Techart 070.530.510.CCC User manual

ASSEMBLY INSTRUCTIONS
TECHART Set of Instrument Dials
Part-no. 070.530.510.CCC for Panamera S manual transmission (km/h)
Part-no. 070.530.511.CCC for Panamera S manual transmission (miles)
Part-no. 070.530.520.CCC for Panamera S with PDK (km/h)
Part-no. 070.530.521.CCC for Panamera S with PDK (miles)
Part-no. 070.530.530.CCC for Panamera S4 with PDK (km/h)
Part-no. 070.530.531.CCC for Panamera S4 with PDK (miles)
Part-no. 070.530.540.CCC for Panamera Turbo with PDK (km/h)
Part-no. 070.530.541.CCC for Panamera Turbo with PDK (miles)
Part-no. 070.530.550.CCC for Panamera Diesel with PDK (km/h)
Part-no. 070.530.560.CCC for Panamera V6 Manual transmission (km/h)
Part-no. 070.530.561.CCC for Panamera V6 Manual transmission (miles)
Part-no. 070.530.570.CCC for Panamera V6 and 4 with PDK (km/h)
Part-no. 070.530.571.CCC for Panamera V6 and 4 with PDK (miles)

TECHART Version 02, dated June 24, 2013 Page 2 of 16
ASSEMBLY INSTRUCTIONS
TECHART Set of Instrument Dials
Contents
Contents ................................................................................................................................................................2
IImportant safety information........................................................................................................ ……..3
II Preparation...............................................................................................................................................5
III Installation................................................................................................................................................6
1 Preparing the vehicle ....................................................................................................................6
2 Component overview ..…………………………………………………………………………………7
3 Dismantle combi-instrument …………………………………………………..……………………….8
4 Disassemble combi-instrument, assemble TECHART Set of Instrumenten-Dials………………13
5 Assemble and install combi-instrument ..................................................................................... 15
6 Perform final work...................................................................................................................... 15

TECHART Version 02, dated June 24, 2013 Page 3 of 16
ASSEMBLY INSTRUCTIONS
TECHART Set of Instrument Dials
I Important safety information
All of the necessary work must be performed by qualified persons with an appropriate
level of expertise.
Vehicle lifts with an insufficient lifting capacity can collapse under the weight
of the vehicle and crush any persons standing underneath.
Compare the weight of the vehicle with the lifting capacity of your vehicle lift.
The weight of the vehicle must not exceed the lifting capacity of your vehicle
lift. The weight of the vehicle can be found in the vehicle operating manual.
Risk of injury from electric current.
Switch off the ignition and disconnect the battery when working on the vehicle
electrical/electronics systems.
Risk of fire and explosion from ignition of windshield cleaning
agents/antifreeze and their vapors.
Risk of poisoning from ingesting windshield cleaning agents/antifreeze and
breathing in their vapors.
Risk of injury due to irritation caused by windshield cleaning agents/antifreeze
coming into contact with eyes, skin and other parts of the body.
Wear protective clothing and safety glasses. Avoid naked flames, fire and
sources of ignition. Avoid contact with eyes, skin and other parts of the body.
Do not eat, drink or smoke when handling windshield cleaning
agents/antifreeze. Do not breathe in vapors and ensure adequate ventilation.
Keep windshield cleaning agents/antifreeze only store them in sealable
original containers.

TECHART Version 02, dated June 24, 2013 Page 4 of 16
ASSEMBLY INSTRUCTIONS
TECHART Set of Instrument Dials
Risk of injury from hands and arms being crushed, cut or lacerated when
working with sharp-edged and bulky objects.
Wear protective clothing and protective gloves. Keep limbs out of narrow and
inaccessible areas of the vehicle and/or avoid dangerous situations by using
special tools and suitable aids.
Risk of injury to back, muscles, joints, tendons and ligaments from lifting and
carrying heavy and/or bulky objects.
Lift and transport heavy and/or bulky objects with the help of other people
and/or with suitable aids.
Before starting the assembly procedure, carefully read the assembly instructions in full
and pay attention to the safety information and sequence of the individual operation steps.
All body parts must be prepared and painted in accordance with the attached painting
guide.
Handling with the airbag systems only by skilled and trained personnel!
- turn off the ignition and pull the key
- no power supply at the external power source / jump start
- disconnect the battery. Insulate earth strap
- after disconnecting the battery wait for at least 1 minute
- exchange parts which were damaged during dismantling
- when laying down the airbag unit make sure that the bag opening shows
towards the top
- store the airbag unit in a closure in case of a long dismantling time
- the airbag unit must not touch fat, oil, detergents, liquids or similar
substances
- do not expose the airbag unit to more than 90° Celsius
- do not remove the short-circuit spring of the plug contacts

TECHART Version 02, dated June 24, 2013 Page 5 of 16
ASSEMBLY INSTRUCTIONS
TECHART Set of Instrument Dials
II Preparation
Help and support
If you have any technical queries, please contact us immediately:
[email protected]
Check parts for completeness
Quantity Part number Part designation
1 070.530.5__.CCC TECHART Instrument Dials
(custom color)
Use the table to check whether all of the required parts are present.
Once parts have been removed from their original packaging, ensure that they are
properly handled and stored.

TECHART Version 02, dated June 24, 2013 Page 6 of 16
ASSEMBLY INSTRUCTIONS
TECHART Set of Instrument Dials
III Installation
1 Preparing the vehicle
i
Before starting work, check that the vehicle is free from defects. Use the PIWIS II
system tester to read out all the fault memories of the individual vehicle
components and first rectify any faults displayed.
Move the steering column adjustment completely downwards and towards the
back (maximum working space).
i
Switch off the ignition and disconnect the battery when working on the vehicle
electrical/electronics system.

TECHART Version 02, dated June 24, 2013 Page 7 of 16
ASSEMBLY INSTRUCTIONS
TECHART Set of Instrument Dials
2. Component overview
A - Panel far left (fuse cover dashboard)
B - Air nozzle far left
C - Trim left (ignition lock)
D - Steering column panel bottom
E - Trim right
F - Lower panel combi-instrument in connection with the upper steering column panel
G - Upper panel combi-instrument
Fig. 01
Fig. 02
A
D
B
CE
F
G
D
B
C
E
G
F

TECHART Version 02, dated June 24, 2013 Page 8 of 16
ASSEMBLY INSTRUCTIONS
TECHART Set of Instrument Dials
3. Dismantle combi-instrument
1 Release airbag retaining spring, for that press the releasing spring with a
screwdriver upwards (lead the screwdriver through the hole at the bottom center
of the steering wheel airbag housing and press the spring upwards).
2 Carefully remove the airbag from the steering wheel.
3 Release and separate both plugs
of the airbag’s reverse side,
disconnect the plug from the
ground connection and remove the
airbag unit
Fig. 03
4 Disconnect the main plug at the
steering wheel.
5 Loosen the main fixing screw of the
steering wheel, mark the steering
wheel center position and remove
the steering wheel.
Fig. 04

TECHART Version 02, dated June 24, 2013 Page 9 of 16
ASSEMBLY INSTRUCTIONS
TECHART Set of Instrument Dials
6 Loosen the 2 screws at the bottom
part of the steering column D.
Fig. 05
7 The upper part Fcan be unclipped
with a small screwdriver.
Fig. 06
8 Loosen the 2 upper screws.
9 Disconnect the plug at the switch
for the steering column adjustment.
10 Remove the lower steering column
panel D.
Fig. 07

TECHART Version 02, dated June 24, 2013 Page 10 of 16
ASSEMBLY INSTRUCTIONS
TECHART Set of Instrument Dials
11 Unclip trim panel C, disconnect
cable plug.
Fig. 08
12 Unclip trim panel E, disconnect
cable plug.
Fig. 09
13 Loosen the 2 screws at the lower
combi-instrument-panel F.
14 Unclip the panel at the combi-
instrument and remove it together
with the upper steering column
panel F.
Fig. 10

TECHART Version 02, dated June 24, 2013 Page 11 of 16
ASSEMBLY INSTRUCTIONS
TECHART Set of Instrument Dials
15 Open panel Afuse box at the
dashboard left.
16 Dismount air nozzle Bleft, for that
remove two screws left.
Fig. 11
17 Remove one screw on the right.
18 Detach air nozzle.
Fig. 12

TECHART Version 02, dated June 24, 2013 Page 12 of 16
ASSEMBLY INSTRUCTIONS
TECHART Set of Instrument Dials
19 Loosen all 4 screws at the combi-
instrument.
Fig.13
i
Both upper screws (outer-torx E8) have to be loosened from the bottom side.
20 Lever the combi-instrument
carefully over the center right air
nozzle by using a wedge, the upper
panel of the combi-instrument G
must not be dismantled.
21 Disconnect main plug and the CAN-
Bus plug.
22 Cover the steering column with a
soft cloth; remove the combi-
instrument carefully and without
damage. Fig. 14

TECHART Version 02, dated June 24, 2013 Page 13 of 16
ASSEMBLY INSTRUCTIONS
TECHART Set of Instrument Dials
4. Disassemble Combi-instrument, assemble TECHART Set of Instrument-Dials
1 Remove button for resetting the trip
recorder.
Fig. 15
2 Loosen the fixing flaps of the
combi-instrument-cover (Fig. 16 +
17)
Fig. 16
Fig. 17

TECHART Version 02, dated June 24, 2013 Page 14 of 16
ASSEMBLY INSTRUCTIONS
TECHART Set of Instrument Dials
3 Remove the cover of the combi-
instrument carefully
Fig. 18
4 Turn all hands carefully towards
the zero-point and pull carefully
upwards at the same time
Fig. 19
5 Carefully lever the center sleeve H
with a small screwdriver upward
Fig. 20
H
H

TECHART Version 02, dated June 24, 2013 Page 15 of 16
ASSEMBLY INSTRUCTIONS
TECHART Set of Instrument Dials
6 Remove the original dials and
exchange them for the TECHART
instrument-dials.
7 Reassemble the center sleeve H,
care for an accurate fitting.
Fig. 21
i
CAUTION: Pulling too forcefully at the hands can destroy the hand
mechanism!!!
5. Assemble and install combi-instrument
i
1 Set the each hand into the center of the respective dial turn it carefully to the
zero-point and press cautiously at the same time.
CAUTION: Pressing too forcefully at the hands can destroy the hand
mechanism!!!
2 Check that all hands are at the zero-point
3 Assemble the combi-instrument in reverse order
4 Install the combi-instrument in reverse order.
6. Perform final work
1 Connect battery
i
Use the PIWIS II system tester to read out all of the fault memories of the
individual vehicle components and first rectify any faults displayed.
2 Functions control of the combi-instrument and finally perform a test drive.

TECHART Version 02, dated June 24, 2013 Page 16 of 16
