22
ISENSEp 23
ISENSEm 24
GNDREF
25
CAP2 63
CAP1 64
GND
65
U13 L9963
C81
2.2nF C82
2.2nF C83
2.2nF C85
2.2nF
R80 1K5 2W
R81 1K5 2W
R85 1K5 2W
R86 1K5 2W
R76
10K
R77
10K
R78
10K
R79
10K
GND_B
Not Assembled
R43 10k
VTREF
Not Assembled
R22
0
GND_B
R67
3K9
C66
6.8nF
R64
10K
R70
NTCG163JH103HTDS
GND_BGND_B
VTREF
NTC_INTERNAL_INPUT
C73
6.8nF
C0 C1 C2 C4 C5 C6 C7 C8
NTC1+
C9 C10 C11 C12 C13 C14 C3
VBAT_CELL
C74
6.8nF
C75
6.8nF
C76
6.8nF
NTC2+ NTC3+ NTC4+
NTC1-
NTC2-
NTC3-
NTC4-
VBAT_CELL
C13 C11
C9 C7
C5 C3
C1
GND_PACK
C12
C10
C8
C6
C4
C2
C0
GND_PACK
C14
NTC1+ NTC2+ NTC3+ NTC4+
NTC1-
NTC2-
NTC3-
NTC4-
C43
22pF
C47
22pF
VCOM
MISO_L9963
MOSI_L9963
SCK_L9963
CS_L9963
C93
47nF
C92
47nF
C91
68nF
C90 33pF
C89
10uF
R93
10 R94
10
ISENSEM
ISENSEP
ISENSEP ISENSEM
NTC_INTERNAL_INPUT
R58
6K2
ISOHp_L9963_output
ISOHm_L9963_output
Not AssembledC38 47nF
Not AssembledC50 47nF
L6
ESMIT4180
R49
60.4
R53
60.4
C53
10nF
I/O1
1
GND
2
I/O2
3I/O2 4
Vbus 5
I/O1 6
U15 USBLC6-2SC6Y
C55
1uF
C54
22pF
C57
22pF
GND_B
Not Assembled
R46 33R
Assembled for L9963 in SPI
R57
33R
Assembled for L9963T
R47
0
Assembled for L9963T
R54 0 GND_B ISOLm_L9963
ISOLp_L9963
VCOM
R21 10k
VBAT_UP
FAULTL_L9963
VBAT_UP 1
2 3 4 SHELL
ISOPORT1
FAULTH_L9963
ISOHm_L9963_output
ISOHp_L9963_output
1 2
4 3
U22
TLX9291
FAULTL_L9963 R131
470R
GND_B
GND
R130
10k
VDD5
FAULT_1
Assembled for L9963T R129 10k GND_B
CS_L9963
MOSI_L9963
MISO_L9963
SCK_L9963
FAULTL_L9963
TP6
GNDB
TP7
GNDB
GND_B GND_B
1 2 3 4 5 6 7 8 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
P2
VBAT_CELL
C14 C13
C12
C11 C10 C9
C8
C7 C6 C5
C4 C3 C2 C1 C0
ISENSEP
ISENSEM
NTC1+ NTC2+ NTC3+ NTC4+
NTC1- NTC2- NTC3- NTC4-
FAULTH_L9963 FAULTH_L9963
C155 47nF
TP1
C14
TP10
C13
TP11
C12
TP12
C11
TP13
C10
TP14
C9
TP15
C8
TP16
C7
TP17
C6
TP18
C5
TP19
C4
TP20
C3
TP21
C2
TP22
C1
TP23
C0
1k R156
D13 LED GND_B
VBAT_FAULT
Not Assembled
RMREG
100k
G
D S
Q1
STL8N10LF3
C26
4.7uF
VREG
HOTPLUG PROTECTION
0603 4.7nF
X7R 100V
CGA3E2X7R2A472K080AA
CGS_HOT
1K
1/10W 5% 0603
AC0603JR-071KL
RG_HOT
100K 1/16W 1% 0402
RN73H1ETTP1003F50
RGS_HOT 47R
1W
1%
2512
ERJU1TF47R0U
RHOT_LIM
S
1
S
2
S
3
G
4
D8
D7
D6
D5
STS8N6LF6AG
SO8
MHOT
2
1 3
JHOT
GND_B
VTREF
VREG
GND_B
BD1
MPZ2012S102ATD25
BD2
MPZ2012S102ATD25
BD3
MPZ2012S102ATD25
BD4
MPZ2012S102ATD25
BD5
MPZ2012S102ATD25
BD6
MPZ2012S102ATD25
BD7
MPZ2012S102ATD25
BD8
MPZ2012S102ATD25
BD9
MPZ2012S102ATD25
BD10
MPZ2012S102ATD25
BD11
MPZ2012S102ATD25
BD12
MPZ2012S102ATD25
BD13
MPZ2012S102ATD25
BD14
MPZ2012S102ATD25
BD15
MPZ2012S102ATD25
GND_PACK GND_PACK
GND_PACK GND_PACK GND_PACK
GND_PACK
GND_PACK GND_PACK GND_PACK
GND_PACK
GND_PACK GND_PACK GND_PACK
GND_PACK
GND_PACK GND_PACK GND_PACK
BD16
MPZ2012S102ATD25
GND_PACK
GND_PACK
GND_PACK
C80
100nF
C79
100nF
C78
100nF
C77
100nF
GND_PACK
GND_PACK
Additional cell input
connector for single board
BMS demonstration like
48v BMS
L9963/L9963T
transceiver assembly note:
UM2846
Board schematics
UM2846 - Rev 1 page 11/23

Figure 12. Board schematic (2/5)
VIO
1
SDO
2
SCK
3
SDI
4
NCS
5
DIS
6
ISOFREQ
7
BNE/CPOL
8TXAMP 9
SPICLKFREQ 10
TXEN/CPHA 11
NSLAVE 12
GND 13
ISOM 14
ISOP 15
VDD 16
U16 L9963T
R100 10k
R99 10k
GNDGND
L9963T_ISO_FREQ
L9963T_BNE
R95
60.4
R96
60.4
C96
10nF
GND
I/O1
1
GND
2
I/O2
3I/O2 4
Vbus 5
I/O1 6
U17
USBLC6-2SC6Y
C98
1uF
GND
C97
22pF C99
22pF
VDD5
ISOp_L9963T
ISOm_L9963T
GND
L7
ESMIT4180
ISOp_output_L9963T
ISOm_output_L9963T
ISOLm_L9963
L9963T_NCS
L9963T_SDI L9963T_SCK L9963T_SDO L9963T_DIS
VADC
C100
100nF
GND
C95
100nF
VDD5
Not Assembled
R97 10k R98 10k
VDD5
GND
JP5
TXEN/CPHA_SEL
JP3
TXAMP_SEL
JP4
Master SPICLK_SEL
VDD5
GND
L9963T_TXAMP
VIO
1
SDO
2
SCK
3
SDI
4
NCS
5
DIS
6
ISOFREQ
7
BNE/CPOL
8TXAMP 9
SPICLKFREQ 10
TXEN/CPHA 11
NSLAVE 12
GND 13
ISOM 14
ISOP 15
VDD 16
U18 L9963T
R106
10k
R105
10k
GNDGND
L9963T_2_ISO_FREQ L9963T_2_BNE
R101 60.4
R102 60.4
C104
10nF
GND
I/O1
1
GND
2
I/O2
3I/O2 4
Vbus 5
I/O1 6
U19
USBLC6-2SC6Y
C106
1uF
GND
C105 22pF
C107 22pF
VDD5
ISOp_L9963T_2
ISOm_L9963T_2
GND
L9963T_2_NCS L9963T_2_SDI L9963T_2_SCK
L9963T_2_SDO L9963T_2_DIS VADC
C108
100nF
GND
C103
100nF
VDD5
Not Assembled
R103 10k
R104 10k
VDD5
GND
JP9 TXEN/CPHA_SEL
JP7
TXAMP_SEL
JP8
Master SPICLK_SEL
VDD5
GND
L9963T_2_TXAMP
ISOp_output_2
ISOm_output_2 1
2 3 4 SHELL
ISOPORT2
1 2 3 4 SHELL
ISOPORT1_1
ISOp_output_1
ISOm_output_1
Not Assembled
C94 47nF
L8
ESMIT4180
Not Assembled
C102 47nF
Not Assembled
C109 47nF
ISOm_output_2
ISOp_output_2
Not Assembled
C101 47nF
ISOm_output_L9963T
ISOm_output_1
ISOp_output_L9963T
ISOLp_L9963
ISOp_output_1
R134 0R
R135 0R
R136 0R
R137 0R
CS_1
SCK_1
SOUT_1 SIN_1
L9963T_SCK L9963T_SDI
L9963T_SDO
Not Assembled
R138 0
Not Assembled
R139 0
Not Assembled
R140 0
Not Assembled
R141 0
CS_1 SCK_1
SOUT_1
SIN_1
CS_L9963
SCK_L9963
MOSI_L9963
MISO_L9963
Not Assembled
R143 0GND_BGND
JP2
Jumper
JP6
Jumper
R132 10k R133 10k
TP29
ISOP
TP30
ISOM
TP28
ISOP
TP31
ISOM
TP26
ISOP
TP27
ISOM
TP25
ISOHP
TP24
ISOHM
L9963T_TXEN
L9963T_2_TXEN
TP_ISO_U16
TP_BNE_U16
TP_DIS_U16
TP_SDO_U18
TP_SCK_U18
TP_SDI_U18
TP_NCS_U18
TP_DIS_U18
TP_ISO_U18
TP_BNE_U18
GND_B
GND_B
TP_NCS_U16
TP_SDI_U16
TP_SCK_U16
TP_SDO_U16
TP_VIO
1 3
1 3
1 3
1 3
1 3
1 3
1 3 1 3
L9963T_NCS
TP_SIN_1
TP_SOUT_1
TP_SCK_1
TP_CS_1
Additional isolated
communication output
interface between BMC
and CMC, if board splited
UM2846
Board schematics
UM2846 - Rev 1 page 12/23

Figure 13. Board schematic (3/5)
GND
D8 STTH2R02
+-
C111
100uF/50V 10uF50V
C112
10uF50V
C113
100nF/50V C114
1k
R107
D9
LED
Power_Device
TP3
VBAT
1k R108
D10 LED
5V
TP4
VDD5
C110
100nF
1 3 2
X1 DC-10A TP5
GND
VDD5
USB_VCC
CANH
CANL
1 2 3 4
Not Assembled
JP11
4 HEADER
GND
Not Assembled
C122 4.7nF
TXD
1
GND
2
VDD 3
RXD
4
VDDIO 5
CANL 6
CANH 7
STBY
8
Not Assembled
U21 MCP2562/L9616
Not Assembled
C121
47pF/100V
Not Assembled
C123
47pF/100V
GND
GND
NEAR TO BOARD CONNECTO R
1 2
3
Not Assembled
D11
ESDCAN03 GND
GND
Not Assembled
R110
60.4
GND
Not Assembled
R112
1k
GND
Not Assembled C119
100nF
Not Assembled
C120
100nF
GND
VDD5
GND
CAN_TX
CAN_0_STBY
Not Assembled
R109
0
Not Assembled
R111 60.4
CANL
CANH
CAN_RX CAN_RX
CAN_TX
GND
VDDIO
C163
10pF
C164 10pF
C165
10pF
C166
10pF
C167 10pF
GND
ADC_MON
RSTN1 RSTN2 TWN WDO
10k R157
10k
R172 CONF1
CONF2
CONF3
NC
R180
NC
R179
JP13
WAKE
C162
100nF
1K
R184
GND
10k R142
10k R23
GND
STBY
WDI
GND
1ADCMON 2
RSTN1 3 RSTN2 4
VDDIO 5
CONF3
6
WAKE
7
V1O 8
VS
9
CP
10
CP2
11
CP1
12
EX-PAD
0
V2O 13
VR1 14
FB2 15
VR2 16
CONF1
17 CONF2
18
VADC 19
TWN 20
WDI 21
STBY 22
WDT
23 WDO 24
U26 L9001
GND
C156 220nF
C157
68nF
L9 SMRH74-220MT
22uF25V
C158
VDD1
GND
0 R20
NC R19
22uF25V
C159
GND
0 R24
52.5k R158
10k R174
GND
C160
1uF/16V
GND
0 R171
VADC
VDDIO
JP12
C161 47nF
GND
Power_Device
TP32
VDD6
ADC_MON
RSTN1
RSTN2
TWN WDO STBY
WDI
NC R173
NC R176
NC R177
NC R178
NC R182
NC R183
NC R185
RSTN1 TWN
ADC_MON
STBY WDI WDO
PORST
PD3
PD4
PD5
PD6
PD7
GND
TP33
ADCV
WDT
D19 STPS3L40-Y
GND
RSTN2
10k R186
10k R187
10k R188
10k R189
10k R190
JP14
Jumper
1 3
GND
JP15
Jumper
1 3
UM2846
Board schematics
UM2846 - Rev 1 page 13/23

Figure 14. Board schematic (4/5)
GND
PA[0]
2
PA[1]
3
PA[2]
4
PA[3]
5
PA[4]
6
TCK 63
TMS 60
TDI 59
TDO 61
PA[10]
12
PA[11]
13
PA[12]
14
PA[14]
16 PA[13] 15
PA[15]
17
PB[0]
18
PB[1]
21
PB[6]
26
PB[7]
27
PB[8]
28
PB[10]
31
PB[11]
32
PB[12]
33
PB[13]
34
PB[14]
35
PB[15]
36
PC[0]
29
PC[1]
30
PC[12] 56 PC[13] 57 PC[14] 58 PC[15] 62
PD[0] 65 PD[1] 67 PD[2] 69 PD[3] 70 PD[4] 71 PD[5] 72 PD[6] 73 PD[7] 74 PD[8] 75
PD[9] 76
PD[10] 77
PD[11] 78
PD[12] 79
PD[13] 80
PD[14] 81
PD[15] 82
PE[0] 83
PE[1] 84
PE[2] 86
PE[3] 87
PE[4] 88
PE[5] 89
PE[6] 90
PE[7] 91
PE[8] 92
PE[9] 93
PE[10] 94
PE[11] 96
PE[12] 97
PE[13] 98
PE[14] 99
PE[15] 100
PORST 66
TESTMODE 64
XTAL 54
EXTAL 53
FCCU_F0
1
PA[5]
7
PA[6]
8
PA[7]
9
PA[8]
10
PA[9]
11
PB[2]
22
PB[3]
23
PB[4]
24
PB[5]
25
PC[4]
42
PC[5]
43
PC[6]
44
PC[7]
45
PC[8]
46
PC[9]
47
PC[10]
48
PC[11]
49
PI[1]
40
PI[2]
41
VDD_HV_IO_MAIN
20
VDD_HV_IO_MAIN 85
VDD_HV_IO_MAIN 95
VDD_LV
19
VDD_LV 52
VDD_LV 68
VREFH_ADC
37
VDD_HV_ADC_TSENSE
39
VDD_HV_IO 51
VDD_HV_OSC 55
FCCU_F1
50
ExpPad
101
VREFL_ADC
38
U24
SPC574S64E3
VDD_HV_IO_MAIN
VDD_LV
Pin 20
C147
2.2uF
C148
100nF
C149
10nF
VDD_LV
VDD_HV_OSC
C150
100nF
C151
10nF
Pin 51
C143
100nF
C144 10nF
Pin 85
C145 100nF
C146 10nF
Pin 95
VDD_HV_IO_MAIN
GND GND
GND GND
VDD_LV
R123
6R8
C140
1uF
C141
100nF
C142
10nF
GND
Pin 37VREFH_ADC
VREFH_ADC
C137
1uF
C138
100nF
C139
10nF
GND
VDD_HV_ADC
Pin 39
PA0
PA1 PA2 PA3 PA4 PA5
PA6 PA7 PA11
PA12 PA13 PA14 PA15 PA10
PA9 PA8
PB0
PB1 PB2 PB3 PB4 PB5
PB6
PB7
PB8
PB10
PB11
PB12
PB13
PB14
PB15
PE15
PE14
PE13
PE12
PE11
PE10
PE9
PE8
PE7
PE6
PE5
PE4
PE3
PE2
PE1
PE0
PD0
PD1 PD2 PD3 PD4 PD5 PD6 PD7 PD8
PD9
PD10
PD11
PD12
PD13
PD14
PD15
XTAL
EXTAL
PC0
PC1
PC4
PC5
PC6
PC7
PC8
PC9
PC10
PC11
PC12
PC13
PC14
PC15
PI1
PI2
GND
VDD_HV_IO_Main
VDD_HV_IO_Main
VDD_HV_ADC
VDD_HV_IO_Main
GND
TCK TDO
TMS TDI
PORST
FCCU_F0
FCCU_F1
GND
VDD_HV_IO_Main
C136
20pF
C135
20pF
R122
0R
1 2
Y2 20MHz
GND
VSS
1RST 2
MR
3VCC 4
U23
STM6315RB - 2.63V
S2
RST
C127
100nF TP8
RST
R113
4K7
VDD_HV_IO_Main
C126
100nF
GND
GND
PORST
1k
R118
D12
LED
VDD_HV_IO_Main PORST
VDD_HV_IO_Main
VDD_HV_OSC
R119
0
VDD_HV_ADC
VDD5
TP9
GND
C152
100nF
C153
10nF
Pin 55
GND
VDD_HV_OSC
Pin 19
GND
C129
100nF
C128
2.2uF
C130
10nF
C131
100nF
C132
10nF
GND
Pin 52
C133
100nF
C134
10nF
GND
Pin 68
VDD_LV
R115 33R
R114 33R RXD
TXD
R120 33R
R121 33R
CAN_TX
CAN_RX
R12533R
R12633R
R12733R
R12433R
SCK_1
SIN_1
CS_1
SOUT_1
R117 33R
R116 33R
L9963T_2_SDI
L9963T_2_SCK
R148 33R L9963T_2_SDO
R147 33R L9963T_2_NCS
R149 0R R150 0R
R151 0R
L9963T_DIS L9963T_ISO_FREQ
L9963T_BNEPC4
PC5 PC7
R144 0R R145 0R R146 0R
L9963T_2_DIS L9963T_2_ISO_FREQ
L9963T_2_BNEPA11
PE2 PE1
R155 0R
PA14 FAULT_1
PD8
R191 0
L9963T_2_TXEN
PD9
R192 0
L9963T_TXEN
FAULT_1
UM2846
Board schematics
UM2846 - Rev 1 page 14/23

Figure 15. Board schematic (5/5)
V_USB 1
USBD- 2
USBD+ 3
ID 4
GND 5
CH-GND 6
CH-GND 7 CH-GND 8 CH-GND 9
P1 USB_MINI_B
GND
GND
L3
60ohm-500mA Wurth 74279267
V_USB
USB -
USB +
VIN VCIO
Not Assembled
R5 0R VCIO
1 2
D1
LED GREEN
1 2
D2
LED GREEN
1 2
D3
LED GREEN
R6
1K
R10
1K
R11
1K
GND
LED_1
LED_2
VCIO
Not Assembled
R13 0R
LED_1 USERIO_0
Not Assembled
R14 0R
LED_2 USERIO_1
A
3GND
2VCCA
1VCCB 6
DIR 5
B4
U12 SN74LVC1T45DCK
GND
3V3_USB
R15
4k7 R16
4k7
GND
GND
VCIO SRST#_DIR
SRST#_O SRST#_USB
A
3GND
2VCCA
1VCCB 6
DIR 5
B4
U11 SN74LVC1T45DCK
GND
3V3_USB VCIO
TRST#_USBTRST#_O
A
3GND
2VCCA
1VCCB 6
DIR 5
B4
U10 SN74LVC1T45DCK
GND
3V3_USB VCIO
TMS_DIR
TMS_USBTMS_IO
R12
4k7
A
3GND
2VCCA
1VCCB 6
DIR 5
B4
U7 SN74LVC1T45DCK
GND
3V3_USB VCIO
TDO_USBTDO_I
GND
A
3GND
2VCCA
1VCCB 6
DIR 5
B4
U6 SN74LVC1T45DCK
3V3_USB VCIO
TDI_USBTDI_O
GND
A
3GND
2VCCA
1VCCB 6
DIR 5
B4
U5 SN74LVC1T45DCK
3V3_USB TCK_O
GND
VCIO TCK_USB
GND
1
OSCI
2
OSCO
3
VPHY
4
GND
5
REF
6
DM
7
DP
8
VPLL
9
AGND
10
GND
11
VCORE
12
TEST
13
RESET#
14
GND
15
ADBUS0 16
ADBUS1 17
ADBUS2 18
ADBUS3 19
VCCIO
20
ADBUS4 21
ADBUS5 22
ADBUS6 23
ADBUS7 24
ACBUS0 26 ACBUS1 27 ACBUS2 28 ACBUS3 29 ACBUS4 30
GND
25
VCCIO
31
ACBUS5 32 ACBUS6 33 ACBUS7 34 BDBUS0 38
GND
35
SUSPEND#
36
VCORE
37
BDBUS1 39
BDBUS2 40
BDBUS3 41
VCCIO
42
BDBUS4 43
BDBUS5 44
BDBUS6 45
BDBUS7 46
GND
47
BCBUS0 48
BCBUS1 52
BCBUS2 53
BCBUS3 54
VREGOUT
49 VREGIN
50
GND
51
BCBUS4 55
VCCIO
56
BCBUS5 57
BCBUS6 58
BCBUS7 59
PWREN#
60
EEDATA
61
EECLK
62
EECS
63
VCORE
64
U1 FT2232H
3V3_USB
GND
V_CORE
TP2
3V3 USB
3V3_USB
3V3_USB
3V3_USB
V_CORE
GND
R1
12K
R2 10R
R3 10R
EECS
EECLK
EEDATA
R4
1K
3V3_USB
TCK_O TDI_O TDO_I TMS_IO
TMS_IO
RTCK_I
LED_1
TRST#_O
SRST#_O
SRST#_DIR
TMS_DIR
LED_2
CS
1
SCL
2DI
3DO 4
GND
5
WE
6PRE 7VCC 8
U8 M93S46XS
3V3_USB
R9
2k2
EEDATA
GND
R7 4k7
EECS
GND
R8
4k7
3V3_USB
EEPRE
EEWRE
EEDATA
EECLK
C9
100nF
C10 100nF
C11 100nF
C17
100nF
C13
100nF
C14
100nF
C15
100nF
C16
100nF
C23 100nF
C24 100nF
C5 100nF
C7
100nF
VPHY
VPLL
USB_OSCI
USB_OSCO
USB_VCC
USB_TX
USB_TX USB_RX
USB_RX
1.8V
C12 3.3uF
1.8V
Wurth Elektronik 74279267
Wurth Elektronik
GND
C6
4.7uF
C8
4.7uF
From FTDI 2232H RS232 mode:
Pin 38 TXD, transmitter output
Pin 39 RXD, receiver input
A
3GND
2VCCA
1VCCB 6
DIR 5
B4
U2 SN74LVC1T45DCK
A
3GND
2VCCA
1VCCB 6
DIR 5
B4
U3 SN74LVC1T45DCK
GND
3V3_USB VCIO
DIR LOW Direction B->A
DIR HIGH, Direction A->B
TXD
RXD
N/A
13
Y1 12MHZ
GND
GND
C1 10pF
C2 10pF
GND
1
Vout 2
Vin
3
U9 LD1117S33TR
C3
100nF
C4 10uF
VPLL VPHY
GND GND
V_CORE
Place close to
VREGOUT pin
3V3_USB
GND
GND
FT2232H->Micro
Micro->FT2232H
GND
3V3_USB
3V3_USB VCIO
3V3_USB
3V3_USB
3V3_USB
3V3_USB
3V3_USB
74279267
LED_232_RX
LED_232_TX
1 2
D4
LED GREEN
1 2
D5
LED GREEN
R17
220
R18
220
3V3_USB
3V3_USB
LED_232_RX
LED_232_TX
C22 100nF
GND
VCIO
C19 100nF
C20
100nF
C18 100nF
GND
3V3_USB RXD
TXD
1 2 3 4
Not Assembled
JP1 4 HEADER
VCIO
GND
I/O1
1
GND
2
I/O2
3I/O2 4
Vbus 5
I/O1 6
U4 USBLC6-2SC6
USB_VCCGND
C84
100nF
USB_VCC
BDBUS4
BDBUS5
BDBUS6
BDBUS7
L1
60ohm-500mA Wurth 74279267
L2
60ohm-500mA Wurth 74279267
USB_VCC
74LVC1T45 Operation
USB <-> Serial communication
USB virtual com port
L4 60ohm-500mA Wurth 74279267
4-pin SMD package, 1/2 means 1/3 in real footprint
2-pin package, 1/2 12MHz crystal
TDI
1GND 2
TDO
3GND 4
TCK
5GND 6
EVTI
7nc 8
RST
9TMS 10
VDD
11 GND 12
RDY
13 JCOMP 14
Not Assembled
J2
JTAG_PPC
GND
10k
R128
GND
C154
20pF
VDD5
TDI_USB TCK_USB VIN TDO_USB SRST#_USB
TMS_USB
TRST#_USB
1 2 3 4 5 6 7 8
16 15 14 13 12 11 10 9
0R
RP1
RESPACK3
VDD5
TMS
TDI TDO
TCK
JCOMP
GND_USB GND
PORST
TDI TDO
TCK
PORST TMS
JCOMP
UM2846
Board schematics
UM2846 - Rev 1 page 15/23

5Board layout
Figure 16. Assembly top
Figure 17. Inner 1
UM2846
Board layout
UM2846 - Rev 1 page 16/23

Figure 18. Inner 2
Figure 19. Assembly bottom
UM2846
Board layout
UM2846 - Rev 1 page 17/23

6Internal and external communication configuration
Figure 20. Internal and external communication configuration
UM2846
Internal and external communication configuration
UM2846 - Rev 1 page 18/23

Revision history
Table 4. Document revision history
Date Version Changes
02-Mar-2021 1 Initial release.
UM2846
UM2846 - Rev 1 page 19/23

Contents
1Hardware description ..............................................................2
1.1 Block diagram .................................................................2
1.2 Featured components...........................................................2
1.3 Board description ..............................................................3
2Jumpers and connectors ..........................................................4
2.1 Mother board jumpers and connectors.............................................4
2.2 Default jumpers setting..........................................................6
2.3 Hot plug protection .............................................................7
3Getting started ....................................................................8
3.1 System requirements ...........................................................8
3.2 EVAL-L9963E-MCU board setup .................................................8
3.2.1 Low voltage power supply..................................................8
3.2.2 L9963E external connection and power supply ..................................9
3.2.3 Transceiver settings ......................................................9
3.2.4 USB to PC connection ...................................................10
3.2.5 Possible connection for battery simulation ....................................10
4Board schematics ................................................................11
5Board layout......................................................................16
6Internal and external communication configuration ...............................18
Revision history .......................................................................19
UM2846
Contents
UM2846 - Rev 1 page 20/23
