TCS AMI Series User manual

TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax:[phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
Product information
Modules of the series AMI
in front-door stations
for flush-mount kits ZAU200x and communication posts K3xxxx

2 01/2013
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
Table of contents
Scope of delivery...............................................................................................................3
Flush-mount kit ZAU200x.................................................................................................3
Communication post K3xxxx............................................................................................3
Safety instructions.............................................................................................................4
General safety regulations ...............................................................................................4
Installation –protective measures....................................................................................4
Intended use.......................................................................................................................4
Flush-mount kit.................................................................................................................4
Communication posts.......................................................................................................4
Endangering when used intended....................................................................................4
Module descriptions..........................................................................................................5
Installation positions for modules in a front-door station...................................................5
Technical data....................................................................................................................6
Modules (except display module).....................................................................................6
Flush-mount kits ZAU200x...............................................................................................6
Communication post K3xxxx............................................................................................7
Install the modules ............................................................................................................8
Installe modules into the front panel (standard) ...............................................................8
Installe modules into the front panel (special design).......................................................9
Installation flush-mount kit ZAU200x...............................................................................9
Installation flush-mount box..............................................................................................9
Installation of the front-door station (front panel)............................................................10
Installation communication post K3xxxx ......................................................................10
Fix the post on the ground..............................................................................................10
… with heavy-duty anchor..........................................................................................11
… with ground anchor.................................................................................................11
Dismount the post roof...................................................................................................11
Open the post.................................................................................................................11
Dismount / installe the front panel..................................................................................12
Connect the post............................................................................................................13
Connect the post............................................................................................................13
Close the post roof.........................................................................................................13
Connect the lines.............................................................................................................14
Commissioning................................................................................................................14
Note for the connexion of more than one front-door station...........................................14
General information on the conduit in TCS systems....................................................15
TCS audio systems........................................................................................................15
Principle loop resistance.............................................................................................15
Measurement loop resistance.....................................................................................15
TCS video systems ........................................................................................................16
6-wire operation..........................................................................................................16
Optional accessory..........................................................................................................17
Cleaning............................................................................................................................18
Conformity........................................................................................................................19
Information on disposal..................................................................................................19
Warranty...........................................................................................................................19
Notizen..............................................................................................................................19
Service..............................................................................................................................20

01/2013 3
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
Scope of delivery
Product information Modules of the series AMI in front-door stations
Flush-mount kit ZAU200x
1x front panel incl. flush-mount box
1 x front panel sealing 3 x 9 mm with assembly instruction
1 x allen key 2.5
4 / 6 / 8 x countersunk screw (= number of drill holes) with hexagon socket and Pin, DIN
7991
Communication post K3xxxx
1 x communication post
4 x heavy duty anchor W-TM M10,
4 x cylinder screw with hexagon socket DIN 912 M10x75
1 x gripper ISO clip (pluggable top)
1 x key for hexagon socket screws DIN 911, SW 2.5
1 x screwdriver with round-handle

4 01/2013
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
Safety instructions
General safety regulations
!
Attention! Mounting, installation, commissioning and repair of electronic devices have
to be carried out only by qualified electricians. Thus, the current standards for the in-
stallation of door communication systems must be observed.
When working in systems with 230 V mains voltage, the safety regulations according to
DIN VDE 0100 must be observed.
When installing TCS:BUS®systems, the general safety regulations for telecommunication
systems according to VDE 0800 must be observed. Inter alia:
separated cabling of heavy and low current lines,
minimum distance of 10 cm for common cabling,
use of separators between heavy and low current lines in shared cable ducts,
use of standard telecommunication lines, e.g. J-Y (St) Y with 0.8 mm diameter,
existing lines (modernisation) with deviating cross sections can be used in compliance
with the loop resistance.
Installation –protective measures
!
With suitable requirements to protect against lightning, it has to be ensured that a volt-
age of each 32 V DC is not to be exceeded at the connections a, b, P, R, S, V1, V2.
All front-door stations and modules are permitted for safety extra low voltage (SELV)
and protective extra low voltage (PELV) only.
Intended use
Front-door stations of the series AMI can be assembled individually with functional mod-
ules. The modules have to be used in combincation with a flush-mount kit (ZAU200x) or a
communication post (K3xxxx).
Other forms of installation must meet protection class IP44 at least.
Flush-mount kit
Modular front-door stations of the series AMI are front panels with flush-mount box.
Communication posts
The communication posts are stand-alone front-door stations constructed as posts.
The posts are suitable for a vertical installation outdoors and need to be installed on even,
massive ground (e.g. concrete)
Possible hazards when using the device
The operating elements of the modules in the front-door stations can get very hot when
placed in direct solar radiation (more than +50 °C). If possible, avoid direct solar radiation
when selecting the mounting site.

01/2013 5
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
Module descriptions
Installation positions for modules in a front-door station
Please find further information on each module in the product datasheet Modules of the
series AMI on the internet under Product planning.
Functional group with display module
when arranged vertically …
AMI10200
loudspeaker module
…the modules will be combined as follows:
Loudspeaker module (above)
Display module (below resp. next to the loudspeaker
module)
Keypad or jogwheel module (below resp. next to the
display module)
AMI10100
display module LCD graphic, 100
flats
AMI10103
display module LCD graphic, 200
flats
AMI10105
display module LCD graphic, 1000
flats
AMI10300
keypad module
AMI10400
jogwheel module
Functional group with built-in door loud-
speaker
when arranged vertically …
AMI11100
built-in door loudspeaker module
above the bell button module
AMI10901
bell button module, 1 button
below resp. next to the built-in door loudspeaker, jog-
wheel, keypad and display module
AMI10902
bell button module, 2 buttons
AMI10903
bell button module, 3 buttons
AMI10904
bell button module, 4 buttons
Access control
when arranged vertically …
AMI11200
code lock module
below keypad, jogwheel, bell button and
illumination module or as stand alone device
AMI12300
transponder reader module
AMI10800
fingerprint scanner module *
Additional modules
when arranged vertically …
AMI11000
blind module
installation as placeholder, reserve
AMI10500
camera module *
above loudspeaker, built-in door loudspeaker module
and below the information module
AMI10600
dome camera module
AMI11300
information module
always arranged on top
AMI11400
illumination module
above keypad, jogwheel, codelock and
transponder reader module
AMI10700
key switch module
always aranged below
*Note:
Recommended mounting height fingerprint scanner: at least 1.30 m.
Recommended mounting height camera: 1.60 m.

6 01/2013
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
!
Subject to technical changes! The here mentioned module arrangements are a rec-
ommendation of the TCS TürControlSysteme AG and are to guarantee the function-
ality of the modules. When of an individual arrangement of the modules is required,
cable lengths have to be considered which may be customised items.
We recommend to arrange the modules in the same order horizontally as vertically.
The positioning of the modules can be started from both sides.
Technical data
Modules (except display module)
dimensions, visible front panel
H x W
82 x 82 mm
module grid spacing
120 mm
degree of protection at the front
panel when modules are in-
stalled correctly
at least IP44
Flush-mount kit ZAU200x
supply voltage
+24 V ±8 % (power supply and control unit)
front panel
flush-mount box
stainless steel, grinded
steel, zink-coated
dimension
and
weight
article
front panel
flush-mount
box
weight
H x W x D in mm
H x W x D in mm
In total in g
ZAU2001-0030
200 x 200 x 3
180 x 180 x 50
1400
ZAU2002-0030
320 x 200 x 3
300 x 180 x 50
2090
ZAU2003-0030
440 x 200 x 3
420 x 180 x 50
2780
ZAU2004-0030
560 x 200 x 3
540 x 180 x 50
3480
ZAU2005-0030
680 x 200 x 3
660 x 180 x 50
4160
ZAU2006-0030
800 x 200 x 3
780 x 180 x 50
4860
ZAU2007-0030
320 x 320 x 3
300 x 300 x 50
3110
ZAU2008-0030
440 x 320 x 3
420 x 300 x 50
4090
audio system: 3-wire technique necessary!
video system: 6-wire technique necessary!

01/2013 7
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
Overview
Communication post K3xxxx
supply voltage
+24 V ±8 % (power supply and control unit)
housing
front panel
aluminium profile, powder-coated, micaceous iron ore
dark grey
aluminium, anodised nature
H x W x D
1700 x 225 x 225 mm
optionally H = 1300 or 2600 mm
(customised item on request)
empty weight
13 kg
audio system: 3-wire technique necessary!
video system: 6-wire technique necessary!
Short description
Communication posts K31xxx to K36xxx are realised with a standard height of 1700 mm.
They can be assembled with a maximum of 6 functional modules of the series AMI.
grinding
direction

8 01/2013
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
Overview
8 mm
1700 mm
30 mm
172 mm
192 mm
□226 mm
Installation of the modules
Installation of the modules into the front panel (standard)
The modules are suited for the installation into the front panels of the flush-mount kits
ZAU200x and K3xxxx with a thickness of 3 mm.
front panel post
front panel ZAU
Put the module unit (1) with front
panel sealing (2) from behind on-
to the welded bolts at the front
panel.
Fix the module unit with 4 fas-
tening screws (3) (enclosed in the
delivery).
Recommendation:
Wire the modules (see product in-
formation of the specific module),
beforeinstalling the front panel into
the post or the flush-mount kit.
post cover, top view
ground plate, from
below
weldet bolt M4
front panel
1
2
3

01/2013 9
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
!
Installation display module AMI1010x see product information Functional group with
display module > installation, page 8.
Installation of the modules into the front panel (special design)
When using a thinner front panel (1.5 to 2.5 mm) the thickness must be increased to 3 mm
spacer (enclosed in the delivery when modules are ordered individually).
Put 1 to 3 spacer foils (2) from
behind on the front panel onto the
welded bolts (1).
Put on the module unit (4) with the
front panel sealing (3).
Fix the module unit with 4 fas-
tening screws (5) (enclosed in the
delivery).
Installation flush-mount kit ZAU200x
Installation flush-mount box
rear view
Loosen the lock screws with the enclosed al-
len key and remove the front panel from the
flush-mount box.
Insert the supply cable through the cable
gland into the flush-mount box and fasten it.
Insert the flush-mount box into the prepared
wall niche.
Note: The flush-mount box must be flush with
the wall of the house.
!
Not enclosed: Screws and dowels to fix
the post in the wall niche.
cable gland
1
2
3
5
4
drilling for
lock screws

10 01/2013
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
Installation of the front-door station (front panel)
rear view
Cut the enclosed front panel sealing for the
front-door station to length: first cut the up-
per, then the stripes for the sides.
Stick the cutted front panel sealing with small
distance to the outer edge onto the front
panel.
!
The lower side stays free and prevents
water from condensing within the system!
Screw the front panel with lock screws using
the allen key onto the flush-mount box.
Thus, the front panel sealing is compressed
and provides an adequate sealing against ex-
ternal influences.
Installation communication post K3xxxx
The installation is realised on a concrete foundation (or ground anchor) provided by cus-
tomer with heavy-duty anchors (enclosed in the delivery).
!
Please ensure that there is free space for the installation at the backside of the com-
munication post on the installation site.
We recommend to provide a cable length of 1 m on site.
Fix the post to the ground
!
Ensure that a line is available to the functional earth.
front panel sealing
countersunk screw

01/2013 11
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
… with heavy-duty anchor
… with ground anchor
Use the base plate of the post as stencil to
mark the drill holes.
Drill and clean drill holes.
Drive the heavy-duty anchor flush into the foun-
dation.
Insert the connection cable provided by cus-
tomer as well as the earthing through the base
plate of the post.
Concrete the ground anchor vertically in
the ground, concrete height 20 mm below
the upper edge of the ground anchor.
Remove the protection caps.
Insert the connection cable provided by
customer as well as the earthing through
the ground anchor and the base plate of
the post.
Fix the base plate with 4 cheese-head screws with a key for hexagon socket screws 8 mm (not
enclosed in the delivery / length of the screws see the illustration above).
!
Ensure that the connection cable provided by customer is not clamped or damaged!
Dismount the post roof
Loosen and remove the 4 countersunk
screws in the post roof with the en-
closed allen key.
Remove the roof of the post.
Put down the roof on clean ground.
Open the post
profile
Loosen the two knurled screws which are lo-
cated on top in the inside of the post corpus.
Push out the upper back panel.
countersunk screw
post roof
upper back panel
knurled screw
cheese-head
screws M10x75
base plate
post corpus
heavy-duty anchor
ground anchor
cheese-head screws
M10x30
(encluded in the
delivery ground
anchor)
20 mm distance
concrete height

12 01/2013
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
profile
Loosen the two knurled screws which are lo-
cated at the inside of the post corpus, directly
above the hollow wall boxes.
Push out the lower back panel.
Dismount / install the front panel
Screw off the knurled nuts and knurled screws
with spacer bolts (location of the modules).
Remove the front panel of the post corpus to
install the modules.
!
In the middle part of the front panel of a post
with up to 3 modules, there are 2 knurled
screws with spacer bolts, and in case of 4, 5
or 6 modules 4 knurled screws with spacer
bolts which needs to be loosened / tight-
ened.
For the installation of modules into the front
panel see Installation of the modules into the
front panel (standard), page 8.
Put on the front panel with the assembled
modules onto the post corpus and fix it again
from the inside using the knurled nuts and
knurled screws with spacer bolts.
knurled screw
lower back panel
hollow wall box
knurled nut
front panel
knurled screw with
spacer bolt

01/2013 13
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
Connect the post
Back view
Break out an opening in one of the
hollow wall boxes for the supply
cable.
Guide the supply cable through the
opening to the connection termi-
nals and fix it with the pluggable
top part of the grippe-Iso-clip
(encluded in the delivery).
Connect the wires to the connec-
tion terminals according to the type
label.
Connect the provided to the con-
nection terminal functional earth.
Close the post
See also Open the post, page 11.
Put the rear back panel into the post profile, align it and fix it with both knurled screws from the
inside.
Put the upper back panel into the post profile, align it and fix it the same way.
Close the post roof
Put the roof of the post with the
rounded part forward on the post
corpus.
Fix the roof of the post with the 4
countersunk screws and rubber
rings using the allen key.
hollow wall box
gripper-Iso-clip,
lower part
connection
terminals
supply cable
earth clamp
countersunk screw
post roof
rubber ring

14 01/2013
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
Connect the lines
!
All modules are permitted exclusivley for safety extra low voltage (SELV) and protec-
tive extra low voltage (PELV).
Commissioning
First install the system completely, than connect it to voltage!
Check the a-, b- and P-wire against each other for short-circuits.
Switch on the power supply.
Note on the connection of more than one front-door station
In a system with a voltage supply realized by a single DC power supply NGV1011-0400,
max. 5 front-door stations with display modules can be connected.
If a front-door stations with modules is operated parallel to other front-door stations with
modules, their AS-addresses must be fix.
The setting can only be realised with the Service Device TCSK-01 or the configuration
software configoTM.
Setting the AS-address of a front-door station when using a display module is realised
with a PS/2 keypad via the menu navigation, with the Service Device TCSK-01 or the
software ADx-configurator.

01/2013 15
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
General information on the conduit in TCS systems
TCS audio systems
The conduit of the lines is determined by structural conditions and is only limited by its
length.
Observe when selecting the cable length:
the loop resistance must not exceed 20 Ω(table)
To keep the max. permitted loop resistance, the
wire cross section can be doubled, that means,
that for one wire two cables are used (illustra-
tion). The lines have to be twisted.
When using shielded cables:
Connect the shielding with each other and put it
on mass (b-wire) on one side at the power sup-
ply.
Optional strand or star shaped wiring.
Table: loop resistances
Line length in m
Line diameter
0.6 mm
0.8 mm
Loop resistance in Ω
10
1.28
0.71
20
2.55
1.43
30
3.83
2.14
40
5.10
2.86
50
6.38
3.57
60
7.65
4.29
70
8.93
5.00
80
10.20
5.71
90
11.48
6.43
100
12.76
7.14
150
19.13
10.71
200
25.51
14.29
250
17.86
300
21.43
Principle loop resistance
Measurement loop resistance
None of the devices (front-door station, indoor
station or extended function) should be further
than 20 Ohm away from the power supply and
control unit!
Procedure for measurement:
Switch off the 230 V / 50 Hz power supply and
control unit.
Install a/b short circuit at the power supply and
control unit.
Other devices are not disturbing the measure-
ment and can stay connected.
Measure the resistance at the strand at a/b of the
last indoor or front-door station.

16 01/2013
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
Rule for 20 Ohm:
Distance from TCS:BUS® power supply to the most
distant front-door or indoor station:
at 0.6 mm wire diameter max. 160 m,
at 0.8 mm wire diameter max. 280 m
TCS video systems
6-wire operation
The 6-wire operation is standard operation mode. Video operation, where two separated
masses (b and M) are used.
The conduit of the lines is determined by structural conditions and is only limited by its
length.
Observe when selecting the cable length:
the loop resistance must not exceed 8 Ω at a-b and M-P (table 1).
In case of loop resistance > 8 Ω: plan mulitple wiring of the strands (double twisted
lines).
Optional strand or star shaped wiring.
Do not use more than 20 video indoor stations per strand. For systems with more video
indoor stations you have to provide video distributors (FVY1200, FVY1400).
Up to 64 front-door stations (16 of them video front-door stations) and almost an unlim-
ited number of indoor stations can be connected within one system polarity-free (a/b |
polarity-free only in 6-wire operation). Thus, a suitable power supply and control unit is
to be selected.
Table 1: loop resistances
Line length a-b/ M-P
in m
Line diameter
0.6 mm
0.8 mm
Loop resistance in Ω
10
1.28
0.71
20
2.55
1.43
30
3.83
2.14
40
5.10
2.86
50
6.38
3.57
60
7.65
4.29
70
5.00
80
5.71
90
6.43
100
7.14

01/2013 17
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
Principle loop resistance
Measurement loop resistance
None of the devices (front-door station, indoor station
or extended function) should be further than 8 Ohm
away from the power supply and control unit!
Procedure for measuring:
Switch off the 230 V / 50 Hz of the power supply
and control unit.
Install a/b short-circuit at the power supply and
control unit.
Other devices are not disturbing the measure-
ment and can stay connected.
Measure the resistance at a/b at the strand of the
last indoor or front-door station. Remove the
short-circuit.
To measure the loop resistance at P/M proceed
in the same way as for a/b.
Rule for 8 Ohm:
Distance from TCS:BUS® power supply to the most
distant front-door or indoor station:
at 0.6 mm wire diameter max. 65 m,
at 0.8 mm wire diameter max. 115 m
Optional accessory
Short text
Article number
name field foil
on request
colored foil red, green, blue, orange
on request
cleaning cloth for stainless steel
on request
ZAB ground anchor K3 post
ZAB3001-0002
If necessary, you can order accessory by calling the TCS Hotline under +49 (0) 4194 / 9881188 or by mailing
to [email protected]

18 01/2013
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
Cleaning
The material of your front-door station needs regular maintenance to preserve the surfac-
es.
!
To clean the device use a slightly wet microfibre cloth.
Remove stronger stains with a mild household cleaner and warm water.
Do not use any abrasive detergents!
When using standard stainless steel cleaner, please observe the instructions for
use carefully.
Acrylic
glass
To preserve the dust-resistant effect for a long time, we recommend
to clean the plastics with an antistatic plastic cleaner.
Aluminium
The anodised surfaces can be cleaned with light detergents.
The surfaces have a self-cleaning effect in their texture.
Stainless
steel
Especially fingerprints and grease residues can react aggressively on sur-
faces of stainless steel.
Regular maintenance preserves the look of your front-door station and
makes the repeated cleaning of the surface easier.
polished surfaces
In case of polished surfaces, cleaning prod-
ucts such as scouring milk, steel wool or simi-
lar products with grinding particles must NOT
be used.
grinded / brushed
surfaces
In case of grinded or brushed surfaces, the
cleaning should always be carried out in grind-
ing resp. brushing direction to preserve the
optical grinding pattern.
After the cleaning, the stainless steel surfaces
should always be rubbed dry to remove water
spots or residues from cleaning detergents.

01/2013 19
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
Conformity
The declarations of conformity are available under www.tcsag.de > Downloads >
trade information.
Information on disposal
The adjoining symbol shows, that the device has to be disposed separately from
domestic waste. The materials used are recyclable. Please do help protecting our
environment and dispose the device via a collection point for electronic scrap.
Dispose the parts of the packaging in collecting tanks for cardboard and paper
resp. plastics.
Warranty
We offer a simplified processing in case of warranty for electricians.
Please note our conditions of sale and delivery, download from
www.tcsag.de > Downloads > trade information.
Notes

20 01/2013
TCS TürControlSysteme AG, TCS Hotline Germany: [e-mail] Subject to technical changes.
Fax: [phone] / 9 88 129 www.tcsag.de PI_AMI1xx00_uk
Service
Please send your questions and inquiries to
[email protected]
Headquarters
TCS TürControlSysteme AG
Geschwister-Scholl-Str. 7, D-39307 Genthin, Germany
Phone [phone], Fax [phone], Mail [e-mail], www.tcsag.de
