Product information
Comfort indoor station
for hands-free talking
ISW3130

2 07/2015
TCS TürControlSysteme AG Subject to technical changes.
E-Mail: [e-mail] • www.tcsag.de PI_ISW3130-uk 2 A
Table of contents
Scope of delivery...............................................................................................................3
Safety instructions.............................................................................................................3
Installation –protective measures....................................................................................3
Intended use.......................................................................................................................3
Max. number of ISW3130 in 2-wire operation..................................................................3
Max. number of ISW3130 in 3-wire operation..................................................................4
Indication and operating elements...................................................................................4
Device overview.................................................................................................................5
Technical data....................................................................................................................5
Short description...............................................................................................................6
Installation..........................................................................................................................6
Mounting site....................................................................................................................6
Install the lower cover.......................................................................................................6
Connect the lines (2-wire technique)................................................................................7
Snap-on the upper cover..................................................................................................7
Open the device...............................................................................................................7
Installation of extended functions.....................................................................................8
Connect the lines...............................................................................................................8
Connection lines...............................................................................................................8
Wiring example.................................................................................................................9
Connection diagram 2-wire technique..............................................................................9
Connection diagram 3-wire technique..............................................................................9
Commissioning................................................................................................................10
Settings.............................................................................................................................10
Preset times...................................................................................................................10
2-wire/3-wire operation...................................................................................................10
Ring tone selection.........................................................................................................11
Adjust the volume...........................................................................................................11
Configuration options .....................................................................................................12
Programming with the Service Device TCSK-01............................................................12
General information on the conduit in TCS audio systems.........................................13
principle loop resistance.............................................................................................13
measurement loop resistance.....................................................................................13
Repair................................................................................................................................14
Error detection and indication.........................................................................................14
Exchange an indoor station –programme bell buttons ..................................................14
Cleaning............................................................................................................................15
Conformity........................................................................................................................16
Information on disposal ..................................................................................................16
Warranty...........................................................................................................................16
Spare parts, accessory....................................................................................................16
Service..............................................................................................................................16

07/2015 3
TCS TürControlSysteme AG Subject to technical changes.
E-Mail: [e-mail] • www.tcsag.de PI_ISW3130-uk 2 A
Scope of delivery
1 x comfort indoor station ISW3130: upper cover, lower cover
product information
instruction manual
Safety instructions
!
Attention! Mounting, installation, commissioning and repair of electronic devices have
to be carried out only by qualified electricians. The current standard for the installation
of door communication systems must be observed!
When installing TCS:BUS systems, the general safety regulations for telecommunication
systems according to VDE 0800 must be observed. Inter alia:
separated cabling of heavy and low current lines,
minimum distance of 10 cm for common cabling,
use of separators between heavy and low current lines in shared cable ducts,
use of standard telecommunication lines, e.g. J-Y (St) Y with 0.8 mm diameter,
existing lines (modernisation) with deviating cross sections can be used in compliance
with the loop resistance.
Installation –protective measures
!
With suitable requirements to protect against lightning, it hast to be ensured that a
voltage of 32 V DC is not be exceeded at the connections a, b, P, E.
Intended use
ISW3130 are indoor stations for hands-free talking for the object area.
They are suitable for the operation in TCS audio systems and combined audio / video
systems.
They are suitable for surface-mount (installation via flush-mounted socket) or desktop
mounting with desktop accessory ZIT3030-0010.
Max. number of ISW3130 in 2-wire operation
when using power supply
and control unit
max. number
ISW3130
BVS20 or
NBV1000, 1 line
20
BVS100,
distributed to 3 lines
80
VBVS05, 1 line
30

4 07/2015
TCS TürControlSysteme AG Subject to technical changes.
E-Mail: [e-mail] • www.tcsag.de PI_ISW3130-uk 2 A
Max. number of ISW3130 in 3-wire operation
when using power supply
and control unit
Max. number
ISW3130
BVS20 or
NBV1000, 1 line
20
BVS100,
distributed to 3 lines
80
VBVS05, 1 line
90
BVS20 + NGV1011,
1 line
90
AS front-door station
VS power supply and control unit
IS indoor station
Note: The number of the front-door stations which can
be connected is limited. Details are described in their
product information!
BVS100 + NGV1011,
3 lines
270
Indication and operating elements
speech button
call acceptance, activate speaking,
manually controlled duplex communication
end conversation
call OFF button
press short: ring tone stopper
press for 8 sec: initiate ring tone selection
indicatation call OFF
(red)
ON: call OFF is activated
flashes: ring tone stopper is deactivated, door release
automatic or call diversion is activated
flashes OFF: ring tone stopper is activated, door re-
lease automatic or call diversion is activated
fault indication: both LEDs flashing
ring tone selection: both LEDs are ON
○
function key
control function 8,
alternate allocation can be activated: internal call, door
release automatic, call diversion
ring tone selection internal call
call indication
(green)
ON: call, speaking activated
blinks 3 x: voice channel is busy
fault indication: both LEDs flash
ring tone selection: both LEDs ON
light switch button
switching lights
ring tone selection floor call (from the flat door)
door release button
open the door
to trigger light switch function (if the light switch function
is activated in the front-door station)
ring tone selection door call from front-door station

volume control for
voice output and
ring tone
adjustable in 8 steps:
when voice communication is established
when no voice communication is established

07/2015 5
TCS TürControlSysteme AG Subject to technical changes.
E-Mail: [e-mail] • www.tcsag.de PI_ISW3130-uk 2 A
Device overview
Technical data
supply voltage: +24 V ±8 % (power supply and control unit)
housing: plastics white (colors like shown in price list)
dimensions (in mm): H 180 x W 100 x D 23
weight 185 g
acceptable ambient temperature: -5 ...+40 °C
degree of protection: IP30
input current (stand-by) 2-wire operation: I(a) = 1 mA
3-wire operation: I(a) = 0.2 mA, I(P) = 1 mA
max. input current: I(Pmax) = 75 mA
microphone
call indication (green)
indication call OFF (red)
call OFF button
light button
function key
ring tone
loudspeaker
door release button
volume control
speech button

6 07/2015
TCS TürControlSysteme AG Subject to technical changes.
E-Mail: [e-mail] • www.tcsag.de PI_ISW3130-uk 2 A
Short description
hands-free talking, manually controlled duplex communication can be activated
large, deteched, blue door release button
large speech button
light switch button
function key (fixed assignment with control function 8, alternate allocation can be acti-
vated: internal call, door release automatic, call diversion)
call OFF button for ring tone mute with optical indication
optical indication of door calls by LED (green)
optical display of a business while an established communication by LED (green)
sending the sender serial number in case of internal calls
ring tones can be adjusted by the user, selection of 13 ring tones with improved quality
voice volume and ring tone volume can be adjusted manually
acoustic call distinction between 2 front-door stations (with the configuration software
configo™), flat door (floor door) and internal call
a parallel call can be activated (with the Service Device TCSK-01 or configo™)
audio privacy function and automatic call cut-OFF (after 2 min)
lower cover with plugged pined screw terminal can be pre-installed and can be
equipped alternatively with the door telephone
optical and acoustic fault indication
can be functional extended due to mounting places for call relays, control for radio sig-
nal device
energy-efficient due to low stand-by consumption of only 0.025 W
automatic call acceptance after an internal call can be activated / deactivated
Installation
Mounting site
The indoor station has to be installed in accord-
ance to a minimum distance to walls or other
obstacles:
lateral space 5 cm and below 10 cm.
Install the lower cover
For placing the connection cables without
any problems, a flush-mount socket must be
installed behind the device.
Position the flush-mount socket below the
cable conduit.
Install the lower cover with three screws.
TIPP: Avoid tearing of the straps:
For fixing the scraps do not use counter-head screws
Rather use flat washers!

07/2015 7
TCS TürControlSysteme AG Subject to technical changes.
E-Mail: [e-mail] • www.tcsag.de PI_ISW3130-uk 2 A
Connect the lines (2-wire technique)
Minimize the length of the lines above the
lower cover to place without any problems
and do not clamp when snapping-on the
upper cover.
Connect the lines according to the labeling:
a b E P (from the button to the top), floor
push button at a –E.
Wiring example see page 9.
Snap-on the upper cover
Set on the upper cover at both adjustment
increments of the lower cover (1).
Snap-on the upper cover below with slight
pressure (2)
Open the device
There is a rectangular release opening at
the underside of the device. Insert a small
screwdriver right straight and with slight
pressure into this opening.
The upper cover can be removed at the
underside (1).
Lift the upper cover out of the two upper
adjustment increments (2).
1
2
1
2
floor push button

8 07/2015
TCS TürControlSysteme AG Subject to technical changes.
E-Mail: [e-mail] • www.tcsag.de PI_ISW3130-uk 2 A
Installation of extended functions
TRE1*
radio transmitter board
FFL1000-0
radio interface FBI4200
The extended functions (and the antennas) have to be fixed in the indoor station with
adhesive pads (see also product information of each extended function).
* Connecting the lines is implemented in analog to the ISW3030 (see product information TRE1-EB/1).
Connect the lines
Connection lines
acceptable cross section (diameter)
0.08 … 0.82 mm2(Ø 0.32 … 1.0 mm)
Max. Anzahl Drähte pro Klemmenkontakt
je 2 x 0.8 mm, 3 x 0.6 mm
!
Further wires have to be connected with auxiliar terminals!
!
Use only connecting lines with identical diameter in one terminal contact.

07/2015 9
TCS TürControlSysteme AG Subject to technical changes.
E-Mail: [e-mail] • www.tcsag.de PI_ISW3130-uk 2 A
Wiring example
Connection diagram 2-wire technique
Connection diagram 3-wire technique

10 07/2015
TCS TürControlSysteme AG Subject to technical changes.
E-Mail: [e-mail] • www.tcsag.de PI_ISW3130-uk 2 A
Commissioning
Install the devices of the system voltage-free and completely.
Check the a-, b- and P-wire against each other for short-circuits.
Switch on the main voltage.
Note:
If the floor push button does not work, check if it is connected to the a-wire of the power
supply and control unit.
Settings
Preset times
conversation time
2 min
flashing period of the green LED, if the voice
channel is busy after establishing a voice
communication
2 sec
3 x blinking
internal stand-by time, if the device is calling
or is called
around
30 sec
2-wire/3-wire operation
The jumper J1 is adjusted for 2-wire operation
in delivery state.
2-wire operation (delivery state)
Install the jumper J1 at both upper contacts
for the 3-wire operation.
3-wire operation
J1

07/2015 11
TCS TürControlSysteme AG Subject to technical changes.
E-Mail: [e-mail] • www.tcsag.de PI_ISW3130-uk 2 A
Ring tone selection
For 4 different incoming calls (door calls from 2 different front-door stations, floor call, in-
ternal call) different ring tones can be selected.
1
End voice communication. Press call OFF button for around 8 seconds.
Both LEDs are ON and an acknowledgement tone sounds, the ring tone selection
is activated.
By pressing the following buttons, a ring tone can be selected. You can choose be-
tween 13 different tones.
2a
Select door ring tone
of the front-door
station*
Press the door release button until the required ring tone
sounds. The ring tone selected last is stored.
2b
select door ring tone
of the floor door
Press the light switch button until the required ring tone
sounds. The ring tone selected last is stored.
2c
select internal ring
tone
Press the control key until the required ring tone sounds.
The ring tone selected last is stored.
3
Short press the call OFF button.
Or: If no button is pressed for around 8 sec, the device end the ring tone selection
automatically. Both LEDs go out and an acknowledgement tone sounds, the ring
tone selection is deactivated.
* The ring tone is identical for all front-door stations and can be selected only identically for all.
To select a second ring tone it is necessary to activate the call distinction by changing the audio AS limit.
Changing the audio AS limit is possible only with the configuration software configo™.
Adjust the volume
Adjustable in 8 steps. A signal tone reproduces the adjusted ring tone volume when turn-
ing the ring tone volume control. If the adjustment is finished, the adjusted ring tone
sounds in the adjusted volume.
voice volume
Turn the ring tone volume control when a conversation is estab-
lished (preset ex works: volume step 4 out of 8)
ring tone volume
Turn the ring tone volume control when no conversation is estab-
lished (in stand-by; preset ex works: volume step 6 out of 8)

12 07/2015
TCS TürControlSysteme AG Subject to technical changes.
E-Mail: [e-mail] • www.tcsag.de PI_ISW3130-uk 2 A
Configuration options
function
manually
TCSK-01
configoTM
as of version 1.6.x
ring tone volume
x
–
–
voice volume
x
–
–
select ring tones for door calls,
internal calls and floor calls
x
–
x
ring tone for door call 2
–
–
x
parallel allocation
–
x
x
control function 8 /internal calls /
call diversion / door release auto-
matic
–
x
x
floor door function* ON/OFF
–
–
x
send sender serial number in case
of an internal call (immer aktiv)
–
–
–
call intrusion after an internal call
–
–
x
change audio AS limit
–
–
x
block ring tone output
x
–
–
block ring tone selection
–
–
x
unlimited communication time
–
–
x
reset to factory settings
–
–
x
* If the floor door release function in the EEPROM has been activated and the door release automatic function via
function key is switched on simultaneously, the control function 11 is send automatically when pressing the floor push
button. If the door release automatic is switched off, the standard floor door release function is implemented when
pressing the floor push button.
Programming with the Service Device TCSK-01
The indoor station is acting as a device for manually controlled duplex communication.
Use the commands “8“ to make configurations (see product information Service Device
TCSK-01).
Ser. no. = the serial number of the indoor station which is to be configured anew
ParSNo.= the serial number of the indoor station, to which the new configured indoor station is allocated to

07/2015 13
TCS TürControlSysteme AG Subject to technical changes.
E-Mail: [e-mail] • www.tcsag.de PI_ISW3130-uk 2 A
General information on the conduit in TCS audio systems
The conduit is determined by structural conditions and is only limited by ist length.
observe when selecting the cables: the loop re-
sistance can amount max. 20 Ω(see table)
in compliance to the max. permitted loop re-
sistance the cross section can be doubled,
which means, that for one wire two lines can be
used (illustration). The lines have to be twisted.
when using shielded cables: connect the shield-
ing with each other and put it one-sided on mass
(b-wire) in the power supply
optional strand- or star formed wiring
Table: loop resistance
cable length in m
cable diameter
0.6 mm
0.8 mm
loop resistance in Ω
10
1.28
0.71
20
2.55
1.43
30
3.83
2.14
40
5.10
2.86
50
6.38
3.57
60
7.65
4.29
70
8.93
5.00
80
10.20
5.71
90
11.48
6.43
100
12.76
7.14
150
19.13
10.71
200
25.51
14.29
250
17.86
300
21.43
principle loop resistance
measurement loop resistance
None of the devices (AS, IS or FE) should ever be
located more than 20 Ohm away from the power
supply and control unit (VS).
Switch off the 230 V / 50 Hz of the VS.
Install the a-b short-circuit at the VS.
Other devices do not disturb the measurement,
they can stay connected.
Measure the resistance on a/b IS at the strand of
the last indoor or front-door station.

14 07/2015
TCS TürControlSysteme AG Subject to technical changes.
E-Mail: [e-mail] • www.tcsag.de PI_ISW3130-uk 2 A
20 Ohm:
max. 160 m distance AS/IS-VS by 0.6 mm diameter
max. 300 m distance AS/IS-VS by 0.8 mm diameter
AS front-door station
VS power supply and control unit
IS indoor station
FE extended functions
Repair
Error detection and indication
Faults are signalled optically and acoustically: constant fault tone and constant flashing of
the operation display. When pressing any button, a fault tone sounds again. The optical
fault indication stays active until the fault is corrected.
fault causes
display
fault
mode
fault tone
elimination
a- and P-wire are inter-
changed or short-circuited
both
LEDs
flash
change a- and P-wire or eliminate short-circuit,
device is in stand-by mode again
a-wire: not connected or
not supplied
connect the a-wire or check power supply,
device is in stand-by mode again
button stucks
(press longer than 15 sec)
remove button at the device or loosen floor push but-
ton, device is in stand-by mode again
Exchange an indoor station –programme bell buttons
Basics
All devices at theTCS:BUS have got an unique serial number.
Programming a bell button means that the serial number of an indoor station is allocat-
ed to the bell button of a front-door station and is stored within the EEPROM of the
front-door station.
Ensure that new the indoor stations is connected to the TCS:BUS and the mains volt-
age is switched on (the operation LED at the power supply and control unit is ON) and
further, that the access to the flat is granted during the programming.
This instruction describes the case that a serial number is allocated to the bell button
without setting a programming lock. To neutralise a programming lock you need a Ser-
vice Device TCSK-01or the configuration software configo™.
a, b hier
kurzschließen

07/2015 15
TCS TürControlSysteme AG Subject to technical changes.
E-Mail: [e-mail] • www.tcsag.de PI_ISW3130-uk 2 A
1
Initiate
power supply and control unit
RUN/PROG push
Button: press short LED blinks
programming mode of the system is switched on
2
Delete a buttona)
press until the delete-tone-melody sounds 1)
release
3
Programming via voice connection
or
establish voice communication
to the front-station 2)
shortly press
the button
... a ring tone sounds at the front-door
and indoor station1)
4
End
power supply and control unit
RUN/PROG-push
button: shortly press LED is ON
programming mode of the system is switched off *)
a) Not necessary, if the bell buttons have not been programmed, comp. product information of the front-door station.
1) If there sounds a Progsperr tone instead, the front-door station is equipped with a programming lock.
The programming lock can be deactivated only with the Service Device TCSK-01 or the configuration software
configo™.
2) New developed front-door stations (as of 2009) respond to that with a positive acknowledgement, if the serial number
of the indoor station was received (see product information of the front-door station).
*) for device specific indication modes of t he front-door station see product information of the front-door station
Cleaning
!
Avoid water from entering the device!
Do not use any abrasive detergents!
Clean the device with a dry or slightly moist cloth.
Remove stronger stains with a mild plastic cleaner.

16 07/2015
TCS TürControlSysteme AG Subject to technical changes.
E-Mail: [e-mail] • www.tcsag.de PI_ISW3130-uk 2 A
Conformity
Declarations of conformity you can find under www.tcsag.de, Downloads, trade in-
formation.
Information on disposal
The adjoining symbol shows that the device has to be disposed separately from
domestic waste. The materials used are recyclable. Please do help protecting our
environment and dispose the device via a collecting point for electronic scrap.
Dispose the parts of the packaging in collecting tanks for cardboard and paper
resp. plastics.
Warranty
We offer a simplified processing in case of warranty for electricians.
Note our conditions of sale and delivery, for download from www.tcsag.de, Down-
loads, trade information.
Please contact us: [email protected]
Spare parts, accessory
short text
article number
10 x lower cover ISx3xxx-x140
E32431
10 pieces cover panel white 120 x 250 x 2 mm
E24340
Service
Please send your questions and inquiries to
[email protected]
headquarters
TCS TürControlSysteme AG, Geschwister-Scholl-Str. 7, 39307 Genthin, Germany
www.tcsag.de
