SWorkz S35-GT2.2FTE Series User manual

2
INTRODUCTION
The project of GT2.2 Factory Team Edition(FTE) is a special product for SWORKz GT worlds drivers to
compete in the 2023 Australia IFMAR GT World Championships. The target is to be faster, lighter and easier
driving performance.
The Car is designed with high quality aluminum bulk heads that can change diff positions. A Direct
response steering servo savor with a new Ackerman system.
The latest S35-GT2.2 FTE series Lay Down Shock Tower System has a new suspension geometry to lay-
down the shock positions. This is especially designed for high speed on road racing. Specially included
options are the S35-GT2 front upper and lower ultra hard material arms. Also included are the latest S35-
4 rear lower ABS arms (ultra hard material) that improves the GT2.2 FTE's cornering speeds. A longer pipe
holder spring that allows the pipe to sit closer to the body shell.
The 2-speed transmission has also been completely revised on the S35-GT2 platform that significantly
improved compared to its predecessor.
The GT2.2 FTE comes standard with a new SWORKz Tornado GT 4-Shoes Clutch and Tornado GT 4-Shoes
Aluminum Clutch Bell to get the maximum power from the engine to the transmission.
The S35-GT2 has a weight-optimized, hard anodized base chassis plate made of high-strength T7075
aluminum.
The HET di󰀨erentials developed by SWORKz are also included with 13T pinion and 45T crowns in the kit.
The wishbone brackets, included with square inserts, allow the axle geometry of your SWORKz S35-
GT2 to be adapted to any track layout. The front and rear CVD wishbones are made of a newly developed
composite material. The side pans have also been redesigned.
The SWORKz S35-GT2.2 FTE has completely new rear knuckles made from composite materials combined
with carbon plates that o󰀨ers you the possibility for di󰀨erent setups.
There are many other changes and new ideas that were incorporated into the SWORKz S35-GT2.2 FTE that
makes this car a real winner.
When designing the vehicle, the SWORKz development team focused on using materials that meet the
highest quality standards. The S35-GT2.2 FTE kit is 100% SWORKz quality.
Congratulations on purchasing the new SWORKz S35-GT2.2 FTE Pro kit and thank you for your trust in
SWORKz.
Please read these assembly instructions carefully before you start building and operating your SWORKz
S35-GT2.2 FTE. These assembly instructions contain step-by-step instructions with which you can nish,
prepare and optimize your car for racing. Updates, setups and new products are published on digital
SWORKz media.
As always, if you have any questions about your SWORKz products or you need help, please contact our
o󰀩cial SWORKz dealers and distributors.
S35-GT2.2 FTE Kit Features:
• New Weight-optimized, Hard anodized T7075 base chassis plate
• New Front & Rear Shock Pro-composite Carbon Shock Towers
• New Aluminum Shock End Extension Holders
• Shock End Extension Holders with Pin-Screws
• New Front and Rear Adjustable Di󰀨 Position Design
• New Aluminum Front & Rear Di󰀨 Case Design
• New Aluminum Di󰀨. Case Inserts
• New Aluminum Lower Arm Plates
• New Aluminum Front Upper Arm Holder
• New Front & Rear Aluminum Chassis Brace
• New Aluminum Ackerman Steering Plate
• New Aluminum Servo Savor Steering System
• New Steering Ball Studs
• New Steering Knuckle Plates
• Comes standard with Ultra Hard Arms Front & Rear
• Comes standard with Ultra Hard Upper Arms Front
• Multi-adjustable Sway Bar Linkage System for Front & Rear
• Comes standard with HET Over Drive Gears (45T/13T)
• 2 Front Chassis Struts
• More balance weight positions
• Optimized composite T7075 aluminum parts
• Comes standard with Hard Material Center Spur Gears (58/62T)(Made in Italy)
• New Tornado GT 4-Shoes Clutch Kit
• New Tornado GT 4-Shoes Aluminum Clutch Bell

3
WARRANTY
Your SWORKz S35-GT2.2 FTE Pro kit warranty covers workmanship and
manufacturing defects of the original and unmodified parts. Warranty claims
resulting from crashes, abuse, improper operation, improper mounting, improper
adjustment or lack of maintenance will not be honored.
Contact your local hobby shop or SWORKz distributor for all claims and
questions. Claims must be well documented. All Claims are subject to expert
examination approval by SWORKz.
Specification
Length: 500mm
Width: 308mm
Height: 145mm
Ground Clearance: 15mm
Wheelbase: 325-330mm
Track: F:306mm / R:308mm
Gear Ratio: C:58/62,19/24T, F/R 45/13T
Weight: Kit weight 3088g
(Full equipment with fuel, without Tires and Body Shell)

4
INDEX
This radio controlled racing car is not a toy!
This high-performance R/C model is recommended for ages 14 and older.
Instruction 2
Warranty 3
Index 4
Required equipment for operation 5
Operation guide 6
Assembly steps 7-36
Blank set-up sheet 37-38
Race Report 39
S35-GT2.2 FTE Key No. List 40-41
S35-GT2.2 FTE Spare Part List 41-42
S35-GT2.2 FTE Option Part List 43
End cover 44

5
Starter box
Engine Starting Equipment
Glow Plug
Double-sided tape
Paint
Long nose pliers
Modeling knife
Instant cement Thread lock
Included items
Hex wrench
1.5mm
2mm
2.5mm
Fuel bottle
Glow plug wrench
Radio Gear Nitro fuel
Stick Type
Throttle servo
Receiver batteries
Wheel & Trigger Type
Receiver
On/Off Switch
We recommend that you use on-road fuel
containing 16~25% nitro.
Steering servo
Tools Recommended
Engine Recommended
Side cutter
Curved scissors
Grease
SPower GT Conical
Exhaust Manifold
(Made in Italy)
SP80212HP
Spower Japan R7GT
SOUL Factory
Hand-Made Modified
.21 Racing Engine
(Pre-Break-in)
SP80115C
Spower Japan MR I EFRA 2165
Tuned Pipe Combo Set with
Conical Exhaust Manifold
SP80116C
Spower Hipex EFRA 2115 Tuned
Pipe Combo Set with Conical
Exhaust Manifold (Made in Italy)
SW-620020-15 SWORKz SST-Pro 1.5mm HEX Wrench
SW-620020-20 SWORKz SST-Pro 2.0mm HEX Wrench
SW-620020-25 SWORKz SST-Pro 2.5mm HEX Wrench
SW-620025SWORKz SST-Pro Shorty 7.0mm Socket Driver
SW-620026SWORKz SST-Pro Shorty 5.5mm Socket Driver
SP-80603
S-POWER ST-7 Turbo Plug
(Medium)(Made in Japan)
SP-80602
Spower ST-6 Turbo Plug
(Hot)(Made in Japan)
Required Equipment for Operation

6
overturn
Assemble for
4 sets
Assemble for
2 sets
Assemble both left
and right sides
Assemble in the
specied order
Assemble front
and rear
Thread Locking
Compound
Grease Pure Silicone Oil Air lter oil
Operation Guide
Safety Precautions
The SWORKz S35-GT2.2 FTE is a high performance radio control model which needs to be
operated with caution and common sense.
The S35-GT2.2 FTE Pro Kit is not intended for children under the age of 14 without adult
supervision. SWORKz shall not be held liable for any loss or damages, whether direct,
indirect, act of nature, arising from the abuse or misuse of this product or any other product
required while operating this model.
- The nitro fuel can be dangerous is improperly handled.
- Always keep your nitro fuel in a cool area and never use near flame, sparks, or while
smoking.
- Keep your nitro fuel, and all other ammables, out of the reach of children.
- Always run your model in a well ventilated area outdoors. Never run your model indoors.
- After running your car, all parts of the engine and exhaust can become extremely hot. Be
careful not to touch these parts especially when refueling, or making repairs.
- This model is controlled by your radio controller and is sometimes vulnerable to interference
from many outside sources. This interference can cause a loss of control so it is necessary to
operate this model in an open area to avoid personal, or property damage. Always ensure
turning on your radio rst.
- Keep all the parts included in the package out of reach of children.
- This model contains many fast rotating parts. Never touch them during operation.
- Follow the instructions included with your radio gear.
- Never operate your model near people or property. The speed of this model has the
potential to injure and or damage people and or property.
- Always use original SWORKz spare parts and option parts.
