Techart 058.500.502.CCC User manual

ASSEMBLY INSTRUCTIONS
TECHART Trunk Box Device Box
Part-no. 058.500.502.CCC for Cayenne starting MJ11

TECHART Version 01 Page 2 of 7
A
SSEMBL
Y
INST
R
UCTIONS
TECHART Trunk Box Device Box
Contents
Contents ................................................................................................................................................................2
IImportant safety information..................................................................................................................3
II Preparation...............................................................................................................................................5
III Installation................................................................................................................................................6
1Lay the TECHART Wiring Harness...............................................................................................6
2Install the TECHART DVD Changer.............................................................................................6

TECHART Version 01 Page 3 of 7
A
SSEMBL
Y
INST
R
UCTIONS
TECHART Trunk Box Device Box
I Important safety information
All of the necessary work must be performed by qualified persons with an appropriate
level of expertise.
Vehicle lifts with an insufficient lifting capacity can collapse under the weight
of the vehicle and crush any persons standing underneath.
Compare the weight of the vehicle with the lifting capacity of your vehicle lift.
The weight of the vehicle must not exceed the lifting capacity of your vehicle
lift. The weight of the vehicle can be found in the vehicle operating manual.
Risk of injury from electric current.
Switch off the ignition and disconnect the battery when working on the vehicle
electrical/electronics systems.
Risk of fire and explosion from ignition of windshield cleaning
agents/antifreeze and their vapors.
Risk of poisoning from ingesting windshield cleaning agents/antifreeze and
breathing in their vapors.
Risk of injury due to irritation caused by windshield cleaning agents/antifreeze
coming into contact with eyes, skin and other parts of the body.
Wear protective clothing and safety glasses. Avoid naked flames, fire and
sources of ignition. Avoid contact with eyes, skin and other parts of the body.
Do not eat, drink or smoke when handling windshield cleaning
agents/antifreeze. Do not breathe in vapors and ensure adequate ventilation.
Keep windshield cleaning agents/antifreeze only store them in sealable
original containers.

TECHART Version 01 Page 4 of 7
A
SSEMBL
Y
INST
R
UCTIONS
TECHART Trunk Box Device Box
Risk of injury from hands and arms being crushed, cut or lacerated when
working with sharp-edged and bulky objects.
Wear protective clothing and protective gloves. Keep limbs out of narrow and
inaccessible areas of the vehicle and/or avoid dangerous situations by using
special tools and suitable aids.
Risk of injury to back, muscles, joints, tendons and ligaments from lifting and
carrying heavy and/or bulky objects.
Lift and transport heavy and/or bulky objects with the help of other people
and/or with suitable aids.
Before starting the assembly procedure, carefully read the assembly instructions in full
and pay attention to the safety information and sequence of the individual operation steps.
All body parts must be prepared and painted in accordance with the attached painting
guide.

TECHART Version 01 Page 5 of 7
A
SSEMBL
Y
INST
R
UCTIONS
TECHART Trunk Box Device Box
II Preparation
Number of people required
At least two people are required to install this product.
Help and support
If you have any technical queries, please contact us immediately:
[email protected]
Check the TECHART parts kit for completeness
Quantity Part number Part designation
1 058.500.502.CCC TECHART Trunk box device box
Consisting of:
1 058.500.502.CCC TECHART-trunk box device box
Please use table to check whether all of the required parts are present.
Please contact us immediately if any parts should be missing: [email protected]
Once parts have been removed from their original packaging, ensure that they are
properly handled and stored.

TECHART Version 01 Page 6 of 7
A
SSEMBL
Y
INST
R
UCTIONS
TECHART Trunk Box Device Box
III Installation
i
Prevent cable from intense squeezing and bending.
1 Lay the TECHART wiring harness
1 Do not lay the cable inside the trunk
tray! Route the cable in such way
that it will stick out about 20 cm
below the tray cover.
Fig. 1
2 Install the TECHART DVD changer
1 Set the left rear seat bench and
backrest into the backmost position.
2 Align the DVD changer via the
device box.
3 Carefully remove the device box
and mark the holes of the changer
bracket.
4 Tighten the DVD changer and
connect the cables.
5 Remove the protection foil of the
adhesive tapes and fit device box. Fig. 2

TECHART Version 01 Page 7 of 7
A
SSEMBL
Y
INST
R
UCTIONS
TECHART Trunk Box Device Box
TECHART AUTOMOBILDESIGN GMBH
RÖNTGENSTRASSE 47
D-71229 LEONBERG / GERMANY
TEL [phone] / 9339- 0
FAX [phone] / 9339-33
[email protected]
www.techart.de
Änderungen und Irrtümer vorbehalten.
Subject to change at any time without prior notice.
Copyright 2008 by TECHART Automobildesign GmbH
Version 01/2012
Artikel-Nr./Part No. 058.500.502.099
