Steelcase Mitra Reference guide

Customer Service for Drainage Bag, IV Pole & Push Bar
on Mitra®& Mineral™Recliner
If you have a problem, question, or request, call
your local dealer, or Steelcase Line 1 at
888.STEELCASE (888.783.3522)
for immediate action by people who want to help you.
(Outside the U.S.A., Canada, Mexico, Puerto Rico,
and the U.S. Virgin Islands, call: 1.616.247.2500)
Or visit our website: www.steelcase.com
©2014 Steelcase Inc.
Grand Rapids, MI 49501
U.S.A.
Printed in U.S.A.
®
Page 1 of 4
939502116 Rev C
HEX DRIVE
PHILLI PS DRIVE

Page 2 of 4
939502116 Rev C
Drainage Bag Installation
NOTE: You will need to cut holes in the fabric.
We recommend a hole punch tool that is 3/8"
diameter. (McMaster-Carr, Osborne, etc.)
1. Mark the two (2) hole locations as shown.
FOR MINERAL ONLY:
2. Verify location by using a pin, find the
center of the treaded inserts that are
pre-installed in the frame under the fabric at the
two (2) marks made in step 1.
3. Now that you know where the center of the
threaded inserts are, push and rotate the hole
punch tool in the center of the verified hole
location to cut through the fabric down to the
wood. DO NOT DAMAGE WOOD! Remove the
cut piece of fabric.
4. Install drainage bag bracket with two (2) flat
head screws (provided) with phillips
screwdriver.
OR MITRA ONLY:
2. There are no inserts behind the fabric. Push
and rotate the hole punch tool in the center
(same as step 3 above) and remove the cut
piece of fabric. (This is done so the installer will
not stretch the fabric when installing the
screws.)
3. Install drainage bag bracket with two (2) flat
head wood screws (provided) with phillips
screwdriver into the wood side frame.
2
1
3
4
Mitra Recliner MINERAL Recliner
5/8"
1-1/4"
17-1/16"
12-5/16"
PIN
HOLE
PUNCH
TOOL
FLAT HEAD
SCREW
DRAINAGE
BAG BRACKET

Page 3 of 4
939502116 Rev C
IV Pole Installation
NOTE: You will need to cut the holes in the
fabric. We recommend a hole punch tool that is
3/8" diameter. (McMaster-Carr, Osborne, etc.)
1. Mark the two (2) hole locations as shown.
FOR MINERAL ONLY:
2. Verify location by using a pin, find the
center of the treaded inserts that are
pre-installed in the frame under the fabric at the
two (2) marks made in step 1.
3. Now that you know where the center of the
threaded inserts are, push and rotate the hole
punch tool in the center of the verified hole
location to cut through the fabric down to the
steel. Remove the cut piece of fabric.
4. Install IV pole bracket with two (2) pan head
screws (provided) with hex allen wrench.
MITRA ONLY:
2. There are no inserts behind the fabric. Push
and rotate the hole punch tool in the center
(same as step 3 above) and remove the cut
piece of fabric. (This is done so the installer will
not stretch the fabric when installing the
screws.)
3. Install IV pole bracket with two (2) flat head
wood screws (provided) with phillips
screwdriver into the wood side frame.
3-1/2” 1-3/8”
5-5/8” 5-5/8”
2
1
3
4
Mitra Recliner Mineral Recliner
(Back View)
3-11/16” 4-1/2”
PIN
HOLE
PUNCH
TOOL
IV POLE
BRACKET
PAN HEAD
SCREW

Page 4 of 4
939502116 Rev C
Push Bar Installation
NOTE: You will need to cut the holes in the fabric. We
recommend a hole punch tool that is 3/8" diameter.
(McMaster-Carr, Osborne, etc.)
1. Mark the two (2) hole locations as shown.
2. Verify location by using a pin, find the center of
the treaded inserts that are pre-installed in the frame
under the fabric at the two (2) marks made in step 1.
3. Now that you know where the center of the
threaded inserts are, push and rotate the hole punch
tool in the center of the verified hole location to cut
through the fabric down to the steel. Remove the cut
piece of fabric.
4. Install the screws, lock washers, collars &
washers with an allen wrench as shown.
5. Place the push bar over the
collar/washer assembly and install
the set screws as shown.
PIN
HOLE
PUNCH
TOOL
1
20-1/4"
6”
2
3
4
5
LOCK WASHER
SCREW
COLLAR
WASHER
Mitra Recliner
(Back View)
Mineral Recliner
(Back View)
1-1/2”
6”
1-1/2”
20-1/4”
