Steelcase Tableau-Run-offs Firmware update

Steelcase,Inc.
GrandRapids,MI49501
U.S.A.
1-888-783-3522
Y9501889
Page1of15
Tools
REV B
24”x90”credenza
with30”x60”run-off
(beginonpage2)
24”x90”credenza
with36”x72”run-off
(beginonpage6)

1.
2.
Placesteelsupportmendingplate
underneathexistingunit.
Securetheplatetotheexistingunitby
usingeight(8)#8panheadwoodscrews
1”long.
Attachinga30”run-offtoanexistingunit
Y9501889
Page2of15
7-13/16”
(198mm)
TopView
2-5/8”
(67mm)
20”
(508mm)
Steelcase

3.Leveltheglidesontheexistingunitand
therun-offtomakesurebothunitsare
alignedproperly.Toaccessglides,
removedrawers.
Page3of15Y9501889
GLIDE
RAISE
4.Installfastenersin
orientationshown.
KNEEWELL
Steelcase

5.Slidetherun-offsoitisflushwiththeexistingunit(Fig.1).Makesuretheisrestingupon
thesteelmendingbracketalreadyinstalledontheexistingunit(Fig.2).
Attachmentscrewsatmodestypanelarenotrequiredwhenunitfitsuptoapower
pedestal.
run-off
NOTE:
Fig.1Fig.2
Page4of15Y9501889
6.Nowlocatethefastenersinstalledinstep4,onpage3.Therearetwo(2)screwdowels
locatedontheendofthemodestypanel.Thesemustfitintothefastenerswhichare
locatedontheendpanel.Oncethedowelsareengagedwiththefasteners,tightenthem
securelybyturningthefittingscrewclockwisewithaPhilipsheadscrewdriver.
MODESTYPANELENDPANEL
DOWEL
MODESTYPANELENDPANEL
FITTING
SCREW
Steelcase

7.Repeattheprocedureasdemonstratedin
step2onpage2,makingsureallscrewsare
securedproperly.
Page5of15Y9501889
Steelcase

1.
2.
Placesteelsupportmendingplate
underneathexistingunit.
Securetheplatetotheexistingunitby
usingapowerdrillandsinkingeight(8)
#8panheadwoodscrews1”long.
Attachinga36”run-offtoanexistingunitusinga6”fillerpanel
Page6of15Y9501889
10”
(254mm)
TopView
2-5/8”
(67mm)
20”
(508mm)
Steelcase

Page7of15Y9501889
4.Attachthree(3)bracketsintopre-locatedholesonmodestypanelusingsix(6)#8panhead
woodscrews1/2”long.Whenattachingwithanendpanel,usetheforwardpositionholes
andusethebackpositionholesforattachingtoapedestal.
NOTE:
Attachingto
Endpanel
(forwardposition
gotopage8)
Attachingto
Pedestal
(backposition
gotopage12)
3.Leveltheglidesontheexistingunitand
therun-offtomakesurebothunitsare
alignedproperly.Toaccessglides,
removedrawers.
GLIDE
RAISE
Steelcase

1.Slidefillerpanelsoitisflushtothemodestypanel(fig.1)tforwardsoitisflush
againstthebracketsonthemodestypanelandflushwiththemodestypanelbottomedge(fig.2).
henslide
Page8of15Y9501889
Attachingfillerpaneltoaunitcontaininganendpanel
Fig.1Fig.2
Steelcase

Page9of15Y9501889
2.Toattachfillerpaneltomodestypanelusesix(6)
#8panheadwoodscrews1/2”long.
3.Attachthree(3)bracketsontotheendpanel
endpanelusingsix(6)#8panheadcrews1/2”
long.Attachbracketsflushwithfrontedgeof
theendpanelatapproximatelocationshown.
Avoidfastenersinfrontedgeofendpanel.
Steelcase

4.Slidetherun-offsoitisflushwiththeexistingunit(Fig.1).Makesuretheisrestingupon
thesteelmendingbracketalreadyinstalledontheexistingunit(Fig.2).run-off
Fig.1Fig.2
Page10of15Y9501889
5.Toattachfillerpaneltoendpanelusesix(6)
#8panheadwoodscrews1/2”long.
Fig.3
Steelcase

6.Securetheplatetotherun-offbyusingeight
(8)#8panheadwoodscrews1”long.
Page11of15Y9501889
5a.Belowisatopviewofwhatthecorrectassemblyshouldlooklikeforinstallationofafiller
paneltoaunitwithanendpanel.
ForwardPosition
FillerPanel
ModestyPanel
EndPanel
Steelcase

1.Slidefillerpanelsoitisflushtothemodestypanel(fig.1).Thenslideforwardsoitisflush
againstthebracketsonthemodestypanelandflushwiththemodestypanelbottomedge(fig.2).
Page12of15Y9501889
Attachingfillerpaneltoaunitcontainingapedestal
Fig.1Fig.2
Steelcase

Page13of15Y9501889
2.Toattachfillerpaneltomodestypanelusesix(6)#8panheadwoodscrews1/2”long.Attach
three(3)bracketsontobacksideoffillerpanel,flushwithoutsideedgeoffillerpanelin
approximatelocationshownusingsix(6)#8panheadwoodscrews1/2”long.When
attachingwithapedestal,usethebackpositionholes.NOTE:
Steelcase
3.Slidetherun-offsoitisflushwiththeexistingunit(Fig.1).Makesuretheisrestingupon
thesteelmendingbracketalreadyinstalledontheexistingunit(Fig.2).run-off
Fig.1Fig.2

Page14of15Y9501889
4.Toattachfillerpaneltopedestalusesix
(6)#8panheadwoodscrews1/2”long.
Ensureunitsarelevelpriorto
securingscrewsinpedestalside.
NOTE:
Steelcase
4a.Belowisatopviewofwhatthecorrectassemblyshouldlooklikeforinstallationofafiller
paneltoaunitwithanpedestal.
BackPosition
FillerPanel
ModestyPanel
Pedestal
1/16"
(1.5mm)

5.Securetheplatetotherun-offbyusingeight
(8)#8panheadwoodscrews1”long.
Page15of15Y9501889
Steelcase
