Steelcase Elective Elements Blade Accessory Shelf User manual

Page 1 of 3
939568003 Rev A
Elective Elements - Blade Accessory Shelf
If you have a problem, question, or request, call
your local dealer, or Steelcase Line 1 at
888.STEELCASE (888.783.3522)
for immediate action by people who want to help you.
(Outside the U.S.A., Canada, Mexico, Puerto Rico,
and the U.S. Virgin Islands, call: 1.616.247.2500)
Or visit our website: www.steelcase.com
© 2014 Steelcase Inc.
Grand Rapids, MI 49501
U.S.A.
Printed in U.S.A.
ACCESSORY SHELF Phillips with Magnetic Bit
TUBE

Page 2 of 3
939568003 Rev A
1. Carefully turn cabinet over with
bottom side up onto carpet or other
clean, soft material.
2. Attach tube flush with back panel
as shown.
Note: If hutch is two-sided or wall
mounted, center tube side to side.
If hutch is one-sided, attach single
side frame first, then center tube in
remaining space.
TIP: Use a magnetic bit
and find access through
the oval openings.
2
CENTER TUBE SIDE TO SIDE
bBOTTOM PANEL
OF CABINET
a
1
#10-9 x .875" Truss Head Screws
(2 per oval openings)
Refer to assembly direction 939500232 for
information to assemble a one-sided hutch.

Page 3 of 3
939568003 Rev A
3. Position shelf so that sets of (2) holes
in shelf are aligned with holes in frame.
4. Secure with screws provided.
5. Carefully turn assembly over and
place into position.
Note: if the unit will be against a window, you
may want to place felt between the shelf, the
tube, and the cabinet. Felt is not provided
but is available through service parts.
4
TIP: Place a shim under shelf to help
when aligning and securing screws.
3
#10-24 x .750"
Flat Head Screws
(fill all holes)
SIDE VIEW
5
