Swisher PowerBlade PBH-1540 User manual

PBH-1540
Honda Models
350 Foreman 89 & Older
May fit additional models see Master List
Front
Caution: Do not exceed 5 MPH with the blade or it’s brackets installed
Remove the mount plate for trail riding where extra ground clearance is needed
1602 Corporate drive
P.O. Box 67
Warrensburg, MO 64093
1-877-627-5860
13125

12
3
4
5
6
Item # Description Part #
1 Mount Plate Right 10516TK
2 Mount Plate Left 10515TK
3 Lock Washer 10146
4 Bolt M10 X30 10304
5 Clevis Pin 10305
6 Hair Pin #39 NB127
Assembly Instructions
Note. Right and Left direction are from the operator position. The lower skid plate, If so equipped, may need
to be removed. Please retain plate and hardware to be reinstalled if the plate is removed..
1. Remove the Skid Pan bolts and allow it to hang Exposing the bolts to the Foot Rest.
2. Remove the bolts holding the foot rest and place the mounting bracket on the outside of the foot
rest. Install new bolts and lock washers provided . Tighten bolts securely.
3. Repeat with the other side.
4. After both Mounting brackets are installed, replace the skid pan.
5. Tighten the bolts securely
Front of ATV
