1. Kombi-Instruments develop
1.1 Disconnect the battery!
1.2 Operate hazard switch and remove the button by means of 2 narrow screw
drivers to the front at the side.
1.3 Bring in a suitable hook into one of the holes from the key accommodation.
Press afterwards with a small screwdriver the mounting straps on the left and
on the right from the hazard switch together and pull out the switch forward.
1.4 Remove the screw at the instrument panel.
1.5 Remove grill screen on left side and likewise remove screw. Clip out
combination instrument upward carefully and loosen the patch cords. At
vehicles with original telephone or telephone preparation still the microphone
(in the grill screen) must be plugged off.
1.6 Remove screws from combination instrument.
T
ECHAR
T
–
Instrument Dials
for Porsche 986 (2,7 lit, MY ‘01)
Art. No.: 086.530.200.001 RDW
Art. No.: 086.530.201.001 RDW Tiptronic
Art. No.: 086.530.210.001 GB
Art. No.: 086.530.211.001 GB Tiptronic
Art. No.: 086.530.220.001 USA
Art. No.:
086.530.221.001 USA Tiptronic

2. Install dials
2.1 Decrease sheet metal-clamps of the fortification-eyelets at the left and right.
Remove activity-button for time-clock and trip odometer.
2.2 Clip out front-frameworks at the lower surface of the combination instrument
and decreases.
2.3 Mark the pointer positions at the edge of the dial carriers and take off the
pointers carefully. (by turn easy anti-clockwise)
2.4 Remove plastic center rings of the instruments with a pointed article. These
are not no more needed.
2.5 Remove original dials, take off protective plastic film from the TECHART dials
and align them on the basis, the fixing taps and the center rings. Press in the
dials slightly, attach pointers, adjust these and bolt again at the rear side.
2.6 Assemble combination instrument again.
2.7 The installation of the instrument takes place in reverse order. (If necessary,
clean protecting glasses of the instruments)
2.8 Connect the battery again and check the Instrument.
